Introduction to Informatica PowerCenter

1
Introduction to Informatica PowerCenter
2
Data Warehousing

• Data warehousing is the entire process of data
  extraction, transformation, and loading of data
  to the warehouse and the access of the data by
  end users and applications

3
Data Mart

• A data mart stores data for a limited number of
  subject areas, such as marketing and sales data.
  It is used to support specific applications.
• An independent data mart is created directly from
  source systems.
• A dependent data mart is populated from a data
  warehouse.

4
(No Transcript)
5
Need For ETL Tool

• Data Extraction
• Often performed by COBOL routines (not
  recommended because of high program maintenance
  and no automatically generated meta data)
• Sometimes source data is copied to the target
  database using the replication capabilities of
  standard RDBMS (not recommended because of dirty
  data in the source systems)
• Increasing performed by specialized ETL software

6
Sample ETL Tools

• DataStage from Ascential Software
• SAS System from SAS Institute
• Informatica
• Data Integrator From BO
• Hummingbird Genio Suite from Hummingbird
  Communications
• Oracle Express
• Abinito
• Decision Stream From Cognos
• MS-DTS from Microsoft

7
Components Of Informatica

• Repository Manager
• Designer
• Workflow Manager

8
Informatica provides the following integrated
components

• Informatica repository. The Informatica
  repository is at the center of the Informatica
  suite. You create a set of metadata tables within
  the repository database that the Informatica
  applications and tools access. The Informatica
  Client and Server access the repository to save
  and retrieve metadata.
• Informatica Client. Use the Informatica Client to
  manage users, define sources and targets, build
  mappings and mapplets with the transformation
  logic, and create sessions to run the mapping
  logic. The Informatica Client has three client
  applications Repository Manager, Designer, and
  Workflow Manager.
• Informatica Server. The Informatica Server
  extracts the source data, performs the data
  transformation, and loads the transformed data
  into the targets.

9
Architecture
10
Process Flow

• Informatica Server moves the data from source to
  target based on the workflow and metadata stored
  in the repository.
• A workflow is a set of instructions how and when
  to run the task related to ETL.
• Informatica server runs workflow according to the
  conditional links connecting tasks.
• Session is type of workflow task which describes
  how to move the data between source and target
  using a mapping.
• Mapping is a set of source and target definitions
  linked by transformation objects that define the
  rules for data transformation.

11
Sources

• Power Mart and Power Center access the following
  sources
• Relational. Oracle, Sybase, Informix, IBM DB2,
  Microsoft SQL Server, and Teradata.
• File. Fixed and delimited flat file, COBOL file,
  and XML.
• Extended. If you use Power Center, you can
  purchase additional Power Connect products to
  access business sources such as PeopleSoft, SAP
  R/3, Siebel, and IBM MQSeries.
• Mainframe. If you use Power Center, you can
  purchase Power Connect for IBM DB2 for faster
  access to IBM DB2 on MVS.
• Other. Microsoft Excel and Access.

12
Targets

• Power Mart and Power Center can load data into
  the following targets
• Relational. Oracle, Sybase, Sybase IQ, Informix,
  IBM DB2, Microsoft SQL Server, and Teradata.
• File. Fixed and delimited flat files and XML.
• Extended. If you use Power Center, you can
  purchase an integration server to load data into
  SAP BW. You can also purchase Power Connect for
  IBM MQSeries to load data into IBM MQSeries
  message queues.
• Other. Microsoft Access.
• You can load data into targets using ODBC or
  native drivers, FTP, or external loaders.

13
General Flow of Informatica

• Step 1 Creating Repository ,creating folders
  ,Creating users and assign permission in
  Repository Manager, so as to work in the client
  tools.
• Step 2Connecting to the repository from the
  designer. importing source and target tables ,
  creation of mappings.
• Step 3 Creation of Workflow through workflow
  Manager which has different tasks connected
  between them. In that ,session is the task which
  is pointing to a mapping created in the designer.

14
Repository

• The Informatica repository is a set of tables
  that stores the metadata you create using the
  Informatica Client tools. You create a database
  for the repository, and then use the Repository
  Manager to create the metadata tables in the
  database.
• You add metadata to the repository tables when
  you perform tasks in the Informatica Client
  application such as creating users, analyzing
  sources, developing mappings or mapplets, or
  creating sessions. The Informatica Server reads
  metadata created in the Client application when
  you run a session. The Informatica Server also
  creates metadata such as start and finish times
  of a session or session status.
• Contd -

15
Repository Contd..

• When you use Power Center, you can develop
  global and local repository to share metadata
• Global repository. The global repository is the
  hub of the domain. Use the global repository to
  store common objects that multiple developers can
  use through shortcuts. These objects may include
  operational or application source definitions,
  reusable transformations, mapplets, and mappings.
• Local repositories. A local repository is within
  a domain that is not the global repository. Use
  local repositories for development. From a local
  repository, you can create shortcuts to objects
  in shared folders in the global repository. These
  objects typically include source definitions,
  common dimensions and lookups, and enterprise
  standard transformations. You can also create
  copies of objects in non-shared folders.

16
Repository Architecture

Repository Client
Repository Server
---------------------------- Repository Agent
Repository Database
17
Creating a Repository

• To create Repository
• 1. Launch the Repository Manager by choosing
  Programs-Power Center (or Power Mart)
  Client-Repository Manager from the Start Menu.
• 2. In the Repository Manager, choose
  Repository-Create Repository.
• Note You must be running the Repository
  Manager in Administrator mode to see the Create
  Repository option on the menu. Administrator mode
  is the default when you install the program.
• 3. In the Create Repository dialog box, specify
  the name of the new repository, as well as the
  parameters needed to connect to the repository
  database through ODBC.

18
Working with Repository..

• By default 2 users will be created in the
  repository .
• Database user used to connect to the repository.
• Administrator User.
• By default 2 Groups will be created
• Public
• Administrators.
• These groups and users cannot be deleted from the
  repository . The administrator group has only
  read privilege for other user groups.

19
Working with Repository contd..

• Informatica tools include two basic types of
  security
• Privileges. Repository-wide security that
  controls which task or set of tasks a single user
  or group of users can access. Examples of these
  are Use Designer, Browse repository , Session
  operator etc.
• Permissions. Security assigned to individual
  folders within the repository. You can perform
  various tasks for each privilege.
• Ex - Read , Write and Execute.

20
Folders

• Folders provide a way to organize and store all
  metadata in the repository, including mappings,
  schemas, and sessions. Folders are designed to be
  flexible, to help you organize your data
  warehouse logically. Each folder has a set of
  properties you can configure to define how users
  access the folder. For example, you can create a
  folder that allows all repository users to see
  objects within the folder, but not to edit them.
  Or you can create a folder that allows users to
  share objects within the folder.
• Shared Folders
• When you create a folder, you can configure it
  as a shared folder. Shared folders allow users to
  create shortcuts to objects in the folder. If you
  have reusable transformation that you want to use
  in several mappings or across multiple folders,
  you can place the object in a shared folder.
• For example, you may have a reusable Expression
  transformation that calculates sales commissions.
  You can then use the object in other folders by
  creating a shortcut to the object.

21
Folder Permissions

• Permissions allow repository users to perform
  tasks within a folder. With folder permissions,
  you can control user access to the folder, and
  the tasks you permit them to perform.
• Folder permissions work closely with repository
  privileges. Privileges grant access to specific
  tasks while permissions grant access to specific
  folders with read, write, and execute qualifiers.
• However, any user with the Super User privilege
  can perform all tasks across all folders in the
  repository. Folders have the following types of
  permissions
• Read permission. Allows you to view the folder as
  well as objects in the folder.
• Write permission. Allows you to create or edit
  objects in the folder.
• Execute permission. Allows you to execute or
  schedule a session or batch in the folder.

22
Creating Folders
23
Other Features of Repository Manager

• Viewing , removing Locks
• Adding Repository
• Backup and Recovery of Repository
• Taking Metadata reports like Completed Sessions
  details , List of reports on Jobs , session ,
  workflow etc

24

• Questions/Comments?

25

• Designer

26
Working with Designer

• Connecting to the repository using User id and
  password.
• Accessing the folder
• Importing the source and target tables required
  for mapping.
• Creation of mapping

27
Tools provided by Designer

• Source Analyzer Importing Source definitions for
  Flat file, XML, COBOL and relational Sources.
• Warehouse Designer Use to Import or create
  target definitions.
• Transformation Developer Used to create reusable
  transformations
• Mapplet Designer Used to create mapplets
• Mapping Designer Used to create mappings

28
Importing Sources
29
Import from Database

• Use ODBC connection for importing from database

30
Import from File
31
Creating Targets

• You can create target definitions in the
  Warehouse Designer for file and relational
  sources. Create definitions in the following
  ways
• Import the definition for an existing target.
  Import the target definition from a relational
  target.
• Create a target definition based on a source
  definition. Drag one of the following existing
  source definitions into the Warehouse Designer to
  make a target definition
• Relational source definition
• Flat file source definition
• COBOL source definition
• Manually create a target definition. Create and
  design a target definition in the Warehouse
  Designer.

32
Creating targets
33
Creation of simple mapping
34
Creation of simple mapping

• Switch to the Mapping Designer.
• Choose Mappings-Create.
• While the workspace may appear blank, in fact it
  contains a new mapping without any sources,
  targets, or transformations.
• In the Mapping Name dialog box, enter ltMapping
  Namegt as the name of the new mapping and click
  OK.
• The naming convention for mappings is
  m_MappingName.
• In the Navigator, under the ltRepository Namegt
  repository and ltFolder Namegt folder, click the
  Sources node to view source definitions added to
  the repository.
•
  Contd..

35
Mapping creation Contd..

• Click the icon representing the EMPLOYEES source
  and drag it into the workbook.

36
Mapping creation Contd..

• The source definition appears in the workspace.
  The Designer automatically connects a Source
  Qualifier transformation to the source
  definition. After you add the target definition,
  you connect the Source Qualifier to the target.
• Click the Targets icon in the Navigator to open
  the list of all target definitions.
• Click and drag the icon for the T_EMPLOYEES
  target into the workspace.
• The target definition appears. The final step is
  connecting the Source Qualifier to this target
  definition.

37
Mapping creation Contd..

• To Connect the Source Qualifier to Target
  Definition
• Click once in the middle of the ltColumn Namegt in
  the Source Qualifier. Hold down the mouse button,
  and drag the cursor to the ltColumn Namegt in the
  target. Then release the mouse button. An arrow
  (called a connector) now appears between the row
  columns

38
Transformations
39
Transformations

• A transformation is a repository object that
  generates, modifies, or passes data
• The Designer provides a set of transformations
  that perform specific functions
• Data passes into and out of transformations
  through ports that you connect in a mapping or
  mapplet
• Transformations can be active or passive

40
Transformations

• Active transformations
• Aggregator performs aggregate
  calculations
• Filter serves as a
  conditional filter
• Router serves as a conditional filter (more
  than one filters)
• Joiner allows for
  heterogeneous joins
• Source qualifier represents all data queried
  from the source
• Passive transformations
• Expression performs simple calculations
• Lookup looks up values and passes to other
  objects
• Sequence generator generates unique ID values
• Stored procedure calls a stored procedure and
  captures return values
• Update strategy allows for logic to insert,
  update, delete, or reject data

41
Transformations Contd..

• Create the transformation. Create it in the
  Mapping Designer as part of a mapping, in the
  Mapplet Designer as part of a Mapplet, or in the
  Transformation Developer as a reusable
  transformation.
• Configure the transformation. Each type of
  transformation has a unique set of options that
  you can configure.
• Connect the transformation to other
  transformations and target definitions. Drag one
  port to another to connect them in the mapping or
  Mapplet.

42
Expression Transformation

• You can use the Expression transformations to
  calculate values in a single row before you write
  to the target.
• For example, you might need to adjust employee
  salaries, concatenate first and last names, or
  convert strings to numbers.
• You can use the Expression transformation to
  perform any non-aggregate calculations.
• You can also use the Expression transformation
  to test conditional statements before you output
  the results to target tables or other
  transformations.

43
Expression Transformation

• Calculating Values
• To use the Expression transformation to calculate
  values for a single row, you must include the
  following ports
• Input or input/output ports for each value used
  in the calculation. For example, when
  calculating the total price for an order,
  determined by multiplying the unit price by the
  quantity ordered, the input or input/output
  ports. One port provides the unit price and the
  other provides the quantity ordered.
• Output port for the expression. You enter the
  expression as a configuration option for the
  output port. The return value for the output
  port needs to match the return value of the
  expression.
• Variable Port Variable Port is used like local
  variable inside Expression Transformation , which
  can be used in other calculations

44
Source Qualifier Transformation

• Every mapping includes a Source Qualifier
  transformation, representing all the columns of
  information read from a source and temporarily
  stored by the Informatica Server. In addition,
  you can add transformations such as a calculating
  sum, looking up a value, or generating a unique
  ID that modify information before it reaches the
  target.

45
Source Qualifier Transformation

• When you add a relational or a flat file source
  definition to a mapping, you need to connect it
  to a Source Qualifier transformation.
• The Source Qualifier represents the records that
  the Informatica Server reads when it runs a
  session. You can use the Source Qualifier to
  perform the following tasks
• Join data originating from the same source
  database. You can join two or more tables with
  primary-foreign key relationships by linking the
  sources to one Source Qualifier.
• Filter records when the Informatica Server reads
  source data. If you include a filter condition,
  the Informatica Server adds a WHERE clause to the
  default query.
• Specify an outer join rather than the default
  inner join. If you include a user-defined join,
  the Informatica Server replaces the join
  information specified by the metadata in the SQL
  query.
• Specify sorted ports. If you specify a number for
  sorted ports, the Informatica Server adds an
  ORDER BY clause to the default SQL query.
• Select only distinct values from the source. If
  you choose Select Distinct, the Informatica
  Server adds a SELECT DISTINCT statement to the
  default SQL query.
• Create a custom query to issue a special SELECT
  statement for the Informatica Server to read
  source data. For example, you might use a custom
  query to perform aggregate calculations or
  execute a stored procedure

46
Configuring Source Qualifier Transformation

• To configure a Source Qualifier
• In the Designer, open a mapping.
• Double-click the title bar of the Source
  Qualifier.
• In the Edit Transformations dialog box, click
  Rename, enter a descriptive name for the
  transformation, and click OK. The naming
  convention for Source Qualifier transformations
  is SQ_TransformationName,.
• Click the Properties tab.

47
Configuring Source Qualifier
Option Description
SQL Query Defines a custom query that replaces the default query the Informatica Server uses to read data from sources represented in this Source Qualifier
User-Defined Join Specifies the condition used to join data from multiple sources represented in the same Source Qualifier transformation
Source Filter Specifies the filter condition the Informatica Server applies when querying records.
Number of Sorted Ports Indicates the number of columns used when sorting records queried from relational sources. If you select this option, the Informatica Server adds an ORDER BY to the default query when it reads source records. The ORDER BY includes the number of ports specified, starting from the top of the Source Qualifier. When selected, the database sort order must match the session sort order.
Tracing Level Sets the amount of detail included in the session log when you run a session containing this transformation.
Select Distinct Specifies if you want to select only unique records. The Informatica Server includes a SELECT DISTINCT statement if you choose this option.
48
Joiner Transformation

• While a Source Qualifier transformation can join
  data originating from a common source database,
  the Joiner transformation joins two related
• heterogeneous sources residing in different
  locations or file systems. The combination of
  sources can be varied. You can use the following
  sources
• Two relational tables existing in separate
  databases
• Two flat files in potentially different file
  systems
• Two different ODBC sources
• Two instances of the same XML source
• A relational table and a flat file source
• A relational table and an XML source
• If two relational sources contain keys, then a
  Source Qualifier transformation can easily join
  the sources on those keys. Joiner transformations
  typically combine information from two different
  sources that do not have matching keys, such as
  flat file sources.
• The Joiner transformation allows you to join
  sources that contain binary data.

49
Creating a Joiner Transformation

• To create a Joiner Transformation
• In the Mapping Designer, choose
  Transformation-Create. Select the Joiner
  transformation. Enter a name for the Joiner.
  Click OK. The naming convention for Joiner
  transformations is JNR_TransformationName. Enter
  a description for the transformation. This
  description appears in the Repository Manager,
  making it easier for you or others to understand
  or remember what the transformation does.
• The Designer creates the Joiner transformation.
  Keep in mind that you cannot use a Sequence
  Generator or Update Strategy transformation as a
  source to a Joiner transformation.
• Drag all the desired input/output ports from the
  first source into the Joiner transformation. The
  Designer creates input/output ports for the
  source fields in the Joiner as detail fields by
  default. You can edit this property later.
• Select and drag all the desired input/output
  ports from the second source into the Joiner
  transformation. The Designer configures the
  second set of source fields and master fields by
  default.
• Double-click the title bar of the Joiner
  transformation to open the Edit Transformations
  dialog box.
• Select the Ports tab.
• Click any box in the M column to switch the
  master/detail relationship for the sources.
  Change the master/detail relationship if
  necessary by selecting the master source in the M
  column.

50
Creating a Joiner Transformation

• Select the Condition tab and set the condition.

51
Configuring Joiner transformation
Joiner Setting Description
Case-Sensitive String Comparison If selected, the Informatica Server uses case-sensitive string comparisons when performing joins on string columns.
Cache Directory Specifies the directory used to cache master records and the index to these records. By default, the caches are created in a directory specified by the server variable PMCacheDir. If you override the directory, be sure there is enough disk space on the file system. The directory can be a mapped or mounted drive.
Join Type Specifies the type of join Normal, Master Outer, Detail Outer, or Full Outer.
52
Lookup Transformation

• Used to look up data in a relational table, view,
  synonym or Flat File.
• It compares Lookup transformation port values to
  lookup table column values based on the lookup
  condition.
• Connected Lookups
• Receives input values directly from another
  transformation in the pipeline
• For each input row, the Informatica Server
  queries the lookup table or cache based on the
  lookup ports and the condition in the
  transformation
• Passes return values from the query to the next
  transformation
• Un Connected Lookups
• Receives input values from an expression using
  the
• LKP (LKP.lookup_transformation_name (argument,
  argument, ...)) reference qualifier to call the
  lookup and returns one value.
• With unconnected Lookups, you can pass multiple
  input values into the transformation, but only
  one column of data out of the transformation

53
Lookup Transformation

• You can configure the Lookup transformation to
  perform different types of
• lookups. You can configure the transformation to
  be connected or unconnected, cached or uncached
• Connected or unconnected. Connected and
  unconnected transformations receive input and
  send output in different ways.
• Cached or uncached. Sometimes you can improve
  session performance by caching the lookup table.
  If you cache the lookup table, you can choose to
  use a dynamic or static cache. By default, the
  lookup cache remains static and does not change
  during the session. With a dynamic cache, the
  Informatica Server inserts rows into the cache
  during the session. Informatica recommends that
  you cache the target table as the lookup. This
  enables you to look up values in the target and
  insert them if they do not exist.

54
Diff bet Connected Unconnected Lookup
Connected lookup Unconnected lookup
1) Receives input values directly from  of a the pipe line transformation. Receives input values from the result of LKP expression within other transformation.
2) U can use a dynamic or static cache   U can use a static cache.
3) Cache includes all lookup columns used in the mapping. Cache includes all lookup out put ports.
4) Support user defined default values Does not support user defined default values
55
Diff between Static Dynamic Cache
Static Cache Dynamic Cache
1)  U can not insert or update the cache U can insert rows into the cache as u pass to the target
2) The Informatica Server does not update the cache while it processes the Lookup transformation The Informatica Server dynamically inserts data into the lookup cache and passes data to the target table.
56
Update Strategy Transformation

• When you design your data warehouse, you need to
  decide what type of information to store in
  targets. As part of your target table design, you
  need to determine whether to maintain all the
  historic data or just the most recent changes.
• For example, you might have a target table,
  T_CUSTOMERS, that contains customer data. When a
  customer address changes, you may want to save
  the original address in the table, instead of
  updating that portion of the customer record. In
  this case, you would create a new record
  containing the updated address, and preserve the
  original record with the old customer address.
  This illustrates how you might store historical
  information in a target table. However, if you
  want the T_CUSTOMERS table to be a snapshot of
  current customer data, you would update the
  existing customer record and lose the original
  address.
• The model you choose constitutes your update
  strategy, how to handle changes to existing
  records. In Power Mart and Power Center, you set
  your update strategy at two different levels
• Within a session. When you configure a session,
  you can instruct the Informatica Server to either
  treat all records in the same way (for example,
  treat all records as inserts), or use
  instructions coded into the session mapping to
  flag records for different database operations.
• Within a mapping. Within a mapping, you use the
  Update Strategy transformation to flag records
  for insert, delete, update, or reject.

57
Setting up Update Strategy at Session Level

• During session configuration, you can select a
  single database operation for all records. For
  the Treat Rows As setting, you have the following
  options

Setting Description
Insert Treat all records as inserts. If inserting the record violates a primary or foreign key constraint in the database, the Informatica Server rejects the record.
Delete Treat all records as deletes. For each record, if the Informatica Server finds a corresponding record in the target table (based on the primary key value), the Informatica Server deletes it. Note that the primary key constraint must exist in the target definition in the repository.
Update Treat all records as updates. For each record, the Informatica Server looks for a matching primary key value in the target table. If it exists, the Informatica Server updates the record. Again, the primary key constraint must exist in the target definition.
Data Driven The Informatica Server follows instructions coded into Update Strategy transformations within the session mapping to determine how to flag records for insert, delete, update, or reject. If the mapping for the session contains an Update Strategy transformation, this field is marked Data Driven by default. If you do not choose Data Driven setting, the Informatica Server ignores all Update Strategy transformations in the mapping.
58
Update Strategy Settings setting you choose
depends on your update strategy and the status of
data in target tables
Setting Use To
Insert Populate the target tables for the first time, or maintaining a historical data warehouse. In the latter case, you must set this strategy for the entire data warehouse, not just a select group of target tables.
Delete Clear target tables.
Update Update target tables. You might choose this setting whether your data warehouse contains historical data or a snapshot. Later, when you configure how to update individual target tables, you can determine whether to insert updated records as new records or use the updated information to modify existing records in the target.
Data Driven Exert finer control over how you flag records for insert, delete, update, or reject. Choose this setting if records destined for the same table need to be flagged on occasion for one operation (for example, update), or for a different operation (for example, reject). In addition, this setting provides the only way you can flag records for reject.
