Title: NAS: Making the Right Choice For Your Business


1
NAS Making the Right Choice For Your Business
  • Wednesday, August 20, 2003
  • 11 a.m. pacific/2 p.m. eastern

Sponsored by
2
Welcome
Matthew Sarrel Technical Director PC Magazine
Labs
Sponsored by
3
Todays Agenda
  • NAS and SAN
  • Navigating Today's Enterprise Storage
    Requirements
  • Emerging Networked Storage Market
  • Windows-Powered NAS Solutions

Sponsored by
4
Featured Speakers
  • Henry Baltazar
  • Senior Analyst
  • eWEEK

Jim Addlesberger CEO NavigateStorage
Steve Kenniston Technology Analyst The
Enterprise Storage Group
Sponsored by
5
Sponsor Speaker
Jared Vishney Senior Manager, Solutions
Marketing Iomega Corporation
Sponsored by
6
Poll 1 Placeholder
  • Does your company plan to purchase NAS or SAN
    equipment this year?
  • Yes
  • No

7
NAS and SAN
Henry Baltazar Senior Analyst eWEEK Labs
Sponsored by
8
Know Your Data
  • This is the only real implementation rule
  • What type of data? Files? Application Data? Big
    or little files?
  • How often is data accessed, and by how many
    users?
  • How much are you willing to spend to store it?

9
Why Use NAS?
  • Relatively inexpensive to deploy since there is
    no need for special hardware (i.e. Fibre Channel
    switches, HBAs)
  • Easy to deploy If you can set up a file server,
    you can easily set up NAS
  • Readily communicates with multiple platforms
    (CIFS, NFS, AppleTalk, Novell)

10
What About SANs?
  • Best option for high performance since it already
    has 2 Gbps with 4 Gbps and 10 Gbps Fibre Channel
    on the way.
  • Block level access to storage is preferable for
    some applications like databases
  • Used for carving up Enterprise RAID systems (EMC,
    IBM, HDS)

11
SAN Drawbacks
  • Interoperability is not quite plug-n-play
  • Not easy to learn or implement
  • Not geared towards data sharing. Servers must be
    connected to SAN to share
  • Management is still evolving

12
NAS and SAN Convergence
  • NAS head units Attach to Fibre Channel SANs
    allowing clients to store files on SAN resources.
  • Network Appliance FAS 900 series is a storage
    system which allows connections via NAS, Fibre
    Channel SANs and iSCSI.
  • EMC Celerra, HP StorageWorks NAS 8000

13
What Else To Look For?
  • Increased Data Protection Mirroring and
    snapshots are becoming more common on NAS
    platforms
  • Emergence of ATA drive based NAS Creates low
    cost, high capacity market segment which is
    attractive for nearline storage market
  • Improved clustering improves NAS performance and
    reliability

14
NAS and SAN
Henry Baltazar Senior Analyst eWEEK Labs
Sponsored by
15
Poll 2 Placeholder
  • Which factor do you feel is mort important when
    considering a NAS purchase?
  • Administration
  • High-availability
  • Manufacturer reputation
  • Performance
  • Price
  • Support policy
  • Upgrade path

16
Navigating Today's Enterprise Storage Requirements
Jim Addlesberger CEO NavigateStorage LLC
Sponsored by
17
DAS - Direct Attached Storage
  • Storage architecture used for the past 30 years
  • Storage devices are directly attached to servers
  • The last decade saw massive growth in demand for
    storage
  • Business continuance and disaster recovery led to
    requirements DAS could not satisfy
  • This has led to emergence of networked storage
    architectures

18
Storage Consolidation
  • Consolidating storage can bring enormous
    benefits. You must carefully discuss and
    understand several issues
  • Applications
  • Platforms
  • File types and their use
  • Data value
  • Regulatory/Compliance requirements
  • Growth requirements - Scalability
  • Availability needs - Redundancy
  • Performance requirements
  • Disaster Recovery
  • Staff expertise and availability
  • Budget

19
NAS Network Attached Storage
  • NAS provides a simple effective way to share
    files in a Local Area Network
  • NAS devices are file server appliances
  • Appliance gt simple to install, configure and
    manage
  • Use industry standard network filing protocols
    over TCP/IP, i.e. connect to existing LAN
  • NAS has achieved broad market penetration, from
    low end through to high end to SANs

20
SAN - Storage Area Network
  • Storage is networked behind file servers
  • Allows consolidation and better utilization of
    storage through virtualization
  • Better support for high availability
    configurations for business continuance and
    disaster recover
  • Non-disruptive expansion and maintenance
  • SAN ROI estimates range from 65-297 percent
  • Today SANs use Fibre Channel expensive, and have
    only penetrated high end

Source CSFB, June 2001
21
IP SANs
  • Cost and inter-operability problems of Fibre
    Channel have limited take up of SANs
  • IP Storage protocols (iSCSI etc.) have been
    developed to allow SANs to be implemented over
    standard Gigabit and 10 Gigabit Ethernet Networks
  • They leverage many existing Internet protocols,
    for security, discovery, zoning etc.
  • This allows low cost IP-SANs to be deployed using
    standard networking infrastructure

Servers
GB Ethernet Switches
Native TCP/IP with Industry Standard iSCSI
encapsulation Gig E.
22
Other Important Considerations
  • Ease of management
  • Snapshot
  • Mirroring
  • Remote replication (disaster recovery)

23
Navigating Today's Enterprise Storage Requirements
Jim Addlesberger CEO NavigateStorage
Sponsored by
24
Poll 3 Placeholder
  • Do you think that NAS may someday replace tape as
    the backup medium of choice?
  • Yes
  • No

25
Emerging Networked Storage Market
Steve Kenniston Technology Analyst Enterprise
Storage Group
Sponsored by
26
Drivers of Networked Storage
  • File based data is still growing at 50 year
    over year
  • Data today has a whole new set of values
  • Reference Information is driving new market opps.
  • Regulatory and Compliance are driving on line
    data
  • The premise of NAS is it is easy to manage
  • IT needs this

27
Networked Storage Grows
NAS Spending Snapshot
NAS Spending
NAS Spending
US Billions
Source Enterprise Storage Group - 2002
28
Reference Information
  • Unique Attributes
  • Larger average file size
  • One 4 sec QuickTime movie clip (3,300KB) consumes
    68 times more storage as a single jpeg image
    (1200x800 d.p.i.) (49KB)
  • Increased retention periods
  • Decades become indefinite Financial Services,
    Health Care, Government
  • Information authenticity, integrity, and security
  • High frequency of collaboration increased
    likelihood of concurrent file access
  • Collaborative software development, CAD/CAM,
    Print / Publishing
  • On line access unlocks incremental value
  • Reducing access time to data empowers
    organizations to fulfill RFIs more quickly,
    reduces cost and delivers revenues to the bottom
    line

29
Reference Information Capacity Growth
Reference Information will surpass all other
information types by the end of 2004
75 CAGR
92 CAGR
61 CAGR
Terabytes
Source Enterprise Storage Group, June 2002
30
Things to Pay Attention to
  • Know your business
  • What applications support NAS and which data
    makes sense to live on a NAS device
  • NAS creep these things multiply
  • Figure out how to manage
  • Value added software integration
  • What is required for business success backup,
    replication, virus protection, etc
  • NAS and Networked Storage is evolving

31
Emerging Networked Storage Market
Steve Kenniston Technology Analyst Enterprise
Storage Group
Sponsored by
32
Windows-Powered NAS Solutions
Jared Vishney Senior Manager, Solutions
Marketing Iomega Corporation
Sponsored by
33
Buying Criteria, Purchasing Requirements
  • Reliability
  • Compatibility with current installed
    environment
  • Service technical support
  • Improves a business process
  • Ease of maintenance
  • Good value

34
Typical Deployment Scenario Workgroup Storage
  • Expand storage capacity for both server and
    clients
  • Keeps storage accessible and available while
    minimizing costs
  • Supports collaborative, heterogeneous workgroups
  • Extends life of general purpose servers

Windows-based General Purpose Server
Macintosh Client
Windows Client
T-1 Link
Ethernet
UNIX Client
Remote Site 1
35
Typical Deployment Scenario Email storage
  • Off-load e-mail archives or attachments to a NAS
    device
  • Improves server backup
  • Extends life of e-mail server
  • Minimizes client mailbox restrictions
  • Optimizes e-mail server performance
  • Enables easier compliance with new retention
    regulations

E-mail Server
E-mail Client
E-mail Attachments
Ethernet
36
Typical Deployment Scenario Storage Consolidation
  • Expand storage capacity for both server and
    clients
  • Eliminates islands of data
  • Single logical view of data that can be expanded
    as required
  • Simplifies storage management and maintenance
    costs
  • Extends life of general purpose servers

8 Devices x 80 GB 640 GB
1.44TB Logical Volume
Aggregated using Dfs
  • More than half of IT storage costs are associated
    with personnel
  • 71 cost savings in people management resources
    when processes and resources are consolidated
  • Source IDC 02-150HARDWA3289, March 2002

37
Typical Deployment Scenario Backup to NAS
Archive to Tape
Server
Iomega NAS
Tape
Ultra SCSI-3
Ethernet
Near-Line Data
Off-Line Data
Live Data
  • Back-up in real-time
  • Actual data is immediately available
  • Fast time to data
  • Disk-to-disk near-line recovery
  • Archive/disaster recovery Solution
  • Tapes can be stored off site
  • Network traffic to tape is eliminated
  • Allows complete back-up within back-up window

38
Windows-Powered NAS Solutions
Jared Vishney Senior Manager, Solutions
Marketing Iomega Corporation
Sponsored by
39
Poll Placeholder
If you would like to receive more information
from Iomega and Microsoft, please -Click here
Sponsored by
40
QA Panel Discussion
Moderator
Matthew Sarrel
Featured Speakers
Sponsor Speaker
Henry Baltazar
Steve Kenniston
Jim Addlesberger
Jared Vishney
Sponsored by
41
Thank You...
... for attending todays online seminar
sponsored by Iomega and Microsoft.
Sponsored by
42
Attendee Services
  • Download a copy of todays presentation
  • View our calendar of upcoming events
  • A recorded version of this seminar will be
    available at www.webseminarslive.com
  • Survey Eligible for a FREE gift from Ziff Davis
    Media

Sponsored by
