Chemistry: Matter and Change

1
(No Transcript)
2
Chapter Menu
Analyzing Data
Section 2.1 Units and Measurements Section 2.2
Scientific Notation and Dimensional
Analysis Section 2.3 Uncertainty in Data Section
2.4 Representing Data
Click a hyperlink or folder tab to view the
corresponding slides.
Exit
3
Section 2-1
Section 2.1 Units and Measurements

• Define SI base units for time, length, mass, and
  temperature.

• Explain how adding a prefix changes a unit.
• Compare the derived units for volume and density.

mass a measurement that reflects the amount of
matter an object contains
4
Section 2-1
Section 2.1 Units and Measurements (cont.)
base unit second meter kilogram
kelvin derived unit liter density
Chemists use an internationally recognized system
of units to communicate their findings.
5
Section 2-1
Units

• Système Internationale d'Unités (SI) is an
  internationally agreed upon system of
  measurements.

• A base unit is a defined unit in a system of
  measurement that is based on an object or event
  in the physical world, and is independent of
  other units.

6
Section 2-1
Units (cont.)
7
Section 2-1
Units (cont.)
8
Section 2-1
Units (cont.)

• The SI base unit of time is the second (s),
  based on the frequency of radiation given off by
  a cesium-133 atom.

• The SI base unit for length is the meter (m), the
  distance light travels in a vacuum in
  1/299,792,458th of a second.
• The SI base unit of mass is the kilogram (kg),
  about 2.2 pounds

9
Section 2-1
Units (cont.)

• The SI base unit of temperature is the kelvin (K).

• Zero kelvin is the point where there is virtually
  no particle motion or kinetic energy, also known
  as absolute zero.
• Two other temperature scales are Celsius and
  Fahrenheit.

10
Section 2-1
Derived Units

• Not all quantities can be measured with SI base
  units.

• A unit that is defined by a combination of base
  units is called a derived unit.

11
Section 2-1
Derived Units (cont.)

• Volume is measured in cubic meters (m3), but this
  is very large. A more convenient measure is the
  liter, or one cubic decimeter (dm3).

12
Section 2-1
Derived Units (cont.)

• Density is a derived unit, g/cm3, the amount of
  mass per unit volume.

• The density equation is density mass/volume.

13
Section 2-1
Section 2.1 Assessment
Which of the following is a derived unit?
A. yard B. second C. liter D. kilogram

1. A
2. B
3. C
4. D

14
Section 2-1
Section 2.1 Assessment
What is the relationship between mass and volume
called? A. density B. space C. matter D. weight

1. A
2. B
3. C
4. D

15
End of Section 2-1
16
Section 2-2
Section 2.2 Scientific Notation and Dimensional
Analysis

• Express numbers in scientific notation.

• Convert between units using dimensional analysis.

quantitative data numerical information
describing how much, how little, how big, how
tall, how fast, and so on
17
Section 2-2
Section 2.2 Scientific Notation and Dimensional
Analysis (cont.)
scientific notation dimensional
analysis conversion factor
Scientists often express numbers in scientific
notation and solve problems using dimensional
analysis.
18
Section 2-2
Scientific Notation

• Scientific notation can be used to express any
  number as a number between 1 and 10 (the
  coefficient) multiplied by 10 raised to a power
  (the exponent).

• Count the number of places the decimal point must
  be moved to give a coefficient between 1 and 10.

19
Section 2-2
Scientific Notation (cont.)

• The number of places moved equals the value of
  the exponent.

• The exponent is positive when the decimal moves
  to the left and negative when the decimal moves
  to the right.

800 8.0 ? 102 0.0000343 3.43 ? 105
20
Section 2-2
Scientific Notation (cont.)

• Addition and subtraction

• Exponents must be the same.
• Rewrite values with the same exponent.
• Add or subtract coefficients.

21
Section 2-2
Scientific Notation (cont.)

• Multiplication and division

• To multiply, multiply the coefficients, then add
  the exponents.
• To divide, divide the coefficients, then subtract
  the exponent of the divisor from the exponent of
  the dividend.

22
Section 2-2
Dimensional Analysis

• Dimensional analysis is a systematic approach to
  problem solving that uses conversion factors to
  move, or convert, from one unit to another.

• A conversion factor is a ratio of equivalent
  values having different units.

23
Section 2-2
Dimensional Analysis (cont.)

• Writing conversion factors

• Conversion factors are derived from equality
  relationships, such as 1 dozen eggs 12 eggs.
• Percentages can also be used as conversion
  factors. They relate the number of parts of one
  component to 100 total parts.

24
Section 2-2
Dimensional Analysis (cont.)

• Using conversion factors

• A conversion factor must cancel one unit and
  introduce a new one.

25
Section 2-2
Section 2.2 Assessment
What is a systematic approach to problem solving
that converts from one unit to another?
A. conversion ratio B. conversion
factor C. scientific notation D. dimensional
analysis

1. A
2. B
3. C
4. D

26
Section 2-2
Section 2.2 Assessment
Which of the following expresses 9,640,000 in the
correct scientific notation? A. 9.64 ? 104
B. 9.64 ? 105 C. 9.64 106 D. 9.64 ? 610

1. A
2. B
3. C
4. D

27
End of Section 2-2
28
Section 2-3
Section 2.3 Uncertainty in Data

• Define and compare accuracy and precision.

• Describe the accuracy of experimental data using
  error and percent error.
• Apply rules for significant figures to express
  uncertainty in measured and calculated values.

experiment a set of controlled observations that
test a hypothesis
29
Section 2-3
Section 2.3 Uncertainty in Data (cont.)
accuracy precision error
percent error significant figures
Measurements contain uncertainties that affect
how a result is presented.
30
Section 2-3
Accuracy and Precision

• Accuracy refers to how close a measured value is
  to an accepted value.

• Precision refers to how close a series of
  measurements are to one another.

31
Section 2-3
Accuracy and Precision (cont.)

• Error is defined as the difference between and
  experimental value and an accepted value.

32
Section 2-3
Accuracy and Precision (cont.)

• The error equation is error experimental value
  accepted value.

• Percent error expresses error as a percentage of
  the accepted value.

33
Section 2-3
Significant Figures

• Often, precision is limited by the tools
  available.

• Significant figures include all known digits plus
  one estimated digit.

34
Section 2-3
Significant Figures (cont.)

• Rules for significant figures

• Rule 1 Nonzero numbers are always significant.
• Rule 2 Zeros between nonzero numbers are always
  significant.
• Rule 3 All final zeros to the right of the
  decimal are significant.
• Rule 4 Placeholder zeros are not significant.
  To remove placeholder zeros, rewrite the number
  in scientific notation.
• Rule 5 Counting numbers and defined constants
  have an infinite number of significant figures.

35
Section 2-3
Rounding Numbers

• Calculators are not aware of significant figures.

• Answers should not have more significant figures
  than the original data with the fewest figures,
  and should be rounded.

36
Section 2-3
Rounding Numbers (cont.)

• Rules for rounding

• Rule 1 If the digit to the right of the last
  significant figure is less than 5, do not change
  the last significant figure.
• Rule 2 If the digit to the right of the last
  significant figure is greater than 5, round up to
  the last significant figure.
• Rule 3 If the digits to the right of the last
  significant figure are a 5 followed by a nonzero
  digit, round up to the last significant figure.

37
Section 2-3
Rounding Numbers (cont.)

• Rules for rounding (cont.)

• Rule 4 If the digits to the right of the last
  significant figure are a 5 followed by a 0 or no
  other number at all, look at the last significant
  figure. If it is odd, round it up if it is even,
  do not round up.

38
Section 2-3
Rounding Numbers (cont.)

• Addition and subtraction

• Round numbers so all numbers have the same number
  of digits to the right of the decimal.

• Multiplication and division

• Round the answer to the same number of
  significant figures as the original measurement
  with the fewest significant figures.

39
Section 2-3
Section 2.3 Assessment
Determine the number of significant figures in
the following 8,200, 723.0, and 0.01. A. 4,
4, and 3 B. 4, 3, and 3 C. 2, 3, and 1 D. 2, 4,
and 1

1. A
2. B
3. C
4. D

40
Section 2-3
Section 2.3 Assessment
A substance has an accepted density of 2.00 g/L.
You measured the density as 1.80 g/L. What is the
percent error? A. 20 B. 20 C. 10 D. 90

1. A
2. B
3. C
4. D

41
End of Section 2-3
42
Section 2-4
Section 2.4 Representing Data

• Create graphics to reveal patterns in data.

independent variable the variable that is
changed during an experiment

• Interpret graphs.

graph
Graphs visually depict data, making it easier to
see patterns and trends.
43
Section 2-4
Graphing

• A graph is a visual display of data that makes
  trends easier to see than in a table.

44
Section 2-4
Graphing (cont.)

• A circle graph, or pie chart, has wedges that
  visually represent percentages of a fixed whole.

45
Section 2-4
Graphing (cont.)

• Bar graphs are often used to show how a quantity
  varies across categories.

46
Section 2-4
Graphing (cont.)

• On line graphs, independent variables are plotted
  on the x-axis and dependent variables are plotted
  on the y-axis.

47
Section 2-4
Graphing (cont.)

• If a line through the points is straight, the
  relationship is linear and can be analyzed
  further by examining the slope.

48
Section 2-4
Interpreting Graphs

• Interpolation is reading and estimating values
  falling between points on the graph.

• Extrapolation is estimating values outside the
  points by extending the line.

49
Section 2-4
Interpreting Graphs (cont.)

• This graph shows important ozone measurements and
  helps the viewer visualize a trend from two
  different time periods.

50
Section 2-4
Section 2.4 Assessment
____ variables are plotted on the ____-axis in a
line graph. A. independent, x B. independent,
y C. dependent, x D. dependent, z

1. A
2. B
3. C
4. D

51
Section 2-4
Section 2.4 Assessment
What kind of graph shows how quantities vary
across categories? A. pie charts B. line
graphs C. Venn diagrams D. bar graphs

1. A
2. B
3. C
4. D

52
End of Section 2-4
53
Resources Menu
Chemistry Online Study Guide Chapter
Assessment Standardized Test Practice Image
Bank Concepts in Motion
54
Study Guide 1
Section 2.1 Units and Measurements
Key Concepts

• SI measurement units allow scientists to report
  data to other scientists.

• Adding prefixes to SI units extends the range of
  possible measurements.
• To convert to Kelvin temperature, add 273 to the
  Celsius temperature. K C 273
• Volume and density have derived units. Density,
  which is a ratio of mass to volume, can be used
  to identify an unknown sample of matter.

55
Study Guide 2
Section 2.2 Scientific Notation and Dimensional
Analysis
Key Concepts

• A number expressed in scientific notation is
  written as a coefficient between 1 and 10
  multiplied by 10 raised to a power.

• To add or subtract numbers in scientific
  notation, the numbers must have the same
  exponent.
• To multiply or divide numbers in scientific
  notation, multiply or divide the coefficients and
  then add or subtract the exponents, respectively.

• Dimensional analysis uses conversion factors to
  solve problems.

56
Study Guide 3
Section 2.3 Uncertainty in Data
Key Concepts

• An accurate measurement is close to the accepted
  value. A set of precise measurements shows little
  variation.

• The measurement device determines the degree of
  precision possible.
• Error is the difference between the measured
  value and the accepted value. Percent error gives
  the percent deviation from the accepted value.
• error experimental value accepted value

57
Study Guide 3
Section 2.3 Uncertainty in Data (cont.)
Key Concepts

• The number of significant figures reflects the
  precision of reported data.

• Calculations should be rounded to the correct
  number of significant figures.

58
Study Guide 4
Section 2.4 Representing Data
Key Concepts

• Circle graphs show parts of a whole. Bar graphs
  show how a factor varies with time, location, or
  temperature.

• Independent (x-axis) variables and dependent
  (y-axis) variables can be related in a linear or
  a nonlinear manner. The slope of a straight line
  is defined as rise/run, or ?y/?x.

• Because line graph data are considered
  continuous, you can interpolate between data
  points or extrapolate beyond them.

59
Chapter Assessment 1
Which of the following is the SI derived unit of
volume? A. gallon B. quart C. m3 D. kilogram

1. A
2. B
3. C
4. D

60
Chapter Assessment 2
Which prefix means 1/10th? A. deci-
B. hemi- C. kilo- D. centi-

1. A
2. B
3. C
4. D

61
Chapter Assessment 3
Divide 6.0 ? 109 by 1.5 ? 103. A. 4.0 ? 106
B. 4.5 ? 103 C. 4.0 ? 103 D. 4.5 ? 106

1. A
2. B
3. C
4. D

62
Chapter Assessment 4
Round the following to 3 significant figures
2.3450. A. 2.35 B. 2.345 C. 2.34 D. 2.40

1. A
2. B
3. C
4. D

63
Chapter Assessment 5
The rise divided by the run on a line graph is
the ____. A. x-axis B. slope C. y-axis D. y-int
ercept

1. A
2. B
3. C
4. D

64
STP 1
Which is NOT an SI base unit? A. meter
B. second C. liter D. kelvin

1. A
2. B
3. C
4. D

65
STP 2
Which value is NOT equivalent to the others?
A. 800 m B. 0.8 km C. 80 dm D. 8.0 x 105 cm

1. A
2. B
3. C
4. D

66
STP 3
Find the solution with the correct number of
significant figures25 ? 0.25 A. 6.25
B. 6.2 C. 6.3 D. 6.250

1. A
2. B
3. C
4. D

67
STP 4
How many significant figures are there in
0.0000245010 meters? A. 4 B. 5 C. 6 D. 11

1. A
2. B
3. C
4. D

68
STP 5
Which is NOT a quantitative measurement of a
liquid? A. color B. volume C. mass D. density

1. A
2. B
3. C
4. D

69
IB Menu
Click on an image to enlarge.
70
IB 1
71
IB 2
72
IB 3
73
IB 4
74
IB 5
75
IB 6
76
IB 7
77
IB 8
78
IB 9
79
IB 10
80
IB 11
81
IB 12
82
CIM
Table 2.2 SI Prefixes Figure 2.10 Accuracy and
Precision
83
Help
Click any of the background top tabs to display
the respective folder.
Within the Chapter Outline, clicking a section
tab on the right side of the screen will bring
you to the first slide in each respective section.
Simple navigation buttons will allow you to
progress to the next slide or the previous slide.
The Chapter Resources Menu will allow you to
access chapter specific resources from the
Chapter Menu or any Chapter Outline slide. From
within any feature, click the Resources tab to
return to this slide.
The Return button will allow you to return to
the slide that you were viewing when you clicked
either the Resources or Help tab.
To exit the presentation, click the Exit button
on the Chapter Menu slide or hit Escape Esc on
your keyboards while viewing any Chapter Outline
slide.
84
End of Custom Shows
This slide is intentionally blank.
