www.themegallery.com

1
ESUN 3D Filament - Bring you creativity, fun,
imagination
SHENZHEN ESUN INDUSTRIAL CO., LTD.
www.themegallery.com
2
Content
Esun Introduction
1
FDM for 3D printing
2
PLA applications in 3D printing
3
PLA modifications
4
Special filaments
5
Summary
6
3
About ESUN
Full name ShenZhen ESUN Industrial Co., Ltd.
Established 2002, privately held
Locations ShenZhen and Wuhan Factory
location XiaoGan city (near Wuhan) Patent
portfolio more than 20 Business scope
Research and development, manufacturing and
production of lactate, lactate esters, phosphate,
PLA, Polymorph etc. Mission statement focus on
biomaterials and biologic solvents using natural
resources to provide recyclable/reusable and
bio-degradable products for better environments
and human life.
www.themegallery.com
4

Esun 3D Filament History and Roadmap
2007
2012
2014
Beyond
2002
2011
2013

1. Soft PLA filament
2. Nylon filament
3. Conductive filament
4. PC filament

RD on PLA
Powder and other materials for various 3D printers
1. PLA filament 2. ABS filament

1. PVA filament
2. HIPS filament
3. Fluorescence filament

1. PE filament
2. PP filament
3. Wood filament
4. Color changing filament

RD on 12 colors of ABS and PLA filament
5
Company Product Certificates
No.CANEC1301362201
FDA PLA 1001SZHH00512395
DIN EN 134322000-12 ASTM D 64002004
6
Esun Introduction
1
FDM for 3D printing
2
PLA applications in 3D printing
3
PLA modifications
4
Special filaments
5
Summary
6
7
FDM for 3D printing
FDM Fused Deposition Modeling
Extruder feeds and retracts the thermoplastic
filament in precise amounts
Filament spool
Nozzle head heats the filament and turns the flow
of the extruded material on and off
Extruded material is laid down in a specific
diameter on the bed
Stepper motors or servo motors, controlled by
computer-aided manufacturing (CAM) software
package, move the extruder and nozzle head in XYZ
directions
8
FDM for 3D printing
Driving factors for FDM3D market and
application a. Open-source software lowers
technical barrier and opens the door for more
companies/individuals to play, from software
optimization and new software development to
innovative structural design and applications
b. 3D printer price drop mature technology,
more competition

• c. Printing materials wider selections and
  lower cost of different materials
• d. Consumer market - cost effectiveness attracts
  more individual consumers
• e. Government funding supports 3D printing in
  different countries.

9
Challenges for Todays 3D Filament
Quality and stability
Size control
Fragile
Bubbles
Clogging
Warp
Limited availability for unlimited applications.
2
Material fluency for faster printing
3
Environmental issues (bio-hazard)
4
Economics
5
10
Some examples of quality issues
Easily crack
Easily warp
Bubble
Block the extruder
Inaccurate diameter
11
Esuns Approaches
Various Material
Environment Friendly
Good Quality
Economics
Adopt stringent and consistent Quality (ISO).
Appearance, Performance, Purity
control, Consistency
Invest heavily into RD and work closely with all
customers to understand their needs
Select the biodegradable material, synthesized
from natural plants, such as PLA and PVA.
Automation, Planning and Logistics, Labor and
OH, Improve SAM for volume,
12
Wide selection of 3D materials from eSUN
13
Esun Introduction
1
FDM for 3D printing
2
PLA applications in 3D printing
3
PLA modifications
4
Special filaments
5
Summary
6
14
PLA in 3D printing
What's PLA?
Poly(lactic acid) or polylactide (PLA) is a
thermoplastic aliphatic polyester derived from
renewable resources. Due to its wide applications
and environmentally friendly nature, PLA is
regarded as one new industrial revolution in
Polymers.

• From renewable resources, such as
• Corn starch (in the United States)
• Tapioca roots, chips or starch (mostly in Asia)
• Sugarcane (in the rest of the world)

15
PLA in 3D printing
Low shrink rate

• Advantages
• Non harmful, non-toxic, biodegradable,
  environmental friendly
• Excellent mechanical strength, good rigidness,
  suitable for complex models.
• Low material shrinkage rate
• Uniform diameter and no warp.
• Printing temperature is 190220?, lower than
  other materials.

Environmentally Friendly
Biocompatibility
Bio-based
Transparent/ Translucent
16
Some examples using eSUN PLA
Turbofan, Esun PLA
17
Esun Introduction
1
FDM for 3D printing
2
PLA applications in 3D printing
3
PLA modifications
4
Special filaments
5
Summary
6
18
PLA Modifications

• Improvements and modifications to existing PLA
  material from eSUN for better performance and
  reliability through the following
• Control Melt Flow Index.
• Match crystallization and rapid prototype
  technology.
• Improve Impact Strength.
• Improve temperature resistance.
• Lifetime study on PLA.
• Functional optimization.

19
PLA Modifications
2D nucleation system control PLA cooling speed
Table 1 Influence of crystallization on PLA
solidification time
Item Unit PLA1001 1D structure 2D structure ABS
Solidification Time S 15 10 6 10
Tensile Yield Strength MPa 63 60 58 45
20
PLA Modifications
Improvement of PLA Impact Strength Single
toughness improvement system (STIS) is limited to
increase PLA toughness
Table 2 Influence of STIS on PLA performance
Item Unit PLA PLA Ingredient (955) PLA Ingredient (955) PLA Ingredient (955) PLA Ingredient (955) PLA Ingredient (9010)
Item Unit PLA Ingredient1 Ingredient2 Ingredient3 Ingredient4 Ingredient 2
Tensile Yield Strength MPa 69.1 48.0 44.2 60.4 46.7 40.4
Elongation at Break 5.5 5.5 9.8 3.4 9.6 13.1
Flexural Strength MPa 61.1 65.0 53.9 53.7 53.3 49.4
Flexural Modulus MPa 2732 2768 1959 2830 2090 1678
Impact Strength KJ/m2 3.5 5.2 4.72 4.63 4.27 5.55
21
PLA Modifications
Influence of added ingredient on PLA performance
Figure 1 Influence of ingredienton PLA toughness
Figure 2 Influence of ingredient on PLA Tensile
Yield Strength and Flexural Strength
22
PLA Modifications
Influence of added ingredient on PLA Impact
Strength
Figure 3 Influence of ingredienton PLA toughness
Figure 4 Influence of ingredient on PLA Tensile
Yield Strength and Flexural Strength
23
PLA Modifications
Presence of rigid particles help reduce the shift
between material clamping tooth
GOAL Increase friction between clamping tooth,
reduce relative shift and ensure stable material
feeding RESULT Improved printing precision,
size stability and warp resistance.
Presence of certain rigid particles
Figure 5 Influence of different rigid particle on
PLA toughness
Figure 6 Influence of different rigid particle on
Tensile Yield Strength
24
PLA modifications
Improvement of PLA printing fluency

• Material fluency cannot be too fast or too slow,
  it must match the printing speed. This ensures
  that printing precision is maintained and not
  degraded.
• Material fluency is closely related to PLA
  melting speed, where Esun employs the following
  factors to ensure optimal PLA melting speed
• Adjust PLA molecular weight and distribution when
  synthesizing PLA.
• Further addition of molecular weight ingredient
  to control PLA melting speed.
• Adopt composite lubrication system to control PLA
  melting speed.
• Adopt sheet structure and fiber material to
  adjust PLA melting speed.

25
PLA Modifications

• PLA Lifetime adjustment

1. Method adopted Generation of various compounds
   to adjust PLA lifetime
2. Current compounds tested PLA/PHA, PLA/PCL,
   PLA/PBS, PLA/PPC, PLA/PBC, PLA/PEG by melting
   mix, and printing body organs via FDM technology
   for medical application.

26
Esun Introduction
1
FDM for 3D printing
2
PLA applications in 3D printing
3
PLA modifications
4
Special filaments
5
Summary
6
27
Special Filaments - PVA

1. Environmental safe, non-toxic
2. Water soluable at normal temperature
3. Co-printing with many materials possible due to
   its good adhesion property
4. Easy strip-off
5. Printing temperature is 190220?,

28
Special Filaments - Cleaning

• Unclog the clogged nozzle
• Preventive maintenance

29
Special Filaments color change
30
Special Filaments Wood

• Applications in 3D printing
• Printing something similar to wood, such as
• Wood furniture
• Wood toys
• Housing model
• Printing parameters
• Temperature 190-200 ?
• Bed temperature 60 ? or no heating
• Infill speed 20-80 mm/s
• Travel speed 30-80 mm/s

31
Special Filaments PETG

• The closest substitute for ABS
• Similar characteristic as ABS
• High mechanical strength
• Low shrink rate
• Odorless, environment-safe
• Printing parameters
• Temperature 230-250 ?
• Bed temperature 80-90 ?
• Infill speed 30-60 mm/s
• Travel speed 30-60 mm/s

32
filaments we can provide now

• PLA PVA
• ABS HIPS
• PC NYLON
• CONDUCTIVE FLEXIBLE
• WOOD CLEANING
• COLOUR CHANGE
• FRAGRANCE
• GLOW IN DARK
• MORE THAN 13 KINDS OF MATERIALS
• MORE THAN 20 KINDS OF COLOUS

33
Compatible 3D Printer
Typical 3D printers
Markerbot
Up
Esun filament is compatible to all the FDM 3D
printers
Cubify
RepRap
34
Some 3D Filament Application
Art Action Figures Jewelry Hearing Aids Prototypes

Home Decor Models Components/Manufacturing Medicine Education

more
35
(No Transcript)
36
(No Transcript)
37
Summary

• eSUN offers our 3D customers consistent high
  quality and continuous improvements
• eSUN always targets at providing product with
  best cost and performance
• Wide selection of FDM materials and varieties
• Continuous improvements with new products and
  materials
• Flexible business models to accommodate different
  customers needs

38
Thank you! welcome to our booth A9
Shenzhen ESUN Industrial Co., Ltd.
www.esunchina.net bright_at_brightcn.net
