Computation of FREE CONVECTION

1
Computation of FREE CONVECTION

• P M V Subbarao
• Associate Professor
• Mechanical Engineering Department
• IIT Delhi

Quantification of Free .
2
Governing Equations

• Now, we can see buoyancy effects replace pressure
  gradient in the momentum equation.

• The buoyancy effects are confined to the momentum
  equation, so the mass and energy equations are
  the same.

Strongly coupled and must be solved simultaneously
3
Dimensionless Similarity Parameter

• The x-momentum and energy equations are

4
Dimensionless Similarity Parameter

• Define new dimensionless parameter,

• Grashof number in natural convection is analogous
  to the Reynolds number in forced convection.
• Grashof number indicates the ratio of the
  buoyancy force to the viscous force.
• Higher Gr number means increased natural
  convection flow

natural
forced
5
Laminar Free Convection on Vertical Surface

• As y ? ? u 0, T T?
• As y ? 0 u 0, T Ts
• With little or no external driving flow, Re ? 0
  and forced convection effects can be safely
  neglects

6

• Analytical similarity solution for the local
  Nusselt number in laminar free convection

Where
Average Nusselt
7
Effects of Turbulence

• Just like in forced convection flow, hydrodynamic
  instabilities may result in the flow.
• For example, illustrated for a heated vertical
  surface
• Define the Rayleigh number for relativemagnitude
  of buoyancy and viscous forces

8
Effects of Turbulence

• Transition to turbulent flow greatly effects heat
  transfer rate.

9
Empirical Correlations
Typical correlations for heat transfer
coefficient developed from experimental data are
expressed as
For Turbulent
For Laminar
10
Vertical Plate at constant Ts
11

• Alternative applicable to entire Rayleigh number
  range (for constant Ts)

• Vertical Cylinders
• Use same correlations for vertical flat plate if

12
Free Convection from Inclined Plate
Cold plate or Hot fluid
Hot plate or Cold fluid
13
Horizontal Plate
Cold Plate (Ts lt T?)
Hot Plate (Ts gt T?)
Active Upper Surface
Active Lower Surface
14
Empirical Correlations Horizontal Plate

• Define the characteristic length, L as

• Upper surface of heated plate, or Lower surface
  of cooled plate

• Lower surface of heated plate, or Upper surface
  of cooled plate

Note Use fluid properties at the film temperature
15
Empirical Correlations Long Horizontal Cylinder

• Very common geometry (pipes, wires)
• For isothermal cylinder surface, use general form
  equation for computing Nusselt

16
Constants for general Nusselt number Equation
17
free convection turbulent heat transfer in an
enclosure

• Turbulent flow in an enclosed cavity or box is a
  model for many flows of practical interest
• Heating of a room.
• Flow in a double glazing Window.
• Spreading of fire and fire generated gases in an
  building.

18
Velocity Vectors on A Central Vertical Plane
19
Isotherms on A Central Vertical Plane
20
Nusselt Number Correlations
21
Natural Convection in A Pool of Saturated Liquid
Tsat
Onset of Convection
Tsurface
22
Further Behavior of Saturated Liquid
Natural Convection
Increasing DT
Onset of Boiling
Isolated Bubble Regime
23
High Overshoots !!!
A
B
A Onset of Natural convection
B Onset of Nucleate Boiling
Heat Flux
Overshoot
Wall Superheat (DTTs Tsat)
24
BOILING HEAT TRANSFER

• P M V Subbarao
• Associate Professor
• Mechanical Engineering Department
• IIT Delhi

A Basic means of Power Generation A science
which made Einstein Very Happy!!!
25
Boiling

• In a steam power plant convective heat transfer
  is used to remove heat from a heat transfer
  surface.
• The  liquid  used  for  cooling  is  usually  in
   a  compressed  state,  (that   is,  a  subcooled
   fluid)  at pressures higher than the normal
  saturation pressure for  the given temperature.
• Under certain conditions some type of boiling can
  take place.
• It is  an important  process  in nuclear  field
   when  discussing convection heat transfer.
• More  than  one  type  of  boiling  can  take
   place  within  a
• nuclear facility.

26
Nuclear Power Plant
27
Steam Boiler
28
Classification of Boiling

• Microscopic classification or Boiling Science
  basis
• Nucleated Boiling
• Bulk Boiling
• Film Boiling
• Macroscopic Classification or Boiling Technology
  basis
• Flow Boiling
• Pool Boiling

29
Nucleate Boiling

• The most common type of local boiling encountered
  in nuclear facilities is nucleate boiling.
• In nucleate boiling, steam bubbles form at the
  heat transfer surface and then break away and are
  carried into the main stream of the fluid.
• Such movement enhances heat transfer because the
  heat generated at the surface is carried directly
  into the fluid stream.
• In the main fluid stream, the bubbles collapse
  because the bulk temperature of the fluid is not
  as high as the heat transfer surface  temperature
   where  the  bubbles  were  created.
• This  heat  transfer  process  is  sometimes
  desirable  because  the  energy  created  at  the
   heat  transfer  surface  is  quickly  and
   efficiently "carried" away.

30
Bulk Boiling

• As  system  temperature  increases  or  system
   pressure drops,  the  bulk  fluid  can  reach
   saturation conditions.
• At this point, the bubbles entering the coolant
  channel will not collapse.
• The bubbles will tend to join together and form
  bigger steam bubbles.
• This phenomenon is referred to as bulk boiling.
• Bulk  boiling  can  provide  adequate  heat
   transfer  provided  that  the  steam  bubbles
   are carried  away  from  the  heat  transfer
   surface  and  the
• surface  is  continually  wetted  with
   liquid water.
• When this cannot occur film boiling results.

31
Film Boiling

• When the pressure of a system drops or the flow
  decreases, the bubbles cannot escape as quickly
  from  the  heat  transfer  surface.
• Likewise,  if  the  temperature  of  the  heat
   transfer  surface  is increased, more bubbles
  are created.
• As the temperature continues to increase, more
  bubbles are formed  than  can  be  efficiently
   carried  away.
• The  bubbles  grow  and  group  together,
   covering small  areas  of  the  heat  transfer
   surface  with  a  film  of  steam.
• This  is  known  as  partial  film boiling.
• Since  steam  has  a  lower  convective  heat
   transfer  coefficient  than  water,  the  steam
  patches on the heat transfer surface act to
  insulate the surface making heat transfer more
  difficult.
• As  the  area  of  the  heat  transfer  surface
   covered  with  steam  increases,  the
   temperature  of  the surface  increases
   dramatically,  while  the  heat  flux  from  the
   surface  decreases.

32

• This  unstable situation continues until the
  affected surface is covered by a stable blanket
  of steam, preventing contact between the heat
  transfer surface and the liquid in the center of
  the flow channel.
• The condition after the stable steam blanket has
  formed is referred to as film boiling.
• The process of going from nucleate boiling to
  film boiling is graphically represented in
  Figure.
• The figure illustrates the effect of boiling on
  the relationship between the heat flux and the
  temperature difference between the heat transfer
  surface and the fluid passing it.

33
Boiling Curve
