Tanks, Drums, and Vessels

1
Tanks, Drums, and Vessels

• Unit 9

2
Learning Objectives

• TLW be able to describe the following about
  tanks, drums, and vessels used in the process
  industry
• Types
• Uses
• Materials of Construction
• Monitoring and Maintenance
• Hazards and Mitigations

3
Types

• Tanks
• Drums
• Vessels
• Reactors
• Distillation columns

4
Tanks, Drums, and Vessels

• Used for Storing
• Inputs (Raw Materials)
• Outputs (Products, Co-Products, Intermediates)
• Waste
• Recoverable waste

• Two types of Storage Tanks
• Atmospheric
• Pressurized

5
Materials of Construction

• Tanks and vessels are usually always made of
  metal.
• Thickness increases as does pressure
• Special alloys for corrosives
• Drums
• Metal
• Plastic for corrosives, additives
• Cardboard - additives
• DOT specs

6
Terms for Tanks, Drums, and Vessels

• Floating Roof
• Sphere
• Foam Chamber
• Sump (Possum Belly)
• Mixer
• Gauge Hatch
• Manway or Manhole

• Blanket
• Vapor Recovery
• Vortex Breaker
• Baffle
• Weir
• Boot

7
Vessels and Pressure

• Cylinders or drum shaped generally atmospheric
  tanks
• High volatility materials stored in pressurized
  tanks
• Round tanks (sphere) - pressure
• Bullet and spherical tanks - pressure
• Hemispheroids low pressure
• Spheroids low pressure

8
(No Transcript)
9
Cone roof tank
10
Floating roof tank
11
(No Transcript)
12
Vortex Breaker
Foam system
Manway
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
Nitrogen blanket
17
(No Transcript)
18
Tank Symbols
19
Hazards

• Overfilling
• Putting in wrong or off spec material
• Misalignment of blanket system
• Misalignment of pump system
• Pulling a vacuum while emptying a tank
• Overpressuring a tank
• Static electricity (dust or vapor explosion)
• Corrosion or mechanical damage

20
Hazards

• Describe potential impacts of these hazards on
  last
• Individual
• Equipment
• Production (Quality)
• Environment

21
Reactors

• Where Chemical Reactions Occur
• Fixed Bed
• Stirred
• Fluidized bed reactor
• Shell and Tube

22
Fixed Bed Reactor
23
Fixed bed reactor
24
Stirred Reactor
25
Fluidized Bed Reactor
26
Fluidized-Bed Reactor
27
Shell and Tube
28
Dikes, Firewalls and Containment Walls

• Contain materials
• Isolate
• Minimize damage
• Protect people, assets, and environment

29
Tank Dikes
30
Monitoring and Maintenance

• Abnormal noise pinging/popping
• Abnormal heat
• Monitor levels and pressures
• Vibrations pumps/mixers
• Check firewalls, sumps and drains, drain valves
  on dikes - rainfall
• Odors/leaks
• Corrosion checks, paint

31
Independent Practice

• Research project see handout
