Title: COMPRESSED GASES


1
COMPRESSED GASES
2
TYPE OF GASES
  • MIXED
  • WELDING
  • REFRIGERANT
  • COMPRESSED
  • ACETYLENE
  • OXYGEN
  • ARGON
  • HELIUM
  • ZERO- AIR
  • CARBON DIOXIDE
  • NITROGEN

3
Types of Gases
  • CURRENTLY 9 NON-PRODUCTION NUMBERS THAT ARE
    STOCKED IN STORES.
  • AVG. 7.0 ISSUES A MONTH
  • CURRENTLY 11 PRODUCTION ITEMS THAT ARE STOCKED IN
    STORES.
  • AVG. 63 ISSUES A MONTH

4
TYPES OF GASES
  • LIQUID NITROGEN BOTTLES ARE FILLED FROM A BULK
    TANK BY OUR MATERIAL SUPPLIERS.
  • AVG. 38 BOTTLES FILLED AND DELIVERED EACH MONTH

5
PROCESS FOR ORDERING
  • ALL GASES SET UP IN STORES ARE ON A MAX/MIN
    PURCHASING SYSTEM EXCEPT LIQUID NITROGEN WHICH IS
    ON A CUSTOMER DEMAND.
  • FLOWTIME FOR INSPECTION IS BUILT IN MAX/MIN
    CALCULATIONS.
  • 90 OF ALL GASES COME FROM PRAXAIR.

6
(No Transcript)
7
RECEIVING GASES
  • RECEIVER IS PROCESSED AFTER DELIVERY.
  • IF NON PRODUCTION / STRAIGHT TO STORES.
  • IF PRODUCTION, GOES TO QUALITY FOR ACCEPTANCE.

8
QUALITY
  • QUALITY SENDS SAMPLE FOR VERIFICATION TESTING TO
    THE LAB.
  • IF MATERIAL IS ACCEPTED IT IS RELEASED TO STORES
    FOR DISTRIBUTION.
  • IF MATERIAL IS REJECTED IT IS RETURNED TO
    SUPPLIER.

9
(No Transcript)
10
(No Transcript)
11
MATERIAL DISTRIBUTION
  • ACCEPTED GASES ARE DISTRIBUTED VIA MSR DEMAND.
  • MSR (MATERIAL STOCK REQUEST)DRIVES THE DEMAND FOR
    MATERIAL.
  • ONCE ACCEPTED INTO STORES, ERP KICKS OUT A PICK
    TICKET, FOR THE SHIP TO CUSTOMER.

12
TRANSPORTING
  • ALL GASES ARE TRANSPORTED AT FMT ON GAS RACKS,
    FOR SAFE TRANSPORT.

13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
MISC. NOTES
  • PRAXAIR DELIVERS AND PICKS UP EMPTY GAS BOTTLES
    TWICE A WEEK.
  • ALL GAS DELIVERED TO FMT COMES IN ON OUR
    CHEMICAL DOCK.
