Title: High Temperature Superconducting Solenoid Punch


1
High Temperature Superconducting Solenoid Punch
2
Our Mission
  • Make an actuator using BSSCO 2223 HTS tape from
    American Superconductor

3
What is an actuator?
A device that converts between mechanical energy
and other forms
Copper solenoids http//www.magnet-schultz.com/msa
MEMX High Performance Steerable MicroMirrors
http//www.memx.com/products.htm
4
What is a superconductor?
  • A material that conducts without resistance
  • Impenetrable by external magnetic fields (up to a
    point)
  • Two types Type I and Type II
  • Examples
  • YBCO Yttrium barium copper oxide
  • BSSCO 2212, 2223 (Bi,Pb)2Sr2Ca1Cu2Ox,
    (Bi,Pb)2Sr2Ca2Cu3Ox

Permanent magnet levitating over a
superconductor http//helium.ee.tut.fi/supraryhma/
images/korkealla.jpg
5
BSSCO 2223Structure
BSSCO 2223 Unit Cell http//www.library.uow.edu.au
/adt-NWU/uploads/approved/adt-NWU20030305.113225/p
ublic/02Whole.pdf
6
Our HTS Tape
  • American Superconductor
  • BSSCO 2223
  • 4 mm (W) x 0.21 mm (T)
  • Up to 108 A
  • Critical temperature (TC) of 110 K

7
BSSCO 2223 Processing
8
BSSCO 2223 IC vs. H
9
Current vs. Bending Diameter
10
Actuator Choice
  • Persistent actuator?
  • Cant make superconducting junction
  • Core choice
  • Magnetostrictive
  • Hard magnet
  • Soft magnet

11
Coil Radius Setup
12
Radius Measurements
13
The Apparatus
14
Field Calculations
15
Force
  • Magnetization of Fe 334225 A/m

Force (N, cm)
16
Apparatus Fabrication
17
Solenoid Assembly
18
Assembled Solenoid
19
Testing Magnetic Field
20
Testing Magnetic Gradient
1 amp, room temperature
21
Self-Field Tests
22
Self-Field Tests
23
Current Tests
24
Load Cell Setup
25
Force
26
Supercool
27
Conclusions
Copper solenoid (1.5 x 2.4) outperforms our
actuator (force), even at room temperature
28
Energy Density
  • Energy density of Supercool solenoid 17400 J/m3
  • 7.0 cm outer diameter
  • 3.36 J of total energy
  • Energy density of 1.5 x 2.4 Cu solenoid 16100
    J/m3

29
Further Considerations
  • Commercial tape gt 135 A
  • Colder temperature
  • YBCO 2nd generation tape
  • 7 T at 77K

30
Acknowledgements
  • Professor Chiang
  • Professor Vander Sande
  • Yin-Lin Xie
  • David Bono
  • Ken Stone
  • Ed Moriarty
  • Leslie Bromberg
  • 3.082 staff

31
References
  • YBCO second generation tape http//www.amsuper.co
    m/html/products/library/2g_white_paper_-_march_200
    4.pdf
  • Montgomery, D. Bruce. Solenoid Magnet Design The
    Magnetic and Mechanical Aspects of Resistive and
    Superconducting Systems. Wiley-Interscience, New
    York. 1969.
  • Magnet-Schultz commercial Cu solenoidhttp//magn
    et-schultz.com/newRTP24X19INT.htm
