Title: Nuclear PoweR


1
Nuclear PoweR
The discovery of nuclear reactions need not
bring about the destruction of mankind any more
than the discovery of matches -Albert
Einstein
2
I. Using Nuclear Reactions to Generate Power
  • A. Nuclear Fission the splitting of a nucleus
    into smaller fragments (the splitting is caused
    by bombarding the nucleus with neutrons). This
    process releases enormous amounts of energy.

A nuclear chain reaction is a reaction in which
the material that starts the reaction (neutron)
is also one of the products and can be used to
start another reaction.
3
  • B. Nuclear Reactors use controlled fission
    chain reactions to produce energy.

4
I. Using Nuclear Reactions to Generate Power
  • C. A radioisotope is a radioactive isotope
    (remember different number of neutrons).
    Uranium-235 is the radioisotope used in nuclear
    reactors to produce energy.
  • D. Nuclear fission produces much more energy than
    coal or natural gas. 2.2 pounds of uranium
    produces the same amount of heat energy as 16
    tons of coal.

5
I. Using Nuclear Reactions to Generate Power
  • E. A nuclear reactor is just a complex device
    used to boil water, generate steam, and use that
    steam to turn a turbine.
  • F. Four critical components to any nuclear
    reactor are shielding, fuel, control rods, and
    coolant.

6
I. Using Nuclear Reactions to Generate Power
  • 1) shielding radiation absorbing material that
    is used to decrease exposure to radiation.

7
I. Using Nuclear Reactions to Generate Power
  • 2) fuel uranium is most often used

8
I. Using Nuclear Reactions to Generate Power
  • 3) control rods neutron absorbing rods that
    help control the reaction by limiting the number
    of free neutrons

9
I. Using Nuclear Reactions to Generate Power
  • 4) coolant water acts as a coolant and
    transports heat between the reaction and the
    steam turbines to produce electric current

10
(No Transcript)
11
  • G. A light water reactor is the type of reactor
    used most in the world (85 worldwide, 100 in
    the U.S.).
  • H. Light-water reactors are very inefficient,
    losing about 83 of the energy in their nuclear
    fuel as waste heat to the environment. Nuclear
    reactors cause huge amounts of thermal pollution
    in the lake or river with which they are
    associated.

12
Coal vs. Nuclear
Coal Nuclear
Ample Supply Ample supply of uranium
High net energy yield Low net energy yield
Very high air pollution No air pollution
High carbon dioxide emissions No carbon dioxide emissions
High land disruption from surface mining Much lower land disruption from surface mining
High land use Moderate land use
Low cost (with huge subsidies) High cost (even with huge subsidies)
Long term waste storage issues
13
II. Radioactive Waste
  • A. Radioactive waste is the huge long-term
    problem with nuclear reactors.
  • B. There are two types of radioactive wastes,
    low-level and high-level wastes.
  • C. Low-level wastes contains low levels of
    radiation, and remains dangerous for a relatively
    short period (has a half-life of a few hundred
    years or less).

14
II. Radioactive Waste
  • D. Low level wastes includes most medical and
    university research.
  • E. Low level waste can be stored on-site, for a
    few hundred years at most, and just needs to be
    stored in barrels, with shielding not required.

15
F. Applications that Produce Low-Level Waste
  • Carbon-14 dating
  • Used to determine the age of historical artifacts
  • 2) Radioactive Tracers
  • In medicine
  • absorbed by specific organs and used to diagnose
    disease (Iodine-131)

16
  • 3. Nuclear Medicine
  • Radiation Treatment
  • larger doses are used to kill cancerous cells
    in targeted organs
  • internal or external radiation source,
  • usually Cobalt-60

17
II. Radioactive Waste
  • G. High level nuclear waste is produced from
    spent nuclear fuel and wastes from producing
    nuclear weapons.
  • H. High-level waste has high levels of
    radioactivity, is hard to store, and has very
    long half-lives (thousands to millions of years).

18
II. Radioactive Waste
  • I. High-level nuclear waste often stays on-site
    until it can be shipped to a permanent repository
    (if one is available). Storage must be stable for
    thousands of years, and waste must be stored in
    specially shielded containers (casks) or in water
    pools.

19
III. Half-life
  1. Knowing how to calculate half-life is very
    important in determining how long things will
    stay radioactive, and how long materials need to
    be safely stored.
  2. Half-life means the amount of time it takes half
    of the original material to decay to a stable,
    non-radioactive form.

20
C. Half-Life Equations
  • Fraction remaining 1/2n
  • n number of half-lives elapsed
  • Amount remaining (g)
  • Original amount x 1/2n
  • Nt No x (1/2)n

21
(No Transcript)
22
IV. Storing Nuclear Waste
  • A. Containment on-site storage and off-site
    disposal (Remember that every radioactive
    substance has a half-life, some only a few
    months, others hundreds of thousands of years.)
  • 1) On-Site Storage most common nuclear waste
    is spent fuel rods from nuclear power plants
  • -water pools
  • -dry casks (concrete or steel)
  • 2) Off-Site Disposal disposal of nuclear waste
    is done with the intention of never retrieving
    the materials.
  • -77 disposal sites around the United States
  • -new site near Las Vegas, Nevada Yucca Mountain

23
IV. Storing Nuclear Waste
  • C. Any long term storage site needs to be very
    geologically stable, and sites are evaluated for
    the following
  • Volcanic activity
  • Earthquake activity
  • Characterization of groundwater flow
  • Estimation of changes in storage environment over
    long periods of time
  • Depth of at least 2,000 ft underground
  • Away from major cities/population centers

24
IV. Storing Nuclear Waste
  • D. All High-level nuclear waste must be stored
    for a minimum of 10,000 years, and up to 240,000
    years before it decays to stable radioactive
    levels.
  • E. Most scientists and engineers agree that deep
    burial is the safest and cheapest way to store
    high-level nuclear waste.

25
IV. Storing Nuclear Waste
  • F. Yucca Mountain 160 miles northwest of Las
    Vegas. Process to evaluate and open a long-term
    storage facility began in 1985, may start
    accepting waste by 2017. Controversial due to
    concerns about flooding and moving waste to be
    stored there.
  • G. WIPP near Carlsbad, NM. Storage facility in
    salt band 2,150 feet underground. Opened in 1999
    for long-term storage of nuclear weapons waste.

26
IV. Storing Nuclear Waste
  • H. Some other suggestions for long term nuclear
    storage include paying to ship to other
    countries, permanently entombing old reactors in
    layers of steel and concrete, storing under the
    deep ocean, storing under large ice sheets
    (Antarctic, Greenland), shipping off on a rocket
    to space, or storing on the moon. As of yet,
    none of these have been deemed acceptable in
    terms of risk and ethics.

27
V. Effects of Radiation
  • A. Radiation is so harmful for living tissue
    because it can cause DNA damage and mutation,
    cell/tissue damage, and cell death.
  • B. Radiation at high enough doses is lethal, and
    at low doses can cause any of the following
    problems

28
V. Effects of Radiation
  • - Cancer/tumors
  • Brain damage
  • Eye damage or cataracts
  • GI damage from nausea and vomiting
  • Damage and birth defects to fetuses
  • Burns
  • Damage to bone marrow
  • Impairment of the immune system

29
VI. Nuclear Disasters
  • A. The worst nuclear accident in U.S. history
    took place at Three Mile Island nuclear power
    plant in 1979. A valve malfunctioned and human
    errors led to a partial core meltdown. High
    levels of radiation were released into a
    containment structure, but only a small amount of
    radiation was released into the environment.

30
VI. Nuclear Disasters
  • B. Although radiation release was small, the
    state of Pennsylvania was unprepared to deal with
    a nuclear problem, and the evacuation and
    aftermath was poorly organized and led to a huge
    public mistrust in nuclear power in the U.S.

31
VI. Nuclear Disasters
  • C. Chernobyl, in 1986, was the worlds worst
    nuclear disaster. An explosion blew the top off a
    containment building, a reactor melted down, and
    a fire burned for 10 days, releasing more than
    100 times the radiation released by the atomic
    bombs dropped by the U.S. in WWII.
  • D. A poor reactor design, combined with human
    error, caused the explosion.

32
VI. Nuclear Disasters
  • E. In 2008, after 22 years, areas of the Ukraine
    and Europe are still dangerously contaminated
    with radioactive materials as a result of
    Chernobyl.
  • F. Eventual death estimates range from 9,000 to
    212,000 from the accident, and in contaminated
    areas rates of birth defects, thyroid cancer,
    leukemia, and immune system abnormalities are
    very common.

33
VI. Nuclear Disasters
  • G. Japan has come close to having a
    Chernobyl-type disaster. It is an
    earthquake-prone country that gets 39 of its
    power from nuclear reactors. In 2007 a huge
    earthquake caused severe damage to the worlds
    largest nuclear reactor.

34
