Threads, CPU Scheduling and Deadlocks

1
Chapter 3

• Threads, CPU Scheduling and Deadlocks

2
Objectives

• After finish this chapter, you will understand
• CPU Scheduling Concept
• CPU Scheduling Criteria
• Scheduling Algorithms
• What is Deadlock Problem?
• Deadlock Characterization
• Methods for Handling Deadlocks
• Deadlock Prevention
• Deadlock Avoidance

3
I-Basic Concepts of CPU Scheduling

• CPU scheduling is the basis of multiprogrammed
  operating systems (Maximum CPU utilization)
• By switching the CPU among processes, the,
  operating system can make the computer more
  productive
• The success of CPU scheduling depends on the
  following observed property of processes Process
  execution consists of a cycle of CPU execution
  and I/O wait. CPUI/O Burst Cycle or Process
  execution consists of a cycle of CPU execution
  and I/O wait.

4
Alternating Sequence of CPU And I/O Bursts
5
CPU Scheduler

• Whenever the CPU becomes idle, the operating
  system must select one of the processes in the
  ready queue to be executed.
• The selection process is carried out by the
  short-term scheduler (or CPU scheduler).
• The scheduler selects from among the processes in
  memory that are ready to execute, and allocates
  the CPU to one of them.

6

• CPU scheduling decisions may take place when a
  process
• 1. Switches from running to waiting state.
• 2. Switches from running to ready state.
• 3. Switches from waiting to ready.
• 4. Terminates.

7
Scheduling Criteria

• CPU utilization keep the CPU as busy as
  possible
• Throughput Number of processes that complete
  their execution per time unit
• Turnaround time amount of time to execute a
  particular process
• Waiting time amount of time a process has been
  waiting in the ready queue
• Response time amount of time it takes from when
  a request was submitted until the first response
  is produced, not output.

8
Optimization Criteria

• Maximized CPU utilization
• Maximized throughput
• Minimized turnaround time
• Minimized waiting time
• Minimized response time

9
Scheduling Algorithms

• First Come First Serve (FCFS)
• Shortest Job First (SJF)
• Round Robin (RR)
• ...

10
Scheduling AlgorithmsFirst-Come, First-Served
(FCFS) Scheduling

• Process Burst Time
• P1 24
• P2 3
• P3 3
• Suppose that the processes arrive in the order
  P1 , P2 , P3 The Gantt Chart for the schedule
  is
• Waiting time for P1 0 P2 24 P3 27
• Average waiting time (0 24 27)/3 17

11
FCFS Scheduling (Cont.)

• Suppose that the processes arrive in the order
• P2 , P3 , P1 .
• The Gantt chart for the schedule is
• Waiting time for P1 6 P2 0 P3 3
• Average waiting time (6 0 3)/3 3
• Much better than previous case. (Shortest Job
  First)

12
Priority Scheduling (Shortest Job First)

• Associate with each process the length of its
  next CPU burst. Use these lengths to schedule
  the process with the shortest time.
• SJF is optimal gives minimum average waiting
  time for a given set of processes.
• SJF is a priority scheduling.

13
Shortest Job First (SJF)

• Suppose that the processes arrive in the order
• P2 , P3 , P1 .
• The Gantt chart for the schedule is
• Waiting time for P1 6 P2 0 P3 3
• Average waiting time (6 0 3)/3 3
• Much better than previous case. (Shortest Job
  First)

14
Round Robin (RR)

• Each process gets a small unit of CPU time (time
  quantum), usually 10-100 milliseconds. After
  this time has elapsed, the process is preempted
  and added to the end of the ready queue.
• If there are n processes in the ready queue and
  the time quantum is q, then each process gets 1/n
  of the CPU time in chunks of at most q time units
  at once. No process waits more than (n-1)q time
  units.

15
Example of RR with Time Quantum 20

• Process Burst Time
• P1 53
• P2 17
• P3 68
• P4 24
• The Gantt chart is
• Typically, higher average turnaround than SJF,
  but better response.

16
II-The Deadlock Problem

• A set of blocked processes each holding a
  resource and waiting to acquire a resource held
  by another process in the set.
• Example
• System has 2 tape drives.
• P1 and P2 each hold one tape drive and each needs
  another one.
• Example
• semaphores A and B, initialized to 1
• P0 P1
• wait (A) wait(B)
• wait (B) wait(A)

17
Bridge Crossing Example

• Traffic only in one direction.
• Each section of a bridge can be viewed as a
  resource.
• If a deadlock occurs, it can be resolved if one
  car backs up (preempt resources and rollback).
• Several cars may have to be backed up if a
  deadlock occurs.

18
Deadlock Characterization

• Deadlock can arise if four conditions hold
  simultaneously.
• Mutual exclusion only one process at a time can
  use a resource.
• Hold and wait a process holding at least one
  resource is waiting to acquire additional
  resources held by other processes.
• No preemption a resource can be released only
  voluntarily by the process holding it, after that
  process has completed its task.
• Circular wait there exists a set P0, P1, ,
  P0 of waiting processes such that P0 is waiting
  for a resource that is held by P1, P1 is waiting
  for a resource that is held by
• P2, , Pn1 is waiting for a resource that is
  held by Pn, and P0 is waiting for a resource
  that is held by P0.

19
Deadlock Prevention
Restrain the ways request can be made.

• Mutual Exclusion not required for sharable
  resources must hold for nonsharable resources.
• Hold and Wait must guarantee that whenever a
  process requests a resource, it does not hold any
  other resources.
• Require process to request and be allocated all
  its resources before it begins execution, or
  allow process to request resources only when the
  process has none.
• Low resource utilization starvation possible.

20
Deadlock Prevention (Cont.)

• No Preemption
• If a process that is holding some resources
  requests another resource that cannot be
  immediately allocated to it, then all resources
  currently being held are released.
• Preempted resources are added to the list of
  resources for which the process is waiting.
• Process will be restarted only when it can regain
  its old resources, as well as the new ones that
  it is requesting.

21
Deadlock Avoidance
Requires that the system has some additional a
priori information available.

• Simplest and most useful model requires that each
  process declare the maximum number of resources
  of each type that it may need.
• The deadlock-avoidance algorithm dynamically
  examines the resource-allocation state to ensure
  that there can never be a circular-wait
  condition.
• Resource-allocation state is defined by the
  number of available and allocated resources, and
  the maximum demands of the processes.

22
Review Questions

• Do exercise in CPU Process Scheduling.
• snµt Process enAkñúg Queue List dUcxageRkam³
• Process Burst Time
• P1 3
• P2 5
• P3 3
• P4 7
• P5 8
• k-cUlKUs Gantt Chat tMNageGay Process nImYy²tam
  FCFS, SJF, RR (time quantum3)?
• x-cUlKNna Average Waiting Time rbs Process
  nImYy²tam FCFS, SJF, RR (Time quantum3)?
