Workload Design: Selecting Representative Program-Input Pairs

1
Workload Design Selecting Representative
Program-Input Pairs

• Lieven Eeckhout
• Hans Vandierendonck
• Koen De Bosschere
• Ghent University, Belgium
• PACT 2002, September 23, 2002

2
Introduction

• Microprocessor design simulation of workload
  set of programs inputs
• constrained in size due to time limitation
• taken from suites, e.g., SPEC, TPC, MediaBench
• Workload design
• which programs?
• which inputs?
• representative large variation in behavior
• benchmark-input pairs should be different

3
Main idea

• Workload design space is p-D space
• with p relevant program characteristics
• p is too large for understandable visualization
• correlation between p characteristics
• Idea reduce p-D space to q-D space
• with q small (typically 2 to 4)
• without losing important information
• no correlation
• achieved by multivariate data analysis
  techniques PCA and cluster analysis

4
Goal

• Measuring impact of input data sets on program
  behavior
• far away or weak clustering different behavior
• close or strong clustering similar behavior
• Applications
• selecting representative program-input pairs
• e.g., one program-input pair per cluster
• e.g., take program-input pair with smallest
  dynamic instruction count
• getting insight in influence of input data sets
• profile-guided optimization

5
Overview

• Introduction
• Workload characterization
• Data analysis
• Principal components analysis (PCA)
• Cluster analysis
• Evaluation
• Discussion
• Conclusion

6
Workload characterization (1)

• Instruction mix
• int, logic, shiftbyte, load/store, control
• Branch prediction accuracy
• bimodal (8K2 bits), gshare (8K2 bits) and
  hybrid (meta 8K2 bits) branch predictor
• Data and instruction cache miss rates
• Five caches with varying size and associativity

7
Workload characterization (2)

• Number of instructions between two taken branches
• Instruction-Level Parallelism
• IPC of an infinite-resource machine with only
  read-after-write dependencies
• In total p 20 variables

8
Overview

• Introduction
• Workload characterization
• Data analysis
• Principal components analysis (PCA)
• Cluster analysis
• Evaluation
• Discussion
• Conclusion

9
PCA

• Many program characteristics (variables) are
  correlated
• PCA computes new variables
• p principal components PCi
• linear combination of original characteristics
• uncorrelated
• contain same total variance over all benchmarks
• VarPC1 gt Var PC2 gt VarPC3 gt
• most have near-to-zero variance (constant)
• reduce dimension of workload space to q 2 to 4

10
PCA Interpretation

• Interpretation
• Principal Components (PC) along main axes of
  ellipse
• Var(PC1) gt Var(PC2) gt ...
• PC2 is less important to explain variation over
  program-input pairs
• Reduce No. of PCs
• throw out PCs with negligible variance

Variable 2
PC 1
PC 2
Variable 1
11
Cluster analysis

• Hierarchic clustering
• Based on distance between program-input pairs
• Can be represented by a dendrogram

12
Overview

• Introduction
• Workload characterization
• Data analysis
• Principal components analysis (PCA)
• Cluster analysis
• Evaluation
• Discussion
• Conclusion

13
Methodology

• Benchmarks
• SPECint95
• Inputs from SPEC train and ref
• Inputs from the web (ijpeg)
• Reduced inputs (compress)
• TPC-D on postgres v6.3
• Compiled with O4 on Alpha
• 79 program-input pairs
• ATOM
• Instrumentation
• Measuring characteristics
• STATISTICA
• Statistical analysis

14
GCC principal components
2 PCs 96,9 of total variance
15
GCC
High branch prediction accuracy
High I-cache miss rates
explow
High D-cache miss rates Many control shift insn
recog
toplev
emit-rtl
protoize
cp-decl
expr
insn-emit
varasm
reload1
insn-recog
dbxout
Many LD/STs and ILP
print-tree
16
Workload space 4 PCs -gt 93.1
Go low branch prediction accuracy Compress high
data cache miss rate Ijpeg high LD/STs rate, low
ctrl ops rate
17
Workload space
18
Small versus large inputs

• Vortex
• Train 3.2B insn
• Ref 92.5B insn
• Similar behavior linkage distance 1.4
• Not for m88ksim
• Linkage distance 4
• Reference input for compress can be reduced
  without significantly impacting behavior 2B vs.
  60B instructions

19
Impact of input on behavior

• For TPC-D queries
• Weak clustering
• Large impact
• I-cache behavior
• In general variation between programs is larger
  than the variation between input sets for the
  same program
• However there are exceptions where input has
  large impact on behavior, e.g., TPC-D and perl

20
Overview

• Introduction
• Workload characterization
• Data analysis
• Principal components analysis (PCA)
• Cluster analysis
• Evaluation
• Discussion
• Conclusion

21
Conclusion

• Workload design
• representative
• not long running
• Principal Components Analysis (PCA) and cluster
  analysis help in detecting input data sets
  resulting in similar or different behavior of a
  program
• Applications
• workload design representativeness while taking
  into account simulation time
• impact of input data sets on program behavior
• profile-guided optimizations
