Destination Dispatch

1
ELEVATOR DESTINATION DISPATCH AT BAY ADELAIDE
CENTRE
2
Destination Dispatch Ground Floor G
Touch screens (4 in total)
Touch screens replace conventional pushbuttons.
3
Destination Dispatch Entry Screen
4
Destination Dispatch Assignment Screen
5
Ground Floor Car Identifier

• Identify assigned car.
• Confirm destination floor(s).

6
Destination Dispatch Floors 10, 38-49
Touch screens

• Touch screens replace conventional pushbuttons
• One at floor 10
• Two each at
• floors 38-45
• Four at floor 46
• Two each at
• floors 47-49.

7
Tenant Floor Car Identifier
F
Above entrances at tenant floors to identify
assigned car.
8
Destination Dispatch Car Target Indicators
Car target indicators
Car buttons are inoperative but illuminate to
confirm destination floor(s).
9
Car Target Indicators
10
Destination Dispatch Meets Accessibility
Guidelines
11
Destination Dispatch Assignment Screen
12
After Hours Floor Access Initial Implementation

• Same as current system
• Select direction of travel at kiosk
• and proceed to first elevator.
• Swipe access card over card
• reader inside car.
• Select your desired floor inside
• car.

13
After Hours Floor Access Final Implementation
(Jan 2013)

• Swipe access card over card
• reader in kiosk.
• Padlocks temporarily removed
• from authorized floor(s)
• Select your desired floor at
• kiosk.
• Proceed to assigned elevator.

14
QA Period
