Safety Coding

1
Safety Coding
2
Objectives

• To understand the coding for safety colors

3
Safety Colors

• The purpose of this system is to alert people to
  danger or hazards.
• Each color or combination of colors conveys a
  specific message.

4
Safety Colors

• 1. Red
• Danger
• Safety switches and fire equipment.
• 2. Orange
• Warning
• Machine hazards such as edges and openings.
• Also used as background for electrical switches,
  levers, and controls.

5
Safety Colors

• 3. Yellow Caution
• Identify parts of machines, such as wheels,
  levers, and knobs that control or adjust the
  machine.
• Yellow and black stripes are used to mark stairs
  and protruding objects
• 4. Blue
• Information
• Used for signs if a warning or caution is
  intended.
• OUT OF ORDER or DO NOT OPERATE.

6
Safety Colors

• 5. Green Safety
• Indicates the presence of safety equipment,
  safety areas and first aid.
• 6. Black and yellow
• diagonal-striped pattern
• Radiation hazards.
• 7. White
• Traffic areas.
• White arrows indicate the direction of traffic.
• Also mark work areas around objects in the shop.

7
Safety Colors

• 8. White and black in alternate stripe
• traffic markings.
• 9. Gray
• Floors of work areas
• Provides good contrast for other safety colors.
• Used to paint body areas of machines

8
Focal Colors

• Used to draw attention to large items such as
  machines, cabinets, and floors.
• Ivory
• used to highlight or improve visibility of
  certain items.
• tool storage chests, table edges, and
  freestanding vises and anvils.

9

• Vista green
• It is used to paint bodies of machines, cabinets,
  and stationary tools such as vises.
• Aluminum
• Waste containers such as those for scrap wood,
  scrap metal, and rags.

10
Summary

• What is the reason for focal colors
• What are some signs that safety color blue is
  used for?
