Designing an Establishment

• Designing a Establishment
• ? Needs to be easy to clean
• ? Needs to comply with ADA guidelines (mainly
  FOH issues)
• ? Layout and design plans should be reviewed by
  local or state regulatory agencies (health
  department) even if not required.
• ? Pre-opening inspection (generally necessary
  to obtain a CO)
• ? Post-opening inspection -- with food and
  employees

3
Flooring

• Non-Porous/Resilient
• ? Non-porous to not absorb fluids
• ? Resilient so it does not crack and allow
  material to enter. Not very durable.
• Rubber Tile non-slip
• Vinyl Sheet not durable
• Vinyl Tile not durable

4
Flooring

• Hard-Surface Flooring--Non-porous but not
  resilient generally more durable
• Marble/Terrazo expensive
• Quarry Tile -- expensive
• Wood requires frequent refinishing
• Acrylic Wood plastic impregnated
• wood

5
Walls and Ceilings

• Walls and Ceilings-- non-porous and easy to
  clean, sealed seams
• Ceramic Tile
• Stainless Steel
• FRP
• Wood, Cinderblock, sealed with glossy
• paints
• Coving gap no more than ¼
• Ceilings --Washable, non-asbetos

6
Dry Storage Areas

• Easy to clean
• Good Air circulation
• No Windows, if it does, then needs to be shaded
  or frosted in glass
• Pipes, water lines and conduits
• No dripping condensation
• All sewer lines need to be labeled

7
Dry Storage Areas

• Adequate Storage Space
• Walk-Ins should be sealed from floor, wall and
  ceiling
• Refrigerator units at least 6 inches off the
  floor
• Blast chillers from 140-37 in less than 90 min
• Tumble Chillers uses chilled water to expedite
  the process
• Cook-Chill Equipment cook, chill, reheat in
  same apparatus

8
Handwashing stations must be equipped with

• Hot (100) and cold running water
• Soap
• A means to dry hands
• A waste container
• Signage indicating employees must wash hands

10 -
2
9
Restrooms must be

• Equipped with a handwashing station
• Equipped with self-closing doors
• Adequately stocked with
• Toilet paper
• Trash receptacles
• Covered waste containers
• Patrons should not pass through food prep areas
  to reach restroom
• Self-Closing doors
• Covered waste containers must be provided in
  womens restrooms

10 -
3
10
Equipment must be

• Easy to disassemble for frequent cleaning
• Easy to clean
• Able to handle commercial loads
• NSF and UL listed

10 -
4
11
Basis for most equipment standards
-Easy to clean -Does not interact with the food
does not stain -Rounded or Coved edges -Surfaces
are easy to clean -Coating materials are
non-toxic and must not chip or crack -Easy to
disassemble to frequently clean -Can handle
commercial loads
10 -
4
12
Stationary equipment must be mounted 1 of 2 ways

• On legs at least 6? off the floor
• Sealed to a masonry base

10 -
5
13
Stationary tabletop equipment must be mounted 1
of 2 ways

• On legs with a 4? clearance between equipment
  base and the tabletop
• Sealed to the countertop
• Clean in Place equipment sticky issue!

10 -
6
14
Cutting boards must be

• Made from nonabsorbent hardwoods or
  synthetic materials
• Free of seams and cracks
• Nontoxic
• Washed, rinsed, and sanitized between uses

10 -
7
15
During water supply interruptions

• Use bottled or boiled water for beverages,
  cooking, and cleaning
• Purchase ice
• Use single-use items
• Keep boiled warm water for handwashing
• Flush and disinfect water systems and equipment

10 -
8
16
Cross-ConnectionA link through which
contaminants enter the potable water
supply Backflow Reverse flow of contaminants
through a cross-connection into the potable
water supply
10 -
9
17
A backup of raw sewage is cause for

• Immediate closure
• Correction of the problem
• Thorough cleaning

10 -
10
18
Garbage containers must be

• Leakproof, waterproof, and pestproof
• Easy to clean
• Covered with tight-fitting lids
• Cleaned frequently, inside and out
• Garbage is wet waste and trash is dry waste.
• Pulpers grind up garbage and extract the water.

10 -
11
19
Other Utility Issues

• Potable Water drinkable water
• Booster heater for dishwasher may be needed
• Lighting requirements
• Food prep 50 foot candles
• Walkin/Freezer 10 foot candles All other
  areas 20 foot candles
• Ventillation
• Reduces the level of steam, smoke, grease and
  heat
• Reduces levels of contamination
• Reduces level of condensation dripping on food

20
Cleaning Process

• Factors affecting the cleaning process
• ? Type of soil
• ? Condition of soil
• ? Water hardness interact with the detergent,
  leaves deposits
• ? Water temperature
• ? Cleaning Agent and surface being cleaned
• ? Agitation or Pressure
• ? Length of treatment

21
Types of Cleaners

• Types of Cleaners
• ? Detergents surfactants alkaline
• ? Solvent Cleaners high concentration alkaline
  detergents
• ? Abrasive Cleaners silica that helps abrade
  soil
• ? Acid Cleaners used to remove things that do
  not respond to alkaline (ex lime-away)

22
Sanitizing

• Heat Sanitizing 180 for 1 second (in
  dishwashers) or 171 for 30 seconds
• Chemical Sanitizing
• Chlorine 50 ppm, corrosive and evaporates
• rapidly when temp is above room temperature
• Iodine 12.5-25 ppm slightly corrosive to some
  metals at
• high temperatures, may stain
• Quats 200 ppm Does not kill certain
  microorganisms, hard water interferes
• Choice of Sanitizer type comes down to economy
  and ease of use.

23
Washing Temperatures

• Machine Warewashing
• Pre-Wash 120-160
• Wash -- 150-160
• Sanitize -- 180
• Manual Warewashing (2-4 compartment)
• Wash at 110
• Rinse at 110
• Sanitize at 70-80 degrees

24
Cleaning Tools

• Brushes synthetic brushes (non porous)
• Scouring Pads not metal
• Mops and Brooms
• Towels non terry is best

25
Starting a Cleaning Program

• What should be cleaned
• Who should clean it
• When should it be cleaned

26
Cleaning Program?

• Not replacing worn out tools
• Not having protective gear
• Not training on proper techniques
• Not motivation
• Not making workload fair
• Not following up with inspections.

27
MSDS

• OSHA occupational safety and health
  administration has a Right-to-Know or HAZCOM
  standard that requires employers to train
  employees to how to use chemicals and about the
  chemical hazards they may be exposed to in an
  establishment.

28
Components of HAZCOM

• Inventory of hazardous chemicals used
• Chemical Labeling Procedures
• MSDS Sheets
• Employee Training
• Written plan for use of chemicals and procedure
  for accidents

29
MSDS Sheets

• Information about safe use and handling
• Physical, health, fire and reactivity hazards
• Precautions
• Appropriate personal protective equipment
• First aid info
• Manufacturers name, address and phone number
• Preparation date of MSDS
• Hazardous ingredients and identity information

30
MSDS Training

• Location of MSDS Book
• How to read MSDS and product labels
• How to use MSDS to prevent errors.
