Student Centered ODS

1
Student Centered ODS

• ETL Processing

2
Insert

• Search for rows not previously in the database
  within a snapshot type for a specific subject and
  year
• Check for duplicates
• Identify test
• Lookup metadata
• Create Unique Test Event identifiers
• Load data
• Copy Previous Year Test details

3
?
How the effective date is determined before /
after noon
In some rare cases, a row is found to be inserted
that has already been end dated. In that case it
will be added to the database and be effective
for one day.
4
Update

• Search for changes to rows already in the ODS
  from Staging within a snapshot type for a
  specific subject and year that occurred since the
  last run of the update ETL
• No need to check for duplicates
• Identify test
• Lookup metadata
• Load data
• Determine how to apply update
• Normally end date prior version of row and insert
  new row
• On some occasions rows that had been previously
  end dated may be reintroduced to the ODS
• Sometimes the only action is to end date the
  current row
• Copy Previous Year Test details

5

How the effective date is determined before /
after noon
6
Update Logic

• Read updated row from Staging
• Read current record from ODS
• If row in ODS is end dated
• Add new row to ODS
• If row in ODS is not end dated
• Compare columns Staging ltgt ODS
• If the columns are different
• End date ODS row
• Add Staging row to ODS
• If the columns are the same and the end date in
  the ODS row is not set and the end date from the
  Staging record is set
• End date ODS row

7
Delete (soft)

• For the subject / year table search for rows in
  the ODS that are no longer in Staging
• The examinee table is not checked for end dated
  rows, only the subject / year table is used to
  determine if a delete is needed per Assessment
• A Cascaded update is performed end dating the
  entire test event and all related rows from the
  following tables
• Event
• EventInst
• EventInd
• BnchLvl
• Score
• RaterScore
• PaperPencilData
• CmptrBasedData
• EventClsRm
• The end date is determined the same way as in the
  insert and update ETL

8
The affects of source tables on Student Centered
tables
Not all tables are loaded for all tests

• Score, Benchmark Level and Rater Score are not
  loaded for Virtual tests
• Presently only Writing has Rater Scores (possibly
  ELPA in the future)
• Paper / Pencil tests load to Paper Pencil Data
  and Event Class Room
• Computer based tests load to Computer Based Data
• Writing has only total Benchmark Level scores
  while other subjects have Benchmark Level scores
  at the category (aka strand) level

Some tables are only loaded if there are values
present

• Only non-blank scores are loaded to the Benchmark
  Level table
• Only non-null scores are loaded to the Score and
  Rater Score tables
• Only non-null institution identifiers are loaded
  to the Event Institution table

9
Example of applying updates
Row is inserted
Update to Subject / Year table
ltlt Changes to an Institution and an indicator
end date current rows
ltlt Insert new current rows null end date
Update to Subject / Year table
ltlt Changes to student demographic data end date
current row
ltlt Insert new current row null end date
10
Maintenance

• Occasionally there may be the need to make
  corrections or to reload portions of the ODS
• After a few years there may also be the need to
  remove some lower level of detail from the ODS
• In any case as maintenance is needed
  communication will be made to inform clients of
  what changes are coming and some suggestions on
  how to deal with those changes

11
How to store the Extracted ODS Data

• It is recommended that the extract layout be used
  as a guide for the staging database
• A data model is available in this format for your
  use
• The model is in power designer 12.5 and available
  in html format for review

12
Considerations for your local ODS

• The ID column from each table is sufficient for a
  primary key
• Columns ending in _ID are foreign keys from other
  tables and should be indexed
• The SMFConfig_ID can be used for vertical
  partitioning of the Core Content data
• Additional indexes are in the data model and you
  may want to tune and add more based on your needs

13
Loading data to your local ODS

• If you follow the suggested database design, the
  process of loading data is simple
• On your schedule you will receive data
• Rows that match by ID are updated
• Rows not found by matching on ID are inserted
• The Security tables are replaced on each load in
  total
• Thats all there is to keeping your local ODS up
  to date.

14
How to retrieve data from your local ODS

• Generally there are two types of queries
• Current data
• Data as of a date
• For current data select where the end date is
  null
• select
  from Event

  where
  UnqTstEvent_ID 500
  and Enddt is null
• For data as of a date a query such as this will
  work
• select
  from
  Event
  where EffDt lt
  2008-11-19 105700.000
  and (EndDt is null or EndDt gt
  2008-11-19 105700.000)
  and UnqTstEvent_ID 500

15
Formal and Inferred Registration System (FIRS)

• FIRS makes it possible for ODE to give the proper
  data for each of the students served by your
  clients
• Spring and Fall Membership, all state assessments
  and any student transfers through OSTX since
  2004-2005 are used by FIRS to form a chronology
  of which institutions a student was related to
  and when
• This information is used by the extract process
  to provide the most complete data possible
• In the coming year the new Consolidated ADM data
  collection will begin providing information to
  this process as well
• The tables FIRS and DistUnqTstEvent provided in
  your extract are taken from this system

16
Extract Process

• Regions must provide a list of districts in order
  to receive the extract
• The ODE helpdesk will setup the relationships
  between the Region and their districts
• The first extract will be a full
• The next extract will change to an incremental
  automatically
• An incremental extract includes changes for
  continuing students plus full extracts for
  students new to the client districts
• Each time an extract is performed the last
  extract date in the Regions configuration is set
• The next extract will contain all changes since
  the last extract date

17
Extract Process (continued)

• Data is extracted into the formats specified by
  the StudentCenteredExportFormat.xls
• One file is produced per table described in the
  format
• The files are in CSV format with text delimited
  by quotes
• Files will only be produced if there are rows
  qualifying for the extract
• The file Manifest.txt contains a list of the
  files extracted with the count of rows and when
  it was produced
• The CSV files and the Manifest.txt are compressed
  into a .zip file and placed on ODEs secure FTP
  site for pickup by the Region

18
File Transfer and Scheduling

• When the districts the Region serves are
  communicated to the ODE Helpdesk ODE will also
  make sure security is setup for connecting to the
  secure FTP server
• Instructions for connection will be provided
• The ODE helpdesk can schedule which days the
  Region will receive files
• The same scheduling system is already in use for
  extracting data from Student Centered Staging

19
Requested extracts

• At times it may be necessary for the Region to
  receive a full extract to repopulate your local
  ODS or the Region may have missed some extracts
  produced previously
• Full extracts can be scheduled by the ODE
  Helpdesk
• The number that can be done in one day is limited
• Full extracts may have to wait until the weekend
• Full extracts will not be provided on a regular
  basis
• For missed extracts, the ODE Helpdesk can set the
  date as of which the extract will pull
  information and provide a larger incremental
  extract
• The date as of which the extract will pull
  information is cleared after the run of the
  extract
• Processing will return to normal automatically

20
Limiting Access

• Each extract will provide a new copy of the
  security files (FIRS and DistUnqTstEvent)
• The FIRS file contains the district related to
  the student with the end date provided for review
  if needed
• The DistUnqTstEvent relates the district to the
  specific test events available to that district
• By simply joining through this table when
  providing access to your clients you can restrict
  access to just the information they are allowed
  to access
• Declare _at_DistInstID int
• Set _at_DistInstID 2082
• select e.
• from Event e
• join DistUnqTstEvent d
• on e.UnqTstEvent_ID d.UnqTstEvent_ID
• and d.DistInstID _at_DistInstID

21
Data Model

• Follows the same definitions provided by the
  StudentCenteredExportFormat.xls spreadsheet
• Organized around the document as well providing
  different color coding for the same major
  subjects as the spreadsheet
• Core Content Data
• Score Data
• File Processing Control Data
• Metadata
• Security
• plus
• Possible changes
• The model show how the tables are related to each
  other and provides useful information about the
  data
• The model is in Power Designer 12.5 an html
  version is available to review the model that
  contains table create statements as well

22
Pulling it all together

• The SMFConfig table is essentially a link to the
  subject and year that the data belongs with
• Most of the metadata is contained in a Table of
  Tables / Master Codes scheme which houses virtual
  tables and related code values
• Each row in the Table of Tables represents a
  virtual table
• Rows in the Master Codes table relate back to the
  Table of Tables for rows that represent the
  values stored in the virtual table of tables
• The Ctgry table is used to indicate the score
  reporting category (aka strand) related to score
  data
• The Ctgry table also contains entries for total
  scores
• Review samples

23
Student Centered ODS

• Thanks for coming!
