MODIS Direct Acquisition, Processing and Applications @ CRISP

1
MODIS Direct Acquisition, Processing and
Applications _at_ CRISP
CRISPCentre for Remote Imaging, Sensing and
Processing
KWOH, Leong Keong Director, CRISP E-mail
lkkwoh_at_nus.edu.sg APEIS Capacity Building
Workshop on Integrated Environmental Monitoring
of the Asia-Pacific Region 20-21 September 2002,
Beijing, China
2
Overview

• Introduction
• Processing Levels
• Level-0 Processing
• Browsed Image Generation
• CRISPs MODIS Web Cataloging System
• Level-1 Processing
• NASA software Vs. IMAPP
• MODIS Georectification
• Recent Application
• Conclusion and Future Developments

3
CRISPCentre for Remote Imaging, Sensing and
Processing

• Status of CRISP MODIS Data Reception
• First Reception of TERRA MODIS 3 March 2001
• First Reception of AQUA MODIS 15 July 2002
• Processing system currently used IMAPP v 1.4
  (beta)
• Computing Platform PC running LINUX

4
6 metre X band Antenna
13 metre X band Antenna
TERRA / AQUA data received if either one of the
antenna is available. Either antenna can be used.
5
The first MODIS captured by CRISP on 3/3/2001
6
First MODIS image received and processed by CRISP
3 March 2001)
7
Processing Levels

• Two main levels
• Level-0 Processing
• Frame Formatting Software developed by CRISP
• Catalogue Software
• RAW data archived on DLT
• Level-1 Processing
• NASA GSFC level 1 processing software
• International MODIS/AIRS Processing Package
  (IMAPP) by University of Wisconsin
• Higher level processing
• Georectification developed in CRISP

8
Level 0 Processing
TERRA / AQUA
Downlinked Raw format
MODIS CCSDS Packets
FrameSync Reformat with RS correction
Recorded on Hard disk (Datron DIS)
GBAD Packets
(AQUA only)
Browse Image
Demodulator (Alcatel Omnisat)
X-Band Antenna
9
Generate Browse Image

• A program is written to generate browse images
  directly from the MODIS PDS file.
• The program incorporate some simple geometry to
  flatten the image and remove bowtie effect.
• The browse images is then fed into on our web
  catalogue system.
• The acquisition, archival, browse image
  generation and catalogue updating are performed
  automatically.

10
Image Captured on 4 July 2001(SWIR, NIR, RED)
11
CRISPs MODIS Web Catalogue (crisp.nus.edu.sg)
12
(No Transcript)
13
TERRA Day Image
14
Night Image
15
AQUA Image
16
Level 1 Processing

• Two versions of level-1 processing has been used
• International MODIS/AIRS Processing Package
  (IMAPP)
• NASA GSFC MODIS level 1 Processing Software

17
Construction records
MOD01
MOD02
MOD03
NASA Software
PDS File
Level 1a
Level 1b
GBAD File
Geolocation
IMAPP
(AQUA Only)
18
Georectification
19
Georectification
20
Georectification
21
Terra MODIS image on 4 July 2001
22
Forest Fire in Sumatra, 4 July 2001
23
Forest Fire in Sumatra, 4 July 2001
24
MODIS Hot Spots validated with SPOT
fires2001-05-23
MODIS Hot Spots 2.8387N 111.9912E 2.8373N
112.0008E 2.8295N 111.9899E 2.8281N 111.9995E
SPOT Fire Locations A 2.8328N 111.9922E B 2.8344N
111.9994E C 2.8308N 111.9997E
25
MODIS Hot Spots validated with SPOT
fires2001-05-23
MODIS Hot Spots 2.5642N 111.9143E 2.5628N
111.9239E 2.5563N 111.9034E 2.5549N
111.9130E 2.5535N 111.9226E 2.5521N
111.9322E 2.5508N 111.9417E 2.5456N
111.9117E 2.5443N 111.9213E
SPOT Fires D 2.5633N 111.9192E E 2.5528N
111.9158E F 2.5533N 111.9211E G 2.5550N
111.9258E H 2.5531N 111.9303E
26
Conclusion and Future Developments

• CRISP has implemented an end to end MODIS DB
  reception, archival and processing system.
• Automatic processing, from level 0 processing,
  catalogue updating to level 1 processing and
  further georectification are performed.
• We are currently developing numerous applications
  for MODIS such as Cloud Mask, 8-days Cloud Free
  Composite, Fires detection and Ocean
  applications.
