Chemical Bonding

1
Chemical Bonding

• Chapters 8 and 9

2
Chemical Bonds

• What is a bond?
• A force that holds atoms together
• We will look at it in terms of energy
• Bond Energy is the NRG required to break a bond
• Why are compounds formed?
• Bonds give the system the lowest NRG

3
Bond Energy is the energy required to break a
bond.

• REMEMBER
• It always takes energy to break a chemical bond.
• AND,
• To form a bond, requires a lowering of energy.

4
Types of Bonds

• Ionic Bonds electrostatic forces that exist
  between ions of opposite charge
• Covalent Bonds sharing of electrons between two
  atoms
• Metallic Bonds found typically in transition
  metals each atom is bonded to several
  neighboring atoms bonding electrons are
  relatively free to move throughout the structure
  of the metal.

5
Ionic Bonding

• An atom with a low ionization energy reacts with
  an atom with high electron affinity.
• Typically a metal with a nonmetal
• The electron transfers atoms.
• The ions each achieve a Noble Gas electron
  configuration low energy state.
• Opposite charges hold ions together.

6
Crystal Lattice

• A repeating and ? crystal lattice results.

NaCl, sodium chloride
7
Ionic Compounds

• Makes a solid crystal.
• Ions align themselves to maximize attractions
  between opposite charges,
• and to minimize repulsion between like ions.
• Chemical formula is actually the empirical
  formula, called the formula unit
• ClNaClNaClNaClNaClNa
• NaClNaClNaClNaClNaCl NaCl
• ClNaClNaClNaClNaClNa

8
Features of Ionic Compounds

• Brittle, hard, crystalline solids at room
  temperature
• High melting points
• Metals bonded to non-metals
• Elements from opposites sides of the Periodic
  Table
• Dissolve in water to form ions
• Conduct an electric current in water

9
Coulombs Law

• Expresses the NRG of interaction between a pair
  of ions.
• E 2.31 x 10-19 J nm (Q1Q2) / r
• E energy of interaction between a pair of ions
  (in Joules)
• r distance (in nm) between ion centers
• Q1 and Q2 charges of the ions
• Opposite charges means (E)
• Endo or Exo? What does that mean about NRG in
  the system?

10
Size of Ions

• Ion size increases down a group.
• Cations are smaller than the atoms they came
  from.
• Anions are larger.
• across a row they get smaller, and then suddenly
  larger.

11
Periodic Trends

• Across the period effective nuclear charge
  increases so they get smaller.
• Energy level changes between anions and cations.

N-3
O-2
F-1
B3
Li1
C4
Be2
12
Size of Isoelectronic ions

• Positive ions have more protons so they are
  smaller.
• A stronger charged nucleus pulls the electrons
  inward.

N-3
O-2
F-1
Ne
Na1
Al3
Mg2
13
Lattice Energy

• The energy release that occurs when separated
  gaseous ions are packed together to form an ionic
  solid
• Xx(g) Y-y(g) ? XyYx (s) energy
• Lattice NRG (Eel) k(Q1Q2)/r
• k constant
• Q1 and Q2 charges of ions
• r distance between ion centers

14
Example

• Which has the most exothermic lattice energy,
  NaCl or KCl?
• NaCl why?
• Since both have the same charges (1 and -1), the
  distance between the charges needs to be
  considered. Since Na is smaller than K, the
  distance between the centers of Na and Cl is less
  and therefore has a greater lattice NRG.

15
Example 2 and 3

• Arrange the following ionic compounds in order of
  increasing lattice energy NaF, CsI, and CaO
• CsI lt NaF lt CaO
• Which substance would you expect to have the
  greatest lattice energy, AgCl, CuO or CrN?
• CrN

16
Covalent Bonds

• Bond is a force which causes a group of atoms to
  behave as a single unit.
• Electrons are shared by atoms.
• Electron orbitals must overlap.

17
The Covalent Bond

• The electrons in each atom are attracted to the
  nucleus of the other.
• The electrons repel each other,
• The nuclei repel each other.
• They reach a distance with the lowest possible
  energy.
• The distance between is the bond length.

18
Energy
0
Internuclear Distance
19
Energy
0
Internuclear Distance
20
Energy
0
Internuclear Distance
21
Energy
0
Internuclear Distance
22
Energy
0
Bond Length
(They reach a distance apart with the lowest
possible energy.)
Internuclear Distance
23
Energy
Bond Energy
0
Internuclear Distance
24
Features of Covalent Compounds (aka Molecular
Compounds)

1. Electrons are shared, (Single, Double or Triple
   Bonds are possible.)

2. Non-metals bonded to Non-metals.
3. Includes all diatomic molecules.
4. Relatively low melting/boiling points.
5. No repeating formula, particle is a single
unit called a molecule.
25
How We Represent Covalent Compounds
1. Molecular Formulas
CH4
2. Structural Formulas
H H - C - H H
Show the bonds between the atoms.
26
Covalent vs. Ionic Bonding

• Covalent is sharing, ionic is stealing.
• Totally different from each other.
• Reality Check There are many compounds which
  exhibit both traits!
• These are called polar covalent bonds.
• The electrons are shared, but shared unequally.

27
Polar Covalent Bonds

• The electrons are shared, but they are not shared
  evenly.
• One atom has the pair more often than the other.
• A polar molecule results One end is slightly
  positive, while the other is slightly negative.
• A partial charge is called a dipole.

28
Example
29
(No Transcript)
30
-

31
-

32
How Do We Know Which Atom Has the Electron Pair
More Often?

• Answer Electronegativity Values
• Electronegativity - The ability of an atom to
  attract shared electrons to itself.
• The more electronegative an atom, the more often
  it has the shared pair.
• Greater electronegativity ? pole

33
Electronegativity

• E.N. values are assigned for almost every element
  (Figure 8.6, p. 285)
• Gives us relative electronegativities of all
  elements.
• Tends to increase left to right and decreases as
  you go down a group.
• Noble gases arent discussed.
• Difference in electronegativity between atoms
  tells us how polar.

34
Helpful Number Line

• Determine the Electronegativity Value difference
  between two atoms

Non-polar covalent
Polar covalent
ionic
0 0.4
2.0 3.4
35
Electronegativity difference
Bond Type
Zero
Covalent
Covalent Character decreases Ionic Character
increases
Intermediate
Large
36
Polar Covalent Bond-How it is drawn
37
Reminder on Writing Formulas and Nomenclature

• Ionic Compounds
• Name the cation then name the anion
• When writing formulas, add subscripts to make
  sure that the charges balance
• Covalent Compounds
• When naming, use prefixes for the subscripts, the
  2nd atom will end in ide
• Write formulas, assign subscripts based on the
  prefixes

38
Lewis Dot Structures are Models to represent both
ionic and covalent

• What is a Model?
• Explains how nature operates.
• Derived from observations.
• It simplifies and categorizes the information.
• A model must be sensible, but it has limitations.

39
Properties of a Model

• A human invention, not a blown up picture of
  nature.
• Models can be wrong, because they are based on
  speculations and oversimplification.
• You must understand the assumptions in the model,
  and look for weaknesses.
• We learn more when the model is wrong than when
  it is right.

40
Lewis Structures

• Show how the valence electrons are arranged.
• One dot for each valence electron.
• A stable compound has all its atoms with a noble
  gas configuration.
• Hydrogen follows the duet rule.
• The rest follow the octet rule.
• Bonding pair is the one between the symbols.

41
Electron Dot Placement
2
6
X
3
5
1
7
4
8
The X represents the symbol for the element.
The dots are placed around the symbol in the
order shown above.
42
Rules

1. Sum the of ALL the valence electrons.
2. Determine the central atom. The least
   electronegative element is central (H never
   central, C nearly always central)
3. Write symbols for the atoms to show which atoms
   are attached and connect them with a single bond
   (a dash)
4. Complete the octets of the atoms attached to the
   central atom (except for H, follows a duet rule).
5. Place any leftover electrons on the central atom.
   Not enough electrons - consider a double or
   triple bond.

43
A useful equation

• ( happy - have ) ? 2 bonds
• (what they want - what they have) ? 2
  bonds

H2O (12 - 8) ? 2 2 bonds
? ? H ? O ? H ? ?
44
Practice Structures

• PCl3
• ICl
• CH4
• CH2Cl2
• HCN
• NO
• CO2
• H2

• NH3
• C2H4
• BrO3-1
• O2
• ClO2-1
• OH-1
• PO4-3

45
Partial Ionic Character

• There are probably no totally ionic bonds between
  individual atoms.

46
75
Ionic Character
50
25
Electronegativity difference
47
How do we deal with it?

• If bonds cant be ionic, what are ionic
  compounds?
• An ionic compound will be defined as any
  substance that conducts electricity when melted.
• Also use the generic term salt.
• As it turns out, most compounds fall somewhere
  between ionic and covalent.

48

• The bond is a human invention.
• It is a method of explaining the energy change
  associated with forming molecules.
• Bonds dont exist in nature, but are useful.

• We have a model of a bond.

H - Cl
49
Exceptions to the octet

• Less than an Octet
• BH3
• Be and B often do not achieve octet, but form
  highly reactive compounds
• More than an Octet
• SF6 and I3-
• Third row and larger elements can exceed the
  octet.
• How? Use 3d orbitals
• Odd Number of Electrons
• NO, NO2, and ClO2

50
Exceptions to the octet

• When we must exceed the octet, extra electrons go
  on central atom.
• ClF3
• XeO3
• ICl4-
• BeCl2

51
Resonance Structures

• When more than one valid Lewis structure can be
  written for a particular molecule.
• Actual structure is an average of the depicted
  resonance structures
• Drawn by writing the variant structures connected
  by a double-headed arrow

52
What to do when more than one Lewis structure
works? Use Formal Charge

• Assign formal charges on atoms to help decide
  which is best.
• Trying to use the oxidation numbers to put
  charges on atoms in molecules doesnt work.
• Molecules try to achieve as low a formal charge
  as possible.
• Negative formal charges should be on the most
  electronegative elements.

53
Formal Charge

• Number of valence electrons on the free atom
  minus number of valence electrons assigned to the
  atom in the molecule
• Lone pair e- belong to atom in question
• Shared e- are divided equally between the sharing
  atoms
• The sum of the formal charges of all atoms in a
  given molecule or ion must equal the overall
  charge on that species
• If the charge on an ion is -2, the sum of the
  formal charges must be -2.

54
Resonance Examples

• NO3-1
• SO3
• HCO2-1

55
Bond Lengths are Averages

• Have made a table of the averages of different
  types of bonds pg. 305
• single bond one pair of electrons is shared.
• double bond two pair of electrons are shared.
• triple bond three pair of electrons are shared.
• More bonds, shorter bond length.

56
How do they share electrons?Localized Electron
Model

• Simple model, easily applied.
• A molecule is composed of atoms that are bound
  together by sharing pairs of electrons using the
  atomic orbitals of the bound atoms.
• Three Parts
• Valence electrons using Lewis structures
• Prediction of geometry using VSEPR
• Description of the types of orbitals

57
VSEPR the 3-D shape

• Lewis structures tell us how the atoms are
  connected to each other.
• They dont tell us anything about shape.
• The shape of a molecule can greatly affect its
  properties.
• Valence Shell Electron Pair Repulsion Theory
  allows us to predict geometry

58
VSEPR

• Molecules take a shape that puts electron pairs
  as far away from each other as possible.
• Have to draw the Lewis structure to determine
  electron pairs.
• count bonding pairs
• count nonbonding (lone) pairs
• Lone pair take up more space.
• Multiple bonds count as one pair.

59
VSEPR

• The number of pairs determines
• bond angles
• underlying structure
• The number of atoms determines
• actual shape

60
VSEPR
61
Actual shape
Non-BondingPairs
ElectronPairs
BondingPairs
Shape
2
2
0
linear
3
3
0
trigonal planar
3
2
1
bent
4
4
0
tetrahedral
4
3
1
trigonal pyramidal
4
2
2
bent
62
Actual Shape
Non-BondingPairs
ElectronPairs
BondingPairs
Shape
5
5
0
trigonal bipyrimidal
5
4
1
See-saw
5
3
2
T-shaped
5
2
3
linear
63
Actual Shape
Non-BondingPairs
ElectronPairs
BondingPairs
Shape
6
6
0
Octahedral
6
5
1
Square Pyramidal
6
4
2
Square Planar
6
3
3
T-shaped
6
2
1
linear
64
How well does it work?

• Does an outstanding job for such a simple model.
• Predictions are almost always accurate.
• Like all simple models, it has exceptions.
• Well spend some time in this class drawing
  structures and making models to better understand
  the different VSEPR models

65
Hybridization

• The mixing of two or more atomic orbitals of
  similar energies on the same atom to produce new
  orbitals of equal energies.
• Creates Hybrid Orbitals
• Methane goes from 2s2 2p2 to 2sp3
• Draw the sub orbitals according to Hunds rule

66
Types of Hybrid Orbitals

• Two orbital sets sp
• Three orbital sets sp2
• Four orbital sets sp3
• Five orbital sets sp3d
• Six orbital sets sp3d2

67
Bond Types

• Sigma Bonds (s)
• Bond in which the electron pair is shared in an
  area centered on a line running between the atoms

• Lobes of bonding orbital point toward each other
• Pi Bonds (p)
• Electron pair above and below the s bond
• Created by overlapping of non-hybridized p
  orbitals

68

• Single bonds consist of one s bond
• Double bonds consist of one s bond and one p bond
• Triple bonds consist of one s bond and 2 p bonds
