Module 1 Introduction to Radiation

1
Module 1Introduction to Radiation
2
Introduction to Radiation

• Terminal Objective
• DEFINE the fundamentals of radiation, radioactive
  material, ionization, ionizing radiation, and
  contamination.

3
Enabling Objectives

• LIST the three basic components of an atom.
• DESCRIBE the differences between ionizing
  radiation and non-ionizing radiation.
• DEFINE radioactivity.

4
Enabling Objectives

• STATE the four basic types of ionizing radiation.
• DESCRIBE the shielding materials and biological
  hazards for each of the four types of ionizing
  radiation.
• LIST the three techniques for minimizing exposure
  to radiation and radioactive material (ALARA).

5
Radiation Basics Video
6
Parts of an Atom

• Protons
• Neutrons
• Electrons

7
Protons
8
Neutrons
9
Electrons
10
Stable and Unstable Atoms

• An atom with too many or too few neutrons
  contains excess energy and is not stable.
• Unstable atoms give off excess energy
  (radiation).
• Unstable atoms are radioactive.

11
Ionization
Radiation

• Removing electrons from atoms or molecules

12
Ionizing Radiation
Excess energy (from unstable atoms), capable of
removing electrons from an atom
Radiation
13
Non-Ionizing Radiation
14
Radioactivity

• Radioactivity is the process of unstable
  (radioactive) atoms trying to become stable by
  emitting ionizing energy.

15
Radioactive Material

• Radioactive Material
• Material containing unstable (radioactive) atoms
• Radioactive Contamination
• Radioactive material in an unwanted place

16
Radiological vs. Nuclear

• Radiological deals with radiation or material
  that emits radiation.
• Example Radiological WMD Dirty Bomb
• Nuclear refers to processes that involve
  splitting a nucleus (fission) or combining nuclei
  of atoms (fusion).
• Example Nuclear WMD atomic bomb

17
Measuring Radiation

• Radiation Dose
• Radiation energy absorbed by the human body
• Dose is measured in units of rem.
• A millirem (mrem) is one thousandth of a rem.

18
Measuring Radiation

• Radiation Dose Rate
• Radiation energy received over a period of time
• Radiation dose rate is dose per time
• mrem per hour mrem/hr strength of
  radiation at a location

19
Types of Ionizing Radiation
20
Types of Ionizing Radiation

• Alpha radiation
• Beta radiation
• Gamma rays/X-rays
• Neutron radiation
• Some radioactive materials may emit more than one
  kind of radiation

21
Alpha Radiation

• Range
• 1 to 2 inches
• Shielding
• Paper, Cloth,
• Dead Layer of Skin

22
Alpha Radiation (continued)

• Biological Hazard
• Not an external radiation hazard
• Easily stopped by the dead layer of skin
• Internal hazard If material is inside the body,
  then the alpha radiation reaches live cells.

23
Alpha Radiation (continued)

• Sources
• Uranium (nuclear power plant fuel and nuclear
  weapons)
• Plutonium (nuclear weapons)
• Americium (smoke detectors)
• Thorium (high-temperature metals)

24
Beta Radiation

• Range
• about 10 feet
• Shielding
• Thick Clothing, ¼ Inch Aluminum, ¼ Inch
  Plastic

25
Beta Radiation (continued)

• Biological Hazard
• External hazard to skin and eyes
• Internal hazard if the material that emits the
  beta radiation is inside the body. Then beta
  radiation can deposit energy in a small area of
  body tissue.

26
Beta Radiation (continued)

• Sources
• Used nuclear reactor fuel
• Nuclear weapons fallout (strontium)
• Some industrial radioactive sources such as
  cesium
• Tritium in glow-in-the-dark EXIT signs, watch
  dials, and night-sights on firearms
• Radioactive nickel in chemical agent detectors

27
Gamma Rays/X-Rays

• Range
• Hundreds of feet
• Shielding
• Inch of Lead, 3 Inches of Steel, 6
  inches Concrete, 1 foot of Dirt

28
Gamma Rays/X-Rays (continued)

• Biological Hazard
• Gamma rays and X-rays easily penetrate body
  tissues, outside or inside of the body.
• Whole body (internal and external) hazard
•

29
Gamma Rays/X-Rays (continued)

•
• Sources
• Uranium, plutonium, radioactive cobalt, and
  cesium
• Industrial radiation sources
• Medical sources, cancer treatment machines
• Many beta-emitters also emit gamma radiation.
• Potassium in soil, bananas, and potassium
  chloride (salt substitute)

30
Neutron Radiation

• Range
• Hundreds of feet
• Shielding
• 10 Inches of Plastic, 1 foot of Concrete, 3
  feet of Dirt, 3 feet of Water

31
Neutron Radiation (continued)

• Biological Hazard
• Whole body hazard (external and internal neutrons
  are a whole body hazard).
• Neutrons penetrate body tissues.
• Neutrons cause damage whether the material is
  inside or outside of the body.

32
Neutron Radiation (continued)

• Sources
• Nuclear reactions inside nuclear reactor while
  reactor is operating
• Burst of radiation from exploding nuclear weapon
• Plutonium, industrial sources, moisture gauges
  with californium or mixture of americium and
  beryllium

33
Comparison of Ionizing Radiation
34
Particle Size Comparison
35
Alpha, Beta, and Neutron Particles
36
Comparison of Radiation and Contaminants

• Radiation is energy.
• Radioactive contaminants are materials that emit
  radiation.
• Radioactive contaminants are radioactive atoms
  that get onto something unwanted or are in an
  uncontrolled place.
• Radioactive atoms cannot be neutralized to make
  them non-radioactive.

37
Exposure vs. Contamination
External Exposure
External Contamination
38
Internal Contamination and Internal Exposure
Radioactive material inside the body Both
contaminated and exposed
39
ALARA

• As
• Low
• As
• Reasonably
• Achievable

40
ALARA Video
41
ALARA

• Minimize time
• Maximize distance
• Use shielding

42
Review

• Whats the difference if I get exposed or if I
  get contaminated?
• How do I protect myself from alpha, beta, gamma,
  or neutron radiation?
• How can I practice the principles of ALARA in
  this situation?

43
Questions?
