Title: Scattering Polarization in the Solar Atmosphere


1
Scattering Polarizationin the Solar Atmosphere
  • R. Casini
  • High Altitude Observatory
  • National Center for Atmospheric Research

2
Polarized Radiation
  • Origin symmetry-breaking processes of the
    Atom-Photon interaction
  • (e.g., anisotropic illumination, deterministic
    magnetic and/or electric fields, anisotropic
    collisions)

3
Polarized Radiation
  • Description 4 independent parameters
  • i) coherency matrix (a.k.a. polarization tensor )
  • ii) Stokes parameters

Jones calculus
Mueller calculus
4
Polarized Radiation
  • Operational definition of Stokes parameters

5
Polarized Radiation
  • Polarized radiation tensors

6
Polarized Radiation

Example Unpolarized radiation from the quiet-sun
photosphere
Only two non-vanishing components
7
Atomic Polarization
  • Gas of atoms subject to
  • Anisotropic and/or polarized illumination
  • External fields
  • Collisions
  • Atomic system not in a pure state
  • Population imbalances and quantum interferences
  • between atomic levels

8
Atomic Polarization
  • Density operator
  • Density matrix

9
Atomic Polarization
  • Irreducible spherical components of the density
    matrix
  • If (e.g., Zeeman effect)
  • Otherwise (e.g.,
    Paschen-Back effect, Stark effect)

10
Atomic Polarization
  • Example Multi-level atom
  • Population
  • Orientation
  • Alignment

11
Atomic Polarization
  • Ex. 1 Positive orientation in a level
  • Ex. 2 Positive alignment in a level
  • Ex. 3 Orientation and alignment in a level
  • Presence of net polarization in the re-emitted
    radiation
  • (even in the absence of external fields)

12
Time evolution of the system
  • Liouvilles equation
  • Evolution equation for expectation values

Atom
Radiation
?
13
Resonance Scattering
  • Atom-Photon interaction to 2nd order of
    perturbation

14
Resonance Scattering
  • Restriction Non-coherent scattering
  • Scattering as the succession of
  • 1st-order absorption and re-emission
  • Complete Re-Distribution in frequency
  • The atom loses memory of the incident photons,
  • and the re-emitted photons are statistically
  • re-distributed in frequency

Flat-Spectrum Approximation
15
Resonance Scattering
  • Restriction Non-coherent scattering
  • Scattering as the succession of
  • 1st-order absorption and re-emission
  • Two-step solution
  • Determine the excitation state of the atomic
    system consistently with the ambient radiation
    field (Statistical Equilibrium Problem)
  • Calculate the scattered radiation consistently
    with the excitation state of the atomic system
    (Radiative Transfer Problem)

16
Statistical Equilibrium

17
Radiative Transfer

in stationary regime
18
Resonance Scattering
19
Resonance Scattering
  • Difficulties
  • The Statistical Equilibrium problem grows rapidly
    with the complexity of the atomic system (very
    large sparse matrices)
  • Possible strategy weak-anisotropy approximation
  • The Radiative Transfer problem requires the
    solution of a
  • set of 4 coupled ODEs
  • Possible strategy Diagonal Elements Lambda
    Operator (DELO)
  • No guarantee of convergence of the
    self-consistency loop
  • (maybe with the exception of the simplest atomic
    models,
  • with appropriate initialization)
  • Possible strategy ?????

20
Atom 0-1
Classical analogy in the 3D harmonic oscillator
with forcing term
21
Atom 0-1
22
Atom 1-0
23
Atom 1-0
24
Atom 1-1
25
Atom 1-1
26
Atomic polarization and Radiative transfer
Homogeneous slab
0-1 or 1-0 w/o atomic pol. (Zeeman effect)
27
Atomic polarization and Radiative transfer
0 1 2
Homogeneous slab
He I
10830 Ã…
28
Atomic polarization and Radiative transfer
0 1 2
He I
Homogeneous slab
10830 Ã…
Trujillo Bueno et al., Nature 415, 403 (2002)
29
Atomic polarization in Na I
F
?
3 2 1 0
?
2 1
D1
D2
2 1
? ? ?
30
Atomic polarization in Na I
D2
F
?
3 2 1 0
?
2 1
5896 Ã…
D1
D2
D1
2 1
? ? ?
31
Atomic polarization in Na I
F
?
3 2 1 0
?
2 1
2 1
? ? ?
32
Alignment-to-Orientation transfer
F
?
3 2 1 0
When quantum interferences between FS and/or HFS
levels are important
?
2 1
2 1
? ? ?
33
Atomic orientation in H I
HAO Advanced Stokes Polarimeter March 2003
THEMIS heliographic telescope September 2003
Spectro-polarimetric observations of Ha in solar
prominences (off the limb)
34
Atomic orientation in H I
Spectro-polarimetric simulations with FS and HFS
THEMIS heliographic telescope September 2003
Maximum net circular polarization 1 order of
magnitude too small for typical prominence
fields (less than 100 G)
35
Atomic orientation in H I
Catalytic effect of small electric fields on H
I atomic orientation
36
vertical magnetic field, forward scattering
Catalytic effect of small electric fields on H
I atomic orientation
Ha
Inclinations of random-azimuth, 1 V cm-1 fields
37
Conclusions
  • Spectro-polarimetric observations reveal the
    complexity of the atomic processes underlying
    resonance scattering (atomic coherences, FS and
  • HFS effects, magnetic and electric fields,
    alignment-to-orientation transfer)
  • The local problem can already become numerically
    very intensive
  • Points to focus on
  • Improve speed in the construction of the
    Statistical Equilibrium matrix
  • Invent new strategies to accelerate convergence
    of the iterative scheme for atoms of arbitrary
    complexity and general illumination conditions
