Title: Mechanical Methods of Material Removal


1
Mechanical Methods of Material Removal
  • Chapter 4

2
Fundamentals
  • The properties of material being cut
  • Properties of the cutting tool
  • Cutting speed
  • Metal is actually pushed and breaks off rather
    than actually being cut. See Pages 78 79.

3
Powered Mechanical Methods of Material Removal
  • Turning
  • Lathes
  • Milling
  • Shaping and Planning
  • Routing
  • Broaching
  • Drilling and Boring
  • Reaming and Honing
  • Sawing
  • Grinding
  • Sanding
  • Polishing

4
Cutting Tools
  • Face
  • Flank
  • End cutting edge
  • End face
  • Nose radius
  • Side cutting edge
  • Shank
  • See Page 101
  • Carbide inserts

5
Feeds Speeds
  • Cutting Speed Velocity of work piece as it
    passes cutting tool. SFPM
  • Spindle Speed Rotational speed of cutting tool.
  • Feed Rate of advance of cutting tool per
    revolution.
  • Depth of Cut Distance cutting tool enters the
    work piece.

6
Coolants
  • Purposes
  • Cool the tool and work surface.
  • Lube the point of contact.
  • Flush chips away from the work piece.
  • Suppress corrosion
  • Types
  • Chemical
  • Emulsions
  • Semichemical fluids
  • Cutting and grinding oils
