Sorting Algorithms

1
Sorting Algorithms
2
Motivation

• Example Phone Book Searching
• If the phone book was in random order, we would
  probably never use the phone!
• Lets say ½ second per entry
• There are 70,000 households in Ilam
• 35,000 seconds 10hrs to find a phone number!
• Best time ½ second
• average time is about 5 hrs

3
Motivation

• The phone book is sorted
• Jump directly to the letter of the alphabet we
  are interested in using
• Scan quickly to find the first two letters that
  are really close to the name we are interested in
• Flip whole pages at a time if not close enough

4
The Big Idea

• Take a set of N randomly ordered pieces of data
  aj and rearrange data such that for all j (j gt
  0 and j lt N), R holds, for relational operator R
• a0 R a1 R a2 R aj R aN-1 R aN
• If R is lt, we are doing an ascending sort Each
  consecutive item in the list is going to be
  larger than the previous
• If R is gt, we are doing a descending sort
  Items get smaller as move down the list

5
Queue Example Radix Sort

• Also called bin sort
• Repeatedly shuffle data into small bins
• Collect data from bins into new deck
• Repeat until sorted
• Appropriate method of shuffling and collecting?
• For integers, key is to shuffle data into bins
  on a per digit basis, starting with the rightmost
  (ones digit)
• Collect in order, from bin 0 to bin 9, and left
  to right within a bin

6
Radix Sort Ones Digit

• Data 459 254 472 534 649 239 432 654 477
• Bin 0
• Bin 1
• Bin 2 472 432
• Bin 3
• Bin 4 254 534 654
• Bin 5
• Bin 6
• Bin 7 477
• Bin 8
• Bin 9 459 649 239
• After Call 472 432 254 534 654 477 459 649
  239

7
Radix Sort Tens Digit

• Data 472 432 254 534 654 477 459 649 239
• Bin 0
• Bin 1
• Bin 2
• Bin 3 432 534 239
• Bin 4 649
• Bin 5 254 654 459
• Bin 6
• Bin 7 472 477
• Bin 8
• Bin 9
• After Call 432 534 239 649 254 654 459 472 477

8
Radix Sort Hundreds Digit

• Data 432 534 239 649 254 654 459 472 477
• Bin 0
• Bin 1
• Bin 2 239 254
• Bin 3
• Bin 4 432 459 472 477
• Bin 5 534
• Bin 6 649 654
• Bin 7
• Bin 8
• Bin 9
• Final Sorted Data 239 254 432 459 472 477 534
  649 654

9
Radix Sort Algorithm

• Begin with current digit as ones digit
• While there is still a digit on which to classify
• For each number in the master list,
• Add that number to the appropriate sublist
  keyed on the current digit
• For each sublist from 0 to 9
• For each number in the sublist
• Remove the number from the sublist and append
  to a new master list
• Advance the current digit one place to the left.

10
Radix Sort and Queues

• Each list (the master list (all items) and bins
  (per digit)) needs to be first in, first out
  ordered perfect for a queue.

11
A Quick Tangent

• How fast have the sorts youve seen before
  worked?
• Bubble, Insertion, Selection O(n2)
• We will see sorts that are better, and in fact
  optimal for general sorting algorithms
• Merge/Quicksort O(n log n)
• How fast is radix sort?

12
Analysis of Radix Sort

• Let n be the number of items to sort
• Outer loop control is on maximum length of input
  numbers in digits (Let this be d)
• For every digit,
• Assign each number to sort to a group (n
  operations)
• Pull each number back into the master list (n
  operations)
• Overall running time 2 n d gt O(n)

13
Analysis of Radix Sort

• O(n log n) is optimal for general sorting
  algorithms
• Radix sort is O(n)? How does that work?
• Radix sort is not a general sorting algorithm
  It cant sort arbitrary information Rectangles
  objects, Automobiles objects, etc are no good.
• Can sort items that can be broken into
  constituent pieces and whose pieces can be
  ordered
• Integers (digits), Strings (characters)

14
Sorting Algorithms

• What does sorting really require?
• Compare pieces of data at different positions
• Swap the data at those positions until order is
  correct

20
3
18
9
5
15
Selection Sort

• void selectionSort(int a, int size)
• for (int k 0 k lt size-1 k)
• int index mininumIndex(a, k, size)
• swap(ak,aindex)
• int minimumIndex(int a, int first, int last)
• int minIndex first
• for (int j first 1 j lt last j)
• if (aj lt aminIndex) minIndex j
• return minIndex

16
Selection Sort

• What is selection sort doing?
• Repeatedly
• Finding smallest element by searching through
  list
• Inserting at front of list
• Moving front of list forward by 1

17
Selection Sort Step Through
20
3
18
9
5
minIndex(a, 0, 5) ? 1 swap (a0,a1)
18
Order From Previous
Find minIndex (a, 1, 5) 4
Find minIndex (a, 2, 5) 3
19
Find minIndex (a, 3, 5) 3
K 4 size-1 Done!
20
Cost of Selection Sort

• void selectionSort(int a, int size)
• for (int k 0 k lt size-1 k)
• int index mininumIndex(a, k, size)
• swap(ak,aindex)
• int minimumIndex(int a, int first, int last)
• int minIndex first
• for (int j first 1 j lt last j)
• if (aj lt aminIndex) minIndex j
• return minIndex

21
Cost of Selection Sort

• How many times through outer loop?
• Iteration is for k 0 to lt (N-1) gt N-1 times
• How many comparisons in minIndex?
• Depends on outer loop Consider 5 elements
• K 0 j 1,2,3,4
• K 1 j 2, 3, 4
• K 2 j 3, 4
• K 3 j 4
• Total comparisons is equal to 4 3 2 1,
  which is N-1 N-2 N-3 1
• What is that sum?

22
Cost of Selection Sort

• (N-1) (N-2) (N-3) 3 2 1
• (N-1) 1 (N-2) 2 (N-3) 3
• N N N gt repeated addition of N
• How many repeated additions?
• There were n-1 total starting objects to add, we
  grouped every 2 together approximately N/2
  repeated additions
• gt Approximately N N/2 O(N2) comparisons

23
Insertion Sort

• void insertionSort(int a, int size)
• for (int k 1 k lt size k)
• int temp ak
• int position k
• while (position gt 0 aposition-1 gt temp)
• aposition aposition-1
• position--
• aposition temp

24
Insertion Sort

• List of size 1 (first element) is already sorted
• Repeatedly
• Chooses new item to place in list (ak)
• Starting at back of the list, if new item is less
  than item at current position, shift current data
  right by 1.
• Repeat shifting until new item is not less than
  thing in front of it.
• Insert the new item

25
Insertion Sort Step Through
Single card list already sorted
20
3
18
9
5
A1
A2
A3
A4
A0
Move 3 left until hits something smaller
20
3
18
9
5
A2
A3
A4
A0
A1
26
Move 3 left until hits something smaller Now
two sorted
18
9
5
3
20
A2
A3
A4
A0
A1
Move 18 left until hits something smaller
20
18
3
9
5
A3
A4
A0
A1
A2
27
Move 18 left until hits something smaller Now
three sorted
9
5
3
18
20
A3
A4
A0
A1
A2
Move 9 left until hits something smaller
3
20
9
18
5
A4
A0
A1
A2
A3
28
Move 9 left until hits something smaller Now
four sorted
3
9
18
20
5
A4
A0
A1
A2
A3
Move 5 left until hits something smaller
3
9
18
20
5
A0
A1
A2
A3
A4
29
Move 5 left until hits something smaller Now
all five sorted Done
3
9
18
20
5
A0
A1
A2
A3
A4
30
Cost of Insertion Sort

• void insertionSort(int a, int size)
• for (int k 1 k lt size k)
• int temp ak
• int position k
• while (position gt 0 aposition-1 gt temp)
• aposition aposition-1
• position--
• aposition temp

31
Cost of Insertion Sort

• Outer loop
• K 1 to lt size 1,2,3,4 gt N-1
• Inner loop
• Worst case Compare against all items in list
• Inserting new smallest thing
• K 1, 1 step (position k 1, while position gt
  0)
• K 2, 2 steps position 2,1
• K 3, 3 steps position 3,2,1
• K 4, 4 steps position 4,3,2,1
• Again, worst case total comparisons is equal to
  sum of I from 1 to N-1, which is O(N2)

32
Cost of Swaps

• Selection Sort
• void selectionSort(int a, int size)
• for (int k 0 k lt size-1 k)
• int index mininumIndex(a, k, size)
• swap(ak,aindex)
• One swap each time, for O(N) swaps

33
Cost of Swaps

• Insertion Sort
• void insertionSort(int a, int size)
• for (int k 1 k lt size k)
• int temp ak
• int position k
• while (position gt 0 aposition-1 gt temp)
• aposition aposition-1
• position--
• aposition temp
• Do a shift almost every time do compare, so O(n2)
  shifts
• Shifts are faster than swaps (1 step vs 3 steps)
• Are we doing few enough of them to make up the
  difference?

34
Another Issue - Memory

• Space requirements for each sort?
• All of these sorts require the space to hold the
  array - O(N)
• Require temp variable for swaps
• Require a handful of counters
• Can all be done in place, so equivalent in
  terms of memory costs
• Not all sorts can be done in place though!

35
Which O(n2) Sort to Use?

• Insertion sort is the winner
• Worst case requires all comparisons
• Most cases dont (jump out of while loop early)
• Selection use for loops, go all the way through
  each time

36
Tradeoffs

• Given random data, when is it more efficient to
• Just search versus
• Insertion Sort and search
• Assume Z searches
• Search on random data Z O(n)
• Sort and binary search O(n2) Z log2n

37
Tradeoffs

• Z n lt n2 (Z log2n)
• Z n Z log2n lt n2
• Z (n-log2n) lt n2
• Z lt n2/(n-log2n)
• For large n, log2n is dwarfed by n in (n-log2n)
• Z lt n2/n
• Z lt n (approximately)

38
Improving Sorts

• Better sorting algorithms rely on divide and
  conquer (recursion)
• Find an efficient technique for splitting data
• Sort the splits separately
• Find an efficient technique for merging the data
• Well see two examples
• One does most of its work splitting
• One does most of its work merging
