Soil for Virginia Master Gardeners

1
Soil for Virginia Master Gardeners

• What you should know
• What you can do
• What you should be able to teach

2
Francis J. Reilly, Jr.

• http//advancedmastergardener.org/
• Webmaster_at_VMGA.net

3
Shameless Commercial

• Have you joined VMGA?
• The Voice of VA Master Gardeners
• Promote fellowship, training communication
• State Coordinators Endowment.

4
Outline

• Why Soils
• What are Soils
• Soil testing and fertility
• Practice
• Compost

5
Why are Soils Important?

• ?
• ?
• ?

6
Why are Soils Important?

• Support Plant growth
• Mediate Climate
• Store water

7
Why do we need to know about soils?

• ?
• ?
• ?

8
Why do we need to know about soils?

• Its what plants grow in
• Troubleshoot plant problems by looking at soil
• Disease Abiotic Factors
• Will water be easily given up to the plant
• Are there any Soil Organisms at Work
• Does water soak in
• Run off?
• Stand on the surface?

9
What is Soil?

• Ideally
• 25 Air
• 25 Water
• 45-48 Minerals
• 2-5 Organic matter
• Soil organisms

Mineral Organic Materials that contain living
matter and can support vegetation
10
Where Does Soil Come from?

• Parent Material
• Climate
• Time
• Relief, Topography
• Organisms
• Human Activity
• Beavers
• Grazers like cows and deer
• Worms
• Bacteria/fungi

11
Physiographic Regions

        Appalachian Plateaus         Valley and Ridge
        Blue Ridge         Piedmont Plateau
                Coastal Plain                 Coastal Plain
12
Physiographic regions and soil types

• Physiographic Regions describe land surface
  features
• Closely related to geology
• Slope, and soils are related

13
Soils Classified

• Soil Survey
• Printed version (1960)
• Ask Debbie where that copy is!
• On-line version
• New version soon (finished 2009)

http//soildatamart.nrcs.usda.gov/Metadata.aspx?Su
rveyVA107UseStateVA
14
What can the soil survey tell you?
15
What can the soil survey tell you?

• Drainage
• Slope
• Topography
• Water features
• Wetlands
• Crop worthiness
• Buildability

16
How Do You Use It?

• Use it to plan
• Dont use it to DO!
• Look up spot on map
• See what it says
• Read about the soil type
• SOIL TYPE?

17
Soil Type

• Soils Classified by
• Depth of layer
• Color
• Texture
• Structure

18
State Soil of Virginia!
19
Soil Taxonomy

• Soil Orders

20
Depth
Horizon Depth Information
O 0-2 Humus
A 1-10 Minerals darkened by organics, zone of max biology
E ? Empty Paler depleted by water leaching out of A into B
B 10-30 Zone of accumulation
C 30-48 Not really like soil
R Below Parent material
21
Color

• Color of parent material
• Other Colors due to pedagenesis

22
Soil Texture
23
Soil Texture

• Sand are the largest particles and they feel
  "gritty."
• Silt are medium sized, and they feel soft, silky
  or "floury."
• Clay are the smallest sized particles, and they
  feel "sticky" and they are hard to squeeze.

Sand 2.00 - 0.05 mm Silt 0.05 - 0.002 mm Clay lt 0.002 mm
24
How to Texture

• 1st a pinch
• Then a ribbon

25
Soil Structure
Granular Blocky
Prismatic Platy
Columnar Single Grained
Massive
26
Soil Structure
27
So what about structure?

• Drainage
• Plant penetration
• Oxygen penetration

28
Pore Spaces

• The smaller the particles
• The smaller the pore spaces
• Water moves slowly
• Less air present

29
How do we improve soils?

• ?
• ?
• ?

30
How do we improve soils?

• Drainage
• Moisture
• Fertility
• Soil Health
• Problems

31
Pore Spaces can decrease due to compaction
32
Soil horizons and water infiltration

• Horizons have different properties
• Some may retard water flow
• Watch out for the builders horizon

33
Check for Yourself

• Dig a hole 12 inches deep and fill it with water
• 30 minutes, the soil has a drainage problem
• 24 hours, waterlogged soils may impact plant
  growth

34
Soils have moisture characteristics

• Important for runoff
• Important for plants

35
Fertility

• Soil Tests
• Kits
• Cheap meters
• Agricultural testing

36
Lets look at our soil tests!
37
So now what?

• Calculate the area
• Read the bag
• Do the math

38
Lets do another!
39
So now what?

• Calculate the area
• Read the bag
• Do the math

40
Calculate the area

• Remember to subtract
• The driveway
• The house
• The sidewalk
• The other gardens
• Remember to add
• The devil strip

41
Read the bag

• NPK
• Turf type
• Complete
• Calculate the percentages
• WIN
• Organics
• Cottonseed meal, Blood Meal
• Sludge
• Farm applications of sludge or poultry litter

42
Specialty Fertilizers
43
Do the math

• Area
• Total pounds N P K needed
• Pounds of fertilizer to use

44
Lets do our own!

• Help your neighbor
• Check your math

45
Apply the fertilizer

• Methods
• Broadcast
• Banding
• Side-Dressing
• Foliar Feeding
• Spreader Calibrate it!!

46
pH Lime

• Lime
• Calcitic
• dolomitic
• Sulfur
• Wood ash
• Pay attention to whats growing there!

47
Micronutrients

• Unusual deficiency
• Blossom end rot
• Green sand
• Other snake oils
• Use compost

48
Composting Recycling
49
Recycle Yard Waste
Composting Considerations

• Microorganisms
• Moisture
• Particle size
• Temperature
• Oxygen
• Carbon / Nitrogen Ratio

50
Microorganisms
Recycle Yard Waste
Bacteria
Fungi
51
Moisture
Recycle Yard Waste
50 is ideal
52
Particle Size
Recycle Yard Waste
53
Particle Size
Recycle Yard Waste
54
Temperature Profile
Recycle Yard Waste
900 to 1400 F
Cool
Hot
Warm
Cold
Cold
55
Compost Pile Dimensions
Recycle Yard Waste

• How Big?
• Maximum Size
• 5 X 5 X 5

• How Small?
• Minimum Size
• 3 X 3 X 3

56
Oxygen
Recycle Yard Waste
To speed process, turn more frequently
57
Carbon Nitrogen Ratio
Recycle Yard Waste
Browns vs. Greens
301 is ideal ratio
58
High Carbon Sources
Recycle Yard Waste

• Leaves
• Paper

• Straw
• Sawdust

59
Materials With High Carbon Value
Recycle Yard Waste
Fruit Wastes 351 Leaves 40-801 Corn
Stalks 601 Straw 801 Bark 100-1301 Paper 1701
Sawdust 5001 Wood 7001
60
Compost or Mulch?
61
High Nitrogen Sources
Recycle Yard Waste

• Grass Clippings
• Kitchen Scraps
• Manures

62
Materials With High Nitrogen Value
Recycle Yard Waste
Food Wastes 151 Grass Clippings 201 Cow
Manure 201 Horse Manure 251
63
CN Ratio How to Measure?
Recycle Yard Waste
Start with equal parts by volume
64
Do Not Compost
Recycle Yard Waste

• Diseased Plants
• Plants with Seeds
• Meat
• Invasive Weeds
• Oily Food Scraps
• Dog/ Cat Manure

65
Constructing A Compost Pile

1. Place coarse materials in bottom of pile
2. Add 4 to 6 layer of leaves
3. Add high nitrogen source ( grass clippings or
   manure)
4. Water the pile after each layer
5. Continue steps 2, 3 4 until bin is full

66
A new compost pile will be built in the center
unit of a three-pallet bin system.
Recycle Yard Waste
67
The first step is to add a bed of twigs and small
branches to promote air circulation.
Recycle Yard Waste
68
A layer of browns is added. Watering between
layers ensures that moisture is evenly
distributed.
Recycle Yard Waste
69
Next, a layer of fresh greens is added.
Recycle Yard Waste
70
Add and water another layer of browns.
Recycle Yard Waste
71
Fresh greens come from flower pruning.
Recycle Yard Waste
72
The browns spent the fall and winter in the
adjacent bin.
Recycle Yard Waste
73
The next layer of greens is also from prunings.
Recycle Yard Waste
74
A fourth layer of browns is added. The layering
process will resume when more greens are
available.
Recycle Yard Waste
75
Finished compost can be improved by sifting
through a screen to remove oversized pieces.
Recycle Yard Waste
76
An inclined screen uses gravity for some of the
sifting effort.
Recycle Yard Waste
77
The screen is loaded with compost.
Recycle Yard Waste
78
Use a square shovel to scrape the compost against
screen.
Recycle Yard Waste
79
The screen is removed to reveal the sifted
compost. The rejects will be added to a fresh
pile.
Recycle Yard Waste
80
Choice in Composting Bins
Recycle Yard Waste

• Home made
• Snow Fencing, Pallets,Wire, Wood Slats, Concrete
  Blocks, Etc.
• Store Bought
• Metal and Plastic Bins and Drums

81
Wire Bin
Recycle Yard Waste
Eleven-foot length of 2 x 4 x 36 welded,
medium-gauge fence wire.
82
Wooden Pallet Bin
Recycle Yard Waste
83
Wooden Pallet Three Bin
Recycle Yard Waste
84
Fasten Pallets With Old Coat Hangers
Recycle Yard Waste
85
Wooden Pallets Snow Fencing
Recycle Yard Waste
86
Purchased Bins
Recycle Yard Waste
87
Compost Trouble Shooting
Symptom Problem Solution
Compost has a bad odor Too much nitrogen or not enough air Add high carbon material and turn pile
Center of pile is dry Not enough water Moisten and turn pile
Pile is damp and warm only in middle Pile is too small Collect more material and mix into a new pile
Pile is damp but will still not heat up Lack of nitrogen Mix in nitrogen source like grass clippings
88
Uses of Compost
Recycle Yard Waste

• Soil Amendment
• Potting Mix
• Lawn Establishment/renovation
• Mulch

89
Benefits of Using Compost
Recycle Yard Waste

• Improves water-holding capacity of soil
• Improves soil structure
• Prevents soil crusting aiding seedling emergence
• Provides a food source for soil organisms
• Increases the fertilizer-holding ability of soil

90
COMPOST HAPPENS!

91
Reduce, Reuse, Recycle Minimize Waste to
Minimize Work

• Questions?
• www.AdvancedMasterGardener.org
