Touch Screen Kiosks

1
Touch Screen Kiosks
Developed by NIC, Haryana at
NIC, Kurukshetra
2
How to use touch Screen?
3
Help Screen - 1
4
Help Screen - 2
5
Help Screen - 3
6
Help Screen - 4
7
Touch Screen

• Features
• Search with minimum entries.
• Searching capable with words those sound alike.
• Also search Relatives
• Also show the images of the voters.
• Very user friendly keyboard
• Audio Notes for help can be On/OFF easily.
• Immediate Help available.
• On Screen display the no. of Searches available.
• Latest Booth Detail information (data from
  randomisation software)

8
How Soundex function will works?

• Words like will be taken as ..
• UTTAM ----------? UTAM, UTTAM.
• ABHISHEK ----------? ABHISHEK, ABISHEK.
• TEEKA ----------? TIKA, TEEKA
• TIKA ----------? TIKA,TIKKA.
• DEEP ----------? DIPAK,DEPAK.

9
Examples of Sound alike names - 1
10
Examples of Sound alike names - 2
11
Examples of Sound alike names - 3
12
Examples of Sound alike names - 4
13
Display voter with Images.
14
Shows the Other Family members details (Sorted on
Age)
15
Display Latest Booth Detail, Vote No. (As the
data is used from the boothdetail table of
randomisation software)
16
Shows the Total Number of Votes of the Family
17
OnScreen display the no. of Searches executed.
18
Layout of keyboard
19
Clearly show for which field keyboard is working.
20
Last used Assembly/Area

• Will keep the record of last assembly/Area used
  in searching.

21
Refreshment of Screen

• After some time screen will automatically refresh.

22
Display the No. of results searches out from the
current query.
23
History of searches.

• Keeps the record of all fields in table what the
  people entering while making the searches (for
  analysis if needed in improvement of the system).

24

• User Manual

25
Entering of Name Etc.
All Entries are Optional. By variations of the
entered text only the No. of results and time
taken will be effected.
26
Touch against the assembly option and select the
Assembly from the List.
Select the Assembly (Optional)
27
Touch against the Area option and select the
Area/Village from the List.Use Buttons to
scroll up down
Select the Area (Optional)
28
Touch your finger on the space against the Name
and type first few characters of your name
Enter Name (Optional)
29
1. Touch your finger on the space
against the requisite field and type.2. Against
F/H Name we can type first few characterFor
Other such as House No./Voter Card No. any
characters can be entered.
Enter Father/Husband Name, Sex, House No., Voter
Card No. (Optional)
30
Press the SEARCH Button.
31
Software will display the No. of Results.
Information of First will be displayed
automatically. Can be scrolled for others.
32
Software will also display the List of Other
Family Members. By clicking on any particular
person, information of that particular
will be displayed.
33
If No record found for the entered queries, then
it will display the No Record Found
34
How to close?

1. Enter the word End in the Name
2. Enter the word END in the F/H Name
3. Enter the password entered in the connection.txt
   file (second line).

35

• Thank You.

Developed by NIC, Haryana at
NIC, Kurukshetra
