Monopill S

1
Kverneland Accord Monopill
Product information 2015
2
Kverneland Accord MonopillPrecision drill
3
Content

• Monopill
• Introduction
• Frames
• Sowing unit
• Zero deposit principle
• Equipment
• Electronic
• Additinonals
• Summery

Monopill S Mechanical (chain) drive
Monopill e-drive II Electric driven
4
Monopill

• For sowing of
• pelleted Sugar Beet and Fodder Beet with a
  standardised seed diameter of 3.5 5mm
• Coated Rape (TKG 4,5 - 5g)
• Pelleted Chicory (2.75-3.25mm or Minipill)
• Row widths 45 - 56cm
• Working widths 3.00 12.00m (624 rows)

Sugarbeet
Chicoree
Rapeseed
5
Monopill Frames

• 6 row, rigid frame
• Working width up to 3.0m rigid
• Power requirement from 40 kW
• Low lifting requirements
• Spring loaded and adjustable drive wheels 5.00 x
  15 AS
• Lever change gearbox with 7 steps (optional
  e-drive II)
• Working speed -7.5 km/h

Monopill S 6 row
6
Monopill Frames

• 12 row, rigid frame
• Working width 5.40m 6.00m
• Power requirement from 70 kW
• Gull-wing track markers
• 2 lever change gearboxes (optional e-drive II)
• Lengthwise transport device as option

Monopill S 12 row with integrated lengthwise
transport device for road transport
7
Monopill Frames

• 18 row, rigid frame
• Working widths 8.10m 9.30m
• Power requirement from 100 kW
• 2 lever change gearboxes (optional e-drive II)
• Integrated hydraulic lengthwise transport device
  with tow hitch and wheels
• Quick and easy conversion for road transport by
  hydraulic move

Monopill e-drive II 18 row with integrated
lengthwise transport device
8
Monopill e-drive II Frames
24 row, rigid
Monopill e-drive II 24 row with integrated
lengthwise transport device

• Working widths 10.80m 12.00m
• Power requirement from 110 kW
• Only with e-drive II
• Gull wing folding disc track marker with
  electro-hydraulic control boxes for double acting
  control valve
• Quick and easy conversion for road transport with
  the integrated hydraulic lengthwise transport
  device

9
Monopill Frames

• 12 rows, Parallel Hydraulic (PH) folding Frame
• Working widths between 5.40m 6.00m
• Power requirement from 75 kW
• Parallel hydraulic foldable wing sections with
  electro-hydraulic control
• 3 lever change gearboxes (optional with e-drive
  II)
• Gull wing folding disc track marker

Monopill e-drive II 12 rows 6m parallel
hydraulic folding frame
10
Monopill Frames

• 18 rows, Parallel Hydraulic (PH) folding Frame
• Working widths between 8.10 9.00m
• Power requirement from 115 kW
• Electric drive only (Controlled by ISOBUS
  IsoMatch Tellus Terminal 11783 compatible)
• Hydraulic folding gull wing disc track markers
• Hydraulic folding to a transport width of 3m with
  electro hydr. control box as standard

Monopill e-drive II 18 rows parallel hydraulic
folding
11
Monopill Rows
Mulch sowing unit with Monoflex press wheel
Standard sowing unit with Finger press wheel
Tandem sowing unit
12
Monopill Sowing Heart

• The seed disc is rotating through the second
  patented seed chamber
• The disc picks only one seed at a time,
  additional seeds are wiped off
• Due to the centrifugal force, the seed remains in
  the seed cell throughout its rotation
• With the seeding heart positioned deep inside the
  seeding coulter, the seed drop height is only 3cm

13
Monopill Sowing Heart

• The seed disc rotates counter clockwise (U), in
  opposite to the driving direction (F)
• With a seed distance down the row of 20cm, the
  circumference speed of the disc drive forward
  speed gt Zero deposit
• Standard seed spacing of 18 - 24cm with seed disc
  A4
• Up down movements of the parallelogram have no
  effect on the seed disc/spacing due to a
  specially designed chain guide

Zero deposit
14
Monopill S Standard Sowing Unit
1
3
2
1 Parallelogram 2 Depth adjustment 3 Lifting
device 4 Seed hopper 5 Press wheel
bracket 7 Front press wheel 8 Seed
coulter 9 Sowing heart 10 Intermediate press
wheel 11 Coverer 12 Rear press wheel (Monoflex)
4
5
11
7
8
9
10
12
15
Monopill S Mulch Sowing Unit
6
1 Double cutting disc 2 Coulter extension
3 Spring loaded intermediate press wheel 4 Disc
coverer - spring loaded 5 Rear press wheel
(Monoflex) 6 Spring load for sowing row up to 50
kg
3
4
5
2
1
16
Monopill S Mechanical Drive

• Working widths between 3.00m - 9.00m
• The basic element with chain driven sowing heart
  for normal mulch seeding
• Depth adjustment in steps of 0,5cm
• Integrated ball bearing drivelines into the
  parallelogram linkage for a consistent seed disc
  turning
• Visus Opto-electronic control
• Control of each unit by an Opto transmitter
• Tramlining
• Monitor seed/ha, total worked area
• Electronic hectare meter

17
Monopill e-drive II

• Working widths between 3.00m - 12.00m
• The enhanced element based on the same row
  concept
• Each sowing heart is driven by an electric motor
• Infinite adjustment of sowing distances for
  optimised seed population (from 12.5 25 cm)

18
Monopill Equipment
Mulch sowing unit with Monoflex press wheel
Standard sowing unit with Finger press wheel
Tandem sowing unit
19
Monopill Press Wheels
Row setting Coulter intermediate press wheel
coverer conical press wheel

• V-shaped coulter opens the furrow
• The intermediate press wheel firms seed into the
  furrow
• The coverers put some more earth on the furrow
• The conical press wheel consolidate the earth at
  the side more than in the middle
• gt The amount of covering soil (B) is similar to
  that of the sowing depth (A)
• ? Ideal for wet and loamy soils

20
Monopill Press Wheels
Row setting Coulter coverer finger press
wheel

• V-shaped coulter opens the furrow
• The coverers put some more earth on the furrow
• The finger press wheel consolidate the earth in
  the middle more than at the sides
• gt The covering soil (B) is lower than the sowing
  depth (A).

? A "Micro climate" then protects the germinated
plant
21
Monopill S/ e-drive II Electronics
22
Introduction tramlines in Sugar Beet

• Reasons for setting up tramlines
• Opportunity to save sugar beet seeds (cost of
  100.000 sugar beet seeds 150 )
• Ease follow-up operations e.g. fertilising and
  spraying with less crop damage
• Opportunity to drive over the sugar beet field
  without special cultivation tyres
• gt reduce handling costs
• Reduction of losses at the edge of rows gt
  uniform root size
• Possibility to reduce soil compaction and damage
  of the earth structure gt use of floatation tyres
  possible
• Reduce the danger of erosion in the tractor wheel
  tracks

23
Visus The Opto - Electronic Control

• Monitoring of seeds/ha
• Control of up to 12 sowing units
• Electric hectare meter
• Summary of worked total area
• Opto transmitter with plug connection
• Automatic tramlining system up to 4 clutches (set
  of 2 or set of 4 clutches)
• Service function

1. Seed coulter
2. Seed disc
3. Optosensor

24
Mechanical Shut-off via Clutches

• Monopill S with Visus
• Opto-electronic control and tramlining
• Only for customers with a fixed tramline widths
• Maximum of 4 shut-off clutches
• Set of 2 or set of 4 shut-off clutches
• Spraying width
• 10.8m 16.2m 27.0m 21.6m 32.4 m
  (12r/45cm/1.80m)
• 12.0m 18.0m 24.0m 32.0m 36.0m
• (12 r/50cm/2.00m)

Visus
25
Monopill with e-drive II

• Monopill e-drive II with IsoMatch Tellus
• All standard tramlines are programmed in Monopill
  e-drive II control box (also chaotic
  systems)
• Seed spacing adjustment during work
• The amount of seed at edge rows can be reduced or
  increased stepwise
• Opto-electronic sensors counting the seeds and
  advising of unit problems (e.g. empty hopper)
• Row by row shut-off ? Ready for GEOcontroll
• On board diagnostic system to help locate
  failures
• Ready for GEOseed

IsoMatch Tellus
26
Monopill e-drive II IsoMatch Tellus
The next generation universal ISOBUS Terminal
IsoMatch Tellus Two ISOBUS interfaces in one
terminal Multifunctional ergonomic design
ISOBUS Shortcut Button
The IsoMatch Tellus is the first ISOBUS with the
capability to operate different machines on 2
screens through 1 terminal, without the need to
constantly toggle between screens.
27
GEOcontroll - the automatically row switch-off,
steered by GPS

• Steered by GPS one row after another is switched
  off at the heads land
• Saving seeds
• No place in field with doubles or triples
• No missings ? no free spots for weeds in the
  field
• Easy handling for driver
• Full concentration of driver on field conditions
  and turning process

28
GEOseed - the intelligent way of precise placing
of seeds

• Seeding in parallel and diamond pattern

• The patented two-dimension placement control
  allows seeding in parallel or diamond patterns
• By adding a precise GPS signal (RTK) in
  combination the sowing heart extension
  synchronisation beyond machine width is ensured
  by GPS co-ordinates.
• Positive effects of GEOseed can be reached with
  close row sowing (37,5 45 cm) and seed
  distances wider than 18-20 cm
• Further information about the possibilities and
  necessary needs for GEOseed you find in GEOseed
  presenation!

29
GEOseed - the intelligent way of precise placing
of seeds

• sugarbeet with Monopill and
  GEOseed

30
Monopill Additional Equipment
31
Option Microgranular applicator

• Hoppers, made out of special plastics
• Capacity per hopper of 35 litres
• Hoppers mounted according to the working width
• With 2 or 3 outlets per unit
• Metering wheels of different sizes and materials
• ? application requirements of most types of
  micro-granule

32
Monopill - Technical Data Frame
Monopill frame 6 rows rigid 12 rows rigid 18 rows rigid 24 rows rigid 12 rows PH 18 rows PH

mechanic drive with 7 gear lever gearbox X X X - X X
e-drive II X X X X X X

Tyres 5.00-15 X X X - X X
Tyres 26x12 STG - - - X - -

Manually operated Track marker X - - - - -
Hyraulic operated track marker arms O X X X X X

Pre Emergence markers O O O on request O O

Mechanic Hectaremeter O O O - O O
Lighting Equipment O O O O O O
Drift prevention disc O O O O O O
Microgranualar applicator O O O - O -

Row width 45/50 45/50 45/50 45/50 45/50 45/50
Total weight (kg) for basic version 400 910 1750 2800 1250 2180

Possibility of collisions between PEM and Lengthwise transport device Possibility of collisions between PEM and Lengthwise transport device Possibility of collisions between PEM and Lengthwise transport device Possibility of collisions between PEM and Lengthwise transport device Possibility of collisions between PEM and Lengthwise transport device Possibility of collisions between PEM and Lengthwise transport device
X Standard equipment Standard equipment Standard equipment Standard equipment Standard equipment Standard equipment
O Optional Equipment Optional Equipment Optional Equipment Optional Equipment Optional Equipment Optional Equipment
- Not Available Not Available Not Available Not Available Not Available Not Available
33
Monopill - Technical Data Sowing Unit
Monopill sowing unit Normal seeding Tandem row Mulch seeding

Parallelogramm hitch X X X
Clod deflector O O -
Parallel clod deflector - - O
Rotating coverer O - X
Rigid coverer X X O
Monoflex press wheel X X X
Finger press wheel O O O
Single hopper content (l) 9 9 9
Weight of one sowing unit (kg) 50 59 64

X Standard equipment Standard equipment Standard equipment
O Optional Equipment Optional Equipment Optional Equipment
- Not Available Not Available Not Available
34
Monopill Main advantages

• Proven, stable frame concept
• Clear design and good accessibility for easy
  operation
• Zero Deposit for precise and very accurate seed
  placement
• Special chain control (no backlash) for a calm
  and constant run of the unit
• Electronic drive for enhanced performance
  (e-drive II)
• Additional tools for a perfect seed bed
• Exact tramlining control system to ease the
  follow up operations
• Precision Farming for cost efficiency and yield
  optimization
• Monopill with e-drive II is ready for GEOseed

35
visit us at www.kvernelandgroup.com

The Future of Farming


See our Machines at work on YouTube
