Security Network Architecture

1

• Security Network Architecture Design

2
Domain Objectives

• Discuss the concepts of network security
• Understand security risks
• Provide the business context for network security

3
Information Security TRIAD
4
Domain Agenda

• Basic Concepts
• OSI Framework

5
Network Telecommunications

• Network Security
• Network Structures
• Transmission Methods
• Transport Formats
• Security Measures
• Network Security is the cornerstone for business
  operations

6
Network Models

• Models
• OSI Reference Model
• TCP/IP Model

7
OSI Reference Model

• Layer 1 Physical Layer
• Layer 2 Data Link Layer
• Layer 3 Network Layer
• Layer 4 Transport Layer
• Layer 5 Session Layer
• Layer 6 Presentation Layer
• Layer 7 Application Layer

8
OSI Reference Model

• Encapsulation
• Layering

9
OSI Model Layer 1 Physical Layer

• Bits are converted into signals
• All signal processing
• Physical Topologies

Application Layer
Presentation Layer
Session Layer
Transport Layer
Network Layer
Data Link Layer
Physical Layer
10
OSI Model Layer 2 Data Link Layer

• Connects layer 1 and 3
• Converts information
• Transmits frames to devices
• Link Layer encryption

Application Layer
Presentation Layer
Session Layer
Transport Layer
Network Layer
Data Link Layer
Physical Layer
Physical Layer
Physical Layer
11
OSI Model Layer 3 Network Layer

• Moves information between two hosts that are not
  physically connected
• Uses logical addressing
• Internet Protocol (IP)

Application Layer
Presentation Layer
Session Layer
Transport Layer
Network Layer
Data Link Layer
Physical Layer
Physical Layer
Physical Layer
12
OSI Model Layer 4 Transport Layer

• End-to-end Transport between Peer Hosts
• Connection Oriented and Connectionless Protocols

Application Layer
Presentation Layer
Session Layer
Transport Layer
Network Layer
Data Link Layer
Physical Layer
Physical Layer
Physical Layer
13
OSI Model Layer 5 Session Layer

• Manages logical persistent connection
• Three Modes
• Full Duplex
• Half Duplex
• Simplex

Application Layer
Presentation Layer
Session Layer
Transport Layer
Network Layer
Data Link Layer
Physical Layer
Physical Layer
Physical Layer
14
OSI Model Layer 6 Presentation Layer

• Ensures a common format to data
• Services for encryption and compression

Application Layer
Presentation Layer
Session Layer
Transport Layer
Network Layer
Data Link Layer
Physical Layer
Physical Layer
Physical Layer
15
OSI Model Layer 7 Application Layer

• The application layer is not the application
• Performs communication between peer applications
• Least control of network security

Application Layer
Presentation Layer
Session Layer
Transport Layer
Network Layer
Data Link Layer
Physical Layer
Physical Layer
Physical Layer
16
TCP/IP Model

• Originated by the U.S. Department of Defense
• Functions like the OSI Model
• Supports the TCP/IP Protocol
• Application layer is unique

17
TCP/IP Model
18
TCP/IP Protocol Stack
Application
TCP, UDP
IP, IGMP, ICMP
ARP, Hardware Interface, PPP
Network Connection
19
Network Security and Risks

• Network is the key asset in many organizations
• Network Attacks

20
Network-based Attacks

• Network as a Channel for Attacks
• Network as the Target of Attack

21
Network as a Bastion of Defense

• Security controls built around social,
  organizational, procedural and technical
  activities
• Based on the organization's security policy

22
Network Security Objectives and Attacks

• Business Risk versus Security Solutions
• Attacks Scenarios
• Network Entry Point - in Both Directions
• Outside-in
• Inside-out

23
Methodology of an Attack

• Attack Trees
• Path of Least Resistance

Methodology of an Attack
2
3
4
1
Target Acquisition
Target Analysis
Target Access
Target Appropriation
24
Target Acquisition
1

• Attacks start by intelligence gathering
• Means of intelligence gathering
• Countermeasures
• Limit information on a network
• Distract an attacker

25
Target Analysis
2

• Analyze identified target for security weaknesses

• Tools available
• Target analysis

26
Target Access
3

• Obtain access to the system
• Manage user privileges
• Monitor access

27
Target Appropriation
4

• Escalate privileges
• Attacker may seek sustained control of the system
• Countermeasures against privilege escalation

28
Network Security Tools

• Tools automate processes
• Network security is more than just technical
  implementations

29
Network Scanners

• Discovery Scanning
• Compliance Scanning
• Vulnerability Scanning

30
Domain Agenda

• Basic Concepts
• OSI Framework
• Layer 1 Physical Layer

31
Layer 1 Physical Layer

• Basic Concepts
• Communications Technology
• Network Topology
• Technology and Implementation

32
Communication Technology

• Analog and Digital Communications
• Digital communication brings quantitative and
  qualitative enhancements

33
Analog Communication

• Analog signals use electronic properties
• Transmitted on wires or with wireless devices

34
Digital Communication

• Uses two electronic states
• Can be transmitted over most media
• Integrity of digital communication less difficult

35
Layer 1 Physical Layer

• Basic Concepts
• Communications Technology
• Network Topology
• Technology and Implementation

36
Network Topology

• Even small networks are complex
• Network topology and layout affects scalability
  and security
• Wireless networks have a topology

37
Bus

• LAN with a central cable to which all nodes
  connect
• Advantages
• Scalable
• Permits node failure
• Disadvantages
• Bus failure

38
Tree

• Devices connect to a branch on the network
• Advantages
• Scalable
• Permits node failure
• Disadvantages
• Failures will split the network

39
Ring

• Closed-loop Topology
• Advantages
• Deterministic
• Disadvantages
• Single Point of Failure

40
Mesh

• All nodes are connected with each other
• Advantages
• Redundancy
• Disadvantages
• Expensive
• Complex
• Scalability

41
Star

• All of the nodes connected to a central device
• Advantages
• Permits node/cable failure
• Scalable
• Disadvantages
• Single point of failure

42
Security Perimeter

• The first line of defense between trusted and
  un-trusted networks
• No direct physical connection between trusted and
  untrusted networks

• Security perimeter most widely used
  implementation of network partitioning

43
Layer 1 Physical Layer

• Basic Concepts
• Communications Technology
• Network Topology
• Technology and Implementation

44
Technology and Implementation

• Physical networks employ a wide variety of
  cabling technologies and components
• Wireless networks use frequency ranges and
  encryption/authentication

45
Cable

• Cable Selection Considerations
• Throughput
• Distance between Devices
• Data Sensitivity
• Environment

Cable
Twisted Pair
Coaxial Cable
Fiber Optics
Patch Panels
Modems
46
Twisted Pair

• One of the Simplest and Cheapest Cabling
  Technologies
• Unshielded (UTP) or Shielded (STP)

47
Unshielded Twisted Pair (UTP)
Category Transmission Rate Use
Category 1 lt 1 Mbps Analog voice and basic interface rate (BRI) in Integrated Services Digital Network (ISDN)
Category 2 lt 4Mbps 4 Mbps IBM Token Ring LAN
Category 3 16 Mbps 10Base-T Ethernet
Category 4 20 Mbps 16 Mbps Token Ring
Category 5 100 Mbps 100 Base-TX and Asynchronous Transfer Mode (ATM)
Category 5e 1000 Mbps 1000 Base-T Ethernet
Category 6 1000 Mbps 1000 Base-T Ethernet
48
Coaxial Cable (Coax)

• Conducting wire is thicker than twisted pair
• Bandwidth
• Length
• Expensive and physically stiff

49
Fiber Optics

• Three Components
• Light Source
• Optical Fiber Cable
• Light Detector
• Advantages
• Disadvantages

50
Patch Panels

• Provides physical cross-connect point for devices
• Alternative to directly connecting devices
• Centralized management

51
Modem

• Converts a digital signal to analog
• Provides little security
• Unauthorized modems

52
Wireless Transmission Technologies

• Include WLANs, Bluetooth and Mobile Telephony

53
Wireless Transmission Technologies
54
Wireless Multiplexing Technologies
Technology Principle Objective
Direct Sequence Spread Spectrum (DSSS) Spread transmission over a wider frequency band Signal less susceptible to noise
Frequency Hopping Spread Spectrum (FHSS) Spread signal over rapidly changing frequencies Interference at one frequency will only have short term effect
Orthogonal Frequency Division Multiplexing (OFDM) Signal is subdivided into sub frequencies bands Split high bandwidth transmission into low BW transmissions
55
Other Multiplexing Technologies
Technology Principle Objective
Frequency Division Multiple Access (FDMA) Divide Frequency into sub bands Open several low bandwidth channels
Time Division Multiple Access (TDMA) Split transmission by time slices Multiplexing between participants
Code Division Multiple Access (CDMA) Multiplex several signals into one signal Multiplexing is performed on a digital level
56
Mobile Telephony

• Mobile telephony is undergoing a rapid
  development
• Most common mobile phone technology is still GSM

Global Service for Mobile Communications (GSM)
Mobile Telephony
57
Domain Agenda

• Basic Concepts
• OSI Framework
• Layer 2 Data Link Layer

58
Layer 2 Data Link Layer

• Concerned with sending frames to the next link
• Determines network transmission format

59
Synchronous/Asynchronous Communications

• Synchronous
• Timing mechanism synchronizes data transmission
• Robust Error Checking
• Practical for High-speed, High-volume Data
• Asynchronous
• Clocking mechanism is not used
• Surrounds each byte with bits that mark the
  beginning and end of transmission

60
Unicast, Multicast, and Broadcast Transmissions

• Multicasts
• Broadcasts
• Do not use reliable sessions
• Unicast

61
Circuit-switched vs. Packet-switched Networks

• Circuit-switched
• Dedicated circuit between endpoints
• Endpoints have exclusive use of the circuit and
  its bandwidth
• Packet-switched
• Data is divided into packets and transmitted on a
  shared network
• Each packet can be independently routed on the
  network

62
Switched vs. Permanent Virtual Circuits

• Permanent Virtual Circuits
• Switched Virtual Circuits

63
Carrier Sense Multiple Access

• Only one device may transmit at a time
• There are two variations
• Carrier Sense Multiple Access with Collision
  Avoidance (CSMA/CA)
• Carrier Sense Multiple Access with Collision
  Detection (CSMA/CD)

64
Polling

• Slave device needs permission from a master
  device
• Used mostly in Mainframe Protocols
• Optional Function of the IEEE 802.11 Standard

65
Token Passing

• Special frame circulates through the ring
• Device must possess the token to transmit
• Token passing is used in Token Ring (IEEE 802.5)
  and FDDI

66
Ethernet (IEEE 802.3)

• Most Popular LAN Architecture
• Supports bus, star, and point-to-point topologies
• Currently supports speeds up to 1000Mbps

67
Hubs and Repeaters

• Hubs
• Used to implement a physical star topology
• All devices can read and potentially modify the
  traffic of other devices
• Repeaters
• Allows longer distances

68
Bridges

• Layer 2 Devices that filter traffic between
  segments based on MAC addresses
• Can connect LANs with unlike media types
• Simple bridges do not reformat frames

69
Switches

• Multi-port devices to connect LAN hosts
• Forwards frames only to the specified MAC address
• Becoming more sophisticated

70
Wireless Local Area Networks

• Allows mobile users to remain connected
• Extends LANs beyond physical boundaries

71
Access Points

• Access Point Placement
• Do not count on hiding Access Points
• Rogue Access Points

72
Authentication

• Paramount to the Security of Wireless LANs
• Open Systems Authentication
• Shared Key Authentication
• MAC Address Filtering
• Extensible Authentication Protocol

73
Wireless Encryption

• Wired Equivalent Privacy (WEP)
• WiFi Protected Access (WPA)
• WiFi Protected Access 2 (WPA2)

74
Wireless Encryption
802.1x Dynamic WEP Wi-Fi Protected Access Wi-Fi Protected Access 2
Access Control 802.1X 802.1X or Pre-Shared Key 802.1X or Pre-Shared Key
Authentication EAP methods EAP methods or Pre-Shared Key EAP methods or Pre-Shared Key
Encryption WEP TKIP (RC4) CCMP (AES Counter Mode)
Integrity None Michael MIC CCMP (AES CBC-MAC)
75
Wireless Standards

• IEEE 802.11b
• IEEE 802.11a
• IEEE 802.11g
• Bluetooth

76
Address Resolution Protocol (ARP) / RARP

• ARP
• RARP (Reverse ARP)

77
Password Authentication Protocol (PAP)

• Identification and Authentication of Remote
  Entity
• Uses a clear text, reusable (static) password
• Supported by most network devices

78
Challenge Handshake Authentication Protocol (CHAP)

• Periodically re-validates users
• Standard password database is unencrypted
• Password is sent as a one-way hash

79
Domain Agenda

• Basic Concepts
• OSI Framework
• Layer 3 Network Layer

80
Layer 3 Network Layer

• Architectures Classified by Scale (size)
• TCP/IP at the Network Layer

81
Local Area Network (LAN)

• LANs service a relatively small area
• Most LANs have connectivity to other networks
• VLANs are software based LAN segments implemented
  by switching technology

82
Wide Area Network (WAN) Description

• A WAN is a network connecting local networks or
  access points
• Connections are often shared and tunneled through
  other connections

83
Public Switched Telephone Network (PSTN)

• PSTN is a circuit switched network
• The PSTN may be subject to attacks

84
Integrated Services Digital Network (ISDN)

• Uses two types of channels
• Comes in two varieties

B (Bearer) Channel 64kBit/s
D (Delta) Channel 16kBit/s
BRI (Basic Rate Interface) 2B1D 144kBit/s
PRI (Primary Rate Interface) North America 23B1D 1.55MBit/s (T1)
PRI Europe and Australia 30B1D 2MBit/s (E1)
85
T Carrier
Channel Multiplex Ratio Bandwidth
T1 1xT1 1.544 Mbps
T2 4xT1 6.312 Mbps
T3 7xT2 28xT1 44.736 Mbps
T4 6xT3 168xT2 274.176 Mbps
86
E Carrier
Channel Multiplex Ratio Bandwidth
E1 1xE1 2.048 Mbps
E2 4xE1 8.848 Mbps
E3 4xE2 16xE1 34.304 Mbps
E4 4xE3 64xE2 139.264 Mbps
87
Digital Subscriber Lines (DSL)

• Uses CAT-3 cables and the local loop
• Asymmetric Digital Subscriber Line (ADSL)
• Rate-adaptive DSL (RADSL)
• Symmetric Digital Subscriber Line (SDSL)
• Very High Bit-rate DSL (VDSL)

88
Cable Modem

• PC Ethernet NIC connects to a cable modem
• The modem and head-end exchange cryptographic
  keys
• Cable modems increase the requirement to observe
  good security practices

89
X.25

• Protocol developed for unreliable networks
• Has a strong focus on error correction
• Users and hosts connect through a packet-switched
  network

90
Frame Relay

• FR network cloud of switches
• FR customers share resources
• Customers are charged for used bandwidth only

91
Asynchronous Transfer Mode (ATM)

• ATM is a connection-oriented protocol
• Uses virtual circuits
• Guarantees QoS but not the delivery of cells

92
Multi-Protocol Label Switching (MPLS)

• Permits traffic engineering
• Provides quality of service (QoS) and defense
  against network attacks
• Operates at Layer 2 and 3

93
Broadband Wireless

• WiMAX allows the implementation of wireless
  Metropolitan Area Networks (MANs)
• Improved access when a base station and user are
  not in line of sight
• Security is based on AES and EAP

94
Wireless Optics

• Two laser transceivers communicate at speeds
  comparable to SONET
• Wireless optics transmissions are hard to
  intercept
• Wireless optics can be unreliable during
  inclement weather

95
Global Area Network (GAN)

• Intranet
• Extranet
• Granting access to external organizations
• Internet

96
TCP/IP at the Network Layer

• TCP/IP protocol suite is the de-facto standard
• Need to provide private communications services
  over public networks

97
Internet Protocol (IP)

• Internet Protocol (IP) is responsible for sending
  packets over a network
• Unreliable Protocol
• IP will subdivide packets
• IPv4 Address Structure

98
Internet Protocol (IP)

• Internet Protocol Address Structure

Class Range of First Octet Number of Octets for Network Number Number of Hosts in Network
A 1-127 1 16777216
B 128-191 2 65536
C 192-223 3 256
D 224-239 Multicast Multicast
E 240-255 Reserved Reserved
99
Risks and Attacks

• Key shortcoming in IP is its lack of
  authentication
• Shortcomings in implementation

100
IP Fragmentation Attacks

• Teardrop Attack
• Overlapping Fragment Attacks

101
IP Addressing Spoofing

• Packets are sent with a bogus source address
• SYN Flood
• Takes advantage of a protocol flaw

102
Source Routing Exploitation

• IP allows the sender to specify the path
• Attacker can abuse source routing
• Could allow an external attacker access to an
  internal network

103
Smurf and Fraggle Attacks

• Smurf attack mis-uses the ICMP Echo Request
• Fraggle attack uses UDP instead of ICMP
• Ping of Death

104
IPv6

• A larger IP address field
• Improved security
• A more concise IP packet header
• Improved quality of service

105
Routers

• Routers forward packets to other networks
• Routers can be used to interconnect different
  technologies

106
Firewalls

• Enforce administrative security policies
• Separate trusted networks from untrusted networks
• Firewalls should be placed between security
  domains

107
Firewalls

• Filtering
• Filtering by Address
• Filtering by Service
• Static Packet Filtering
• Stateful Inspection or Dynamic Packet Filtering
• Personal Firewalls

108
Network Address Translation / Port Address
Translation
Network and Port Address Translation
Source IP 199.53.72.2 Destination IP
206.121.73.5 Source Port 1058 Destination Port
- 80
Source IP 192.168.1.50 Destination IP
206.121.73.5 Source Port 1037 Destination Port
- 80
109
Proxy Firewalls

• Circuit Level Proxy
• Application Level Proxy

110
Firewalls
Firewall Type OSI Model Layer Characteristics
Packet Filtering Network layer Routers using ACLs dictate acceptable access to a network Looks at destination and source addresses, ports and services requested
Application-level Proxy Application layer Deconstructs packets and makes granular access control decisions Requires one proxy per service
111
Firewalls
Firewall Type OSI Model Layer Characteristics
Circuit-level Proxy Session layer Deconstructs packets Protects wider range of protocols and services than app-level proxy, but not as detailed as a level of control
Stateful Network layer Keeps track of each conversation using a state table Looks at state and context of packets
112
Network Partitioning

• Boundary Routers
• Dual-homed Host

113
Network Partitioning

• Bastion Host
• Demilitarized Zone (DMZ)

114
Network Partitioning

• Three-legged Firewall

115
End Systems

• Servers and Mainframes
• Operating Systems
• Notebooks
• Workstations
• Smart Phones
• Personal Digital Assistants

116
Virtual Private Network (VPN)

• Remote access through VPN
• LAN to LAN configuration

117
Virtual Private Network (VPN)

• Secure Shell (SSH)
• IPSEC Authentication and Confidentiality for VPNs
• SSL/TLS VPNs
• SOCKS

118
IPSEC Authentication Confidentiality for VPNs

• Authentication Header (AH)
• Encapsulating Security Payload (ESP)
• Security Associations
• Transport Mode / Tunnel Mode
• Internet Key Exchange (IKE)

119
Tunneling

• Point-to-Point Tunneling Protocol (PPTP)
• Layer 2 Tunneling Protocol (L2TP)

120
Dynamic Host Configuration Protocol (DHCP)

• Dynamically assigns IP addresses to hosts
• Client does not request a new lease every time

121
Internet Control Message Protocols (ICMP)

• ICMP Redirect Attacks
• Ping of Death
• Traceroute Exploitation
• Ping Scanning

122
Internet Group Management Protocol (IGMP)

• Used for Multicast Messages
• Sets up Multicast Groups

123
Routing Protocols

• Routing Information Protocol (RIP)
• Virtual Router Redundancy Protocol (VRRP)

124
Domain Agenda

• Basic Concepts
• OSI Framework
• Layer 4 Transport Layer
• Layer 5 Session Layer

125
Layer 4 Transport Layer

• Transmission Control Protocol (TCP)
• Well-known Ports
• Registered Ports
• Dynamic and/or Private Ports
• User Datagram Protocol (UDP)

126
Transmission Control Protocol (TCP) Session
127
Technology and Implementation

• Port Scanning
• FIN, NULL and XMAS Scanning
• SYN Scanning
• TCP Sequence Number Attacks
• Session Hijacking
• Denial of Service

128
Transport Layer Security (TLS)

• Functions of TLS
• Mutual authentication
• Encryption

129
Layer 5 Session Layer

• Remote Procedure Calls

130
Directory Services

• Domain Name Service (DNS)
• Lightweight Directory Access Protocol (LDAP)
• Network Basic Input Output System (NetBios)
• Network Information Service (NIS)/NIS

131
Access Services

• Common Internet File System (CIFS)/Server Message
  Block (SMB)
• Network File System (NFS)
• Secure NFS (SNFS)

132
Domain Agenda

• Basic Concepts
• OSI Framework
• Layer 7 Application Layer

133
Data Exchange (World Wide Web)

• Trivial File Transfer Protocol (TFTP)
• File Transfer Protocol (FTP)
• Hypertext Transfer Protocol (HTTP)
• HTTP over TLS (HTTPS)
• Secure Hypertext Transfer Protocol (S-HTTP)
• Passive and Active Content (HTML, ActiveX, Java,
  JavaScript)
• Peer-to-peer Applications and Protocols

134
Messaging Services

• Instant Messaging
• Asynchronous Messaging
• Email Spoofing
• Open Mail Relay Servers
• Spam
• Post Office Protocol (POP)
• Internet Message Access Protocol (IMAP)
• Network News Transfer Protocol (NNTP)
• Internet Relay Chat (IRC)
• Spam over Instant Messaging (SPIM)

135
Administrative Services

• Remote Authentication Dial-In User Service
  (RADIUS)
• Simple Network Management Protocol (SNMP)

136
Remote Authentication Dial-In User Service
(RADIUS)

• Network Access Server sends authentication
  requests to the Centralized Authentication Server.

137
Remote Access Services

• TCP/IP Terminal Emulation Protocol (TELNET)
• Remote Login (RLOGIN), Remote Shell (RSH), Remote
  Copy (RCP)
• X Window System (X11)

138
Information Services

• Finger User Information Protocol
• Network Time Protocol (NTP)

139
Traditional Telephony and Network Layouts
140
Voice over IP (VoIP)

• Session Initiation Protocol (SIP)
• Proprietary Applications and Services

141
Voice over IP (VoIP)

• IP Telephony Network Issues
• IP Telephony Vulnerabilities

142
Voice over IP (VoIP)
143
Voice over IP (VoIP)
144
Voice over IP (VoIP)
145
Domain Summary

• Provides the foundation for IT security
• OSI TCP/IP Models
• Ports and Protocols
• Network Devices

146
Domain Summary

• Discuss the concepts of network security
• Understand security risks
• Provide a business context on network security

147
Security
Transcends
Technology
