Mobile TV

1
Mobile TV

• Presentation by
• Chetna R Parmar
• M.E.E.C. (C.S.E) Sem-I
• LD College of Engineering

2
Outline

• Introduction
• Concept of Mobile TV
• Mobile TV Technologies
• Comparison
• Conclusion
• References

3
Outline

• Introduction
• Concept of Mobile TV
• Mobile TV Technologies
• Comparison
• Conclusion
• References

4
Introduction

• Mobile TV is television service delivered to
  subscribers via mobile telecommunications
  networks
• It combines the services of a mobile phone with
  television content

5
Introduction?Why Mobile TV ?

• Watching TV Independent of Location
• Transportation Vehicle
• Public Places
• Private Spaces
• Watching TV Independently of Time

6
Outline

• Introduction
• Concept of Mobile TV
• Mobile TV Technologies
• Comparison
• Conclusion
• References

7
Concept of Mobile TV? TV Technology Development
8
Outline

• Introduction
• Concept of Mobile TV
• Mobile TV Technologies
• Comparison
• Conclusion
• References

9
Mobile tv technologies
10
CELLULAR3G

• Provide more advanced services.
• Downlink speed 14.4 Mbps and uplink speed 5.8
  Mbps.

11
CELLULAR MBMS

• Multimedia Broadcast Multicast Service is a
  broadcast TV, film, information and other media.
• MBMS has the major benefits that it uses existing
  GSM UMTS cellular network.
• Uses multicast distribution.

12
CELLULAR TDtv

• TDtv operates in the 3G spectrum bands at 1900MHz
  and 2010MHz.
• TDtv allows UMTS operators to fully utilize their
  existing spectrum and base stations to offer
  mobile TV and multimedia packages without
  impacting other voice and data 3G services.

13
BROADCAST1 Seg

• 1Seg is a mobile terrestrial digital audio/video
  and data broadcasting service in Japan.
• In terrestrial digital broadcast each channel is
  divided into 13 segments. HDTV broadcast occupies
  12 segments, and the remaining (13th) one segment
  is used for mobile receivers. Thus the name,
  '1seg'

14
BROADCASTDMB

• Digital Multimedia Broadcasting (DMB) is a
  digital radio transmission system for sending
  multimedia (radio, TV, and datacasting) to mobile
  phones.
• It uses radio frequency bands band III (VHF) and
  L (UHF).
• In DMB uses MPEG-4 part 10 for video MPEG-4
  part 3 BSAC for audio.

15
BROADCASTDVB

• DVB-T
• DVB-T is the world's most used digital
  terrestrial television system
• Consumes too much battery
• DVB-H
• Latest development from DVB family
• Based on DVB-T technology
• Consumes less battery (time slicing)
• Improves the robustness of the difficult
  reception environments with built-in antennas

16
BROADCASTMedia FLO

• Developed by QUALCOMM
• Based on FLO (Forward Link Only) technology
• It uses unidirectional COFDM
• Less power consumption
• Currently popular in North America
• Frequency spectrum 716-722 MHz.

17
BROADCASTISDB

• The core standards of ISDB are ISDB-S, ISDB-T,
  ISDB-C
• 12 GHz band ISDB-S uses PSK modulation,
• 2.6 GHz band digital sound broadcasting uses CDM
• ISDB-T (VHF / UHF ) uses COFDM with PSK/QAM

18
Outline

• Introduction
• Concept of Mobile TV
• Mobile TV Technologies
• Comparison
• Conclusion
• References

19
Comparison
DVB-H DMB Media-FLO ISDB
Region US, Europe, Asia N-America, Europe US Japan
Developer Open Standard Open Standard Qualcomm ARIB
OEM Support Nokia, Motorola, Siemens LG, Samsung Samsung, Nokia Nokia, Siemens
Network DVB-T DAB-T DAB-S CDMA-EVDO ARIB STD-B25
Channels 9-18 8-12 15-20 24-50
20
Outline

• Introduction
• Concept of Mobile TV
• Mobile TV Technologies
• Comparison
• Conclusion
• References

21
Conclusion

• Mobile TV Broadcasting allows user to watch their
  favorite TV programs on their mobile device
• The Service works by Receiving Digital TV
  broadcast signal from the air in much same way as
  TV at home by using different technologies

22
Outline

• Introduction
• Concept of Mobile TV
• Challenges
• Mobile TV Technologies
• Comparison
• Conclusion
• References

23
References

• http//www.3g4g.co.uk/Tv/
• http//www.3g.co.uk/PR/March2006/2732.htm
• http//en.wikipedia.org/wiki/Mobile_TV

24
Thank You

• Questions?
