Chapter 2

1
Chapter 2 Chemistry
2
Why Study Chemistry in Biology?

• Chemical changes in matter are the foundation for
  all life processes
• Living things are composed of the same kinds of
  matter that make up nonliving things

3
Chemical breakdown of human body is

• 65 Oxygen
• 18 Carbon Makes up 96 of living
  things
• 10 Hydrogen
• 3 Nitrogen
• 1.5 Calcium
• .35 Potassium
• .25 Sulfur
• .15 Sodium
• .15 Chlorine
• .05 Magnesium
• .0004 Iron
• .00004 Iodine
• Traces of fluorine, silicon, manganese, zinc,
  copper, aluminum, and arsenic

4
How are these elements all put together to make
up the human body?
2.1 Composition of Matter

• Matter
• anything that occupies space and has
• Mass
• quantity of matter an object has. (Weight is not
  the same downward force of gravity factored in)
• Elements
• pure substances that cannot be broken down
  chemically into simpler kinds of matter.
• 118 elements as of 2006.
• N, C, H, O, P, S are important elements in Biology

5
The Periodic Table of Elements

• Table that lists all known elements and their
  important information
• The elements are organized in a specific way
• Table

6
ALL ELEMENTS ARE ELECTRICALLY NEUTRAL TO START!!!

• Atomic number
• the number of protons in atom ( electrons also)
• Element symbol
• (Carbon)
• Mass number
• of protons of neutrons
• Atomic Mass relative average mass of element
  a decimal

6 C 12
12.01
7
(No Transcript)
8
Element symbols to be familiar with

• Carbon __________
• Hydrogen __________
• Oxygen _________
• Nitrogen __________
• Calcium __________
• Phosphorus __________
• Potassium __________
• Sulfur __________
• Sodium __________
• Chlorine __________
• Magnesium _________
• Iron __________
• Iodine __________
• Fluorine __________
• Silicon __________
• Zinc __________
• Copper __________
• Aluminum __________
• Arsenic __________

9
Atoms

• simplest particles of an element that retain all
  the properties of that element.
• Properties of atoms determine the
• properties of matter they compose

10
Parts of an Atom

• Protons
• Positive electrical charge
• Mass 1AMU
• Location in nucleus
• Neutrons
• No electrical charge
• Mass 1AMU
• Location in nucleus
• 3. Electrons
• Negative electrical charge
• Mass 1/2000 (so it is counted as 0 AMU)
• Location surrounding nucleus

11
  Element Symbol Atomic Number Mass Number Number of Protons Number of Neutrons Number of Electrons Electrons in ourter most orbital
1 Carbon   6 12
2   O         8
3 Magnesium       12 12
4 Sodium   11 23
5   N
6 Chlorine   17 35
7   H         1
8   S 16
9 Iodine   53 127     53
10   Si     14
11   Ca     20
12   P 15 31
13 Iron   26     30
14 Aluminum           13
15   Mn     25
16 Copper   29 64
17 Zinc         35 30
18 Arsenic As
19   K     19
20 Fluorine     19     9
12
Isotopes

• Element that have the same number of protons but
  different number of neutrons
• They vary by their atomic mass and mass number
• For example C-12, C-13, C-14
• The decimal you see on the PT average of the
  relative amounts in nature of the various isotopes

13
Models of the atom

• Bohr model electrons appear to orbit the
  nucleus aka Planetary Model
• Electron cloud model - protons and neutrons
  concentrated in the nucleus and electrons
  occupying various energy levels around the
  nucleus not sure where the electrons are at any
  time

14
How are the electrons arranged in the energy
levels?

• First energy level
• will get a maximum of 2 electrons
• Second energy level 8 electrons
• Third energy level 8 electrons
• Electrons sit in these levels in ONLY this
  order!!!

15
Filling Energy Levels

• Filling rules 2,8,8 electrons
• Orbitals - probability

Yellow nucleus Blue level 1 2 Red level 2
8 Green level 3 8
16
1
2
17
Diagram the following atoms

1. 1H1
2. 12C6 atomic number
3. 14N7
4. 16O8
   mass number
5. 23Na11
6. 35Cl17
7. 39K19
8. 40Ca20

NOTE THESE ARE ISOTOPE DESIGNATIONS
18
Why Do Atoms Combine?

• Atoms will combine chemically to produce
  compounds
• Compounds form due to arrangement of electrons in
  outermost energy level
• VALENCE ELECTRONS
• Atoms are most stable when outer energy level is
  filled
• Chemical bonds are broken, atoms are rearranged,
  and new chemical bonds are formed.
• Chemical Bonds attractive forces holding atoms
  together
• ALL OF THESE CHANGES INVOLVE AN
• EXCHANGE OF ENERGY

19
When atoms combine you get

• Compounds are
• Pure substances made up of atoms of 2 or more
  different elements
• i.e. Water, Glucose, Salt
• can be ionic or covalent
• Molecules are
• Pure substances made up of atoms of 2 or more
  similar elements, i.e. O2
• - Can only be covalent

20
Atoms in molecules and compounds are arranged in
fixed proportions

• The chemical formula
• 2H2O
• coefficient
• CH4 (Methane)
• 1 C 4 H
• C6H12O6 (Glucose)
• 6 C 12 H 6 O
• (NH4)2SO4 (Ammonium Sulfate)
• 2 N 8H 1S 4 O

subscript
21
Types Of Chemical Bonds, Overview

• https//www.youtube.com/watch?v_M9khs87xQ8

22

• Physical and Chemical properties of compounds
  differ from the elements that make them up.
• i.e. NaCl, H2O
• http//www.bing.com/videos/search?qionicandcova
  lentbondsqsnformQBVRpqionicandcovalentbo
  ndssc8-24sp-1skviewdetailmidFC661AB5D492
  7AD1FDD7FC661AB5D4927AD1FDD7

23
Valence electrons those in the outermost energy
level
24

• 1. Ionic Bonds
• Bonding produced when atoms transfer electrons.
• Not as strong as covalent bonds.
• Produce charged atoms (ions).
• i.e. NaCl

25

• Na has lost an electron (thus the charge)
• Cl has gained an electron (thus the charge)

Na Cl- ----?NaCl
26
2. Covalent Bonds

• Covalent Bonds
• form when 2 atoms share 1 or more electrons
• H2O, CH4, C6H12O6
• Strong bonds
• All organic (have C H) substances

H2O
27
Covalent Bonds

• Covalent bonds are strong bonds due to the
  sharing of electrons.
• In order to break a covalent bond,
• High heat
• Electrical current
• High Pressure
• Enzymes (catalysts produced by living things)

28
Molecule

• simplest part of a substance that retains all of
  the properties of the substance
• only covalent compounds form
• molecules
•
  water

29
Using the model kits, make the following

• H2O
• O2
• CH4
• HCl
• O3
• CO2
• H2
• 8. C2H6
• 9. C2H4
• 10. C2H2
• 11. C3H8
• 12. NH3

• Colors of spheres on board
• Use wooden sticks for single bonds springs for
  double and triple bonds

Draw Structural Diagrams of each
30
2.2 Energy

• Energy Ability to do work or cause change
• All living things need a constant flow of
  energy types???
• 1st Law of Energy Energy is neither created nor
  destroyed but transferred
• Free energy energy in a system that is
  available to do work.
• Body contains glucose to provide free energy
  and stored energy (glycogen and fat). To tap
  into these, you must break these down (digestion)
  into their simplest form (glucose).

31
States of Matter

• Solids, liquids and gases
• Particle movement (greater in gases) higher
  energy
• Shape and volume (fixed in solids)
• Concentration of particles (tighter in a solid)

32
Chemical Reactions
Yields

• CO2 H2O H2CO3 (Carbonic acid)
• Reactants Product

The above reaction occurs in one direction and is
non-reversible. The reaction below occurs in
both directions and is reversible.
CO2 H2O H2CO3 (Carbonic acid)
33
THE WINTER BALL
34
Energy Transfer

• Body continuously goes through series of chemical
  reactions METABOLISM
• Exergonic net release of free energy
• Temperature increases to indicate a release of
  energy

35

• Endergonic net absorption of free energy
• Temperature decreases to indicate an absorption
  of energy

36
Activation Energy

• Amount of energy necessary to begin a
  reaction
• Catalysts Chemicals that lower the amount of
  needed Activation Energy
• Enzymes Organic catalysts (found only in
  living things) help without being changed
• Lactase breaks down the milk sugar
  Lactose

37
Redox Reactions

• INVOLVE Transfer of electrons
• Oxidation reactions Reactants lose one or more
  electrons forming ions
• Reduction reactions Reactants gain one or more
  electrons. Form ions
• Na Cl NaCl-
• Oxidized Reduced
• These reactions always occur together

38
2.3 Water and Solutions

• Most mass of living things is water (Universal
  solvent)
• About 65 of the total mass of our cells is water

• Chemical reactions occur in water
• Must understand chemistry of water

39
DEMO

• Add water to a beaker, about half full
• Into another beaker, add the same amount of
  rubbing alcohol
• Into a third beaker, do the same with cooking oil
• Sprinkle a small amount of salt into each and
  swirl
• Let stand for a moment
• Name the solute and solvent in each beaker.
• Solute Solvent
• Salt Water, Alcohol, cooking oil
• In which beaker did the salt dissolve (go into
  solution)?
• The water and somewhat in alcohol
• Which solution is an aqueous solution (one in
  which the solvent is water)?
• Only the water

40
Solutions

• A mixture of one or more substances uniformly
  distributed in another substance physically
  combined
• Solute substance being dissolved (sugar)
• Solvent substance that does the dissolving
  (water)

41
Solutions, cont.

• Physically but not chemically combined
• Solutions can vary in concentration of solute 5
  sugar solution has 5 sugar and 95 water
• A solution is said to be saturated when the
  solvent can no longer dissolve all the solute
• Aqueous solution solvent is water

42
Concentration
43
What Makes Water Such a Good Solvent?

• The chemical nature of water is called POLARITY

44
The Hydrogen Bondhttp//www.youtube.com/watch?va
H2IbYs_XjY
Occurs between H and O and between H and N
45
Properties of Water(due to its polar nature)

• Cohesion water sticking to itself a barrel of
  monkeys- surface tension
• http//www.youtube.com/watch?vynk4vJa-VaQ
• Adhesion water sticking to another polar
  substance glass slide demo - capillarity
• Thermal regulation high heat capacity,
  evaporative cooling
• Density of ice

46
Acids and Bases

• Acid sour, corrosive - lemons
• Alkaline bitter, smooth - bleach
• Chemical significance???

47

• Ionization or Dissociation
• the production of ions when atoms or molecules
  break apart
• NaCl Na and Cl- ionic
  dissociate
• H20 H OH covalent ionize
• H Hydrogen ion
• OH- Hydroxide ion
• H3O Hydronium ion

48
Dissociation of Salt in Waterhttp//www.youtube.c
om/watch?vCLHP4r0E7hg
49
Production of the Hydronium ion

• Due to the high kinetic energy of the molecules
  of water, there are numerous collisions. Some of
  these collisions are strong enough to dislodge
  protons (H) from a water molecule or from an
  ionized acid molecule such as HCl-.
• Other water molecules will pick up these stray
  protons
• H2O H OH-
• H20 H H3O (Hydronium ion)

50
Acids

• Acid Solution
• of H30 ions outnumbers the OH- ions in a
  solution
• HCl H Cl-
• H H2O H3O Hydronium ion
• Acids are sour and corrosive
• Acid rain - pH of normal rain 5.0 5.6 on pH
  scale
• SO3 H2O H2SO4

51
(No Transcript)
52
(No Transcript)
53
Bases (Alkaline)

• Base Solution
• of OH- ions outnumbers the H ions in a
  solution
• NaOH ---? Na OH-
• Alkaline solutions are bitter
• Feel slippery (OH- ions react with oils of skin
  forming a soap)

54
pH

• Scale from 0 14 to show how acidic or
  alkaline a solution is
• Logarithmic scale (10 fold gt/lt for each step)

55
Activity

• Using universal pH paper, determine the pH of the
  following solutions
• Dip the tip of the pH paper into the solution,
  wait a minute and compare it to the colored scale
  on the vial
• List the pHs of the following solutions
• ammonia
• vinegar
• milk
• black coffee
• baking soda solution
• cola
• milk of magnesia
• lemon juice
• water
• On a blank pH scale, place the solutions in the
  proper spot

56
(No Transcript)
57
Buffers

• Buffers
• Naturally control the pH in living systems
• Neutralize small amounts of acids and bases
• Maintain homeostasis
• Enzymes in body require a particular pH!!!
• Stomach acids and urine acidic
• Blood and intestinal fluids are alkaline
• Neutralization reactions Occurs when acids
  bases react w/each other
• Results in the formation of a salt and water
• NaOH- HCl- NaCl H2O
