Artificial Intelligence Informed search and exploration

1
Artificial IntelligenceInformed search and
exploration

• Fall 2008
• professor Luigi Ceccaroni

2
Heuristic search

• Heuristic function, h(n) it estimates the
  lowest cost from the n state to a goal state.
• At each moment, most promising states are
  selected.
• Finding a solution (if it exist) is not
  guaranteed.
• Types of heuristic search
• BB (Branch Bound), Best-first search
• A, A
• IDA
• Local search
• hill climbing
• simulated annealing
• genetic algorithms

2
3
Branch Bound

• For each state, the cost is kept of getting from
  the initial state to that state (g).
• The global, minimum cost is kept, too, and guides
  the search.
• A branch is abandoned if its cost is greater than
  the current minimum.

3
4
Best-first search

• Priority is given by the heuristic function
  (estimation of the cost from a given state to a
  solution).
• At each iteration the node with minimum heuristic
  function is chosen.
• The optimal solution is not guaranteed.

5
Greedy best-first search
6
Importance of the estimator
Operations - put a free block on the table
- put a free block on another free block
Estimator H1 - add 1 for each block which
is on the right block - subtract 1
otherwise
Initial state H1 4 H2 -28
Estimator H2 - for each block, if the
underlying structure is correct, add 1 for each
block of that structure - otherwise,
subtract 1 for each block of the structure
Final state H1 8 H2 28 ( 7654321)
7
Initial state H1 4 H2 -28
H1 ? H2 ?
H1 ? H2 ?
H1 ? H2 ?
8
Initial state H1 4 H2 -28
H1 6 H2 -21
H1 4 H2 -15
H1 4 H2 -16
9
Heuristic functions
Initial state
Possible heuristic functions h(n) w(n)
misplaced h(n) p(n) sum of distances to
the final position h(n) p(n) 3 s(n) where
s(n) is obtained cycling over non-central
positions and adding 2 if a tile is not followed
by the right one and adding 1 if there is a tile
in the center
2 8 3 1 6 4 7
5
1 2 3 8 4 7
6 5
Final state
10
A and A algorithms
A
A
11
A algorithm
12
A algorithm

• The priority is given by the estimation function
  f(n)g(n)h(n).
• At each iteration, the best estimated path is
  chosen (the first element in the queue).
• A is an instance of best-first search
  algorithms.
• A is complete when the branching factor is
  finished and each operator has a constant,
  positive cost.

13
A treatment of repeated states

• If the repeated state is in the structure of open
  nodes
• If its new cost (g) is lower, the new cost is
  used possibly changing its position in the
  structure of open nodes.
• If its new cost (g) is equal or greater, the node
  is forgotten.
• If the repeated state is in the structure of
  closed nodes
• If its new cost (g) is lower, the node is
  reopened and inserted in the structure of open
  nodes with the new cost. Nothing is done with its
  successors they will be reopened if necessary.
• If its new cost (g) is equal or greater, the node
  is forgotten.

13
14
Example Romania with step costs in km
15
A search example
16
A search example
17
A search example
18
A search example
19
A search example
20
A search example
21
A admissibility

• The A algorithm, depending on the heuristic
  function, finds or not an optimal solution.
• If the heuristic function is admissible, the
  optimization is granted.
• A heuristic function is admissible if it
  satisfies the following property
• ?n 0 h(n) h(n)
• h(n) has to be an optimistic estimator it never
  has to overestimate h(n).
• Using an admissible heuristic function guarantees
  that a node on the optimal path never seems too
  bad and that it is considered at some point in
  time.

22
Example no admissibility

• h3
• /\
• / \
• h2 h4
• h1 h1
• h1 goal
• h1
• goal

23
Optimality of A

• A expands nodes in order of increasing f value.
• Gradually adds "f-contours" of nodes.
• Contour i has all nodes with ffi, where fi lt
  fi1.

24
A1, A2 admissible ? n?final 0 h2(n) lt
h1(n) h(n) ? A1 more informed than A2
25
(No Transcript)
26
More informed algorithms

• Compromise between
• Calculation time in h
• h1(n) could require more calculation time than
  h2(n) !
• Re-expansions
• A1 may re-expand more nodes than A2 !
• Not if A1 is consistent
• Not if trees (instead of graphs) are considered
• Loss of admissibility
• Working with non admissible heuristic functions
  can be interesting to gain speed.

27
1
3
2
1
3
2
4
8
4
8
5
6
7
5
6
7
28
(No Transcript)
29

1
3
A3 no admissible
2
4
8
5
6
7
30
Memory bounded search

• The A algorithm solves problems in which it is
  necessary to find the best solution.
• Its cost in space and time, in average and if the
  heuristic function is adequate, is better than
  that of blind-search algorithms.
• There exist problems in which the size of the
  search space does not allow a solution with A.
• There exist algorithms which allow to solve
  problems limiting the memory used
• Iterative deepening A (IDA)
• Recursive best-first
• Simplified memory-bounded A (SMA)

31
Iterative deepening A (IDA)

• Iterative deepening A is similar to the
  iterative deepening (ID) technique.
• In ID the limit is given by a maximum depth.
• In IDA the limit is given by a maximum value of
  the f-cost.
• Important The search is a standard depth-first
  the f-cost is used only to limit the expansion.
• Starting limit f (initial)

(deepening expansion limit)
02
11
12
21
21
31
31
40
41
goal
50
goal
32
Iterative deepening A (IDA)

• Iterative deepening A is similar to the
  iterative deepening (ID) technique.
• In ID the limit is given by a maximum depth.
• In IDA the limit is given by a maximum value of
  the f-cost.
• Important The search is a standard depth-first
  the f-cost is used only to limit the expansion.
• Starting limit f (initial)

(deepening expansion limit)
(1,3,8)
02
11
(2,4,9) (5,10) (11)
(6,12) (7,13) (14) (15)
12
21
21
31
31
40
41
goal
50
goal
33
IDA algorithm
34
IDA algorithm
Algorithm IDA depthf(Initial_state) While
not is_final?(Current) do Open_states.insert(I
nitial_state) Current Open_states.first()
While not is_final?(Current) and not
Open_states.empty?() do Open_states.delete_
first() Closed_states.insert(Current)
Successors generate_successors(Current,
depth) Successors process_repeated(Success
ors, Closed_states, Open_states)
Open_states.insert(Successors) Current
Open_states.first() eWhile depthdepth1
Open_states.initialize() eWhile eAlgorithm

• The function generate_successors only generate
  those with an f-cost less or equal to the cutoff
  limit of the iteration.
• The OPEN structure is a stack (depth-first
  search).
• If repeated nodes are processed there is no
  space saving.
• Only the current path (tree branch) is saved in
  memory.

35
Other memory-bounded algorithms

• IDAs re-expansions can represent a high
  temporal cost.
• There are algorithms which, in general, expand
  less nodes.
• Their functioning is based on eliminating less
  promising nodes and saving information which
  allows to re-expand them (in necessary).
• Examples
• Recursive best-first
• Memory bound A (MA)

35
36
Recursive best-first

• It is a recursive implementation of best-first,
  with lineal spatial cost.
• It forgets a branch when its cost is more than
  the best alternative.
• The cost of the forgotten branch is stored in the
  parent node as its new cost.
• The forgotten branch is re-expanded if its cost
  becomes the best one again.

36
37
Recursive best-first example
38
Recursive best-first example
39
Recursive best-first

• In general, it expands less nodes than IDA.
• Not being able to control repeated states, its
  cost in time can be high if there are loops.
• Sometimes, memory restrictions can be relaxed.

39
40
Memory bound A (MA)

• It imposes a memory limit number of nodes which
  can be stored.
• A is used for exploration and nodes are stored
  while there is memory space.
• When there is no more space, the worst nodes are
  eliminated, keeping the best cost of forgotten
  descendants.
• The forgotten branches are re-expanded if their
  cost becomes the best one again.
• MA is complete if the solution path fits in
  memory.

40
41
Local search algorithms and optimization problems

• In local search (LS), from a (generally random)
  initial configuration, via iterative improvements
  (by operators application), a state is reached
  from which no better state can be attained.
• LS algorithms (or meta-heuristics or local
  optimization methods) are prone to find local
  optima, which are not the best possible solution.
  The global optimum is generally impossible to be
  reached in limited time.
• In LS, there is a function to evaluate the
  quality of the states, but this is not
  necessarily related to a cost.

42
Local search algorithms
43
Local search algorithms

• These algorithms do not systematically explore
  all the state space.
• The heuristic (or evaluation) function is used to
  reduce the search space (not considering states
  which are not worth being explored).
• Algorithms do not usually keep track of the path
  traveled. The memory cost is minimal.
• This total lack of memory can be a problem (i.e.,
  cycles).

44
Hill-climbing search

• Standard hill-climbing search algorithm
• It is a simple loop which search for and select
  any operation that improves the current state.
• Steepest-ascent hill climbing or gradient search
• The best move (not just any one) that improves
  the current state is selected.

45
Steepest-ascent hill-climbing algorithm
46
Steepest-ascent hill-climbing algorithm
Algorithm Hill Climbing Current Initial_state
end false While end do Children
generate_successors(Current) Children
order_and_eliminate_worse_ones(Children,
Current) if empty?(Children) then Current
Select_best(Children) else endtrue
eWhile eAlgorithm
47
Hill climbing

• Children are considered only if their evaluation
  function is better than the one of the parent
  (reduction of the search space).
• A stack could be used to save children which are
  better than the parent, to be able to backtrack
  but in general the cost of this is prohibitive.
• The characteristics of the heuristic function
  determine the success and the rapidity of the
  search.
• It is possible that the algorithm does not find
  the best solution
• Local optima no successor has a better
  evaluation
• Plateaux all successors has the same evaluation

48
Simulated annealing

• It is a stochastic hill-climbing algorithm
  (stochastic local search, SLS)
• A successor is selected among all possible
  successors according to a probability
  distribution.
• The successor can be worse than the current
  state.
• Random steps are taken in the state space.
• It is inspired by the physical process of
  controlled cooling (crystallization, metal
  annealing)
• A metal is heated up to a high temperature and
  then is progressively cooled in a controlled way.
• If the cooling is adequate, the minimum-energy
  structure (a global minimum) is obtained.

49
Simulated annealing

• Aim to avoid local optima, which represent a
  problem in hill climbing.

50
Simulated annealing

• Solution to take, occasionally, steps in a
  different direction from the one in which the
  increase (or decrease) of energy is maximum.

51
Simulated annealing methodology

• Terminology from the physical problem is often
  used.
• Temperature (T) is a control parameter.
• Energy (f or E) is a heuristic function about the
  quality of a state.
• A function F decides about the selection of a
  successor state and depends on T and the
  difference between the quality of the nodes (?f
  ) the lower the temperature, the lower the
  probability of selecting worse successors.
• The cooling strategy determines
• maximum number of iterations in the search
  process
• temperature-decrease steps
• number of iterations for each step

52
Simulated annealing - Basic algorithm
53
Simulated annealing - Basic algorithm

• An initial temperature is defined.
• While the temperature is not zero do
• / Random moves in the state space /
• For a predefined number of iterations do
• LnewGenerate_successor(Lcurrent)
• if F(f(Lactual)- f(Lnew),T) gt 0 then
  LactualLnew
• eFor
• The temperature is decreased.
• eWhile

54
Simulated annealing
55
Simulated annealing

• Main idea Steps taken in random directions do
  not decrease (but actually increase) the ability
  of finding a global optimum.
• Disadvantage The very structure of the algorithm
  increases the execution time.
• Advantage The random steps possibly allow to
  avoid small hills.
• Temperature It determines (through a probability
  function) the amplitude of the steps, long at the
  beginning, and then shorter and shorter.
• Annealing When the amplitude of the random step
  is sufficiently small not to allow to descend the
  hill under consideration, the result of the
  algorithm is said to be annealed.

56
Simulated annealing

• It is possible to demonstrate that, if the
  temperature of the algorithm is reduced very
  slowly, a global maximum will be found with a
  probability close to 1
• Value of the energy function (E) in the global
  maximum m
• Value of E in the best local maximum l lt m
• There will be some temperature t high enough to
  allow to descend from the local maximum, but not
  from the global maximum.
• If the temperature is reduced very slowly, the
  algorithm will work enough time with a
  temperature close to t, until it finds and ascend
  the global maximum and the solution will stay
  there because there wont be available steps long
  enough to descend from it.

57
Simulated annealing

• Conclusion During the resolution of a search
  problem, a node should occasionally be explored,
  which appears substantially worse than the best
  node in the L list of OPEN nodes.

58
Hill climbing and simulated annealing
applications

• Minimum spanning tree (MST, SST) A
  minimum-weight tree in a weighted graph which
  contains all of the graph's vertices.
• Traveling salesman (TSP) Find a path through a
  weighted graph which starts and ends at the same
  vertex, includes every other vertex exactly once,
  and minimizes the total cost of edges.

59
Simulated annealing applications TSP

• Search space N!
• Operators define transformations between
  solutions inversion, displacement, interchange
• Energy function sum of distances between cities,
  ordered according to the solution.
• An initial temperature is defined. (It may need
  some experimentation.)
• The number of iteration per temperature value is
  defined.
• The way to decrease the temperature is defined.

60
Hill climbing and simulated annealing
applications

• Euclidean Steiner tree A tree of minimum
  Euclidean distance connecting a set of points,
  called terminals, in the plane. This tree may
  include points other than the terminals.
• Steiner tree A minimum-weight tree connecting a
  designated set of vertices, called terminals, in
  an undirected, weighted graph or points in a
  space. The tree may include non-terminals, which
  are called Steiner vertices or Steiner points.

61
Hill climbing and simulated annealing
applications

• Bin packing problem Determine how to put the
  most objects in the least number of fixed space
  bins. More formally, find a partition and
  assignment of a set of objects such that a
  constraint is satisfied or an objective function
  is minimized (or maximized). There are many
  variants, such as, 3D, 2D, linear, pack by
  volume, pack by weight, minimize volume, maximize
  value, fixed shape objects.
• Knapsack problem Given items of different values
  and volumes, find the most valuable set of items
  that fit in a knapsack of fixed volume.

62
Simulated annealing conclusions

• It is suitable for problems in which the global
  optimum is surrounded by many local optima.
• It is suitable for problems in which it is
  difficult to find a good heuristic function.
• Determining the values of the parameters can be a
  problem and requires experimentation.

63
Local beam search

• Keeping just one node in memory may be an extreme
  reaction to the problem of memory limits.
• The local beam search keeps track of k nodes
• It starts with k states randomly generated
• At each step all successors of the k states are
  generated.
• It is checked if some state is a goal.
• If not, the k best successors from the complete
  list are selected and the process is repeated.

63
64
Local beam search

• There is a difference between k random executions
  in parallel and in sequence!
• If a state generates various good successors, the
  algorithm quickly abandons unsuccessful searches
  and moves its resources where major progress is
  made.
• It can suffer from a lack of diversity among the
  k states (concentrated in a small region of the
  state space) and become an expensive version of
  hill climbing.

64
65
Stochastic beam search

• It is similar to local beam search.
• Instead of choosing the k best successors, k
  successors are chosen randomly
• The probability of choosing a successor grows
  with its fitness function.
• Analogy with the process of natural selection
  successors (descendants) of a state (organism)
  populate the following generation as a function
  of their value (fitness, health, adaptability).

65
66
Genetic algorithms

• A genetic algorithm (GA) is a variant of
  stochastic beam search, in which two parent
  states are combined.
• Inspired by the process of natural selection
• Living beings adapt to the environment thanks to
  the characteristics inherited from their parents.
• The possibility of survival and reproduction are
  proportional to the goodness of these
  characteristics.
• The combination of good individuals can produce
  better adapted individuals.

66
67
Genetic algorithms

• To solve a problem via GAs requires
• The representation of the states (individuals)
• Each individual is represented as a string over a
  finite alphabet (usually, a string of 0s and 1s)
• A function, which measure the fitness of the
  states
• Operators, which combine states to obtain new
  states
• Cross-over and mutation operators
• The size of the initial population
• GAs start with a set of k states randomly
  generated
• A strategy to combine individuals

67
68
Genetic algorithms representation of individuals

• The coding of individuals defines the size of the
  search space and the kind of operators.
• If the state has to specify the position of n
  queens, each one in a column of n squares,
  nlog2n bits are required (8, in the example).
• The state could be represented also as n digits
  1,n.

68
69
Genetic algorithms fitness function

• A fitness function is calculated for each state.
• It should return higher values for better states.
• In the n-queens problem, the number of
  non-attacking pairs of queens could be used.
• In the case of 4 queens, the fitness function has
  a value of 6 for a solution.

70
Genetic algorithms operators

• The combination of individuals is carried out via
  cross-over operators.
• The basic operator is crossing over one (random)
  point and combining using that point as reference

71
Genetic algorithms operators

• Other possible exchange-operators
• Crossing over 2 points
• Random exchange of bits
• Ad hoc operators
• Mutation operators
• Analogy with gene combination
• Sometimes the information of part of the genes
  randomly changes
• A typical case (in the case of binary strings)
  consists of changing the sign of each bit with
  some (very low) probability.

72
Genetic algorithms combination

• Each iteration of the search is a new generation
  of individuals
• The size of the population is in general constant
  (N).
• To get to the following population, the
  individuals that reproduce have to be chosen
  (intermediate population).

73
Genetic algorithms combination

• Selection of individuals
• Individuals are selected according to their
  fitness function value
• N random tournaments of pairs of individuals,
  choosing the winner of each one
• There will always be individuals represented more
  than once and other individuals not represented
  in the intermediate population

74
Genetic algorithms algorithm

• Steps of the basic GA algorithm
• N individuals from current population are
  selected to form the intermediate population
  (according to some predefined criteria).
• Individuals are paired and for each pair
• The crossover operator is applied with
  probability P_c and two new individuals are
  obtained.
• New individuals are mutated with a probability
  P_m.
• The resulting individuals form the new population.

75
Genetic algorithms algorithm

• The process is iterated until the population
  converges or a specific number of iteration has
  passed.
• The crossover probability influences the
  diversity of the new population.
• The mutation probability is always very low.

76
Genetic algorithms 8-queens problem

• An 8-queens state must specify the positions of 8
  queens, each in a column of 8 squares, and so
  requires 8 x log 8 24 bits.
• Alternatively, the state can be represented as 8
  digits, each in the range from 1 to 8.
• Each state is rated by the evaluation function or
  the fitness function.
• A fitness function should return higher values
  for better states, so, for the 8-queens problem
  the number of non-attacking pairs of queens is
  used (28 for a solution).

2
76
77
Genetic algorithms 8-queens problem

• The initial population in (a)
• is ranked by the fitness function in (b),
• resulting in pairs for mating in (c).
• They produce offspring in (d),
• which are subject to mutation in (e).

77
78
Genetic algorithms

• Like stochastic beam search, GAs combine
• an uphill tendency
• random exploration
• exchange of information among parallel search
  threads
• The primary advantage of GAs comes from the
  crossover operation.
• Yet it can be shown mathematically that, if the
  genetic code is permuted initially in a random
  order, crossover conveys no advantage.

78
79
Genetic algorithms application

• In practice, GAs have had a widespread impact on
  optimization problems, such as
• circuit layout
• scheduling
• At present, it is not clear whether the appeal of
  GAs arises
• from their performance or
• from their aesthetically pleasing origins in the
  theory of evolution.

79
