Eliminating Web Software Vulnerabilities with Automated Verification

1
Eliminating Web Software Vulnerabilities with
Automated Verification

• Tevfik Bultan
• Verification Lab
• Department of Computer Science
• University of California, Santa Barbara
• bultan_at_cs.ucsb.edu http//www.cs.ucsb.edu/vl
  ab

2
University of California at Santa Barbara
3
Verification Lab (VLab) at UCSB

• Application of automated verification techniques
  to software
• Automated verification of web applications
• Checking input validation, sanitization, string
  analysis (PHP)
• Checking navigation correctness (MVC farmeworks)
• Checking data models (Ruby on Rails)
• Automated verification of web services
• Modular testing and verification of web services
  (WSDL)
• Formal modeling and analysis of choreography and
  orchestration (WS-CDL, WS-BPEL)
• Automated verification of access control policies
• Policy composition (XACML)
• Automated verification of concurrency
• Analyzing concurrency, deadlock detection (Java)


4
VLab Publications on String Analysis

• Relational String Verification Using Multi-Track
  Automata Yu, Bultan, Ibarra CIAA10
• Stranger An Automata-based String Analysis Tool
  for PHP Yu, Alkhalaf, Bultan TACAS10
• Generating Vulnerability Signatures for String
  Manipulating Programs Using Automata-based
  Forward and Backward Symbolic Analyses Yu,
  Alkhalaf, Bultan ASE09
• Symbolic String Verification Combining String
  Analysis and Size Analysis Yu, Bultan, Ibarra
  TACAS09
• Symbolic String Verification An Automata-based
  Approach Yu, Bultan, Cova, Ibarra SPIN08

5
Web software

• Web software is becoming increasingly dominant
• Web applications are used extensively in many
  areas
• Commerce online banking, online shopping,
• Entertainment online music videos,
• Interaction social networks
• We will rely on web applications more in the
  future
• Health records
• Google Health, Microsoft HealthVault
• Controlling and monitoring of national
  infrastructures
• Google Powermeter
• Web software is also rapidly replacing desktop
  applications
• Could computing software-as-service
• Google Docs, Google

6
One Major Road Block

• Web applications are not trustworthy!
• Web applications are notorious for security
  vulnerabilities
• Their global accessibility makes them a target
  for many malicious users
• As web applications are becoming increasingly
  dominant
• and as their use in safety critical areas is
  increasing
• their trustworthiness is becoming a critical
  issue

7
Web applications are not secure

• There are many well-known security
  vulnerabilities that exist in many web
  applications. Here are some examples
• Malicious file execution where a malicious user
  causes the server to execute malicious code
• SQL injection where a malicious user executes
  SQL commands on the back-end database by
  providing specially formatted input
• Cross site scripting (XSS) causes the attacker
  to execute a malicious script at a users browser
• These vulnerabilities are typically due to
• errors in user input validation or
• lack of user input validation

8
Web Application Vulnerabilities
9
Web Application Vulnerabilities

• The top two vulnerabilities of the Open Web
  Application Security Project (OWASP)s top ten
  list in 2007
• Cross Site Scripting (XSS)
• Injection Flaws (such as SQL Injection)
• The top two vulnerabilities of the OWASPs top ten
  list in 2010
• Injection Flaws (such as SQL Injection)
• Cross Site Scripting (XSS)

10
Why are web applications error prone?

• Extensive string manipulation
• Web applications use extensive string
  manipulation
• To construct html pages, to construct database
  queries in SQL, etc.
• The user input comes in string form and must be
  validated and sanitized before it can be used
• This requires the use of complex string
  manipulation functions such as string-replace
• String manipulation is error prone

11
String Related Vulnerabilities

• String related web application vulnerabilities
  occur when
• a sensitive function is passed a malicious string
  input from the user
• This input contains an attack
• It is not properly sanitized before it reaches
  the sensitive function
• String analysis Discover these vulnerabilities
  automatically

12
XSS Vulnerability

• A PHP Example
• 1lt?php
• 2 www _GETwww
• 3 l_otherinfo URL
• 4 echo lttdgt . l_otherinfo . . www .
  lt/tdgt
• 5?gt
• The echo statement in line 4 is a sensitive
  function
• It contains a Cross Site Scripting (XSS)
  vulnerability

ltscript ...
13
Is it Vulnerable?

• A simple taint analysis, e.g., Huang et al.
  WWW04, can report this segment vulnerable using
  taint propagation
• 1lt?php
• 2 www _GETwww
• 3 l_otherinfo URL
• 4 echo lttdgt . l_otherinfo . .www.
  lt/tdgt
• 5?gt
• echo is tainted ? script is vulnerable

tainted
14
How to Fix it?

• To fix the vulnerability we added a sanitization
  routine at line s
• Taint analysis will assume that www is untainted
  and report that the segment is NOT vulnerable
• 1lt?php
• 2 www _GETwww
• 3 l_otherinfo URL
• s www preg_replace(A-Za-z0-9
  .-_at_//,,www)
• 4 echo lttdgt . l_otherinfo . .www.
  lt/tdgt
• 5?gt

tainted
untainted
15
Is It Really Sanitized?

• 1lt?php
• 2 www _GETwww
• 3 l_otherinfo URL
• s www preg_replace(A-Za-z0-9
  .-_at_//,,www)
• 4 echo lttdgt . l_otherinfo . .www.
  lt/tdgt
• 5?gt

ltscript ...
16
Sanitization Routines can be Erroneous

• The sanitization statement is not correct!
• preg_replace(A-Za-z0-9 .-_at_//,,www)
• Removes all characters that are not in A-Za-z0-9
  .-_at_/
• .-_at_ denotes all characters between . and _at_
  (including lt and gt)
• .-_at_ should have been .\-_at_
• This example is from a buggy sanitization routine
  used in MyEasyMarket-4.1 (line 218 in file
  trans.php)

17
String Analysis

• String analysis determines all possible values
  that a string expression can take during any
  program execution
• Using string analysis we can identify all
  possible input values of the sensitive functions
• Then we can check if inputs of sensitive
  functions can contain attack strings
• How can we characterize attack strings?
• Use regular expressions to specify the attack
  patterns
• Attack pattern for XSS SltscriptS

18
String Analysis

• If string analysis determines that the
  intersection of the attack pattern and possible
  inputs of the sensitive function is empty
• then we can conclude that the program is secure
• If the intersection is not empty, then we can
  again use string analysis to generate a
  vulnerability signature
• characterizes all malicious inputs
• Given SltscriptS as an attack pattern
• The vulnerability signature for _GETwww is

• SltasacaraiapatS
• where a? A-Za-z0-9 .-_at_/

19
Vulnerabilities can be tricky

• Input lt!scrip!t ...gt does not match the attack
  pattern
• but it matches the vulnerability signature
• and it can cause an attack
• 1lt?php
• 2 www lt!scrip!t ...gt
• 3 l otherinfo URL
• s www preg replace(A-Za-z0-9 .-_at_//,,
  lt!scrip!t...gt)
• 4 echo lttdgt . l otherinfo . . ltscript
  ...gt .lt/tdgt
• 5?gt

20
Automata-based String Analysis

• Finite State Automata can be used to characterize
  sets of string values
• We use automata based string analysis
• Associate each string expression in the program
  with an automaton
• The automaton accepts an over approximation of
  all possible values that the string expression
  can take during program execution
• Using this automata representation we
  symbolically execute the program, only paying
  attention to string manipulation operations

21
Symbolic Automata Representation

• We use the MONA DFA Package for automata
  manipulation
• Klarlund and Møller, 2001
• Compact Representation
• The transition relation of the DFA is represented
  as a multi-terminal BDD (MBDD)
• Exploits the MBDD structure in the implementation
  of DFA operations
• Union, Intersection, and Emptiness Checking
• Projection and Minimization
• Cannot Handle Nondeterminism
• We extended the alphabet with dummy bits to
  encode nondeterminism

22
Symbolic Automata Representation
Explicit DFA representation
Symbolic DFA representation
23
String Analysis Stages

• Construct dependency graphs for the PHP programs
• Combine symbolic forward and backward symbolic
  reachability analyses
• Forward analysis
• Assume that the user input can be any string
• Propagate this information on the dependency
  graph
• When a sensitive function is reached, intersect
  with attack pattern
• Backward analysis
• If the intersection is not empty, propagate the
  result backwards to identify which inputs can
  cause an attack

Front End
Forward Analysis
Backward Analysis
PHP Program
Vulnerability Signatures
Attack patterns
24
Dependency Graphs

• Given a PHP program,
• first construct the
• Dependency graph
• 1lt?php
• 2 www GETwww
• 3 l_otherinfo URL
• 4 www preg_replace(
• A-Za-z0-9 .-_at_//,,www
• )
• 5 echo l_otherinfo .
• .www
• 6?gt

_GETwww, 2
A-Za-z0-9 .-_at_//, 4
, 4
www, 2
URL, 3
, 5
l_otherinfo, 3
preg_replace, 4
str_concat, 5
www, 4
str_concat, 5
echo, 5
Dependency Graph
25
Forward Analysis

• Using the dependency graph we conduct
  vulnerability analysis
• Automata-based forward symbolic analysis that
  identifies the possible values of each node
• Each node in the dependency graph is associated
  with a DFA
• DFA accepts an over-approximation of the strings
  values that the string expression represented by
  that node can take at runtime
• The DFAs for the input nodes accept S
• Intersecting the DFA for the sink nodes with the
  DFA for the attack pattern identifies the
  vulnerabilities
• Uses post-image computations of string
  operations
• postConcat(M1, M2)
• returns M, where MM1.M2
• postReplace(M1, M2, M3) (language-based
  replacement)
• returns M, where Mreplace(M1, M2, M3)

26
Forward Analysis
Forward S
Attack Pattern SltS
_GETwww, 2
, 4
A-Za-z0-9 .-_at_//, 4
www, 2
URL, 3
Forward e
Forward S
Forward A-Za-z0-9 .-_at_/
Forward URL
, 5
preg_replace, 4
l_otherinfo, 3
Forward
Forward A-Za-z0-9 .-_at_/
Forward URL
str_concat, 5
www, 4
Forward URL
Forward A-Za-z0-9 .-_at_/
str_concat, 5
Forward URL A-Za-z0-9 .-_at_/
echo, 5
n
L(SltS)
L(URL A-Za-z0-9 .-_at_/)
Forward URL A-Za-z0-9 .-_at_/
L(URL A-Za-z0-9 .--_at_/ltA-Za-z0-9 .-_at_/)
? Ø
27
Intersection Result Automaton
U
R
L

A-Za-z0-9 .--_at_/
A-Za-z0-9 .-_at_/
Space
lt
URL A-Za-z0-9 .--_at_/ltA-Za-z0-9 .-_at_/
28
Widening

• String verification problem is undecidable in
  general
• Two string variables, equality checks and
  concatenation is enough to get to undecidability
• The forward fixpoint computation is not
  guaranteed to converge in the presence of loops
  and recursion
• We compute a sound approximation
• During fixpoint we compute an over approximation
  of the least fixpoint that corresponds to the
  reachable states
• We use an automata based widening operation to
  over-approximate the fixpoint
• Widening operation over-approximates the union
  operation and accelerates the convergence of the
  fixpoint computation

29
Backward Analysis

• A vulnerability signature is a characterization
  of all malicious inputs that can be used to
  generate attack strings
• We identify vulnerability signatures using an
  automata-based backward symbolic analysis
  starting from the sink node
• Uses pre-image computations on string operations
• preConcatPrefix(M, M2)
• returns M1 and where M M1.M2
• preConcatSuffix(M, M1)
• returns M2, where M M1.M2
• preReplace(M, M1, M2)
• returns M3, where Mreplace(M1, M2, M3)

30
Backward Analysis
Forward S
Backward ltltS
_GETwww, 2
node 3
node 6
A-Za-z0-9 .-_at_//, 4
, 4
www, 2
URL, 3
Forward e
Forward A-Za-z0-9 .-_at_/
Forward S
Forward URL
Backward Do not care
Backward Do not care
Backward ltltS
Backward Do not care
preg_replace, 4
, 5
Vulnerability Signature ltltS
l_otherinfo, 3
Forward
Forward A-Za-z0-9 .-_at_/
Forward URL
Backward Do not care
Backward A-Za-z0-9 .--_at_/ltA-Za-z0-9
.-_at_/
Backward Do not care
node 10
str_concat, 5
www, 4
Forward A-Za-z0-9 .-_at_/
Forward URL
node 11
Backward A-Za-z0-9 .--_at_/ltA-Za-z0-9 .-_at_/
Backward Do not care
str_concat, 5
Forward URL A-Za-z0-9 .-_at_/
Backward URL A-Za-z0-9 .--_at_/ltA-Za-z0-
9 .-_at_/
node 12
echo, 5
Forward URL A-Za-z0-9 .-_at_/
Backward URL A-Za-z0-9 .--_at_/ltA-Za-z0-
9 .-_at_/
31
Vulnerability Signature Automaton
S
lt
lt
Not ASCII
ltltS
32
Vulnerability Signatures

• The vulnerability signature is the result of the
  input node, which includes all possible malicious
  inputs
• An input that does not match this signature
  cannot exploit the vulnerability
• After generating the vulnerability signature
• Can we generate a patch based on the
  vulnerability signature?
• The vulnerability signature automaton for
  the running example

lt
S
lt
33
Patches from Vulnerability Signatures

• Main idea
• Given a vulnerability signature automaton, find a
  cut that separates initial and accepting states
• Remove the characters in the cut from the user
  input to sanitize
• This means, that if we just delete lt from the
  user input, then the vulnerability can be removed

lt
S
lt
min-cut is lt
34
Patches from Vulnerability Signatures

• Ideally, we want to modify the input (as little
  as possible) so that it does not match the
  vulnerability signature
• Given a DFA, an alphabet cut is
• a set of characters that after removing the
  edges that are associated with the characters in
  the set, the modified DFA does not accept any
  non-empty string
• Finding a minimal alphabet cut of a DFA is an
  NP-hard problem (one can reduce the vertex cover
  problem to this problem)
• We use a min-cut algorithm instead
• The set of characters that are associated with
  the edges of the min cut is an alphabet cut
• but not necessarily the minimum alphabet cut

35
Automatically Generated Patch

• Automatically generated patch will make sure that
  no string that matches the attack pattern reaches
  the sensitive function
• lt?php
• if (preg match(/ ltlt./, GETwww))
• GETwww preg replace(lt,,
  GETwww)
• www _GETwww
• l_otherinfo URL
• www preg_replace(A-Za-z0-9
  .-_at_//,,www)
• echo lttdgt . l_otherinfo . .www.
  lt/tdgt
• ?gt

36
Experiments

• We evaluated our approach on five vulnerabilities
  from three open source web applications
• MyEasyMarket-4.1 A shopping cart program
• (2) BloggIT-1.0 A blog engine
• (3) proManager-0.72 A project management system
• We used the following XSS attack pattern
• SltscriptS

37
Forward Analysis Results

• The dependency graphs of these benchmarks are
  reduced based on the sinks
• Unrelated parts are removed

Input Input Input Input Results Results Results
nodes edges sinks inputs Time(s) Mem (kb) states/bdds
21 20 1 1 0.08 2599 23/219
29 29 1 1 0.53 13633 48/495
25 25 1 2 0.12 1955 125/1200
23 22 1 1 0.12 4022 133/1222
25 25 1 1 0.12 3387 125/1200
38
Backward Analysis Results

• We use the backward analysis to generate the
  vulnerability signatures
• Backward analysis starts from the vulnerable
  sinks identified during forward analysis

Input Input Input Input Results Results Results
nodes edges sinks inputs Time(s) Mem (kb) states/bdds
21 20 1 1 0.46 2963 9/199
29 29 1 1 41.03 1859767 811/8389
25 25 1 2 2.35 5673 20/302, 20/302
23 22 1 1 2.33 32035 91/1127
25 25 1 1 5.02 14958 20/302
39
Alphabet Cuts

• We generate alphabet cuts from the vulnerability
  signatures using a min-cut algorithm
• Problem When there are two user inputs the patch
  will block everything and delete everything
• Cannot interpret the relations among input
  variables (e.g. only block when the concatenation
  of two inputs contains ltscript)

Input Input Input Input Results
nodes edges sinks inputs Alphabet Cut
21 20 1 1 lt
29 29 1 1 s,,
25 25 1 2 S , S
23 22 1 1 lt,,
25 25 1 1 lt,,
Vulnerability signature depends on two inputs
40
Relational String Analysis

• Instead of using multiple single-track DFAs use
  one multi-track DFA
• Each track represents the values of one string
  variable
• Using multi-track DFAs
• Identifies the relations among string variables
• Generates relational vulnerability signatures for
  multiple user inputs of a vulnerable application
• Improves the precision of string analysis
• Proves properties that depend on relations among
  string variables, e.g., file usr.txt

41
Multi-track Automata

• Let X (the first track), Y (the second track), be
  two string variables
• ? is a padding symbol
• A multi-track automaton that encodes X Y.txt

(?,t)
(?,x)
(?,t)
(a,a), (b,b)
42
Relational Vulnerability Signature

• Performs forward analysis using multi-track
  automata to generate relational vulnerability
  signatures
• Each track represents one user input
• An auxiliary track represents the values of the
  current node
• Intersects the auxiliary track with the attack
  pattern upon termination

43
Relational Vulnerability Signature

• Consider a simple example having multiple user
  inputs
• lt?php
• 1 www _GETwww
• 2 url _GETurl
• 3 echo url. www
• ?gt
• Let the attack pattern be S lt S

44
Relational Vulnerability Signature

• A multi-track automaton (url, www, aux)
• Identifies the fact that the concatenation of two
  inputs contains lt

(a,?,a), (b,?,b),
(a,?,a), (b,?,b),
(lt,?,lt)
(?,a,a), (?,b,b),
(?,a,a), (?,b,b),
(?,lt,lt)
(?,lt,lt)
(?,a,a), (?,b,b),
(?,a,a), (?,b,b),
45
Relational Vulnerability Signature

• Project away the auxiliary variable
• Find the min-cut
• This min-cut identifies the alphabet cuts lt for
  the first track (url) and lt for the second
  track (www)

(a,?), (b,?),
(a,?), (b,?),
(lt,?)
(?,a), (?,b),
(?,a), (?,b),
(?,lt)
(?,lt)
(?,a), (?,b),
(?,a), (?,b),
min-cut is lt,lt
46
Patch for Multiple Inputs

• Patch If the inputs match the signature, delete
  its alphabet cut
• lt?php
• if (preg match(/ ltlt./, GETurl.
  GETwww))
• GETurl preg replace(lt,,
  GETurl)
• GETwww preg replace(lt,,
  GETwww)
• 1 www GETwww
• 2 url GETurl
• 3 echo url. www
• ?gt

47
Technical Issues

• To conduct relational string analysis, we need to
  compute intersection of multi-track automata
• Intersection is closed under aligned multi-track
  automata
• ?s are right justified in all tracks, e.g., ab??
  instead of a?b?
• However, there exist unaligned multi-track
  automata that are not describable by aligned ones
• We proposed an alignment algorithm that
  constructs aligned automata which over or under
  approximate unaligned ones

48
Other Technical Issues

• Modeling Word Equations
• Intractability of X cZ
• The number of states of the corresponding aligned
  multi-track DFA is exponential to the length of
  c.
• Irregularity of X YZ
• X YZ is not describable by an aligned
  multi-track automata
• We proposed a conservative analysis
• Constructs multi-track automata that over or
  under-approximate the word equations

49
Composite Analysis

• What I have talked about so far focuses only on
  string contents
• It does not handle constraints on string lengths
• It cannot handle comparisons among integer
  variables and string lengths
• We extended our string analysis techniques to
  analyze systems that have unbounded string and
  integer variables
• We proposed a composite static analysis approach
  that combines string analysis and size analysis

50
Size Analysis

• Size Analysis The goal of size analysis is to
  provide properties about string lengths
• It can be used to discover buffer overflow
  vulnerabilities
• Integer Analysis At each program point,
  statically compute the possible states of the
  values of all integer variables.
• These infinite states are symbolically
  over-approximated as linear arithmetic
  constraints that can be represented as an
  arithmetic automaton
• Integer analysis can be used to perform size
  analysis by representing lengths of string
  variables as integer variables.

51
An Example

• Consider the following segment
• 1 lt?php
• 2 www GETwww
• 3 l otherinfo URL
• 4 www preg replace(A-Za-z0-9
  ./-_at_//,,www)
• 5 if(strlen(www) lt limit)
• 6 echo lttdgt . l otherinfo . . www .
  lt/tdgt
• 7?gt
• If we perform size analysis solely, after line 4,
  we do not know the length of www
• If we perform string analysis solely, at line 5,
  we cannot check/enforce the branch condition.

52
Composite Analysis

• We need a composite analysis that combines string
  analysis with size analysis.
• Challenge How to transfer information between
  string automata and arithmetic automata?
• A string automaton is a single-track DFA that
  accepts a regular language, whose length forms a
  semi-linear set
• For example 4, 6 ? 2 3k k 0
• The unary encoding of a semi-linear set is
  uniquely identified by a unary automaton
• The unary automaton can be constructed by
  replacing the alphabet of a string automaton with
  a unary alphabet

53
Arithmetic Automata

• An arithmetic automaton is a multi-track DFA,
  where each track represents the value of one
  variable over a binary alphabet
• If the language of an arithmetic automaton
  satisfies a Presburger formula, the value of each
  variable forms a semi-linear set
• The semi-linear set is accepted by the binary
  automaton that projects away all other tracks
  from the arithmetic automaton

54
Connecting the Dots

• We developed novel algorithms to convert unary
  automata to binary automata and vice versa
• Using these conversion algorithms we can conduct
  a composite analysis that subsumes size analysis
  and string analysis

String Automata
Unary Length Automata
Binary Length Automata
Arithmetic Automata
55
Stranger A String Analysis Tool
Stranger is available at www.cs.ucsb.edu/vlab/st
ranger

• Uses Pixy Jovanovic et al., 2006 as a PHP front
  end
• Uses MONA Klarlund and Møller, 2001 automata
  package for automata manipulation

Attack patterns
Symbolic String Analysis
Pixy Front End
String/Automata Operations
Automata Based String Manipulation Library
Parser
String Analyzer
Dependency Graphs
Stranger Automata
PHP program
CFG
DFAs
Dependency Analyzer
String Analysis Report (Vulnerability
Signatures)
MONA Automata Package
56
Case Study

• Schoolmate 1.5.4
• Number of PHP files 63
• Lines of code 8181
• Forward Analysis results
• After manual inspection we found the following

Time Memory Number of XSS sensitive sinks Number of XSS Vulnerabilities
22 minutes 281 MB 898 153
Actual Vulnerabilities False Positives
105 48
57
Case Study False Positives

• Why false positives?
• Path insensitivity 39
• Path to vulnerable program point is not feasible
• Un-modeled built in PHP functions 6
• Unfound user written functions 3
• PHP programs have more than one execution entry
  point
• We can remove all these false positives by
  extending our analysis to a path sensitive
  analysis and modeling more PHP functions

58
Case Study - Sanitization

• We patched all actual vulnerabilities by adding
  sanitization routines
• We ran stranger the second time
• Stranger proved that our patches are correct with
  respect to the attack pattern we are using

59
Related Work String Analysis

• String analysis based on context free grammars
  Christensen et al., SAS03 Minamide, WWW05
• Application of string analysis to web
  applications Wassermann and Su, PLDI07,
  ICSE08 Halfond and Orso, ASE05, ICSE06
• Automata based string analysis Xiang et al.,
  COMPSAC07 Shannon et al., MUTATION07
• String analysis based on symbolic/concolic
  execution Bjorner et al., TACAS09
• Bounded string analysis Kiezun et al.,
  ISSTA09

60
Related Work

• Size Analysis
• Size analysis Hughes et al., POPL96 Chin et
  al., ICSE05 Yu et al., FSE07 Yang et al.,
  CAV08
• Composite analysis Bultan et al., TOSEM00 Xu
  et al., ISSTA08 Gulwani et al., POPL08
  Halbwachs et al., PLDI08
• Vulnerability Signature Generation
• Test input/Attack generation Wassermann et al.,
  ISSTA08 Kiezun et al., ICSE09
• Vulnerability signature generation Brumley et
  al., SP06 Brumley et al., CSF07 Costa et
  al., SOSP07

61
THE END
