INC341 Root Locus

1
INC341Root Locus

• Lecture 7

2
Rectangular vs. polar
s 4 j3
Rectangular form 4 j3 Polar
form magnitude5, angle 37
3
Rectangular form
Add, Subtraction
Polar form
Multiplication
Division
4
b
r
?
a
5
Vector representation of a transfer function
6
Vector s
(sa)
(s7) s 5j2
(sa)
7
Example
Find F(s) at s -3j4
8
What is root locus and why is it needed?

• Fact I poles of closed-loop system are an
  important key to describe a performance of the
  system (transient response, i.e. peak time,
  overshoot, rise time), and stability of the
  system.
• Fact II closed-loop poles are changed when
  varying gain.
• Implication Root locus paths of closed-loop
  poles as gain is varied.

9
Cameraman Object Tracking using infrared
10
Varying gain (K)
Varying K, closed-loop poles are moving!!!
11

• Transient
• Klt25 ? overdamped
• K25 ? critically damped
• Kgt25 ? underdamped
• Settling time remains the same under underdamped
  responses.
• Stability
• Root locus never crosses over into the RHP,
  system is always stable.

12
Concept of Root Locus
13
Closed-loop transfer function
Characteristic equation
magnitude
phase
14

• If there is any point on the root locus, its
  magnitude and phase will be consistant with the
  follows

magnitude
phase

• Note that phase is an odd multiple of 180

15
Example
Is the point -23j a closed-loop pole for some
value of gain? Or is the point on the root locus?
16
-23j is not on the root locus!!! What about
?
17
The angles do add up to 180!!!
is a point on the root locus
What is the corresponding K?
18
Sketching Root Locus

• Number of branches
• Symmetry
• Real-axis segment
• Starting and ending points
• Behavior at infinity

19
1. Number of branches
20
2. Symmetry
21
3. Real-axis segment
On the real axis, the root locus exists to the
left of an odd number of real-axis
22

• Sum of angles on the real axis is either 0 or 180
  (complex poles and zeroes give a zero
  contribution).
• Left hand side of even number of poles/zeros on
  the real axis give 180 (path of root locus)

23
Example
root locus on the real axis
24
4. Starting and ending points
closed-loop transfer function
25
K0 (beginning) poles of T(s) are
K8 (ending) poles of T(s) are
26
Example
27
5. Behavior at infinity
28
Rule of thumb

• of poles of zeroes
• has 3 finite poles at 0 -1 -2, and 3 infinite
  zeroes at infinity

29
Example
Sketch root locus
30
