Chapter 12 Gene Expression

1
Chapter 12Gene Expression

• Unlocking the secrets of DNA

2
DNA is difficult to understand, even for the cell.

• The nucleotide sequence of DNA is the blueprint
  for building proteins, but the ribosomes
  responsible for making proteins cannot read DNA.

3
Ribonucleic Acid

• 1) Messenger RNA
• Single strand, complimentary copy of DNA created
  in nucleus contains triplet codons
• 2) Transfer RNA
• Cloverleaf-shaped strand that picks up amino
  acids and delivers them to the ribosome contains
  triplet anti-codons
• 3) Ribosomal RNA
• Makes up ribosomes joins amino acids together to
  create a growing protein chain

4
RNA vs DNA

• RNA is single instead of double strand
• RNA has different sugar (ribose)
• RNA has uracil which takes the place of thymine
• RNA moves out of nucleus controls protein
  synthesis

5
Transcription the production of RNA from the DNA
code
Adenine (DNA and RNA) Cystosine (DNA and
RNA) Guanine(DNA and RNA) Thymine (DNA
only) Uracil (RNA only)
RNApolymerase
DNA
RNA
6
Protein Synthesis

• 1. Transcription
• Occurs in nucleus
• DNA makes a complimentary copy in the form of
  M-RNA in a process similar to replication
• M-RNA moves out of nucleus and to ribosomes in
  the cytoplasm

7
Transcription
8
Benefits of transcription

• Transcribed copies of the DNA (in the form of
  RNA) are used instead of the original DNA.
• In eukaryotes, DNA in the cytoplasm is degraded
  but RNA is not.

9
How does transcription work?

• DNA double helix must be separated at the
  hydrogen bonds between nitrogen bases.
• Only one DNA strand is read by RNA polymerase.
• RNA polymerase constructs an RNA polymer.

10
Building RNA polymer

• DNA ? (codes for) RNA
• A ? U
• T ? A
• C ? G
• G ? C

11
Click on image to play video.
12
What happens to the RNA once it is created?

• In prokaryotes, the RNA is immediately
  translated.
• In eukaryotes, the RNA is processed.
• Introns removed
• Exons joined together

13
RNA processing

• Introns (segments of useless genes) are removed,
  leaving on exons (expressed genes).

14

• 2. Translation
• Occurs in cytoplasm
• T-RNA delivers amino acids to ribosomes joins
  complimentary anti-codons, putting amino acids in
  proper order
• R-RNA forms peptide bonds to join amino acids
  into a protein molecule
• (T-RNA returns to pick up new amino acids)

15
Translation
16
Translation
17
Ribosomes use this decoding scheme to determine
how to build the appropriate protein.
18
How does the decoding work?

• RNA AUGCGAGGGAGAUUAUAGGAC
• Ribosomes read AUG CGA GGG AGA UUA UAG
  GAC.
• Each 3 nucleotide word is called a codon.

19
(No Transcript)
20
Try to decode AUG CGA GGG AGA UUA UAG GAC.

• Met Arg Gly Arg Leu - stop

21
What happens to MetArgGlyArgLeustop?

• The ribosomes create an amino acid polymer that
  is folded into a protein.
• The original DNA code, transcribed to RNA,
  instructs the cell to make a protein for a
  specific function.

22
Click on image to play video.
23
What happens if there is a mutation in the
original DNA?

• Point mutations change of one nucleotide
  sequence
• This may or may not affect the amino acid
  sequence, depending upon where the mutation
  occurs in the DNA sequence.

24
Gene mutations

• Point mutations
• Change one nucleotide or just a few nucleotides
  in a gene
• Examples sickle cell anemia cystic fibrosis
• Frame-shift mutations
• The reading pattern is displaced and shifts
  into new positions
• Examples duchenne Muscular Dystrophy

25
Frame shift mutations

• The cat and the rat ran far.
• The ca and the rat ran far.
• The caa ndt her atr anf ar.

t
r
26
Click on image to play video.
27
Mutations

• Disadvantages
• Abnormal, even lethal genes can be passed on to
  offspring
• Advantages
• New, stronger genes can be passed on to offspring

28
Chromosomal mutations
A B C D E F G H

• Deletion
• Insertion
• Inversion
• Translocation

A B C D E G H
A B C D J E F G H
A B C D E G F H
A B C D E F
G H W X Y Z
29

• DNA 5 A T G C C T G A A T G A 3
• 3 T A C G G A C T T A C T 5 coding
  strand
• mRNA A UG C C U G A A U G A codons
• tRNA U A C G G A C U U A C U anti
  codons
• amino
• acids Met Pro Glu stop
• protein

30
(No Transcript)
31
(No Transcript)
32
The Central Dogma theory of Biology
(DNA RNA protein cell
functions)
33
Animation of translation

• Click to automatically start animation.

34
Nucleus
35
(No Transcript)
36
Single Messenger RNA Strand
37
Single Messenger RNA Strand
38
tRNA
Single Messenger RNA Strand
39
tRNA
Single Messenger RNA Strand
40
tRNA
Single Messenger RNA Strand
41
tRNA
Single Messenger RNA Strand
42
tRNA
Single Messenger RNA Strand
43
tRNA
Single Messenger RNA Strand
44
Single Messenger RNA Strand
45
Single Messenger RNA Strand
46
Single Messenger RNA Strand
47
Single Messenger RNA Strand
48
Single Messenger RNA Strand
49
Single Messenger RNA Strand
50
Single Messenger RNA Strand
51
Single Messenger RNA Strand
52
Single Messenger RNA Strand
53
tRNA
tRNA
Single Messenger RNA Strand
54
tRNA
tRNA
Single Messenger RNA Strand
55
tRNA
tRNA
Single Messenger RNA Strand
56
tRNA
Single Messenger RNA Strand
57
tRNA
Single Messenger RNA Strand
58
tRNA
Single Messenger RNA Strand
59
tRNA
Single Messenger RNA Strand
60
tRNA
Single Messenger RNA Strand
61
tRNA
Single Messenger RNA Strand
62
Single Messenger RNA Strand
63
Single Messenger RNA Strand
64
Single Messenger RNA Strand
65
Single Messenger RNA Strand
66
Single Messenger RNA Strand
67
Single Messenger RNA Strand
68
Single Messenger RNA Strand
69
Single Messenger RNA Strand
70
tRNA
Single Messenger RNA Strand
71
tRNA
Single Messenger RNA Strand
72
tRNA
Single Messenger RNA Strand
73
tRNA
Single Messenger RNA Strand
74
tRNA
Single Messenger RNA Strand
75
tRNA
Single Messenger RNA Strand
76
tRNA
Single Messenger RNA Strand
77
tRNA
Single Messenger RNA Strand
78
tRNA
Single Messenger RNA Strand
79
tRNA
Single Messenger RNA Strand
80
tRNA
Single Messenger RNA Strand
81
Single Messenger RNA Strand
82
Single Messenger RNA Strand
83
Single Messenger RNA Strand
84
(No Transcript)
85
(No Transcript)
86
(No Transcript)
87
(No Transcript)
88
(No Transcript)
89
(No Transcript)
90
(No Transcript)
91
(No Transcript)
92
(No Transcript)
93
tRNA
94
(No Transcript)
95
(No Transcript)
96
(No Transcript)
97
(No Transcript)
98
(No Transcript)
99
(No Transcript)
100
(No Transcript)
101
(No Transcript)
102
(No Transcript)
103
(No Transcript)
104
(No Transcript)
105
(No Transcript)
106
Protein Synthesis overview
107
Transcription DNA codes for RNA

• RNA polymerase
• A ? U
• T ? A
• C ? G
• G ? C

108
mRNA processing

• The RNA polymer made messenger RNA (mRNA)
• DNA has junk genes. These are called introns
  (useless pieces of RNA made as a result of
  useless DNA).
• Introns are cut (spliced).
• Exons are remaining RNA nucleotides carrying the
  actual DNA code.
• Exons are translated.

109
(No Transcript)
110
Translation RNA to amino acids

• Ribosomes read codons.
• AUG start codon
• tRNA with anticodons have amino acids attached.

111
Translation
Ribosomes read until the codon that indicates
STOP.
112
Amino acid chain

• The amino acid chain made in translation is then
  folded.
• Folded proteins enzymes, pigments, etc.
• Proteins made phenotype
