Quality Control
Data Processing Operations Scanning data capture
and quality assurance Quality in the Data Process
Geoffrey Greenwell, Data Processing Advisor IPC
2
Quality in the Data PROCESS

• P-R-O-C-E-S-S

Personal Process Automated Process
3
Conceptual Overview
P-R-O (TQM)
P ersonal Commitment to Excellence
R eject Cynicism or Satisfaction
O wn the process
C-E-S-S (Six Sigma, Lean Manufacturing)
C areful Design
E valuate Continually
S hift Perspectives
S helf Life
4
Conceptual Overview
Tabulation controls
Form Flow Information Exformation
Data Archive
Data Entry Manual Scanning
Edits Structure Pre-edit Consistency
5
Form flow

• Flow Charting is a fundamental tool for careful
  design.
• Flow charting is the mapping of the process.
• A flow chart is defined as a pictorial
  representation describing
• a process being studied or even used to plan
  stages of a project.
• Flow charts tend to provide people with a common
  language
• or reference point when dealing with a project or
  process.
• deming.eng.clemson.edu

6

• EXAMPLE
• Process Flow Chart- Finding the best way home
• This is a simple case of processes and decisions
  in finding the best route home at the end of the
  working day.

Primary Symbols
7
Form Flow

• Software for flowcharting
• ABC Flowcharter
• Visio
• Corel Flow
• (Microsoft word has basic flow chart symbols)

8
Form Flow
Internal information flow Information
External information flow Exformation All the
processes involved in managing questionnaires
and producing progress reports.
All the processes involved in managing the
electronic processes and producing FEEDBACK.
Data flow
Paper Flow
9
Ex-Form Flow
Look at the nodes. In this case, the exchange
of forms is a pressure drop.
2A
5
1
4
2B
2C
3
6

1. Field office to data entry center.
2. Center to Date entry group supervisor.
3. Supervisor to data entry person
4. Problems/trouble shooting.
5. Storage
6. Retrieval

10
Ex-Form Flow
Every node is a potential loss of control in the
process.

• Ways to control
• Operational control forms (electronic systems)
• Progress reports
• Assign responsible persons

11
Ex-Form Monitoring
Control Forms Input and Output
Define a fundamental unit based on geographic
criteria. Census Enumeration areaa box of
formsan electronic batch Survey A regiona time
cyclean electronic batch

• All forms are traced and verified to a master
  control form.
• The flow of the form is followed through the
  phases of the
• data process.
• The process has an audit trail all the way to the
  individual
• data entry station.

12
Ex-Form Flow
A division of labor into logical, efficient and
affordable processes designed to optimize the
efficiency of the production line.
Pf(K,L) Classic production function. Capital
and labor inputs
Labor Intensive Solutions
Space Trained personnel (division of labor) Low
tech supplies boxes, paper, labels
13
In-form flow

• An electronic management system for
• Processing the primary survey or census
  instrument.
• Provide a tool for managing the ex-formation.
• Provide feedback in the form of reports (end of
  information).

Capital Intensive Solutions
Network servers Data entry stations Cabling Printe
rs
14
In-form flow
15
Form Flow (In or Ex?)

• Transferring the box from the project vehicle to
  the forms depot.

• Designing a flow chart for a data entry program.

• Assigning a form to a data entry operator

• Scanning or keying in a form

• Two EA boxes are not closed well and the forms
  scatter
• during transport.

• Backing up data on the central server.

• Supply clerk checking the inventory of paper
  folders labels and
• filling out a form to re-stock needed items.

16
Data Entry
Manual Entry vs. Scanning
The Great Debate
pre unit of time to process
17
Manual Data Entry

• Cost Consideration
• A. Training for all Clerks
• B. Monitoring systems and supervisory time.
• C. Verification of Clerks Work
• D. Keying costs

18
Manual Data Entry
Design Considerations

• Data File Structure
• Levels
• Multiple items vs. records

• Data Dictionary (Critical through all stages!)
• Good and consistent variable labels
• Logical and efficient variable names
• Well defined value sets (several value sets)

• Screen Formats
• Font Size and type
• Soft backgrounds
• Field and text positioning
• Field Size
• Physical form emulation

19
Manual Data Entry

• Path
• Logical Path
• Items vs. fields
• Levels

• Skips
• To skip or not to skip
• Census vs. Surveys

• On-line edits/Error Messages and Warnings
• Census vs. Survey

20
Manual Data Entry
CAPI (Computer Assisted Personal Interviewing)
CATI (Computer Assisted Telephone Interviewing)

• Controls the process of carrying out the
  interview by the enumerator.
• Removes the ex-form process by directly keying
  in responses into
• a portable computer.

21
Manual Data Entry

• Controlling the data entry personnel
• Establish objective measures (extract
  information from Log Files)

Speed and accuracy (8000 keystrokes/hour)

• Heads up vs. Head down keying

• Census vs. Survey Constraints

Censuses High Volumes (Time primary quality
constraint)
Surveys Low Volume (Place is the primary
constraint)
22
Manual Data Entry
Verification procedures Verification is a
duplication of the data entry process in order to
compare two identical records for
inconsistencies Dependent vs.
independent Dependent verification duplicates
the data entry process and compares the data
files on-line and corrects the files when an
error is encountered. Independent verification
is a complete re-entry of a form followed by a
full comparison of the two data
files. Verification is dynamic and is adjusted
to the learning curve. 100 at the outset and
may drop to 2-3 at the end.
23
Scanning
Refer to A Comparison of Data Capture Methods
by Sauer

• Machine quality is very important.
• Glass optics and color corrected instead of
  plastic optics
• (light sensors and diffusion)
• Resolution (DPI) 300
• Bit depth higher bit the better ability to
  interpret grayscales
• Scanning speed
• Optimal environment 60-85 F and 40-60 relative
  hum.

24
Scanning

• Rotary Scanners move the form. Best for censuses
  and surveys.
• Other Options to consider
• Automatic document feeder
• Multi feed detector
• Exit hoppers
• Color bulbs
• Image processing

25
Scanning
Character reading OCR, ICR and OMR

• OMR-Optical Mark Reading. Reads a mark
• from a questionnaire.
• OCR-Optical Character Recognition. Converts
• characters through photosensitive sensors and
  software
• enhancements.
• ICR-Intelligent Character Reading. ICR is
  pattern
• based character recognition and is also known as

• Hand-Print Recognition. (Software differences).

• Remembers patterns.
• Note OCR and ICR usually require constrained
  handwriting or
• BLOCK capital letters.

26
Scanning
Advantages and Disadvantages Speed of
process Loss of process control Technological
Innovation Minimal technological
transfer Minimize human error Maximize machine
error Cost
World Bank CWIQ (Core Welfare Indicators
Questionnaire)
27
Scanning
Quality Issues

• Pencil type, paper jams, damaged forms
• Accurate character recognition dependent on form
  quality and image
• Field level accuracy vs. character level accuracy
• Machine Maintenance
• Software deficiencies (Voting)
• KFI (Key from image) for character correction
• KFP (Key from paper) for form and field
  correction
• Confidence level reports (recognition rates)
• See page 18, Sauer for Quality Control issues

28
Coding
Coding of open ended questions like Occupation
and activity require coding. In Scanning this
can be done from the image. In Manual entry it
is usually the first step. It requires its own
process and supervision. In Scanning it can be
seen as a parallel operation. In Manual Entry it
is linear.
29
Now that you have A well designed dictionary
with the simplest and most efficient structure
and well defined variable labels with easy to use
variable names and well defined value sets
clearly designed, simple and user friendly
screens emulating the forms and flowing logically
with programmed skips and have clear interactive
messages should you use them and have defined
productivity targets for your census or survey
and a system to objectively measure productivity
and reward accordingly and verified the work and
finally rigorously subjected it against the
PROCESS rule of quality you still need to
check for errors.

30
Edit Flow
Consolidate
I. Verified Files
II. Structure
IV. Pre-Tabulation
III. Consistency
II. Pre-Consolidate
Analyst
Data Processor
Statistician
Data Processor
31
Structure Edit Controls

• Performed after verification
• Control totals used to check completeness
• File totals compared with manual counts
• Corrections done with questionnaires
• Limit checks to rendering questionnaires clear
  enough for computer processing (processability)
  only.

32
Pre-edit Consolidation Controls

• Follow pre-established geographical priorities
• Check control totals
• Use operational control data base
• Avoid geographic coding (geocode) conflicts in
  joining files

33
Consistency Edit Controls

• Develop consistency specifications
• Prioritize variables
• Monitor corrections
• Use control tabulations
• Re-run output file

34
Pre-tabulation Consolidation Controls

• Consolidate to facilitate tabulation
• Check control totals for each record type
• Use standardized forms for operational control
• Avoid geocode conflicts in joining files

35
Tabulation Controls

• Computer Program Specifications
• User Approval of Tables
• Tables Grouped by Characteristics
• Tables Checked Against Control Totals
• Control Tables Show Weighted and Un-weighted
  Numbers
• Geographic Subtotals Match
• Standardized Control Forms for Production Control
• Final Table Review
• Data Dissemination to User Community

36
Data Archiving
Data and Metadata
metadata are often called "codebooks Metadata is
the data which defines the data
http//www.icpsr.umich.edu/DDI/ORG/index.html
DDI-Data Documentation Initiative The definition
of an international standard to define Metadata
in the social sciences.
37
Data Archiving
The DDI defines a hierarchy of information
related to a Census or survey. The DDI defines
these by using XML (Extensible Mark up
language) XML defines document tags much the same
way as HTML.
Example of Codebook Structure http//www.icpsr.u
mich.edu/DDI/CODEBOOK/codedtd.html
38
Data Archiving
NESSTAR is an example of a web based distributed
DDI compliant system.
39
Data Archiving
All processes need to be documented. This
includes Codebooks Data entry manuals Program
documentation Edit programs Imputation
rules Tracking/process manuals
40
Final Concepts
Lean Manufacturing A quality control system for
monitoring process flow. Six Sigma A
statistical system developed by Motorola to
establish process problems and error tolerances
and methods to correct.
41
Final Concepts
Lean Manufacturing

• Workplace organization
• Standardizing work/work stations.
• Division of labor to increase process flow.
• JIT-Just-in-Time delivery
• Pull systems

Six Sigma

• Means six deviation tolerance for error 3.4
  error events
• out of one-million
• Measurement (quantifiable) system for process
  improvement.

42
Final Concepts
43
Conceptual Summary
P-R-O (TQM)
Personal Commitment to Excellence
Reject Cynicism or Satisfaction
Own the process
C-E-S-S (Six Sigma, Lean Manufacturing)
Careful Design (Flow Charts)
Evaluate Continually (Six Sigma)
Shift Perspectives (Lean Manufacturing)
Shelf Life (Data Archive)
44
From John Henry The man that invented the steam
drill Thought he was mighty fine But John Henry
made fifteen feet The steam drill only nine,
Lord, Lord The steam drill made only nine. John
Henry hammered in the mountain His hammer was
striking fire But he worked so hard, he broke his
poor heart He laid down his hammer and he died,
Lord, Lord. He laid down his hammer and he died
