Landscapes of New York

1
Landscapes of New York
2
What are landscapes?

• 3 Major Classifications
• Mountains
• Plains / Lowlands
• Plateaus / Uplands

3
New York has all three!
Notice the Catskills are part of a plateau, and
are not really mountains
4
Mountains / Highlands

• At least 300 meters above the surrounding land.
• Created by a tectonic collision between two
  landmasses (Orogeny).
• Characterized by distorted rock structures
  (metamorphic bedrock) a result of the pressures
  applied during collision.

5
(No Transcript)
6
Plains / Lowlands

• Large areas of flat land at low elevations.
• Lots of gravel, sand and clay.
• HOME SWEET HOME!

7
Plateau / Uplands

• Large areas of flat land at high elevation.
• Usually flat, horizontal, sedimentary rock
  structures.

8
Check your note sheet now
Landscapes Landscapes Landscapes
Mountains Plateaus Plains
9

• Landforms are the result of the interaction of
  tectonic forces and the processes of weathering,
  erosion, and deposition.

10
(No Transcript)
11
What tectonic events and surface processes were
occurring during these times?
12
Adirondack High Peaks
13
Correlate page 2 to page 3 of your ESRT
14
What was happening in NY during the Middle
Proterozoic?
15
Correlate pages 2 3 to pages 8 9.
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
No horizontal layering blocky, chunky, jointed
metamorphic rock.
20
Isolated garnet crystals like this one, tell us
the rock has been subjected to a lot of heat and
pressure (metamorphism).
21
Anorthosite composed of large crystals of
labradorite feldspar (another clue of
metamorphism).
22
Distorted bedrock structure result of
compression forces during the collision of
landmasses that created the supercontinent that
came before Pangea.
23
Letchworth Gorge
24
Correlate page 2 to page 3 of your ESRT
25
What was happening in NY during the Devonian?
26
Correlate pages 2 3 to pages 8 9.
27

• During the Devonian the western parts of NY are
  underwater. The Acadian orogeny occurs mostly to
  the North (Maine, Newfoundland, Greenland, etc).
• The rising of those mountains produced a lot of
  erosion of the softer surface sedimentary rocks
  and the Catskill delta was formed.

28
Is this a true mountainous region?
29
Elevated sedimentary rocks being worn down by
running water
30
Watkins Glen
31
These and other marine fossils tell us that the
area was once covered by a shallow sea.
32
(No Transcript)
33
Sedimentary rocks, at fairly high elevations,
being worn down by running water
34
Take Us Home!

• What NYS Landscape do we live in?

35
Hudson-Mohawk Lowlands
36
(No Transcript)
37
(No Transcript)
38
Notice the layering in the rocks
39
Conglomerate rock from the Catskills. The
Catskills are made of sedimentary rocks, not
metamorphic rocks!
40
Long Island
41
Correlate page 2 to page 3 of your ESRT
42
Correlate pages 2 3 to pages 8 9.
43
Caumsett State Park, Lloyds Neck, LI
Pleistocene Sands Gravels
Cretaceous Clay
44
Loess
Glacial till
