Cellular Respiration Harvesting Chemical Energy

1
(No Transcript)
2
Cellular RespirationHarvesting Chemical Energy
ATP
3
Burn fuels to make energy
combustion making heat energy by burning fuels in
one step
aerobic respiration making ATP energy ( some
heat) by burning fuels in many small steps
ATP CO2 H2O ( heat)
4
Energy needs of life

• All organisms need energy.
• What do we need energy for?
• synthesis (building for growth)
• reproduction
• active transport
• movement
• temperature control (making heat)

5
Where do we get energy?

• Energy is stored in organic molecules
• carbohydrates, fats, proteins
• Animals eat these organic molecules ? food
• digest food to get
• fuels for energy (ATP)
• raw materials for building more molecules
• carbohydrates, fats, proteins, nucleic acids

ATP
6
What is energy in biology?
ATP
Adenosine TriPhosphate
Whoa! HOT stuff!
7
Harvesting energy stored in food

• Cellular respiration
• breaking down food to produce ATP
• in mitochondria
• using oxygen
• aerobic respiration
• usually digesting glucose
• but could be other sugars, fats, or proteins

8
Using ATP to do work?
ATP

• Cant store ATP
• too unstable
• only used in cell that produces it
• only short term energy storage

work
Adenosine TriPhosphate
Adenosine DiPhosphate
ADP
A working muscle recycles over 10 million ATPs
per second
Whoa! Pass me theglucose oxygen!
9
Mitochondria Structure

• Double membrane bound organelle
• Contains its own DNA (different from nucleus
  DNA)
• Matrix jelly-like fluid
• Cristae folds of membrane within the
  mitochondria

10
Mitochondria are everywhere!!
animal cells
plant cells
11
Steps of Cellular Respiration

• 1. Glycolysis (Anaerobic does not require
  oxygen)
• 2. Krebs Cycle (Aerobic- requires oxygen)
• 3. Electron Transport Chain (Aerobic)

12
(No Transcript)
13
Which of the following is a product of cell
respiration?

1. ATP
2. Glucose
3. Oxygen
4. NADPH

14
Cell Respiration takes place in the

1. Chloroplast
2. Nucleus
3. Mitochondria
4. Rough ER

15
Which of the following processes requires oxygen?

1. Photosynthesis
2. Aerobic Respiration
3. Anaerobic Respiration
4. Glycolysis

16
Which of the following is NOT a stage of cell
respiration?

1. Krebs Cycle
2. Calvin Cycle
3. Glycolysis
4. Electron Transport

17
The first step of cellular respiration is

1. Glycolysis
2. Kreb Cycle
3. Calvin Cycle
4. Electron Transport Chain

18
Plants conduct which of the following processes?

1. Glycolysis
2. Photosynthesis only
3. Respiration only
4. Both Photosynthesis and respiration

19
Glycolysis takes place in the

1. Mitochondrial matrix
2. cytoplasm
3. Cell membrane
4. Cristae of mitochondria

20
Which of the following steps of cellular
respiration does not require oxygen?

1. ETC
2. Krebs Cycle
3. Glycolysis

21
NAD and FAD
NAD
22
Electron Carrier Molecules
NAD can be energized to make NADH FAD2
can be energized to make FADH2
23
Step 1 Glycolysis

• Takes place in cytoplasm
• Anaerobic process- no oxygen required
• Splits glucose into two 3-carbon molecules called
  pyruvate
• REACTANTS (IN) 2 ATP, 2 NAD, and 4 ADP
• PRODUCTS 2 ADP, 2 NADH, 4 ATP
• Net gain 2 NADH and 2 ATP

24
Step 2 Krebs Cycle (Citric Acid Cycle)

• Takes place in matrix of mitochondria
• Aerobic Process - Uses oxygen
• Electron carriers NADH and FADH2 are produced
  from NAD and FAD
• NADH and FADH2 are go to the Electron Transport
  Chain to be used to make more ATP
• Carbon Dioxide is released
• 2 ATP are produced

25
Step 3 Electron Transport Chain

• Takes place in cristae of mitochondria
• Aerobic process uses oxygen
• Uses the NADH produced in Glycolysis the Krebs
  Cycle
• Uses the FADH2 produced in the Krebs Cycle
• Produces 34 ATP!!!!
• Water is released

26
What if oxygen is missing?

• No oxygen available cant complete aerobic
  respiration
• Anaerobic respiration
• also known as fermentation
• alcohol fermentation
• lactic acid fermentation
• no oxygen or no mitochondria (bacteria and
• yeast)
• can only make very little ATP
• large animals cannot survive

yeast
bacteria
27
Anaerobic Respiration

• Fermentation
• alcohol fermentation
• Yeast (a unicellular fungus that
• Eats glucose and releases CO2
• and alcohol)
• glucose ? ATP CO2 alcohol
• make beer, wine, bread
• lactic acid fermentation
• bacteria, animals
• glucose ? ATP lactic acid
• bacteria make yogurt
• animals feel muscle fatigue

28
Got the energy Ask Questions!!
29

• 2KClO3(l) ? 2KCl(s) 3O2(g)
• C12H22O11(s) 12O2(g) ? 12CO2(g) 11H2O(l)
  heat
