Access

1
Access
Review
2
Creating tables

• Define the tables before start creating in Access
• use the DB design materials
• define the type of fields and length

• Create each table in Access
• select Tables, new, design view
• enter definition in design view

3
Entering and editing data

• When you "created" you just created the table
  structure
• How to add data to a table?
• After you save the table select datasheet
• and enter the data as in the example
• save frequently
• How to edit?
• Select table, go to datasheet view and add,
  delete, or change.

NOTE In older versions select Database Window
to navigate between your tables queries,
forms, etc.
4
Creating relations

• Close all design window windows before starting
• Use Tools, Relationships or the icon
• Click on each table in the Show Table Window to
  place them in the work area
• Click on the field of the one table and paste it
  on top of the same field in the many table
• Access will open a relation dialog, be sure to
  select enforce referencial integrity
• repeat this step as necessary
• you will see the relations as in this example

5
Creating queries

• Start from database window and select queries,
  new and Design View
• you will see a blank query grid and Show Table
  window
• select the table(s) to use in the query
  (double-click) and close the Show Table
• select the fields you want to place in the query
  (in the order you want to see the results)
• You can easily sort the results and create
  calculated fields.
• You can create a new table with the results of a
  query
• In Design View click the arrow next to Query Type
  button on the toolbar, and then click Make Table.

• The Make Table dialog box appears. In the Table
  Name box, enter the name of the table you want to
  create and select current database and save it.

6
Creating reports

• Simple reports can be created by selecting
  Reports, New, selecting the table or query to
  use, and clicking on the Basic Report icon .
• More complex layouts can be created using the
  Report Wizard. Click on the Report Wizard icon
  and you will see the fields to choose from. The
  order you choose the fields will be the one shown
  in the report, click next, ignore grouping (click
  next again), now select a sort order (e.g.
  customer, product or order), click next, select
  Tabular, next, next and give a Title to the
  report, and click Finish.
• At this point you have your report formatted, but
  you have no total and sub-totals.
• Select the basic report in the left pane,
  right-click and choose design view. Now add
  totals to the report right-click in the design
  view, select Sorting and grouping and a toolbar
  will be added at the bottom to do so.
• Click on the toolbar to group by a field (e.g.
  customer number) and choose the field to create
  totals as in this example.
• Save everything. You are mostly done. You can now
  embellish the report at your hearts content. Use
  help for more details.

7
Creating forms

• There are six types of forms single column,
  tabular, datasheet, subforms, pivot tables and
  graphs.
• In the database window, select Forms, New, and
  select the table you will create the form for.
• You can use a series of wizards or the default
  Design View. In your project you can simplify
  your work if you use the columnar autoform.
• If you use the Design View, place the table
  fields and toolbox in the work area using their
  toolbar icons to make your
  work easier, as show in this image.
• Save and name it.
• Use help for more details.
