Chapter 19 Real-Time Systems

1
Chapter 19 Real-Time Systems

• CS 540 Advanced Operating systems
• Instructor Dr. Behzad Perviz
• Fall 2010
• Presented By
• Monali Bhavsar
• Amee Joshi

2
Real-Time Systems

• System Characteristics
• Features of Real-Time Systems
• Implementing Real-Time Operating Systems
• Real-Time CPU Scheduling
• An Example VxWorks 5.x

3
Objectives

• To explain the timing requirements of real-time
  systems
• To distinguish between hard and soft real-time
  systems
• To discuss the defining characteristics of
  real-time systems
• To describe scheduling algorithms for hard
  real-time systems

4
Overview of Real-Time Systems

• A Real-time system requires that results be
  produced within a specified deadline period
• Example Robot
• Contrast Desktop computer system, Batch
  processing system.
• An Embedded system is a computing device that is
  part of a larger system.(i.e. automobile,
  airliner)
• No timing requirements.
• Embedded in specialized devices.
• Presence of computing device is not obvious.
• Examples dishwashers, microwave ovens, cameras,
  MP3 players.

5
Continue

• A Safety-critical system is a real-time system
  with catastrophic results in case of failure.
• Weapons systems, antilock brake system, flight
  management system health related systems.
• System must respond to events by specific
  deadline period.
• A Hard real-time system guarantees that
  real-time tasks be completed within their
  required deadlines.
• Critical real time tasks be completed within
  their deadlines.
• Safety critical systems are typically hard real
  time systems.
• A Soft real-time system provides priority of
  real-time tasks over non real-time tasks.
• Priority retain until task completed.
• Linux and many OS provide soft real time system.

6
System Characteristics

• Single purpose
• Small size
• Inexpensively mass-produced
• Specific timing requirements

7
System Characteristics

• Single purpose
• Unlike PCs real time systems serves single
  purpose. Design of it reflects single purpose and
  its simple.
• Small size
• Existing environment is constrained in physical
  space so CPU power and memory available is less
  then standard pcs.
• Real time systems run on 8- or 16- bit processors
  and less then megabytes of memory.
• Footprint amount of memory required to run the
  OS and its applications.
• Real time systems must have small footprints.
• Specific timing requirements
• Real time operating systems meet timing
  requirements by using scheduling algorithms that
  gives real-time processes the highest scheduling
  priorities.
• Priority of scheduling tasks does not degrade
  over time.
• Technique for addressing timing requirements
  minimize response time to events such as
  Interrupts.

8
System Characteristics

• Inexpensively mass-produced
• Real time systems are used in home appliances and
  consumer devices which are cost conscious
  environment, so microprocessors for real time
  systems must inexpensively mass produced.
• Example SOC.

• Bus Oriented System

9
System-on-a-Chip

• Many real-time systems are designed using
  system-on-a-chip (SOC)strategy
• SOC allows the CPU, memory, memory-management
  unit, and attached peripheral ports (I.e. USB) to
  be contained in a single integrated circuit.
• Less expensive then bus oriented organization.

10
System-on-a-Chip
11
Features of Real-Time Kernels

• Features provided by many operating systems are
• Support variety of peripheral devices
• Protection and security mechanism
• Multiple users
• Supporting these features results in large
  kernel. Example, Windows XP.
• Most real-time systems do not provide the
  features found in a standard desktop system as
  above.
• Reasons include
• Real-time systems are typically single-purpose
• Real-time systems often do not require
  interfacing with a user
• Features found in a desktop PC require more
  substantial hardware that what is typically
  unavailable in a real-time system due to lack of
  memory and fast processors.
• Both of these are unavailable in real time
  systems due to space constraints.
• Addition to that many systems lack sufficient
  space to provide graphical displays or disk
  drives, they support file systems using NVRAM(Non
  Volatile RAM).
• Features of desktop PC increase the cost of real
  time systems which makes systems economically
  impractical.

12
Virtual Memory in Real-Time Systems

• Providing virtual memory features requires that
  the system include a Memory Management Unit(MMU).
• MMUs increase the cost and power consumption.
• Time required to translate logical address to
  physical address especially in case of
  Translation Look aside Buffer(TLB) miss may be
  prohibited in hard real time systems.
• Address translation may occur via
• Real-addressing mode where programs generate
  actual addresses
• Relocation register mode
• Implementing full virtual memory

13
Address Translation
14
Address Translation

• Real-addressing mode
• CPU generates logical
• address L which must be
• mapped to physical address P.
• Bypass the logical address and directly generate
  physical address.
• Not employ virtual memory techniques so P equals
  L.
• Problem no memory protection between processes
  and programmers need to specify physical location
  of memory load.
• Benefits fast, no time spent on address
  translation.
• Used in embedded systems with hard real time
  constraints.

15
Address Translation

• Relocation register mode
• Same as Dynamic
• relocation register.
• Relocation register R is set to memory location
  where a program is loaded.
• Physical address P is generated by adding the
  contents of relocation register R to L.
• Real time systems are configure the MMU to
  perform this way because MMU can easily translate
  logical addresses to physical addresses using
  PLR.
• This system will also not provide memory
  protection between processes.

16
Address Translation

• Implementing full virtual memory
• Address translation take
• place via page table and
• Translation Look aside buffer(TLB).
• This strategy provides program to be loaded at
  any memory location memory protection between
  two processes.
• Without attaching disk drives not possible to
  provide all virtual memory features like Demand
  Paging and Swapping.
• Contrast to that some system provides that using
  NVRAM.
• Examples LynxOS and OnCore Systems.

17
Implementing Real-Time Systems

• In general, real-time operating systems must
  provide
• Preemptive, priority-based scheduling
• Preemptive kernels
• Latency must be minimized

18
Implementing Real-Time Systems

• Preemptive, priority-based scheduling
• Important feature must respond immediately to a
  real time process so system must support
  Priority-based algorithm with Preemption.
• Priority based scheduling algorithms assign
  priority based on their importance.
• If scheduler supports preemption, a process
  currently running on CPU will be preempted if a
  higher priority process will available to run.
• Solaris, Windows XP Linux systems assign
  highest scheduling priority to real time
  processes.
• This will provide only soft real time
  functionality. For hard real time functionalities
  we need additional scheduling features to meet
  timing requirements.

19
Windows XP priorities

• Windows XP has 32 different priority levels, the
  highest priority level values 16-31 are reserved
  for real time processes.

20
Implementing Real-Time Systems

• Preemptive kernels
• Allows the Preemption of a task running in kernel
  mode.
• Designing preemptive kernel is difficult so if
  quick response is not require its not
  implemented. Ex. Windows XP is non-Preemptive.
• In Hard real time systems preemptive kernels are
  mandatory.
• There are two strategies to make kernel
  preemptible
• First Insert Preemption points in long duration
  system calls.
• Preemption points can be placed at safe locations
  in kernel that is where kernel data structure is
  not modified.
• Second Use of synchronization mechanisms.
• Any kernel data being updated are protected from
  modification by the high priority process so
  kernel will always preemptible.

21
Minimizing Latency

• Event latency is the amount of time from when an
  event occurs to when it is serviced.

22
Interrupt Latency

• Interrupt latency is the period of time from when
  an interrupt arrives at the CPU to when it is
  serviced.

23
Interrupt Latency

• Important factor contributing to interrupt
  latency is the amount of time interrupts may be
  disabled while kernel data structures are being
  updated.
• Real time operating systems required that
  interrupts be disabled for very short period of
  time.
• In hard real time systems it must not only be
  minimized, it must in fact bounded to guarantee
  the deterministic behavior of hard real time
  systems.

24
Dispatch Latency

• Dispatch latency is the amount of time required
  for the scheduler to stop one Process and start
  another

25
Dispatch Latency

• If we want to provide real time tasks with
  immediate access to CPU mandates that operating
  system should minimize Dispatch latency. To keep
  Dispatch latency low, provide Preemptive kernels.
• The Conflict phase of dispatch latency has two
  components
• Preemption of any process running in the kernel
• Release by low priority processes of resources
  needed by a high-priority process.
• Ex. Solaris.
• One issue that can affect the dispatch latency
  arises when a higher priority process needs to
  read or modify kernel data that are currently
  being accessed by a lower priority process. Or a
  chain of lower priority processes.
• Problem Priority inversion.
• Solved by Priority-inheritance protocol.

26
Priority Inversion
27
Priority Inversion Priority Inheritance
28
Real-Time CPU Scheduling

• Scheduling Deciding how to allocate a single
  resource
• among multiple clients.
• In what order and for how long.
• Usually refers to CPU scheduling.
• CPU Scheduling decisions may take place when a
  process
• Switches from running to waiting state
• Switches from running to ready state
• Switches from waiting to ready
• Terminates.

29
Real-Time CPU Scheduling

• Two types of Real Time
• Soft Real Time Meet Deadline most of the time,
  but not mandatory.
• Example Live audio-video systems are usually
  soft real-time violation of constraints results
  in degraded quality, but the system can continue
  to operate.
• Hard Real Time Must meet deadline, otherwise
  can cause fatal error.
• Example a car engine control system is a hard
  real-time system because a delayed signal may
  cause engine failure or damage.

30
Real-Time CPU Scheduling

• Periodic processes require the CPU at specified
  intervals (periods)
• p is the duration of the period
• d is the deadline by when the process must be
  serviced
• t is the processing time

31
Real-Time CPU Scheduling

• Unusual about this scheduling is that a process
  may have to announce its deadline requirements to
  the scheduler.
• Using Technique an Admission Control algorithm
  the scheduler
• either admits the process, guaranteeing that the
  process will complete on time,
• or rejects the request as impossible if it cannot
  guarantee that task will be serviced by its
  deadline.

32
Real Time CPU Scheduling Algorithms

• Rate Monotonic Scheduling
• Earliest Deadline First Scheduling
• Proportional Share Scheduling
• Pthread Scheduling

33
Rate Monotonic Scheduling

• It schedules periodic tasks using a static
  priority policy with preemption.
• If a lower priority process is running and a
  higher priority process becomes available to run,
  it will preempt the lower priority process.
• Each periodic task is assigned a priority
  inversely based on its period
• The shorter the period , the higher the priority.
• The longer the period, the lower the priority.
• Rate monotonic scheduling assumes that the
  processing time of a periodic process is the same
  for each CPU burst.
• Every time a process acquires the CPU, the
  duration of its CPU burst is the same.

34
Example

• Two Processes P1 and P2.
• The periods for p1 50 and p2 100.
• The Processing times are t1 20 for P1 and t2
  35 for P2.
• The deadline for each process requires that it
  complete its CPU burst by the start of its next
  period.
• The CPU utilization of a process Pi as the ratio
  of its burst to its period ti/pi so, for P1 it
  is 20/50 0.40 and for P2 it is 35/100 0.35.
  so total CPU utilization of 75 percent.
• First, suppose we assign P2 a higher priority
  than P1.

35
Example - continue

• Now suppose we use rate monotonic scheduling, in
  which we assign P1 a higher priority than P2.

36
Missing Deadline with rate monotonic scheduling

• Assume that Process P1 has a period of p1 50
  and CPU burst of t1 25.
• For P2, the corresponding values are p2 80 and
  t2 35.
• The total CPU utilization of the two processes is
  (25/50) (35/80) 0.94.

37
Limitation

• CPU utilization is bounded.
• The worst case CPU utilization for scheduling N
  processes is 2(2(1/n)-1).
• With one process in the system, CPU utilization
  is 100 percent, but it falls to approximately 69
  percent as the number of processes approaches
  infinity.
• With two processes, CPU utilization is bounded at
  about 83 percent.

38
Earliest Deadline First Scheduling

• It dynamically assigns priorities according to
  deadline.
• The earlier the deadline, the higher the
  priority.
• The later the deadline, the lower the priority.
• If two tasks have the same absolute deadlines,
  chose one of the two at random (ties can be
  broken arbitrarily).

39
Example

• Suppose we have two Process P1 and P2.
• P1 has values of p1 50 and t1 25.
• P2 has values of p2 80 and t2 35.

40

• Unlike the rate monotonic algorithm, EDF
  scheduling does not require that processes be
  periodic, nor must a process require a constant
  amount of CPU time per burst..
• The only requirement is that a process announce
  its deadline to the scheduler when it becomes
  runnable.
• The appeal of EDF scheduling is that,
  theoretically it can schedule processes so that
  each process can meet its deadline requirements
  and CPU utilization will be 100 percent.
• Its impossible due to the cost of context
  switching between processes and interrupt
  handling.

41
Proportional Share Scheduling
Wt2
Wt1
Applications
2/3
1/3
CPU bandwidth

• Associate a weight with each application and
  allocate CPU bandwidth proportional to weight
• T shares are allocated among all processes in the
  system
• An application receives N shares where N lt T
• This ensures each application will receive N / T
  of the total processor time

42
Example

• Assume that a total of T 100 shares is to be
  divided among three processes, A, B and C.
• A is assigned 50 shares, B is assigned 15 shares,
  and C is assigned 20 shares.
• This scheme ensures that A will have 50 percent
  of total processor time, B will have 15 percent,
  and C will have 20 percent.

43
Proportional Share Scheduling

• Proportional Share Schedulers must work in
  conjunction with an admission control policy to
  guarantee that an application receives its
  allocated shares of time.
• An admission control policy will only admit a
  client requesting a particular number of shares
  if there are sufficient shares available.

44
Pthread Scheduling

• The Pthread (POSIX Thread) Library is set of
  functions that enable C/C code to spawn
  multiple threads of execution to do multiple
  tasks simultaneously.
• The Pthread API provides functions for managing
  real-time threads.
• Pthreads defines two scheduling classes for
  real-time threads
• (1) SCHED_FIFO - threads are scheduled using a
  FCFS strategy with a FIFO queue. There is no
  time-slicing for threads of equal priority
• (2) SCHED_RR - similar to SCHED_FIFO except
  time-slicing occurs for threads of equal priority

45
Pthread Scheduling API

• include ltpthread.hgt
• include ltstdio.hgt
• define NUM THREADS 5
• int main(int argc, char argv)
• int i, policy
• pthread_t tidNUM THREADS
• pthread_attr_t attr
• / get the default attributes /
• pthread _attr_ init(attr)
• / get the current scheduling policy /
• if (pthread_attr_getschedulepolicy (attr,
  policy) ! 0)
• fprintf (stderr, Unable to get policy.\n)

46
Pthread Scheduling API

• else
• if (policy SCHED_OTHER)
• printf(SCHED_OTHER\n)
• elase if (policy SCHED_RR)
• printf(SCHED_RR\n)
• else if (policy SCHED_FIFO)
• printf(SCHED_FIFO\n)
• / set the scheduling policy - FIFO, RT, or
  OTHER /
• if (pthread_attr_setschedpolicy (attr,
  SCHED_OTHER) ! 0)
• / create the threads /
• for (i 0 i lt NUM _THREADS i)
• pthread _create (tidi, attr, runner, NULL)

47
Pthread Scheduling API

• / now join on each thread /
• for (i 0 i lt NUM _THREADS i)
• pthread _join (tidi, NULL)
• / Each thread will begin control in this
  function /
• void runner(void param)
• / do some work /
• pthread _exit(0)

48
An Example VxWorks 5.x

• A popular real-time operating system providing
  hard real-time support.
• Commercially developed by Wind River Systems.
• It is widely used in automobiles, consumer and
  industrial devices, and networking equipment such
  as switches and routers.
• It is also used to control the two rovers
  Spirit and Opportunity that began exploring the
  planet Mars in 2004.

49
The Organization of VxWorks
50
Wind Microkernel

• The Wind microkernel provides support for the
  following
• (1) Processes and threads using Pthread API
• (2) preemptive and non-preemptive round-robin
  scheduling
• (3) manages interrupts (with bounded interrupt
  and dispatch latency times)
• (4) shared memory and message passing as
  communication between separate tasks. Also allows
  tasks to communicate using a technique known as
  pipes. Also provides semaphores and mutex locks
  with a priority inheritance protocol to prevent
  priority inversion.

51
Interesting approach to memory management

• Supports two levels of virtual memory.
• First Level
• Quite simple, allows for control of the cache on
  a per-page basis.
• Enables and application to specify certain pages
  as non-cacheable.
• Second Level
• Virtual memory requires the optional virtual
  memory component VxVMI along with processor
  support for a memory management unit(MMU).
• VxWorks allows pages containing kernel code along
  with the interrupt vector to be declared as
  read-only.

52
References

• Operating System Concepts, 8th edition by
  Silberschatz, Galvin and Gange.
• www.wikipedia.com

53
Thank you
