Title: Soil, Manure, and Water Sampling and Analysis


1
Soil, Manure, and Water Sampling and Analysis
  • Leticia S. Sonon
  • Ag and Env Services Laboratories
  • March 31, 2009

2
Agenda
  • Manure testing
  • Sample collection
  • Tests to request
  • Reports
  • Soil testing
  • Sample collection
  • Tests to request
  • Reports
  • Groundwater
  • monitoring

Lagoon sample
Soil sampler
3
Why Test Soil and Manure?
  • Know the soil fertility status
  • Know the fertilizer value of the manure
  • These are the basics for Comprehensive Nutrient
    Management Planning (CNMP) and Waste Utilization.

4
Manure Testing
  • When?
  • Near to the time of application as possible
  • gt1000 animal units (AU) semi-annual
  • gt3000 AU - quarterly for swine operations
  • How?
  • Depends on the type of manure and manure handling
    system
  • Procedures differ for lagoon effluent, liquid
    slurry, lagoon sludge, and solid manure.

5
Lagoon EffluentSemiannually for operations over
1000 auQuarterly for swine operations over 3000
au
  • Collect what you intend to pump for crop
    irrigation no mixing of the lagoon.
  • Where possible, collect effluent from the
    spray-system at the point of application.
  • Grab eight 1-pint samples throughout a
    spray-irrigation event and composite into a
    plastic bucket.
  • Mix bucket contents and fill a 1-pint bottle for
    lab analysis.

6
Lagoon Effluent (continued)
  • When samples cannot be taken from the
    spray-system, collect 8 grab samples at least 6
    feet from the lagoon bank and at a depth of about
    1 foot or whatever would represent the material
    pumped for irrigation.
  • Avoid floating debris.
  • Never use galvanized buckets.
  • Tightly cap the manure sample bottles and check
    for leaks.
  • Rinse or wipe off any manure from the outside of
    the container.

7
Alternative Lagoon Effluent Sampler
plastic tubing
float
steel pipe
8
thrown into lagoon
9
sample collection using a suction pump
suction pump
suction reservoir
10
Liquid Slurry
Composite Sampling Device
  • If you agitate your storage pond or lagoon,
    samples can be collected with the equipment and
    procedure used for lagoon effluent.
  • If you dont agitate, use the composite sampling
    device illustrated here.

11
Lagoon Sludge (two methods) Method One
Method Two
  • You will need a boat or floating dock.
  • Insert a pipe to the bottom of the lagoon.
  • Seal the surface end and extract the pipe from
    the lagoon.
  • Deposit the sludge portion into a bucket.
  • Composite 12-20 sub-samples from various
    locations around the lagoon.
  • Pump lagoon down to the sludge layer.
  • Agitate and collect a slurry-type sample using
    the liquid sampler described for sampling lagoon
    effluent or slurry.

12
Handling Liquid Manure Samples
  • Container
  • Clean 1-pint plastic wide-mouth bottle
  • NO GLASS
  • Filling
  • Leave 1-inch headspace for gas expansion and to
    facilitate mixing at the laboratory.
  • Storage
  • Preferably ship or deliver samples immediately
    after sampling.
  • However, refrigerate or freeze samples that
    cannot be immediately shipped or delivered to the
    laboratory.

13
Solid ManureStockpiled, Surface-scraped, or
Composted
  • Composite at least 6 or more cores that represent
    the average moisture content.
  • Core samples to a depth of at least 18 inches.
  • Sub-sample a 1-quart portion into a plastic-bag
    for the lab. Dont overfill.
  • Refrigerate if samples are stored for more than 2
    days.

Solid Manure Sampling Device
14
Sampling In-house Litter
  • Previous sampling recommendation

Collect at least 10 to 12 one pint samples
throughout the house, combine and mix them in a
plastic bucket, and place one quart into a
plastic bag for submission to the laboratory.
15
Research on N content shows that
Center of the house
Around the feeders
Around the drinkers

Average 3.31 4.41
3.49
Minimum 2.83 4.15
2.35
Maximum 3.68 4.75
4.50
  • Around feeders, N was 25 higher than from
    center of the house and 21 higher than from
    around drinkers (30 samples)
  • N varied as much as 48 around drinkers

16
Therefore
  • It is not recommended to sample litter while
    still being used as a bedding layer in the
    poultry house.
  • Wait until clean out to sample after mixing the
    litter by scraping it into a pile. Then, follow
    the procedure given below for sampling litter
    from piles, stockpiles, or spreader trucks.
  • If sampling of litter is necessary in the house
    prior to clean out, use the sampling procedures
    as originally provided.

17
Solid Manure Tests to Request
Essential
Other Tests
  • Total nitrogen (N)
  • Phosphorus (P)
  • Potassium (K)
  • Calcium (Ca)
  • Magnesium (Mg)
  • Sodium (Na)
  • Sulfur (S)
  • Aluminum (Al)
  • Iron (Fe)
  • Boron (B)
  • Copper (Cu)
  • Manganese (Mn)
  • Zinc (Zn)

18
for Nutrient Management and Reg.
ComplianceNon-swine and swine except new and
expanding swine operations over 3000 AU
Liquid Manure Test (Lagoon Effluent)
  • Nutrients listed for solid manure
  • In Addition
  • Total Kjeldahl nitrogen (TKN)
  • Nitrate nitrogen (NO3-N)
  • Ammonium nitrogen (NH4-N)- not
  • required on your permit but good for
  • predicting available nitrogen

19
Liquid Manure Test (Lagoon Effluent)for new and
expanding swine operations over 3000 AU
Quarterly Monitoring
  • 5-day Biochemical Oxygen Demand (BOD)
  • Total Suspended Solids (TSS)
  • Total Kjeldahl Nitrogen (TKN)
  • Ammonia-Nitrogen (NH4-N)
  • Nitrate-Nitrogen (NO3-N)
  • pH

20
Nitrogen Analysis
  • Total Nitrogen by Combustion for Solids
  • All forms of Nitrogen
  • Organic-N
  • Ammonium-N
  • Nitrate Nitrite-N
  • Total Kjeldahl Nitrogen for Liquids
  • Only Organic-N Ammonia-N
  • Total-N is TKN NO3

21
Lagoon sample
Litter sample
22
Solid Manure Report
  • Units provided on UGA reports are
  • Percent
  • Pounds per ton
  • Phosphorus and potassium are reported as
  • P2O5 (P2O5 divided by 2.29 P)
  • K2O (K2O divided by 1.20 K)
  • All concentrations are reported on an as
    received basis and not on a dry matter basis.

23
Solid Manure Report
Litter Broiler
lbs/ton
24
Liquid Manure Report
  • Units provided on UGA reports are
  • Parts per million (ppm)
  • Pounds per 1000 gallons
  • Pounds per acre inch
  • Phosphorus and potassium reported as
  • P2O5 (P2O5 divided by 2.29 P)
  • K2O (K2O divided by 1.20 K)

25
Liquid Manure Report
Lagoon - Dairy
ppm lbs/1000 gal lbs/acre-inch
26
Soil Testing
  • When?
  • Annually
  • Fall is a good time, but samples can be taken
    during any season.
  • For year to year comparisons it is best to sample
    at approximately the same time each year.

27
Where to Soil Sample
  • Divide large fields according to obviously
    different
  • soil types
  • management
  • drainage
  • crop productivity
  • slope
  • erosion.
  • Collect separate samples from these smaller
    areas.
  • Composite 10 to 20 soil cores while traveling in
    a zigzag pattern.

28
How to Collect Soil
  • Sample depth
  • plowed fields
  • 6 inches
  • or plow depth
  • no-till or pastures
  • 4 inches
  • Composite 10 to 20 cores in a plastic bucket and
    mix well.
  • Fill a 1-pint soil test bag that has been clearly
    labeled with the field identification and the
    area within that field that this sample
    represents.

29
Basic Soil Test
  • Phosphorus (P)
  • Potassium (K)
  • Calcium (Ca)
  • Magnesium (Mg)
  • Zinc (Zn)
  • pH
  • Lime requirement

30
Soil Nitrogen
  • Tests for residual soil nitrogen are usually not
    able to reliably predict available soil nitrogen
    and crop response.
  • Therefore, recommended nitrogen amendments are
    based on long-term research conducted to
    determine the nitrogen rates that produce the
    optimum yield for specific crops and forages.

31
Soil Extractants
  • Mehlich I (P, K, cations, micronutrients)
  • Georgia and other Southeastern States
  • Mehlich III (P, K, cations, micronutrients)
  • many other labs
  • Bray-1 (P only)
  • older extractant may still be used by some labs
  • Olsens (P only)
  • used by Western States on calcarious soils

32
Soil Test Reports(Not a P Index)
  • Soil test results are concentrations of nutrients
    that are extracted from your soil using
    extractants designed to measure various forms of
    each nutrient.
  • These concentrations are know as Soil Test
    Indices.
  • These Soil Test Indices are correlated to crop
    or forage yield and then calibrated using
    fertilizer trials so that they can be converted
    into a pounds per acre fertilizer recommendation.

33
Soil Fertility Recommendations
  • Nitrogen is based on forage or crop species and
    management.
  • P and K are based on Soil Test Indices.
  • Recommended N, P, and K may be supplied from
    either
  • Commercial fertilizer
  • Animal manure
  • Lagoon effluent
  • Green manure crops
  • Or a combination of sources.

34
Test Questions?
35
Questions
  • Why is manure tested for developing a CNMP?
  • When should manures be sampled for lab analysis?
  • How should manure be sampled?
  • How do you calculate the rate of manure to apply?
  • Why should soil be tested when developing a CNMP?

36
Questions
  • How should soil samples be taken in the field?
  • Which nutrients are measured in the routine soil
    test?
  • Which nutrients are of primary environmental
    concern and why?

37
Monitoring Well Testing
38
Who must do groundwater Monitoring?
  • Animal feeding operations over 1000 animal units

39
Agenda
  • Well location
  • Well construction
  • Monitoring requirements
  • Sampling and analysis
  • Guidance documents

40
Locating Wells
  • Up-gradient wells
  • Up-gradient monitoring is not required in the
    swine or non-swine rules
  • But, a minimum of three wells are needed to
    determine the gradient of the groundwater
  • In many cases the groundwater gradient will
    follow the slope of the land surface, but not
    always
  • Down-gradient wells
  • At least 25 feet from the outer down-gradient
    edge (toe) of the lagoon or manure storage
    structure
  • Should not be installed into fill material
  • Into the shallowest saturated zone that is
  • the first saturated water bearing unit
  • saturated year-round

41
Stay Away From
  • Septic tanks 50 ft
  • Leach Fields 100 ft
  • Dead animal burial pits 150 ft
  • Animal or fowl enclosure 100 ft
  • Pesticide storage, mixing, or loading 100 ft
  • Fertilizer storage 100 ft
  • Petroleum storage 100 ft

42
Using Existing Wells
  • Must be in the water bearing unit influenced by
    the lagoon or spray field
  • If used for a down-gradient well it must be
    immediately down-gradient of the water bearing
    unit influenced by the lagoon or spray field.
  • Must be approved by the Georgia EPD

43
Well Construction
  • Details are in EPDs Manual for Groundwater
    Monitoring.
  • Must be installed by a licensed well driller that
    is supervised by a licensed geologist or
    professional engineer
  • Following installation you should have
  • well log
  • land surface contour map

44
Monitoring Requirements(Except new and expanding
swine operations over 3000AU)
Parameter Frequency Tolerance Holding Times
Nitrate-N (mg-N/L) Twice/Year 10 14 days
Total Kjeldahl-N (mg TKN/L) Twice/Year - 28 days
Depth to Groundwater (not required) Twice/Year - On-site
45
New and expanding swine operations over 3000 AU
Parameter Frequency Tolerance Holding Time
Specific Conductance Quarterly - On-site
Nitrate-N Quarterly 10 mg/L 28 days
pH Quarterly 1 pH unit change On-site
Depth to Groundwater Quarterly - On-site
46
Written Sampling Plan
  • Procedures for sample collection
  • Sample preparation and collection
  • Analytical procedures
  • Chain-of-custody

47
Sampling Procedure
  • Measure water depth.
  • Purge well
  • bail dry
  • or bail three well volumes.

48
Sampling Procedure (continued)
  • Allow well to recover.
  • Collect sample for
  • TKN
  • nitrate-N.

49
Guidance Documents
  • Manual for Groundwater Monitoring.
  • Monitoring Well Construction for Hazardous-Waste
    Sites in Georgia
  • Rules and Regulations for Water Quality Control
  • The Water Well Standards Act of 1991

50
Locating These Documents
  • These documents can be found at the Georgia
    Department of Natural Resources.
  • Contact Thomas E. Hopkins, 4220 International
    Parkway, Atlanta, GA 30354.
  • Phone (404) 362-4916 or (404) 362-2680
  • Email Tom_Hopkins_at_dnr.mail.state.ga.us

51
Test Questions?
52
Questions
  • What monitoring parameters are required by the
    Animal Feeding Operations Permit on lagoon
    effluent and groundwater?
  • How frequently must wells be sampled?
  • What well monitoring parameter needs to be
    determined on-site?

53
Questions
  • Where is the proper location for the monitoring
    well?
  • Who is responsible for constructing the
    monitoring wells?
  • How many wells are required to determine the
    groundwater gradient?
Write a Comment
User Comments (0)
About PowerShow.com
