WELCOME
  • To ELECTRONICS AND COMMUNICATION DEPARTMENT

2
WORKSHOP TRAINING
  • JULY 2011
  • DEPARTMENT OF ELECTRONICS AND COMMUNICATION
    ENGINEERING

3
Topics to be Covered
  • Section-I
  • Introduction
  • Electronics Components
  • Semiconductor Physics
  • Electronic devices
  • Basic of Digital Electronics
  • Electronics Instrumentation
  • Section-II
  • Project Work

4
Introduction
5
  • Electronics---
  • It is the word derived from electron which is
    present in all materials.
  • The Branch of science and engineering which deals
    with the flow of electrons through vacuum or gas
    or semiconductor is known as electronics.

6
(No Transcript)
7
Applications of Electronics
  • Electronics is available in every sphere of life.
  • Electronics deals in the micro and milli range of
    voltage, current and power, and controls kilo,
    mega volts, amperes and watts.
  • 1. Communications And entertainments
  • 2.Industrial Applications
  • 3. Defence Applications
  • 4. Applications in Medical sciences
  • 5.Applications in Auto mobiles
  • 6.Digital Electronics
  • 7.Instrumentation

8
Communications And entertainments

Heinrich Hertz
9
(No Transcript)
10
Industrial Applications
11
Defence Applications
12
Applications in Medical sciences
13
Applications in Auto mobiles
14
Digital Electronics
15
Instrumentation
16
QUIZ
  • MSI means?
  • Birth of electronics took place in 1897 with the
    invention of ..?
  • The system of units adopted in INDIA is.?
  • The term giga stands for.?
  • The term eV stands for..?
  • The charge on an electron is.coulomb?
  • The term micro stands for..?
  • The term pico stands for..?
  • The velocity of light is..m/s?

17
Any Questions??
18
Electronics Components
19
TYPES OF COMPONENTS
  • ACTIVE COMPONENTS
  • The electronic components which are capable
    of amplifying or processing an electrical signal
    are called active component. Such as..
  • vacuum diodes, vacuum triodes, vacuum
    pentode, gas diodes, zener diodes, transistor,
    field effect transistor, unijunction transistors,
    silicon control rectifier, tunnel diode etc.

20
  • PASSIVE COMPONENTS
  • Components which are not capable of amplifying
    or processing an electrical signal are called
    passive components
  • such as resistor, capacitor and inductor.

21
Passive components
  • RESISTORS

22
Symbol Of Resistor (R)
  • It is used to limit the amount of current or
    divide the voltage in an electronic circuit.
  • MATHEMATICAL - R (? L) / A
  • REPRESENTATION

23
RESISTANCE
  • The ability of resistor to oppose the flow of
    current is called Resistance.
  • Unit of resistance R is ohm.

ohm
24
Types of Resistors
  • There are two main Characteristics of resistance
  • Resistance in ohms
  • Power rating in watts
  • FIXED RESISTORS
  • Carbon-composition Resistors
  • Made of mixture of carbon or graphite
  • And clay. Two materials are mixed in the
    proportion for the desired value of R.

25
Carbon composition
  • A


    broken resistor showing the ceramic
    core.

A carbon resistor with and without the outer
paint.
26
  • Carbon composition are readily available in
    values ranging from 1 ohm to 22 Mega ohm, having
    a tolerance range of
  • 5 to 20 .
  • FILM TYPE RESISTOR

27
Wire wound resistor
  • Nichrome, tungsten is used for wires.
  • Hollow porcelain cylinder
  • Ends are joined with metal
  • pieces.
  • Assembly is coated with
  • enamel containing powdered
  • Glass.

28
Resistor colour coding
29
  • B
  • B
  • R
  • O
  • Y
  • G
  • B
  • V
  • G
  • W

30
Question
  • A resistor has a colour band sequence red,
    black, red, gold
  • first digit----2
  • second digit0
  • third
    multiplier----100 ohm

  • gold--------------5

  • result----2000ohm or 2 k ohm with 5
  • tolerance

31
Question????
32
Variable Resistors
  • Some times it is require to change the value of
    resistance while in circuit such as voice
    controller, or speed controller, brightness
    controller etc.
  • This can be done with the held of variable
    resistor. These resistors can be carbon
    composition or wire wound.
  • Carbon composition Resistor
  • Wire wound variable Resistor

33
Carbon composition resistor
  • A thin carbon coating on pressed paper or a
    molded carbon disc constitutes the carbon
  • composition resistance element.
  • Available from 1000 ohm to
  • 5Mohm.
  • Power rating from1/2 to 2W.

34
Wire Wound variable Resistors
Wire wound adjustable resistor
Adjustable Contact
Fixed contact
35
  • Wire is wound over a dough shaped core of
    Bakelite or ceramic.
  • The two ends of the resistance wire are joined to
    the external soldering plug terminals. 1 and 3.
  • The middle terminal is connected to the variable
    arm that contacts the resistor element.

36
Quiz
  • The electronic component which cannot process the
    signal are called components.
  • The electronic component which can process the
    signal are calledcomponents.
  • The resistors are rated inand..
  • When there are only three color bands on the
    resistor, the tolerance is
  • The third band on the resistor shows the.
  • 180ohm and 10 tolerance, the colour bands in the
    sequence will be

37
ELECTRONICS INSTRUMENTS
38
CONTENTS
  • INTRODUCTION TO CRO
  • FUNCTION GENERATOR
  • DSO
  • MULTIMETER (DIGITAL AND ANALOG)

39
CRO
  • Cathode ray oscilloscope
  • It is used for the development of electronic
    circuits.
  • It shows the amplitude of electrical
    signals(power, current or voltage)as a function
    of time.
  • CRO is faster than other devices.

40
BLOCK DIAGRAM OF CRO
41
BLOCK DIAGRAM
  • (i) Cathode ray tube
  • (ii) vertical deflection system
  • (iii) delay line
  • (iv) horizontal deflection system
  • (v) Trigger circuit
  • (vi) Time base
  • (vii) Power Supply

42
CRT
43
  • Electron gun produces an electron beam.
  • This beam is allowed to pass down the tube and to
    fall on the screen.
  • The screen is formed by the flat end of glass
    tube which is coated with the fluorescent
    material.
  • The point at which the electron beam strikes the
    screen, a spot is formed.
  • Beam passes through two plates i.e, vertical
    deflection plates and horizontal deflection
    plates.

44
  • Electron Gun Assembly
  • Consist of heater, focusing anodes and cathode.

45
(No Transcript)
46
FLOURESCENT SCREEN
  • The front end of CRT acts as a Fluorescent
    Screen. Inner side is coated with phosphor.
  • A phosphor converts the electrical energy to
    light energy. Phosphor crystals get excited and
    they emit light. This phenomenon is called
    fluorescence.

47
HORIZONTAL DEFLECTION SYSTEM
  • Time base generator
  • Trigger circuit
  • Horizontal amplifier

48
Time base generator
  • It generate saw tooth voltage, which will deflect
    the beam in the horizontal direction.
  • The CRT spot is deflected at a constant time
    dependant rate because of the voltage.
  • TRIGGER CIRCUIT
  • This circuit ensures that the horizontal sweep
    begins at the same point of the vertical input
    signal.
  • Without this there is no synchronization between
    sweep signal and the signal which is to be
    observed on the vertical deflection plates.

49
DELAY LINE
  • Every electronic circuit which are used in
    oscilloscope take certain time for the required
    operation. such as attenuators, amplifiers,
    waveshapers etc.
  • So Delay line is used to delay the signal for
    some time in the vertical sections. Generally, a
    time delay of 200 ns is provided to observe the
    leading edge of the waveforms.
  • the time delay at the horizontal deflecting
    plates the time delay is about 80ns.
  • Thus horizontal sweep starts prior to the
    vertical sweep.

50
FRONT PANEL CONTROL OF CRO
  • Basic general purpose controls
  • Controls in the Vertical Section
  • Controls in the Horizontal Section
  • Special Controls

51
(No Transcript)
52
Display
  • A is the display. This can be a phosphor screen
    or an LCD, and is usually about 100mm corner to
    corner.
  • B shows the trace. This is the line drawn by the
    scope to represent the signal. On a CRO, this
    line is created by a bright dot moving across the
    screen at high speed (sometimes faster than the
    speed of light - because nothing
    is physically moving across the screen, this does
    not break any rules). On a digital scope, the
    line is drawn on the LCD like a graphical
    calculator.
  • The screen is overlaid with a grid of horizontal
    (C) and vertical (D) lines, called the graticule,
    which divides the screen into squares,
    called major divisions. The graticule is usually
    10 major divisions wide and 8 tall.
  • The central horizontal and vertical lines (E) are
    usually thicker than the others and are divided
    into minor divisions, usually five per major
    division. When we talk about "divisions" in later
    sections, we will always mean the major divisions
    - the minor divisions are just to aid measuring.
  • There are also special horizontal lines labeled
    "0" (2.5 divisions below the centre) and "100"
    (2.5 divisions above it). The "10" and "90" lines
    have tick marks like the central axes. These four
    horizontal lines are guides for scaling the
    signal for rise-time measurement.

53
Power, Calibration and Display Controls
  • 1 is the Power On/Off Button. 2 is the Power
    Indicator which lights when the oscilloscope is
    on. This may be an LED in newer scopes or a neon
    tube in older scopes.
  • 3 is the trace rotation (TR) control. This sets
    the inclination of a flat signal relative to the
    graticule. This is usually a Trimpot and needs to
    be set using a flat-bladed screwdriver. Once set,
    this control should retain its position and will
    rarely need adjusting.
  • 4 is the intensity of the trace. Turning this up
    increases the brightness of the trace, and
    turning it down makes it dimmer. An overly bright
    trace can damage the phosphor of the screen if
    the dot is moving too slowly.
  • The trace can get fuzzy if the electron beam is
    not focused correctly. The focus control (5) sets
    this. Most scopes can focus the beam to form a
    trace about 1mm wide.
  • 6 is the calibration point. This gives a steady
    square wave at a set frequency and voltage,
    allowing the scaling of the trace to be set
    accurately. Sometimes, more than one frequency
    and voltage is available to give a more
    representative calibration. The standard
    calibration signal is between 0V and 2V at 1KHz.

54
Vertical Axis Controls
  • When plotting a signal against time (the standard
    use for a scope), the vertical axis represents
    voltage. Most controls for the vertical axis are
    duplicated for each channel to give independent
    control over each signal.
  • 7 controls the position of the trace. It can be
    adjusted to set the voltage relative to a ground,
    or it can be adjusted to separate the two signals
    - perhaps the first channel in the top half of
    the screen and the second channel in the bottom.
  • 8 inverts the relevant channel. That is, the
    negative voltage is displayed, and the trace is
    upside-down.
  • 9 is the vertical scale control, often called the
    volts/div. control. This sets the height of the
    trace. It operates in discrete steps.
  • 10 is a variable height control. It can adjust
    the height of the trace up to the next set
    increment on the volts/div. control. When set to
    CAL, the height is as stated on the volts/div.
    control.
  • 11 is the AC/DC toggle. When set to AC, any DC
    component of the voltage is filtered out by
    switching a capacitor in series with the input
    signal, leaving just an AC voltage. This is
    useful when the DC component swamps the AC
    component, making it either too small to see or
    driving it off the top of the screen. When set to
    DC, the signal is displayed as is.

55
  • 12 is the GND toggle. By selecting this, the
    input signal is ignored, and the trace shows 0V.
    This can be useful to measure a voltage or to
    eliminate one of the traces from the display.
  • 13 is the Channel 1 signal input and 14 is the
    Channel 2 input. This is where the oscilloscope's
    probe is plugged in.
  • Each channel has a copy of most of these controls
    (except chop/alt, which applies to all channels).
    The way the channels are combined is set
    using 15, which is usually a sliding switch. When
    set to CH. 1, only the trace from Channel 1 is
    displayed, and likewise for CH. 2. When DUAL is
    selected, the traces are shown side by side. This
    is when the chop/alt control applies. ADD shows
    the sum of the two traces as one trace. By
    inverting the traces, one can be subtracted from
    the other. This can be seen in the illustration
    below. This shows a square wave on one channel
    and a sinusoidal wave on the other. On the left,
    the scope is set to "dual", and the two traces
    are shown side by side. On the right, the scope
    is set to "add", and the trace is the sum of the
    two signals.

56
Horizontal Axis Controls
  • When operating in the normal voltage vs. time
    mode, this axis represents time. The primary
    control is the time base selector, 19. The time
    base is the length of time displayed per major
    horizontal division on the screen. This ranges
    from about 0.1 milliseconds to about 1 second (or
    more on digital scopes).
  • The position of the trace from side to side is
    controlled by 17. This is useful if part of the
    trace is off the edge of the screen but you don't
    want to change the time base.
  • The 10 MAG control, 16, is a very useful control
    if you want to quickly zoom in on a feature
    without changing the timebase and losing your
    settings. This buttom magnifies the central area
    of the trace by a factor of 10 in the horizontal
    direction (but leaves the voltage height
    unchanged).
  • 18 toogles the mode between the usual voltage vs.
    time format and the XY mode. This continuously
    plots the voltage on Channel 1 along the
    horizontal axis against the voltage on Channel 2
    (the vertical axis). This can be extremely useful
    to analyse frequency or phase relationships. This
    is a complex topic, and will be covered in its
    own section later in the module.
  • 20 and 21 act in much the same way as 10 does on
    the vertical axis. This diagram shows it to be
    slighly different from the vertical control. To
    select a non-standard timebase, press 20, and
    adjust 20 until the correct setting is obtained.
    To return to a calibrated time base, press 20
    again. Sometimes these controls are the same
    style as 10, sometimes the vertical controls are
    like these.

57
  • 22 is the GND terminal of the scope. This is used
    to set a "datum" voltage against which to measure
    the voltages on the input channels. Be careful
    when using isolated mains voltage circuits, as
    the "ground" is sometines floating at mains
    voltage, and can short to the real ground,
    casuing injury or death.
  • 23 toggles between chop-mode and alt-mode.
    Chop-mode means that when the scope is drawing
    two signals side by side it alternates rapidly
    between the two over the course of passing across
    the screen. This action is called chopping.
    Alt-mode alternates at the end of each pass, and
    can appear to flicker at slow speeds.

58
FUNCTION GENERATOR
59
  • Function generator is an instrument which
    produces different functions (waveforms)at the
    output.
  • A function generator can be capable of generating
    Sine, square and triangular functions
    simultaneously at the output.
  • Range of frequencies is from few Hz to several
    MHz.
  • Amplitude range is from mv to few tens of volts
    rms.

60
Block Diagram of Function generator
61
Working
  • Frequency control can be internal or external.
  • If external then DC voltage is applied.
  • Upper and lower current sources supply constant
    DC currents I1 and I2 opposite in directions.
  • Let upper supply is ON and supplying dc constant
    current I1
  • to an integrator. Now the output of an
    integrator is
  • Voi1/c?I1 dt
  • Voi is the linear ramp wave increasing towards
    positive as shown in fig.

62
(No Transcript)
63
  • Ramp voltage is less than upper triggering
    point(UTP).

64
Features of Function Generator
  • Freq range- 0.01Hz to 100 KHz
  • It can produce different waveforms like sine,
    square, triangular, sawtooth etc.
  • Accuracy is within (-1)
  • Distortion is less than 1 for sine wave.

65

66
DSO (Digital storage oscilloscope)
67
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
