Forensic Toxicology

1
Forensic Toxicology

• Chapter 10

2
What is Forensic Toxicology?

• The detection and identification of drugs or
  poisons present in body fluids, tissues and
  organs.

3
The Biggest Culprit

• Alcohol is the most abused drug in the West and
  most likely the world.
• 40 of all traffic accidents are alcohol related.
• So the most numbers of samples sent to forensic
  toxicology labs are alcohol related.

4
What is Alcohol?

• Organic compound
• Carbon and hydrogen backbone with at least one
  hydroxyl group (OH)
• Many types, depending on the number of carbons
  present
• Humans consume Ethyl Alcohol or Ethanol

• Colorless liquid
• Produced when yeast ferment grain, fruit and
  other vegetation such as potatoes

5
Toxicology of Alcohol

• What happens to alcohol once it enters the body?
• Consumption / Ingestion
• Absorption into bloodstream
• It then crosses the blood-brain barrier into
  neurons, affecting the Central Nervous System
  (CNS)
• Elimination
• Oxidation (alcohol is changed to other products)
• Excretion (alcohol is unchanged)

6
How do we measure alcohol levels?

• The most obvious measure of intoxication would be
  to see how much an individual has consumed
• This is impossible for a forensic toxicologist
  for several reasons
• He wasnt present (Duh!)
• Persons body weight varies
• Rate of alcohol absorption into bloodstream
  varies

7
(No Transcript)
8
This is your brain on ethanol

• The Absolute (no pun intended) best way to check
  for intoxication would be to check brain tissue
• This is also impossible for obvious reasons
  unless the person in question is dead.

9
The next best thing

• So forensic toxicologists concentrate on blood.
• Blood circulates the consumed alcohol to ALL body
  tissues
• The concentration of alcohol in the blood is
  directly proportional to the concentration of
  alcohol in the brain

10
The Route Alcohol Takes

• Mouth ? Esophagus ? Stomach ? Small Intestine ?
  Bloodstream
• Alcohol is absorbed across the lining of the
  small intestine, into the bloodstream (some
  absorption can occur across stomach wall also)
• This happens within minutes of consumption
• The blood concentration levels keep increasing as
  more and more alcohol gets absorbed across S.I.

11
The path alcohol follows to your brain, via
bloodstream
12
The Rate of Absorption

• Several factors affect the rate of absorption
• The amount of alcohol consumed
• What was the alcohol content (or proof) of the
  beverage?
• The rate at with it was consumed (1 beer over 1
  hour, or 1 beer over 1 minute)
• How much food was in the stomach?

13
You need to absorb this material!

• The longer it takes for all the alcohol consumed
  to be absorbed, the lower the peak alcohol
  concentration in the bloodstream.
• Food in stomach hinders/slows absorption

14
Empty vs. Full Stomach
15
After Absorption

• When all the alcohol is absorbed, its levels will
  be equally distributed in the watery tissues of
  the body (so not in fat, hair, nails, bones,
  etc.).
• If blood is not available (dead body) a
  forensic toxicologist can work with other body
  fluids and tissues Cerebrospinal fluid,
  vitreous humor, or brain

16
BAC Blood Alcohol Concentration

• It is usually measured as mass per volume and
  expressed as a percentage.
• For example, a BAC of 0.02 means 0.02 grams of
  alcohol per 100 grams of an individual's blood,
  or 0.2 grams of alcohol per 1000 grams of blood.
• BAC can vary according to the persons tolerance
  and metabolic rate

17
Can you tolerate it?

• Tolerance to alcohol varies from one person to
  another, and can be affected by such factors as
  genetics, adaptation to chronic alcohol use, and
  synergistic effects of drugs.

18
Metabolism

• The breakdown of chemicals, including alcohol
• The elimination of alcohol from the body depends
  upon the individuals metabolism.

19
Elimination by Oxidation

• Nearly all alcohol (95-98) gets oxidized.
• Oxidation Ethanol is oxidized to produce carbon
  dioxide and water
• Oxidation occurs almost entirely in the cells of
  the liver.
• Oxidation of ethanol is performed by an enzyme
  called Alcohol Dehydrogenase in the following
  process.

The Acetic Acid is then oxidized further into CO2
and H2O
20
Rate of Ethanol Oxidation

• The rate of elimination via oxidation varies from
  individual to individual, depending upon their
  metabolic rate. Oxidation is also called
  burn-off and it reduces blood-alcohol
  concentrations.
• Absorption must be complete in order for
  burn-off to reduce BAC levels.

21
Elimination by Excretion

• The 2 of ethanol that is not eliminated by
  oxidation is excreted through the breath, urine
  and perspiration.
• This excreted alcohol is not changed chemically
  it remains ethanol.

22
Breath Dragon (Alveolar breath)

• The amount of alcohol exhaled in the breath is
  directly proportionate to the concentration of
  alcohol in blood.
• When air is exhaled, it contains CO2 and alcohol
• Hence the Breathalyzer Test

23
Alveolar Breath
Pulmonary Vein
Pulmonary Artery
24
Breathalyzer

• A breathalyzer (or breathalyser) is a device for
  estimating blood alcohol content (BAC) from a
  breath sample.
• Breathalyzer is a brand name and was originally
  made by Smith and Wesson, but now is a generic
  term used for all such devices.
• Measures alcohol found in alveolar breath.

25
(No Transcript)
26
(No Transcript)
27
Wheres the Proof?

• Alcoholic proof is a measure of how much ethanol
  is in an alcoholic beverage, and is approximately
  twice the percentage of alcohol by volume
• The proof number is twice the percentage of the
  alcohol content measured by volume at a
  temperature of 60 F (15.5 C). Therefore "80
  proof" is 40 alcohol by volume, and pure alcohol
  is "200 proof".

28
(No Transcript)
29
Whats in a drink?
30
Legal BAC Levels

• The alcohol level at which a person is considered
  to be legally impaired varies by country.
• In the US the BAC limit is 0.08
• However, drivers of commercial vehicles have a
  limit of 0.04
• Sweden is one of the countries with the lowest
  level of 0.02

31
When can you drink legally?

• As of 2007, all U.S. states have a minimum
  purchase age of 21. Unlike the states, Puerto
  Rico, the U.S. Virgin Islands, and Guam have a
  minimum purchase age of 18.
• In Mexico and Canada the drinking age is lower
  than 21, which encourages young people to go to
  these countries if they live near the border.

32
The brain of a six-week old baby with Fetal
Alcohol Syndrome
Normal brain of six week old baby
33
Field Sobriety Testing

• Horizontal Gaze Nystagmus
• Walk and Turn Test
• One Leg Stand Test

34
Horizontal gaze nystagmus
35
Horizontal gaze nystagmus

• The officer attempts to estimate the angle at
  which the eye begins to jerk
• "nystagmus" is medical jargon for a distinctive
  eye oscillation
• if this occurs sooner than 45 degrees, it
  theoretically indicates a blood-alcohol
  concentration over .05.
• The smoothness of the eye's tracking the penlight
  (or finger or pencil) is also a factor, as is the
  type of jerking when the eye is as far to the
  side as it can go.

36
Walk and Turn
37
One leg stand
38
Collection and Preservation of Blood Evidence

• Must be drawn aseptically under medically
  accepted conditions
• An anticoagulant such as EDTA or potassium
  oxalate is added to prevent clotting
• A preservative such as sodium fluoride is added
  to prevent bacterial growth
• Stored in refrigerator
• Tested at a lab or medical facility

39
Other toxins in blood

• Narcotics (Heroine)
• Non-narcotic substances (Cocaine)
• Carbon Monoxide (CO)
• Heavy metals such as lead, mercury, arsenic, etc.

40
ACID vs. BASE Drugs

• Barbiturates and Aspirin (Acetylsalicylic acid)
  are acidic drugs with pHs lower than 7.
• Phencyclidine (PCP), Methadone, Amphetamines and
  Cocaine are basic drugs with pHs higher than 7.

41
Carbon Monoxide

• CO is a by product of combustion of organic
  materials (Gas, fires, etc.)
• CO has a greater affinity to hemoglobin than does
  CO2 or O2.
• CO hemoglobin carboxyhemoglobin
• So once it is inhaled an enters the bloodstream,
  it competes with O2 for hemoglobin.
• Too much CO kills death by asphyxiation

42
The fate of other drugs in the bloodstream

• Heroin gets converted into morphine once in the
  bloodstream

43
THE END
