Title: TERRACES


1
(No Transcript)
2
TERRACES
Haris Khurshid
2008-ag-1775
3
What is Terrace. . ?
  • A terrace is an embankment or ridge of earth
    constructed across a slope to control runoff and
    minimize soil erosion

4
TERRACING
  • It is the practice of making such structures
    like embankments along with flattened portions of
    land on a slope to utilize it precisely, keeping
    in mind the protection and improvement of soil
  • Or
  • Terracing is the mechanical practice used on
    slopping agricultural land to reduce the length
    and /or the degree of slope

5
TERRACE FARMING
  • Cultivation of crops on terraces keeping
    suitability of a particular crop and good crop
    husbandry practices in mind to utilize that land
    maximum to get wholesome returns

6
Objectives of Terracing
  • Land use
  • Soil conservation
  • To check soil erosion
  • To improve soil structure
  • To maintain fertility status
  • Water conservation
  • Increase infiltration rate
  • Decrease runoff
  • Storage of water by water harvesting
    occasionally

7
Types of Terraces
  • Ridge Type Terrace
  • Which remove or retain water on sloping land
  • Level terrace or contour Bunding
  • Bench Terrace
  • Which reduce the land slope

8
Ridge type Terraces
  • Depending on the width of the base, ridge
    type terrace may be classified as
  • Narrow Based Terraces
  • Medium based Terraces
  • Broad Based Terraces

9
  • Narrow-base terraces
  • Where soil movement is limited to about
    three meters
  • Medium-base terraces
  • Where soil movement is three to six meters
  • Wide or broad-based terraces
  • Where soil is moved more than six meters, but
    normally less than 12 meters

10
(No Transcript)
11
Broad based Terraces
  • A broad base terrace has a ridge 25 to 50cm
    high with gently slopping sides and a dish
    stopped channel along the upper side constructed
    to control erosion by diverting runoff at a non
    erosive velocity. based on greed it is divided
    or classified as
  • Level Terrace
  • Graded Terrace

12
  • Level terrace
  • A level terrace follows the contour line, in
    control to a graded terrace and recommended in
    areas having permeable soil.
  • Graded terrace
  • A grads terrace has a constant or variable
    grade along its lengthened used to convey excess
    runoff at safe velocity into a vegetated waterway
    or channel.

13
Bench Terracing
  • A bench terrace is shelf like embankment of
    earth with a level or nearly level top and a step
    or vertical downhill face constructed along the
    contour of sloping land.
  • In very stable soils, the walls may be held
    by vegetation, and in others some structural
    walls are necessary, as brick, stone or timber.

14
Cross section showing benched effect
15
. A sketch of a typical bench terrace
16
Classification of bench terraces based on slope
  • Absorption or Level Terraces
  • These are constructed exactly on the contour and
    provided with sufficient freeboard so that they
    can trap all the rain that falls.
  • They are principally used in dry areas where
    rainfall is low and moisture for crop production
    is, therefore, at a premium.

17
Absorption or Level Terraces
18
  • Outward-sloping terraces
  • Bench terraces sloping outwards are effective
    only in low rainfall areas with a permeable soil
    of medium depth at lower ends graded channels are
    provided for safe disposal of runoff.
  • Suitable for orchards
  • Better on steep slopes
  • Used to mild slope
  • Slope up to 15

19
  • Some terraces have a grassed waterway
    outlet. . .
  • While other terraces channel runoff water to
    a storage section where it is released slowly
    through a surface inlet and underground pipe or
    tile. . .

20
  • 3) Reverse/Inward sloping Terraces
  • In heavy rainfall areas, bench terraces of
    sloping inwards type are more effective. It
    prevents in-ponding of water and useful for crops
    susceptible to water logging.
  • No super-saturation of
  • profile
  • Back slope stabilization
  • Runoff towards hillside

21
  • 4) Conservation bench terraces
  • Modified form of level terrace
  • In limiting soil moisture
  • Use moisture of
  • Uncropped area by runoff

22
Conservation bench terracing
23
Pictorial comparison of slope based bench terraces
24
Classification of bench terraces based on use
  • Depending upon the purpose for which they are
    used, bench terraces are classified as follows
  • Hill type Bench Terraces
  • Irrigated Bench Terraces
  • Orchard Bench Terraces

25
  • Hill type Bench Terraces
  • It is used for hilly areas whit a reverse
    grad towards the hill.

26
  • Irrigated Bench Terraces
  • Level benches are adopted under irrigated
    conditions. The level table top terraces are
    referred to as irrigated bench Terries.

27
  • Orchard Bench Terraces
  • Narrow width terraces for individual trees are
    prepared in this type. These are also referred as
    intermittent terraces and step terraces. The
    conversion of land into bench terraces over a
    period of time is referred as gradual bench
    terracing.

28
Designing construction of Bench terraces
  • Factors of Site suitability
  • Soil depth
  • Land slope
  • Implement widths
  • Back slope stabilization
  • Runoff disposal

29
  • Steps in design of bench Terraces
  • Step I-Type of the bench terrace
  • Selection of the type of bench terrace
    depends upon the rainfall and soil, condition.
  • Step II -Terrace Spacing
  • It is normally expressed in terms of the
    vertical interval between two terraces. It
    depends upon soil, slope, surface condition,
    grade and agriculture use.

30
  • Considerations for spacing
  • Find Out the maximum depth of productive soil,
  • maximum admissible cutting depth
  • Given land slope
  • From this, The width of the terraces can be
    computed for a given slope

31
  • Step III Terrace cross section
  • Design of terrace cross consists of deciding
  • 1 The slope2 Dimensions of shoulder bund3
    Inward slope in case of terraces sloping inward,
    and4 Outward slope in case of terraces sloping
    outward.

32
  • Step IV
  • The cross- section of shoulder bund along outer
    edge of terrace should also be designed suitably
    to make the bund stable against slipping.

33
  • TERRACING COSTS
  • The costs that will be incurred in constructing
    terraces is largely a function of
  • Width of terrace,
  • Slope of land,
  • Type of protection for the back slope
  • construction machinery.

34
Construction using a disc plough
C LINECUT LINE F LINEFILL LINE
35
BENEFITS OF TERRACING
  • Avoid soil erosion
  • Up to 25 reduction in soil loss

Terraces in China (photo by UN - World Food
Programme)
36
  • Benefits . . .
  • Reduction in Runoff(up to 30-35)
  • Soil structure integrity
  • Proper land use
  • Feasibility of crop production in hilly areas
  • Increase in soil moisture level

37
  • Benefits . . .
  • Maintenance of soil fertility
  • Water conservation(up to 45-55 saving)
  • Enhanced infiltration rate
  • Improved water holding capacity

38
  • TERRACE FARMING WORLDWIDE

39
Terraces in northern Luzon Philippines 2000-B.C
40
Level terracing in JAPAN
41
Tea on bench terraces, BHUTAN
42
KOREA
43
TERRACES ON ERODED SOILS OF ISRAEL
44
TERRACED FIELDS IN SA PA, VETNAAM
45
RICE TERRACE PENORAMA IN BALI
46
CHINA
47
FLAT TERRACES IN HUNZA VALLEY, GILGIT
48
SWAT VALLEY, PAKISTAN
49
GRASSY TERRACES IN CHITRAL, PAKISTAN
50
KASHMIR, PAKISTAN
51
  • FUTURE OF TERRACE FARMING

52
THANKS
Questions ???
