Title: Use of Locally Available Materials and Stabilisation Technique


1
Use of Locally Available Materials and
Stabilisation Technique
  • Dr. M.S. AMARNATH
  • Bangalore University
  • Bangalore

2
Soil Stabilization
  • The soil stabilization means the improvement of
    stability or bearing power of the soil by the use
    of controlled compaction, proportioning and/or
    the addition of suitable admixture or
    stabilizers.
  • Basic Principles of Soil Stabilization.
  • Evaluating the properties of given soil
  • Deciding the lacking property of soil and choose
  • effective and economical method of soil
    stabilization
  • Designing the Stabilized soil mix for intended
    stability
  • and durability values

3
Need for Soil Stabilization
  • Limited Financial Resources to Provide a complete
    network Road System to build in conventional
    method
  • Effective utilization of locally available
    soils and other suitable stabilizing agents.
  • Encouraging the use of Industrial Wastages in
    building low cost construction of roads.

4
Methods of Soil Stabilization
  • Mechanical Stabilization
  • Soil Cement Stabilization
  • Soil Lime Stabilization
  • Soil Bitumen Stabilization
  • Lime Fly ash Stabilization
  • Lime Fly ash Bound Macadam.

5
Mechanical Stabilization
  • This method is suitable for low volume roads i.e.
    Village roads in low rainfall areas.
  • This method involves the correctly proportioning
    of aggregates and soil, adequately compacted to
    get mechanically stable layer
  • The Basic Principles of Mechanical Stabilization
    are Correct Proportioning and Effective
    Compaction

6
Desirable Properties of Soil-Aggregate Mix
  • Adequate Strength
  • Incompressibility
  • Less Changes in Volume
  • Stability with Variation in water content
  • Good drainage, less frost Susceptibility
  • Ease of Compaction.

7
Factors Affecting Mechanical Stabilization
  • Mechanical Strength of aggregates
  • Gradation
  • Properties of the Soil
  • Presence of Salts
  • Compaction

8
  • Mechanical Strength
  • When the soil is used in small proportion to
    fill up the voids the crushing strength of
    aggregates is important
  • Gradation
  • A well graded aggregate soil mix results in a
    mix with high dry density and stability values
  • Properties of soil
  • A mix with Plasticity Index, results poor
    stability under soaking conditions. Hence it is
    desirable to limit the plasticity index of the
    soil

9
  • Presence of Chemicals
  • Presence of Salts like Sulphates and mica
  • are undesirable
  • Presence of Calcium Chloride is Beneficial
  • Compaction
  • Effective Compaction is desirable to
  • produce high density and stability mix

10
Soil Cement Stabilization
  • Soil Cement is an intimate mix of soil, cement
    and water, compacted to form a strong base course
  • Cement treated or cement modified soil refers to
    the compacted mix when cement is used in small
    proportions to impart some strength
  • Soil Cement can be used as a sub-base or base
    course for all types of Pavements

11
Factors affecting soil cement stabilization
  • Soil
  • Cement
  • Pulverisation and Mixing
  • Compaction
  • Curing
  • Additives

12
Soil THE PHYSICAL PROPERTIES
  • Particle Size Distribution
  • Clay content
  • Specific Surface
  • Liquid limit and Plasticity Index

Cement A increase in cement content
generally causes increase in strength and
durability
13
  • Pulverisation and Mixing
  • Better the Pulverisation and degree of mixing,
    higher is the strength
  • Presence of un pulverised dry lumps reduces the
    strength
  • Compaction
  • By increasing the amount of compaction dry
    density of the mix, strength and durability also
    increases

14
  • Curing
  • Adequate Moisture content is to be retained in
  • order to accelerate the strength
  • Additives
  • There are some additives to improve properties
  • Lime
  • Sodium hydroxide
  • Sodium Carbonate
  • Calcium Chloride

15
Design of Soil Cement Mix
  • Soil Cement specimens are prepared with various
    cement contents in constant volumes moulds
  • The compressive strength of these specimens
    tested after 7 days of curing
  • A graph is plotted Cement content Vs compressive
    strength
  • The Cement Content Corresponding to a strength of
    17.5 kg/cm2 is taken as design cement content

16
Soil Lime Stabilization
  • Soil- Lime has been widely used as a
  • modifier or a binder
  • Soil-Lime is used as modifier in high plasticity
  • soils
  • Soil Lime also imparts some binding action
  • even in granular soils

17
Soil-Lime is effectively used in Expansive soils
with high plasticity index.
18
Factors affecting Properties of Soil-Lime
  • Lime Content
  • Generally increase in lime content causes slight
    change in liquid limit and considerable increase
    in Plasticity index
  • The rate of increase is first rapid and then
  • decreases beyond a certain limit
  • The point is often termed as lime fixation point
  • This is considered as design lime content

19
  • Type of Lime
  • After long curing periods all types of limes
    produce same effects. However quick lime has
    been found more effective than hydrated lime
  • Calcium Carbonate must be heated at higher
    temperature to form Quick lime calcium oxide(
    CaO)
  • Calcium oxide must be slaked ( by the addition of
    water) to form Hydrated lime
  • Compaction
  • Compaction is done at OMC and maximum dry density.

20
  • Curing
  • The strength of soil-lime increases with curing
  • period upto several years. The rate of
    increase is rapid during initial period
  • The humidity of the surroundings also affects
    the strength
  • Additives
  • Sodium metasilicate, Sodium hydroxide and
  • Sodium Sulphate are also found useful
    additives

21
Soil- Bituminous Stabilization
  • The Basic Principles of this stabilization are
    Water Proofing and Binding
  • By Water Proofing inherent strength and other
    properties could be retained
  • Most Commonly used materials are Cutback and
    Emulsion
  • Bitumen Stabilized layer may be used as
  • Sub-base or base course for all the roads

22
Factors affecting properties of soil-bitumen
  • Soil
  • The particle size, shape and gradation of the
    soil influence the properties of the soil-bitumen
    mix.
  • Types of Bitumen
  • Cutbacks of higher grade should be preferred
  • Emulsions generally gives slightly inferior
    results than Cutback.

23
  • Amount of Mixing
  • Increasing proportion of bitumen causes a
    decrease in dry density but increases the
    stability after a certain bitumen content
  • The optimum bitumen content for maximum stability
    generally ranges from 4 to 6
  • Mixing
  • Improved type of mixing with low mixing period
  • may be preferred

24
  • Compaction
  • Effective Compaction results higher
  • stability and resistance to absorb water
  • Additives
  • Anti stripping and reactive chemical
    additives have been tried to improve the
    properties of the mixes
  • Portland cement can also be used along with the
    soil bitumen

25
Use of Locally Available Materials in Road
Construction
26
Necessity
  • Scarcity of good quality aggregates / soil for
    road construction
  • Production and accumulation of different waste
    materials
  • Disposal and environmental problem
  • Economical and gainful utilisation

27
Limitations of Using Waste Materials
  • Quality of waste is not controlled by their
    manufacturers
  • Characteristics of by-products vary in a wide
    range
  • Road construction practice is accustomed to
    traditional materials of steady quality
  • Specifications of layers compaction of
    traditional materials are not suitable for waste
    materials

28
General Criteria for Use of Waste Materials
  • Amount of yearly produced waste material should
    reach a certain lower limit
  • The hauling distance should be acceptable
  • The material should not have a poissonous effect
  • The material should be insoluble in water
  • The utilisation should not have a pollutional
    effect to the environment

29
Special Requirement for Using Waste Materials
  • Free from organic matter
  • Should not swell or decay as influenced by water
  • Should not be soluble in water
  • Particles should be moderately porous

30
Industrial wastes
  • Thermal Power Stations
  • Fly ash
  • Bottom ash
  • Pond ash
  • Steel Plants
  • Blast furnace slag
  • Granulated blast furnace slag
  • Steel slag

31
Utilisation of fly ash
  • Thermal power - Major role in power
    generation
  • Indian scenario - Use of coal with high ash
    content
  • - Negligible utilisation of ash
    produced
  • Bulk utilisation - Civil engineering
    applications like construction of
    roads embankments

32
Utilisation of fly ash
  • Can be used for construction of
  • Embankments and backfills
  • Stabilisation of subgrade and sub-base
  • Rigid and semi-rigid pavements
  • Fly ash properties vary widely, to be
    characterised before use
  • Major constituents - oxides of silica, aluminum,
    iron, calcium magnesium
  • Environmentally safe material for road
    construction
  • Possesses many favourable properties for
    embankment road construction

33
Favourable properties of fly ash
  • Light weight, lesser pressure on sub-soil
  • High shear strength
  • Coarser ashes have high CBR value
  • Pozzolanic nature, additional strength due to
    self-hardening
  • Amenable to stabilisation
  • Ease of compaction
  • High permeability
  • Non plastic
  • Faster rate of consolidation and low
    compressibility
  • Can be compacted using vibratory or static roller

34
Engineering properties of fly ash
Parameter Range
Specific Gravity 1.90 2.55
Plasticity Non plastic
Maximum dry density (gm/cc) 0.9 1.6
Optimum moisture content () 38.0 18.0
Cohesion (kN/m2) Negligible
Angle of internal friction (j) 300 400
Coefficient of consolidation Cv (cm2/sec) 1.75 x 10-5 2.01 x 10-3
Compression index Cc 0.05 0.4
Permeability (cm/sec) 8 x 10-6 7 x 10-4
Particle size distribution ( of materials) Clay size fraction Silt size fraction Sand size fraction Gravel size fraction 1 10 8 85 7 90 0 10
Coefficient of uniformity 3.1 10.7
35
Differences between Indian US fly ashes
Property compared Indian fly ash US fly ash
Loss on ignition (Unburnt carbon) Less than 2 per cent 5 to 8 per cent
SO3 content 0.1 to 0.2 per cent 3 to 4 per cent
CaO content 1 to 3 per cent 5 to 8 per cent
Increase in concentration of heavy metals 3 to 4 times in comparison to source coal 10 times or more in comparison to source coal
Rate of leaching Lower Higher
36
Fly ash for road embankment
  • Ideally suited as backfill material for urban/
    industrial areas and areas with weak sub soils
  • Higher shear strength leads to greater stability
  • Design is similar to earth embankments
  • Intermediate soil layers for ease of construction
    and to provide confinement
  • Side slope erosion needs to be controlled by
    providing soil cover
  • Can be compacted under inclement weather
    conditions
  • 15 to 20 per cent savings in construction cost
    depending on lead distance

37
Fly ash for road embankment
Typical cross section of fly ash road embankment
38
Approach embankment for second Nizamuddin bridge
at Delhi
  • Length of embankment - 1.8 km
  • Height varies from 6 to 9 m
  • Ash utilised - 1,50,000 cubic metre
  • Embankment opened to traffic in 1998
  • Instrumentation installed in the embankment
    showed very good performance
  • Approximate savings due to usage of fly ash is
    about Rs.1.00 Crore

39
Approach embankment for second Nizamuddin bridge
at Delhi
40
Spreading of pond ash
Second Nizamuddin bridge approach embankment
Compaction of pond ash
41
Stone pitching for slope protection
Second Nizamuddin bridge approach embankment
Traffic plying on the embankment
42
Utilisation of fly ash Four laning work on NH-6
(Dankuni to Kolaghat)
Length of stretch 54 km Height of embankment
3 to 4 m Fly ash utilisation 2 Million cubic
metres
Water logged area (soft ground conditions)
Compaction of fly ash over layer of geotextile
43
Reinforced fly ash embankment
  • Fly ash - better backfill material for reinforced
    embankments
  • Polymeric reinforcing materials Geogrids,
    friction ties, geotextiles
  • Construction sequence similar to reinforced
    earth structures

44
Okhla flyover approach embankment
  • First geogrid reinforced fly ash approach
    embankment constructed in the country
  • Length of embankment 59 m
  • Height varied from 5.9 to 7.8 m
  • Ash utilised 2,700 cubic metre
  • Opened to traffic in 1996
  • Performance has been very good

45
Okhla flyover approach embankment
46
Erection of facing panels
Okhla flyover approach embankment
Rolling of pond ash
47
Support provided to facing panels during
construction
Okhla flyover approach embankment
Laying of geogrids
48
Hanuman Setu flyover approach embankment
  • Geogrid reinforced fly ash approach embankment
  • Length of embankment 138.4 m
  • Height varied from 3.42 m to 1.0 m
  • Opened to traffic in 1997

49
Sarita Vihar flyover approach embankment
  • Length of embankment 90 m
  • Maximum height 5.25 m
  • Embankment opened to traffic in Feb 2001
  • Polymeric friction ties used for reinforcement

50
Laying of friction ties
Sarita Vihar flyover reinforced approach
embankment
Arrangement of friction ties before laying pond
ash
51
Compaction of pond ash using static and vibratory
rollers
Sarita Vihar flyover reinforced approach
embankment
Compaction using plate vibrator near the facing
panels
52
Fly ash for road construction
  • Stabilised soil subgrade sub-base/base courses
  • Mixing with soil reduces plasticity
    characteristics of subgrade
  • Addition of small percentage of lime or cement
    greatly improves strength
  • Leaching of lime is inhibited and durability
    improves due to addition of fly ash
  • Pond ash bottom ash can also be stabilised
  • Lime-fly ash mixture is better alternative to
    moorum for construction of WBM / WMM

53
Fly ash for road construction
  • Construction of semi-rigid/ rigid pavements
  • Lime-fly ash concrete
  • Dry lean cement fly ash concrete
  • Roller compacted concrete
  • Fly ash admixed concrete pavements
  • Lime-fly ash bound macadam
  • Precast block paving
  • High performance concrete

54
Typical cross section of flexible pavement
conventional section
55
Fly ash 6 cement stabilised layer 150 mm
Typical cross section of flexible pavement
using fly ash
56
Fly ash admixed PQC 300 mm
DLFC 100 mm
Pond ash 300 mm
Typical cross section of rigid pavement using
fly ash
57
Demonstration road project at Raichur
  • Total length of the road 1 km
  • Five sections of 200 m each with different
    pavement sections
  • Pond ash has been used for replacing moorum in
    sub-base course
  • Stabilised pond ash used for replacing part of
    WBM layer
  • One rigid pavement section using DLFC and RCCP
    technology was laid
  • Performance of all the specifications is good

58
Mixing of lime stabilised pond ash
Demonstration road project using fly ash at
Raichur
Compaction of stabilised pond ash using road
roller
59
Construction of roller compacted concrete pavement
Demonstration road project using fly ash at
Raichur
View of the demonstration road stretch after
three years
60
Demonstration road project using fly ash near
Dadri (U.P)
  • A rural road near Dadri in District Gautam Budh
    Nagar, Uttar Pradesh was selected
  • Total length of road 1.4 km
  • Bottom ash used as embankment fill
  • Base course constructed using fly ash stabilised
    with 8 cement
  • RCCP Wearing course 10 cm thickness
  • RCCP Mix proportion 124
  • 30 per cent of cement and 20 per cent of sand
    replaced with fly ash in RCCP
  • Shoulders 8 cement stabilised fly ash

61
Demonstration road project using fly ash near
Dadri (U.P) Typical section
62
Demonstration road project using fly ash near
Dadri (U.P)
Stabilised base course
Compaction of RCCP
Mixing laying of RCCP
63
IRC Guidelines / Specifications
  • Guidelines available on pavement construction
  • IRC 60 Tentative guidelines for use of lime fly
    ash concrete as pavement base or sub-base
  • IRC 68 Tentative guidelines on cement fly ash
    concrete for rigid pavement construction
  • IRC 74 Tentative guidelines for lean cement
    concrete and lean cement fly ash concrete as a
    pavement base or sub-base
  • IRC 88 Recommended practice for lime fly ash
    stabilised soil as base or sub-base in pavement
    construction

64
Guidelines for use of fly ash in road embankments
  • Published recently by Indian Roads Congress
    (SP- 582001)
  • Includes design aspects also
  • Handling and construction
  • Loose layer thickness of 400 mm can be adopted if
    vibratory rollers are used
  • Moisture content - OMC 2 per cent
  • Use of vibratory rollers advocated
  • Minimum dry density to be achieved - 95 per cent
    of modified Proctor density
  • Ash layer and side soil cover to be constructed
    simultaneously

65
Utilisation of steel slags
  • Total production of slag from steel industries is
    about 8.0 million tonnes
  • Types of slags
  • Blast furnace slag
  • Granulated blast furnace slag (GBFS)
  • Air cooled slag
  • Steel slag

66
Granulated blast furnace slag Contains reactive
silica Suitable for lime / cement stabilisation
Air cooled blast furnace slag Non
reactive Suitable for use as coarse aggregates
67
CRRI work on utilisation of steel slags
  • Characterisation of slags produced at different
    steel plants
  • Laboratory studies on Lime-GBFS mixes
  • Semi-field studies on Lime-GBFS concrete
  • Test track studies on usage of slags in road
    works

68
Properties of air cooled slag
Property Durgapur Bhilai Rourkela Delhi Quartzite Specification requirements
Specific gravity 2.78 2.82 2.82 3.33 2.97 2.99 2.67 -
Water absorption () 1.53 1.72 0.58 1.38 0.74 1.29 0.48 2 Max
Los Angeles abrasion value () 18.80 25.00 14.28 34.00 40 Max
Impact value () 15.79 14.80 16.90 24.50 30 Max
Soundness value () 1.66 1.17 0.33 0.17 12 Max
Percentage voids 46.40 43.90 43.10 43.80 -
69
Steel slags
  • Obtained as a waste product during production of
    steel
  • Particle size varies from 80 mm to 300 microns
  • Compared to blast furnace slag, steel slag
    contains lower amount of silica, higher amounts
    of iron oxide and calcium oxide
  • Due to presence of free lime, steel slag should
    be weathered before using it in construction

70
Road projects executed under CRRI guidance using
slags
  • Plant roads at Visakhapatnam
  • Test tracks in collaboration with AP PWD using
    slags from Visakhapatnam Steel Plant
  • Test tracks in collaboration with Orissa PWD
    using slags from Rourkella Plant
  • Test tracks at RD Centre for Iron Steel,
    Ranchi using Slags from Bokaro Plant

71
Construction of test track using slag at Orissa
Labour based techniques for construction of
stabilised layer
72
Lime stabilisation of iron slags (Orissa)
View of finished surface of road constructed
using slags at Orissa
73
Processed municipal wastes
  • Processed municipal wastes utilised for
    construction of test track on village road near
    Delhi
  • Stabilised municipal waste used for construction
    of sub-base layer
  • Performance of stretch is good

74
Kimberlite tailings
  • Kimberlite tailings are waste produced from
    diamond mining
  • Can be used in base or sub-base course by
    adopting mechanical or cement stabilisation
  • High value of water absorption makes them
    unsuitable for use in bituminous pavement

75
THANK YOU
Write a Comment
User Comments (0)
About PowerShow.com
