Mini Pathria

1
1986-1987

• Mini Pathria
• Michael Zlatkin
• Richard (Rick) G Stiles

2
Mini Pathria

• Middle-aged male
• Hx of recent knee trauma

3
Case 1

• Middle-aged male
• Hx of recent knee trauma

4
Radiographs
5
Sagittal
6
Coronal
7
Axial
8
Thigh
9
Differential diagnosis

• Neurofibromatosis
• Melorheostosis with soft tissue component

10
Neurofibromatosis

• Further history obtained
• Skin nodules
• Neurofibromas on cranial CT 7 years previously
  (not acoustic neuroma)

11
Case 2

• Middle-aged female with thigh mass

12
Radiographs
13
Coronal
14
MR
15
Follow-up

• Mass biopsied, benign plexiform neurofibroma
• Patient developed hip pain

16
Hip MR
17
Neurofibromatosis

• Plexiform neurofibroma at biopsy
• No evidence of malignancy

18
Case 3

• 40 year old male with slowly growing painless mass

19
Plexiform neurofibroma
20
Plexiform neurofibroma

• Specific finding for NF1 (peripheral form)
• 5 of patients with NF1
• Approximately 5-10 degenerate to neurosarcoma

courtesy of Mark Murphey, AFIP
21
Neurofibroma

• Localized
• Diffuse
• Plexiform
• Well-defined
• Bag of worms
• Infiltrating

22
Elephantiasis neurofibromatosa

• Diffuse form of plexiform neurofibroma
• Overgrowth of epidermal and subcutaneous tissue
• Wrinkled and pendulous appearance

23
Michael B. Zlatkin and Alfredo Arraut NMSI

• 27 year old male involved in a motor vehicle
  accident

24
27 year old male involved in a motor vehicle
accident
25
27 year old male involved in a motor vehicle
accident
26
Findings

• Subscapularis tendon is avulsed with bone from
  the lesser tuberosity
• Humeral avulsion of the anterior band of the
  glenohumeral ligament (HAGL)
• Middle glenohumeral ligament and possibly the
  superior glenohumral ligament may be avulsed as
  well
• Possible reverse Hill-Sachs lesion

27
Subscap Rupture and HAGL (BHAGL)

• Rupture of the subscapularis tendon uncommon but
  can be seen in younger patients injured by forced
  external rotation or extension of a partially
  abducted arm
• Tears occur near insertion on the lesser tub. May
  occur at sup margin, where tendon may be weakened
  by degeneration
• Avulsion fracture of the lesser tuberosity may
  occur, and is displaced medially and inferiorly
• Subscapularis avulsions are also associated with
  injury to the anterior capsule and glenohumeral
  ligaments (HAGL)
• When the AIGHL avulses a fragment of bone from
  the humerus, the lesion is known as a bony HAGL,
  or BHAGL
• ? With MGHL and SGHL torn Super BHAGL

28
Michael B. Zlatkin and Alfredo Arraut NMSI

• 17 year old male with bony growth on the dorsum
  of hand

29
17 year old male with bony growth on the dorsum
of hand
30
17 year old male with bony growth on the dorsum
of hand
31
Findings

• Bone prominence on the dorsum of the hand between
  the trapezoid, capitate, and bases of the 2nd and
  3rd metacarpals
• Associated with base of 3rd metacarpal, but no
  marrow continuity with it
• Sclerosis and cystic change at junction with 3rd
  metacarpal base

32
Carpal Boss

• Bone protuberance on dorsum of the hand
• Degenerative osteophyte or os styloideum
• Located between trapezoid, capitate, and base of
  2nd and 3rd metacarpals
• Most often fused to a metacarpal base, but rarely
  (2) can be completely isolated
• Symptoms caused by degeneration, formation of
  ganglion or bursa, or snapping of an extensor
  tendon moving over it

33
Carpal Boss

• Can be demonstrated on lateral radiograph with
  hand flexed and supinated 30-40 degrees best
  seen with mild ulnar deviation
• Alternatively can image with CT or MR
• MR can demonstrate marrow edema in the carpal
  boss and surrounding soft tissue changes

34
Carpal Boss Companion Case
Carpal boss fused to base of third metacarpal
with edema in overlying soft tissues
35
Carpal Boss - Companion Case
Carpal boss fused to third metacarpal with
fracture at its base
36
Carpal Boss Companion Case
Surface rendering of carpal boss with fracture at
its base
37
Michael B. Zlatkin and Alfredo Arraut NMSI

• 33 year old professional hockey player with pain
  in the flank after practice

38
33 year old professional hockey player with pain
in the flank after practice
39
33 year old professional hockey player with pain
in the flank after practice
40
Findings

• Partial thickness tear of the internal oblique
  muscle belly proximally, with surrounding edema
  and hematoma
• Fluid tracking between internal and external
  obliques
• Feathery pattern of edema at the more distal
  aspect of the internal oblique

41
Side Strain

• Uncommon sporting injury presenting with pain and
  tenderness over anterolateral and posterolateral
  lower ribcage
• Associated with cricket, golf, and ice hockey
  eccentric contraction of trunk muscles
• Partial or complete tear of lateral abdominal
  wall musculature (internal oblique gt external
  oblique gt transversus abdominis)
• May also see avulsion at the muscular origins
  from the lower ribs
• Recovery takes 6-10 weeks. Full recovery is the
  norm

42
Michael B. Zlatkin and Alfredo Arraut NMSI

• 19 year old injured while pitching, now has
  valgus instability of elbow on exam

43
19 year old injured while pitching, now has
valgus instability of elbow on exam
44
Findings

• Thickened ulnar collateral ligament (UCL) with
  increased intrasubstance signal distally and at
  its midportion, indicating partial thickness tear
• No complete disruption
• Edema in the adjacent flexor/pronator musculature
• Reactive marrow edema in the sublime tubercle

45
UCL Partial Tear

• Most often injured in overhand throwing athletes,
  especially baseball pitchers
• Pitching causes valgus stress on the elbow that
  can injure the UCL
• MR arthrogram reportedly higher sensitivity than
  conventional MR for partial thickness tears
• MR findings thickening/irregularity/laxity of
  the ligament, edema in adjacent soft tissues
• T sign pathognomonic sign of contrast extending
  into a partial thickness tear, giving a sideways
  T shaped appearance
• Tears tend to occur more distally in younger
  pitchers, more proximally in older pitchers

46
Michael B. Zlatkin and Alfredo Arraut NMSI

• 16 year old pitcher with elbow pain

47
16 year old pitcher with elbow pain
48
Findings

• Delayed union of the olecranon apophysis
• Persistent widening of physis with surrounding
  edema consistent with stress injury/stress
  fracture

49
Olecranon Stress Fracture/Apophysitis

• May occur in young throwing athletes and gymnasts
  due to repetitive microtrauma
• Present with pain localized to the tip of the
  olecranon
• Imaging shows a widened physis or open physis
  after expected age of closure, and stress related
  edema
• Normal fusion occurs at age 12-15, comparison to
  contralateral side may help

50
Michael B. Zlatkin and Alfredo Arraut NMSI

• 24 year old male with shoulder pain and suspected
  rotator cuff tear after fall on outstretched hand

51
24 year old male with shoulder pain and suspected
rotator cuff tear after fall on outstretched hand
52
Findings

• Avulsion fracture of the greater tuberosity, with
  a small fracture fragment retracted medially with
  a torn supraspinatus tendon
• Associated marrow edema

53
Greater Tuberosity Avulsion Fracture

• RCT uncommon in younger patients
• Usually occurs after trauma, may be concomitant
  fx
• Great tub fxs may be difficult to distinguish
  from RCT clinically. May be radiographically
  occult if non-displ
• MR useful in differentiating contusion/nondisplace
  d fracture from RCT
• Concomitant rotator cuff tears not common in
  nondisplaced fractures, but more common in more
  severe injuries with avulsions/displaced
  fractures
