Bone Diseases

1
Bone Diseases

• Dr Derakhshandeh, PhD

2
Dominant negative mutations

• Dominant negative mutations
• antimorphic mutations
• an altered gene product that acts
  antagonistically to the wild-type allele
• These mutations usually result in an altered
  molecular function
• (often inactive)
• Dominant
• or semi-dominant phenotype

3
Dominant negative mutations

• In humans
• Marfan syndrome is an example of a dominant
  negative mutation
• occurring in an autosomal dominant disease
• the defective glycoprotein product of the
  fibrillin gene (FBN1)
• antagonizes the product of the normal allele

4
Fibrillin gene
Marfan syndrome
5
Osteogenesis imperfecta
6
Osteogenesis imperfecta
7
Definition

• Osteogenesis imperfecta
• a congenital (present from birth) condition of
  abnormal fragility of the bones

8
CollagenFibrillin in EM
9
Collagen

• in most tissues and organs
• is most plentiful in
• dermis
• Tendon
• Cartilage
• and bone
• as a scaffolding for our bodies
• Controls cell shape
• broken bones regenerate
• and wounds heal

10
Collagens

• the fibrous protein constituent
• Insoluble
• extracellular glycoprotein
• found in all animals
• the most abundant proteins in the human body

11
Primary Structure of Collagens

• The basic unit of collagens
• a polypeptide consisting of the repeating
  sequence
• (Glycine (Gly) - X - Y)n
• X is often Proline (Pro)
• and Y is often hydroxyproline

12
Procollagen Type I

• The most common form of fibrillar collagen
• It is a major constituent of
• bone
• and skin
• consists of a heterotrimer of
• two alpha1(I)
• and one alpha2(I) chains

13
Tertiary Structure
14
Extracellular processes of collagen synthesis
Prockop Kivirikko (1984)
15
Genetic

• OI, TYPE IOSTEOGENESIS IMPERFECTA WITH BLUE
  SCLERA
• Gene map locus 17q21.31-q22, 7q22.1
• OI type I phenotype can be produced by mutation
  in either the COL1A1 gene or the COL1A2 gene

16
Osteogenesis imperfecta type I

• 110 000
• dominantly inherited (AD)
• Connective tissue disorder
• characterized mainly by bone
• fragility
• blue sclera
• 'functional null' alleles of COL1A1 on chromosome
  17
• or COL1A2 on chromosome 7
• lead to reduced amounts of normal collagen I

17
What is the official name of the COL1A1 gene?

• The official name of this gene is
• collagen, type I, alpha 1
• COL1A1 is the gene's official symbol

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
Glycine Serin
24
What conditions are related to the COL1A1 gene?

• Ehles-Donlos syndrome (AD)
• Arthrochalasia
• (Short stature, Hyper elasticity of skin, AR,
  Problem with healing, N-Terminal defect
• caused by mutations in the COL1A1/2 gene

25
Arthrochalasia
26

• The mutations in the COL1A1/2 gene
• instruct the cell to leave out a part of the
  pro-alpha1(I) chain that contains a segment used
  to attach one molecule to another
• When this part of the protein is missing, the
  structure of type I collagen is compromised
• Tissues that are rich in type I collagen
• such as the skin, bones, and tendons, are
  affected by this change

27
OI Type I

• Osteogenesis imperfecta is the most common
  disorder
• Mutations inactivate one of the two copies of
  the COL1A1/2 gene

28
OI Type I

• The mutated copy of the gene does not produce any
  pro-alpha1/2(I) collagen chains
• Because only one copy of the gene
• cells from people with this disorder make only
  half of the normal amount of type I collagen
• which results in bone fragility and other symptoms

29
OI Type II

• - caused by mutations in the COL1A1/2 gene
• Many different types of mutations in the COL1A1/2
  gene can cause osteogenesis imperfecta type II
• These mutations range
• from missing pieces of the COL2A1/2 gene
• to amino acid substitutions
• in which the amino acid glycine is replaced by
  another amino acid in the protein strand
• C-terminal

30
OI Type II

• Sometimes one end of the gene (called the
  C-terminus) is altered
• which interferes with the association of the
  protein strands
• All of these changes prevent the normal
  production of mature type I collagen
• which results in this severe condition, type II
  osteogenesis imperfecta

31
OI Type III

• caused by mutations in the COL1A1/2 gene
• Mutations in the COL1A1/2 gene may result
• unusable for collagen production
• Other mutations cause the amino acid glycine to
  be replaced by a different amino acid in the
  pro-alpha1(I) chain
• inhibits the essential interaction between
  protein chains

32
type III osteogenesis imperfecta

• inability of the altered procollagen strands
• These alterations negatively affect tissues that
  are rich in type I collagen
• such as the skin, bones, teeth (Dentinogenesis
  imperfecta), and tendons

33
OI Type (IV)

• caused by mutations in the COL1A1/2 gene
• Several different types of mutations in the
  COL1A1/2 gene cause osteogenesis imperfecta type
  IV
• missing pieces of the COL1A1/2 gene
• or changes in base pairs
• formation of the mature triple-stranded collagen
  molecule

34
OI

• Position effect (5/3- Mutation)
• Protein effect (Gly)
• Chain effect (aI/aII)

35
Where is the COL1A1 gene located?

• Cytogenetic Location 17q21.3-q22.1
• Molecular Location on chromosome 17

36
CLINICAL FEATURES

• Osteogenesis imperfecta
• Characterized chiefly by multiple bone fractures,
  usually resulting from minimal trauma
• Affected individuals have blue sclerae,
  normal-near normal teeth, and normal or
  near-normal stature

37
CLINICAL FEATURES

• Osteogenesis imperfecta
• Fractures are rare in the neonatal period
• fracture tendency is constant from childhood to
  puberty
• Often increases following menopause in women and
  after the sixth decade in men

38

• CLINICAL FEATURES
• OI

39
CLINICAL FEATURES

• Fractures
• heal rapidly with evidence of a callus formation
• and, with good orthopedic care, without deformity
• Hearing loss
• occurs in about 50 of families
• beginning in the late teens
• to profound deafness, by the end of the fourth to
  fifth decade

40
CLINICAL FEATURES

• Radiologically
• wormian bones are common
• but bone morphology is generally normal at birth
• Vertebral body morphology
• in the adult is normal initially
• but often develops the classic 'cod-fish'
  appearance

41
EYES

• Individuals with OI type I have distinctly blue
  sclera which remain intensely blue throughout
  life
• The intensity of the blue fades with time that
  these individuals may have sclerae of normal hue
  by adult life

42
EYES

• Hartikka et al. (2004) found that
• patients with COL1A1 mutations more frequently
  had blue sclerae than those with COL1A2 mutations

43
CARDIOVASCULAR

• Mitral valve prolapse occurred in 18 (3 times
  the prevalence in unaffected relatives)

44
EARS

• In likely heterogeneous groups of patients with
  OI
• about half of affected individuals have hearing
  loss
• that begins during the second decade as a
  conductive loss
• Audiometry showed hearing loss in 25 patients
  (59.5)

45
EARS

• Hartikka et al. (2004) reported
• No correlation was found between the mutated gene
  or mutation type and hearing pattern
• The authors interpreted this to mean that the
  basis of hearing loss in OI is complex
• and that it is a result of multifactorial

46
Causes, incidence, and risk factors

• All four types of OI are caused by defects in the
  amount or
• structure of Type 1 collagen
• an important part of the bone matrix

47
Causes, incidence, and risk factors

• The defect may be inherited in an autosomal
  dominant pattern from an affected parent
• This means that an affected parent, who carries a
  single gene for the disorder
• has a 50 chance of having children with the
  disorder
• Any child who inherits this gene will be affected

48
Prevention

• Genetic counseling
• is recommended for prospective parents if one or
  both are affected by this disorder

49
Symptoms

• OI
• all of the bones are abnormally weak
• The severity of the abnormality varies enormously
  from Type II OI
• which is usually lethal in infancy (or even
  before birth)
• Type I OI, which may be so mild that the
  diagnosis is not made, even in adulthood

50
Symptoms

• The three classic symptoms of OI includes
• fragile bones
• early hearing loss
• and whites of the eyes that appear bluish (blue
  sclerae)

51
Symptoms

• not all people with OI will have blue sclerae or
  hearing loss
• All do have fragile bones, but not all people
  with OI actually ever break a bone
• penetrance of hearing loss is clearly
  age-dependent (Garretsen and Cremers, 1991)

52
SKIN

• Skin elasticity
• OI type I increased elasticity in comparison to
  the type III patients

53
INHERITANCE

• Paternal age effect
• for increased risk of new mutations has been
  documented
• although it appears to be considerably lower
  than, for example, in Achondroplasia
• Blumsohn et al. (2001) confirmed the presence of
  a small paternal age effect in apparently
  sporadic OI

54

• CLINICAL FEATURES
• OII

55

• OSTEOGENESIS IMPERFECTA CONGENITA,
• NEONATAL LETHAL FORMOSTEOGENESIS IMPERFECTA,
  TYPE IIOI
• Gene map locus 17q21.31-q22, 7q22.1

56
OSTEOGENESIS IMPERFECTA, TYPE II
57
Osteogenesis imperfecta, type II

• the most severe form of the disorder
• Infants with the disorder
• have soft, fragile bones that may appear bent or
  crumpled
• Bones are easily broken
• and multiple fractures can occur even before
  birth
• The chest is narrow
• with short ribs and underdeveloped lungs

58
Osteogenesis imperfecta, type II

• Affected infants
• have short bowed arms and legs and unusually
  soft skull bones
• Characteristic facial features include a small,
  narrow nose and a dark blue tint to the part of
  the eyeball that is usually white
• Most infants with this condition are stillborn or
  die shortly after birth, usually from respiratory
  problems. A few children have lived from several
  months to a few years

59

• CLINICAL FEATURES
• OIII

60
OSTEOGENESIS IMPERFECTA, TYPE IIIOI

• Gene map locus 17q21.31-q22, 7q22.1
• The causative mutation in most cases lies in one
  of the genes for type I collagen, COL1A1 or
  COL1A2

61
TYPE III OI
62
TYPE III OI

• People with the disorder are much shorter than
  average
• because the condition prevents bones from growing
  normally.
• Spinal curvature (scoliosis)
• and bone abnormalities often become progressively
  worse during childhood
• but tend to stabilize during adolescence
• These complications may shorten a person's
  lifespan by affecting heart and lung function
• Other signs and symptoms include a light blue
  tint to the part of the eyeball that is usually
  white , brittle and discolored teeth, loose
  joints, and, in some cases, hearing loss.

63
Gene Therapy

• Chamberlain et al. (2004)
• used adeno-associated virus vectors
• to disrupt mutant COL1A1 collagen genes
• in mesenchymal stem cells, from individuals with
  severe OI
• demonstrating successful gene targeting in adult
  human stem cells

64

• CLINICAL FEATURES
• OI IV

65
OSTEOGENESIS IMPERFECTA, TYPE IV

• OI, TYPE IVOSTEOGENESIS IMPERFECTA WITH NORMAL
  SCLERAE
• Gene map locus 17q21.31-q22

66
OSTEOGENESIS IMPERFECTA, TYPE IV
67
Hypothesis

• more than one broken bone occurring in a single
  episode (multiple)
• present at birth
• occuring after only minor trauma
• a minority of people with OI never break a bone
• deformed or short extremities (such as leg
  deformities or arm deformities)
• deafness (conductive hearing loss may occur in
  adults)

68
Hypothesis

• Short stature
• tooth abnormalities
• low nasal bridge
• easy bruising
• bowed legs

69
Signs and tests

• A physical examination may confirm the presence
  of fractures, deformities, and other symptoms.
• Bone X-rays may show multiple healed fractures.
• Once the specific molecular diagnosis is known,
  family members can be tested by a DNA blood test.
• DNA testing on prenatal chorionic villus samples
  (CVS) can make the diagnosis during pregnancy.
• Severe OI is visible on prenatal ultrasound as
  early as 16 weeks.

70

• Osteomyelitis

71
Osteomyelitis

• Procedure
• Osteomyelitis is an acute or chronic bone
  infection, usually caused by bacteria or by fungus

72
Causes, incidence, and risk factors Osteomyelitis

• The infection that causes osteomyelitis
• often is in another part of the body and spreads
  to the bone via the blood
• Affected bone may have been predisposed to
  infection because of recent trauma
• In children
• the long bones are usually affected
• In adults
• the vertebrae and the pelvis (hip) are most
  commonly

73
Osteomyelitis

• Risk factors are recent trauma, diabetes,
  hemodialysis, and intravenous drug abuse. People
  who have had their spleen removed are also at
  higher risk for osteomyelitis
• The incidence of osteomyelitis is 2 in 10,000
  people.

74
Prevention

• Prompt and complete treatment of infections is
  helpful
• High-risk people should see a health care
  provider promptly if they have signs of an
  infection anywhere in the body

75
Symptoms

• Pain in the bone Local swelling
• redness
• and warmth
• Fever
• General discomfort, uneasiness, or ill feeling

76

• Achondroplasia

77
Achondroplasia

• Definition
• An inherited disorder of bone growth
• that causes the most common type of dwarfism

78
Achondroplasia

• its characteristic normal to large-sized head
• shortened arms and legs (especially the upper
  arm)
• a normal-sized trunk
• and waddling gait

79
Achondroplasia

• Achondroplasia is inherited as an (AD) trait
• However, the majority of cases, approximately
  80, appear as spontaneous mutations
• If one parent has Achondroplasia, the infant has
  a 50 chance of inheriting the disorder
• If both parents have the condition, the infant's
  chances of being affected increase to 75

80
Genetics of Achondroplasia

• 99 of the affected individuals
• a single point mutation
• in the Fibroblast Growth Factor Receptor gene3
  (FGFR 3)
• located on chromosome 4
• glycine is substituted for arginine at codon 380
  of FGFR 3

81

• Such a mutation results
• in an abnormal cartilage and fibrous connecting
  tissue formation
• Therefore, not only bones, but the ligaments,
  tendons and muscles of the patient with
  Achondroplasia are affected

82
Family with compound heterozygosity for N540K and
G380R mutations
83
Prevention

• Genetic counseling may be helpful for prospective
  parents
• when one or both have achondroplasia
• Because achondroplasia arises as a spontaneous
  mutation
• absolute prevention is not possible

84
Symptoms

• at birth
• Short stature
• short limbs
• large appearing head
• Skeletal (limb) abnormality
• Abnormal hand appearance
• with persistent space between the long and ring
  fingers
• marked kyphosis and lordosis (spine curvatures)

85

• kyphosis and lordosis

86
Symptoms

• Waddling gait
• prominent forehead (frontal bossing)
• increased inward curve of lower back
• increased outward curve of upper back making back
  appear slightly hunched (kyphosis)
• head appears disproportionately large for body
• bowed legs
