Low-z BAOs: proving acceleration and testing Neff

1
Low-z BAOsproving acceleration and testing Neff

• Will Sutherland (QMUL)

2
Talk overview

• Cases for low-redshift BAO surveys
• Smoking-gun test of cosmic acceleration - assumes
  only homogeneity isotropy, not GR.
• Testing fundamental assumptions from CMB era, in
  particular the number of neutrino species.

3
2005 first observation of predicted BAO
feature by SDSS and 2dFGRS
(Eisenstein et al 2005)
4
BAO feature in BOSS DR9 data 6
sigma (Anderson et al 2012)
5
BAO observables transverse and radial
Spherical average gives rs / DV ,
6
BAOs strengths and weaknesses

• BAO length scale calibrated by the CMB .
• Uses well-understood linear physics (unlike
  SNe).
• - CMB is very distant hard to independently
  verify assumptions.
• BAO length scale is very large, 153 Mpc
• Ruler is robust against non-linearity, details
  of galaxy formation
• Observables very simple galaxy redshifts and
  positions.
• - Huge volumes must be surveyed to get a precise
  measurement.
• - Cant measure BAO scale at z 0
• BAOs can probe both DA(z) and H(z) no
  differentiation needed for H(z). More sensitive
  to features in H(z) enables consistency tests
  for flatness, homogeneity.

7
Precision from ideal BAO experiments
(Weinberg et al 2012)
Right panel idealized assumes matterbaryon
densities known exactly
8
Cosmic speed trapProving cosmic acceleration
with BAOs only

• Assuming homogeneity, evidence for accelerating
  expansion is strong SNe, CMBlow-z measurements
  .
• SNe require acceleration independent of GR (if no
  evolution, and photon number conserved)
• CMB LSS acceleration evidence very strong,
  but requires assumption of GR.
• Possible loophole to allow non-accelerating model

• Assume SNe are flawed by evolution and/or photon
  non-conserving processes (peculiar dust,
  photon/dark sector scattering).
• AND GR not correct, so CMB inferences are
  misleading.
• This is contrived, but we should close this
  loophole

9
Cosmic expansion rate da/dt
10
Cosmic expansion rate, relative to today
11
BOSS Busca et al 2012 Caveat assumed flatness
and standard rs
12
Speed-trap motivations

• Radial BAO scale directly measures rs H(z) / c
• Ratio of two such measurements will cancel rs ,
  and detect acceleration directly.
• BUT, there is a practical problem
• very feeble acceleration at z gt 0.3
• Not enough volume to measure radial BAOs at z lt
  0.3 .
• Cant measure rs H0 at z 0.
• Spherical-average BAOs can prove acceleration IF
  we assume almost-flatness, but we dont want to
  rely on this.
• Workaround use radial BAO at z 0.7, compare
  to spherical-average BAO observable at z 0.2 .

13
Limit relating DV(z1) and H(z2) for any
non-accelerating model
Comoving radial distance
No acceleration requires
therefore
14
Assuming homogeneity, angular-diameter distance
is
No acceleration requires
Therefore
Open curvature ( ) gt 1
Closed curvature
15
radial BAO observable
Spherical-average BAO observable, at z1
Divide
Use previous limit for DV
16
Rearrange square-bracket onto LHS now RHS
becomes 1 O(z2), depends very weakly on
curvature.
Define XS as excess speed , ratio of BAO
observables
Flat models RHS 1 exactly . Open models RHS
lt 1 limit gets stronger. Closed models RHS gt
1 need to constrain this. But, closed models
have a maximum angular diameter distance lt Rc
/ (1z) , so z 3 galaxy sizes eliminate
super-closed models.
17
(Sutherland, MN 2012, arXiv1105.3838)
Blue/green predictions for LambdaCDM / wCDM
Red upper limits for non-accelerating model,
various (extreme) curvatures.
18
Speed-trap result

• If we assume
• Homogeneity and isotropy
• Redshift due to cosmic expansion, and constant
  speed of light
• BAO length conserved in comoving coordinates
• No acceleration after redshift z2
• Then
• Observable BAO ratio must be below red-lines
  above
• If observed XS gt 3 sigma above red-line ,
• at least one of four statements above
  is false.
• Signal 10 percent need lt 3 (ideally 2)
  precision on ratio of two BAO observables.
  Challenging, but definitely achievable.

19
Hou et al 2011 Effect of varying Neff on CMB
damping tail.
20
Measuring the absolute scale of BAOs

• BAO length scale is essentially the sound horizon
  at drag redshift zd 1020.
• If we assume
• Standard GR
• Standard neutrino content
• Standard recombination history
• Nearly pure adiabatic fluctuations
• Negligible early dark energy
• Negligible variation in fundamental constants
• Then BAO length depends on just two numbers, ?m
  and ?b both well determined by WMAP and Planck.

• WMAP results give rs(zd) 153 2 Mpc (1.3
  percent). Planck gives rs(zd) 151.7 0.5 Mpc
  (0.33 percent).

21
Measuring the absolute scale of BAOs (2)

• Above assumptions are (mostly) testable from CMB
  acoustic peaks structure.
• But theres a risk of circular argument a wrong
  assumption may be masked by fitting biased
  values of cosmological parameters especially H0
  also Om, w etc.
• Highly desirable to actually measure the BAO
  length with a CMB-independent method.
• Obvious way measure transverse BAOs and DL(z)
  at same redshift distance duality gives DA(z)
  and absolute BAO scale.
• Would like to work at lower z , and use DV(z)
• Snag DV(z) is not directly measurable with
  standard distance indicators.

22
Effect of non-standard radiation density
Definition of Neff
Matter density
Sound horizon in terms of rad. density and zeq
Define and use base parameter set
23
(WMAP7 Komatsu et al 2010)
24
WMAP7 likelihood contours
Strong degeneracy between Neff and ?m but zeq
is basically unaffected.
25
WMAP7 likelihood contours
26
Not exact, but accurate summary

• If we drop the assumption of standard Neff, then

• WMAP still tells us redshift of matter-radiation
  equality 3200, (Planck 3350) , but the
  physical matter and radiation densities are much
  less precise.
• Keeping CMB acoustic angle constant requires
  physical dark energy density to scale in
  proportion to matter radiation.
• best-fit inferred H0 scales as v(Xrad)
• Sound horizon rs scales as 1/ v(Xrad) .
• The BAO observables dont change inferred Om ,
  w are nearly unbiased (Eisenstein White 2004).
• If a 4th neutrino species, equivalent to 13.4
  increase in densities, 6.5 increase in H (e.g.
  70 to 74.5) and 6.1 reduction in cosmic
  distances/ages. Substantial effect !

27
Neff affects all dimensionful parameters

• Nearly all our WMAP SNe BAO observables are
  actually dimensionless (apart from photonbaryon
  densities)
• redshift of matter-radiation equality
• CMB acoustic angle
• SNe give us distance ratios or H0 DL /c .
• BAOs also give distance ratios.
• All these can give us robust values for Os , w,
  E(z) etc almost independent of Neff .
• But there are 3 dimensionful quantities in FRW
  cosmology
• Distances, times, densities.
• Two inter-relations distance/time via c ,and
  Friedmann equation relates density timescale,
  via G.
• This leaves one short, i.e. any number of
  dimensionless distance ratios cant determine
  overall scale.
• Usually, scales are (implicitly) anchored to the
  standard radiation density, Neff 3.04 . But if
  we drop this, then there is one overall unknown
  scale factor.

28
Neff , continued

• Photon and baryon densities are determined in
  absolute units but these dont appear separately
  in Friedmann eq., only as partial sums.
• Rescaling total radiation, total matter and dark
  energy densities by a common factor leaves WMAP,
  BAO and SNe observables (almost) unchanged but
  changes dimensionful quantities e.g. H.
• Potential source of confusion use of h and ?s.
  These are unitless but they are not really
  dimensionless, since they involve arbitrary
  choice of H 100 km/s/Mpc , and corresponding
  density.

29
What BAOs really measure

• Standard rule-of-thumb is CMB measures ?m , and
  the sound horizon then BAOs measure h only
  true assuming standard radiation density.
• Really, CMB measures zeq adding a low-redshift
  BAO ratio measures (almost) Om. These two tell
  us H0 / v(Xrad) , but not an absolute scale.
• Thus, measuring the absolute BAO length provides
  a strong test of standard early-universe
  cosmology, especially the radiation content
  (Neff).
• Measuring just H0 is less good, since it mixes
  Neff, w and curvature. The absolute BAO scale
  probes only the early universe.

30
Measuring the absolute BAO scale (3)

• Need two observations a relative BAO ratio at
  some redshift, and an absolute distance
  measurement to a matching redshift.
• It is generally easier to measure cosmic
  distances at lower z 0.25, which favours BAOs
  at moderate redshift.
• For SNe, the issue is evolution, so shorter time
  lever arm is favourable.
• SNe are better in near-IR (Barone-Nugent et al
  2012) sweet spot at z0.3 where rest-frame J, H
  appear in observed H,K.
• For lens time delays, degeneracy with cosmology
  zl ltlt zs is favourable for absolute distances.
• The ideal distance indicators long-term may be
  gravitational wave standard sirens precision
  limited by SNR , favours lower z.
• It is feasible to reach 1.5 precision on BAO
  ratio at z 0.25 this is probably better than
  medium-term distance indicators.

31
Measuring the absolute scale of BAOs (4)

• Most robust quantity from a BAO survey is rs /
  DV(z) this is (almost) theory-independent.
• DV is related to comoving volume per unit
  redshift
• Could measure DV exactly if we had a population
  of standard counters of known comoving number
  density. But prospects dont look good galaxy
  evolution.
• At very low z, DV c z / H0 . But error is 6
  at z 0.2 much too inaccurate.
• Next well find much better approximations for
  DV(z)

32
Pretty good approximations (lt 0.5 percent at z lt
0.4)
Suitable choice of zs can eliminate H and gives
33
Relative accuracy of approximation
1 percent
34
Relative accuracy of approximation
1 percent
35
Better approximation
1 percent
Accuracy lt 0.2 percent at z lt 0.5
36
An easy route to Om
h becomes a derived parameter
Define e as error in approximation
BAO ratio is
This is exact (apart from non-linear shifts in rs
) and fully dimensionless all H and ?s
cancelled.
37
An easy route to Om
For WMAP baryon density, the above
simplifies to the following , to 0.4 percent

• This is all dimensionless, and nicely splits
  z-dependent effects
• Zeroth-order term is just Om-0.5 (strictly Ocb
  , without neutrinos)
• Leading order z-dependence is E(2z/3)
• The eV is second-order in z, usually z2 / 25
  and almost negligible
• at z lt 0.5

38
An easy route to Om
Repeat approximation from previous slide
Substituting in the WMAP range for zeq , and the
BAO measurement at z 0.35 from Padmanabhan et
al (2012), and discarding the sub-percent eV ,
this gives
And just square and rearrange to
39
Why DV approximation is good post-hoc
explanation using Taylor series
Deceleration and Jerk parameters
For reasonable models, abs lt 4 leading
order error lt z2 / 27
40
Conclusions

• BAOs are a gold standard for cosmological
  standard rulers. Very well understood
  observations huge in scope but clean.
• Most planned BAO surveys are targeting z gt 0.7,
  to exploit the huge available volume and
  sensitivity to dark energy w.
• However, there are still two good cases for
  optimal low-z BAO surveys at z 0.25 (e.g.
  extending BOSS to South and lower galactic
  latitude)
• A third direct test of cosmic acceleration,
  without GR assumption. (arXiv1105.3838)
• In conjunction with precision distance
  measurements, can provide a test of the CMB
  prediction rs 151 Mpc, and/or a clean test for
  extra dark radiation, independent of DE and
  curvature.
• (arXiv1205.0715)

41
Thank you !
42
(No Transcript)
