Transrapid Maglev System Innovative
traintechnology
2
Comparison of Systems Railroad / Maglev
Titel
Wheel-on-rail
Electromagnetic Levitation
Guidance
Propulsion
Propulsion
Support
Support
3
System Components
Electromagnetic Levitation
Stator Pack
Guidance Magnet Eddy Current Brake
Support Magnet Linear Generator
Guidance Rail
4
Linear Motor
5
Propulsion Principle
6
Longstator Propulsion Switching
Motor Section Switched Off
Activated Motor Section
Motor Section Switched Off
Energy Supply
7
Comparison Propulsion Systems
Transrapid (Track-mounted drive)
Gradient (max. 10)
Railroad (Vehicle-mounted drive)
Gradient (max. 4)
8
Transrapid/ICE Acceleration distance to 300 km/h
(185 mph)
9
Transrapid Acceleration of a 6-section vehicle
km/h
500
400
300
200
100
0
s
0
50
100
150
200
250
300
10
Guideway Types
At-grade guideway Typ III
1,25-3,5 m
Elevated guideway Typ II
49,536 m
Elevated guideway Type I
11
Guideway Bending Switch
Turn-out Direction
3,60 m
150 m
Straight Direction
12
Transrapid 08
13
Trainset Configurations
14
Cargo Vehicle
15
Safety
16

Land Consumption
17
Transrapid Collocation with highways
TR Standard 26.4.2001
18
Specific Energy Consumption
19
Specific CO2 Emissions
20
Noise Emission
21
Magnetic Field Strength
22
Track Investment Costs ICE/Transrapid Long
Distance Application
ICE
(in million per double track km)
ICE
ICE
Transrapid
ICE
HannoverWürzburg
CologneFrankfurt
MannheimStuttgart
HannoverBerlin
BerlinHamburg
level, few tunnels, 94 mi, Price level 1997
low-mountains, many tunnels, 205 mi, Price level
1988
low-mountains many tunnels, 62 mi, Price level
1988
low-mountains many tunnels, 118 mi, Price level
1998
level, few tunnels, 181 mi, Price level 1998
New route including track infrastructure,
operation/maintenance facilities, without trains
and station New route including guideway
infrastructure, operation/maintenance facilities,
without vehicles and stations (Berlin-Hamburg
Project planning)
23
Overall System Maintenance Costs Long Distance
Application
Eurocent per seat-km (under identical conditions)
Vehicle
Guideway
Overall System
100
100
34
100
29
41
Operating Speed ICE 250 km/h (155
mph) Transrapid (TR) 450 km/h (280 mph)
24
Emsland Test Facility TVE
Guideway Length 31.5 km / 19.5 miles
North Loop
South Loop
High-speed Section (400-450 km/h)
Observation Point
Switch
Switch
Switch
At-grade Guideway
At-grade Guideway
Visitor / Test Center
25
Shanghai Airport Link
26
Shanghai Airport Link Route
27
Shanghai Airport Link Project Data
Route Length 30 km double track Link to
maintenance facilities 3 km single
track Stations 2 Number of vehicles in 2003 3
vehicles each with 5 sections Traffic
Volume in 2005 10 million passengers in
2010 20 million passengers in 2020 33 million
passengers Travel speed (max.) 430 km/h Trip
time 8 minutes Headway 10 minutes (option 5
minutes) Daily operation 18 hours
28
Transrapid project Munich
29
Munich Airport Link
Western Route
Possible tunnel
Airport
Neufahrn b. Fsg.
Eching
Unterschleißheim
Oberschleißheim
AB.-Dreieck Feldmoching
Ismaning
Olympiapark
Main Station
Messe
Ostbahnhof
30
Munich Airport Link Project Data
Munich Airport Central Station
Number of vehicles Sections / Vehicle
Seats per vehicle including seats
Stations Traffic Volume Travel
speed (average speed) Trip Time Train schedule
5
3
148
148
2
7.86 million passengers/year
350 km/h / 218 mph (220 km/h / 137 mph)
10 minutes
every 10 minutes
31
Munich Airport Link Track Data
Munich Airport Central Station
Route length in collocation with federal
highways in collocation with roads/railways
Track length elevated (gt 6m above
GUE) at grade (gt 2m above GUE) at grade (1,45
m above GUE) within tunnel GUE Ground
Upper Edge
37.4 km / 23.2 miles
18.7 km / 11.6 miles (50)
2.9 km / 1.8 miles (8)
37.4 km / 23.2 miles
5.25 km / 3.3 miles (14)
12.7 km / 7.9 miles (34 )
19.45 km / 12.1 miles (52)
7.2 km / 4.5 miles (19)
32
Pennsylvania Project Route Alternatives
Pittsburgh International Airport Magport
North Shore Magport
Pittsburgh
Monroeville Magport
Station Square Magport
Monongahela
Greensburg Magport
33
Baltimore-Washington ProjectRoute Alternatives
795
Baltimore to Washington D.C. Route length 62.8
km / 39 miles Stations 3 Trip time 18.5
minutes Vehicles 7 (3 sections each) Invest
cost 3.7 billion
Baltimore
32
295
95
Washington D.C.
34
TransrapidLas Vegas
35
TransrapidProject Netherlands
Amsterdam Schiphol Groningen (Zuiderzeelijn)
Route length 186 km / 116 miles Stations
8 Trip time 59 minutes
Groningen
Drachten
NORTH SEA
Heerenveen
NETHERLANDS
Emmeloord
Lelystad
Amsterdam
Almere
Schiphol International Airport
