Classification and Prediction

1
Classification and Prediction
Bamshad Mobasher DePaul University
2
What Is Classification?

• The goal of data classification is to organize
  and categorize data in distinct classes
• A model is first created based on the data
  distribution
• The model is then used to classify new data
• Given the model, a class can be predicted for new
  data
• Classification prediction for discrete and
  nominal values
• With classification, I can predict in which
  bucket to put the ball, but I cant predict the
  weight of the ball

3
Prediction, Clustering, Classification

• What is Prediction?
• The goal of prediction is to forecast or deduce
  the value of an attribute based on values of
  other attributes
• A model is first created based on the data
  distribution
• The model is then used to predict future or
  unknown values
• Supervised vs. Unsupervised Classification
• Supervised Classification Classification
• We know the class labels and the number of
  classes
• Unsupervised Classification Clustering
• We do not know the class labels and may not know
  the number of classes

4
Classification 3 Step Process

• 1. Model construction (Learning)
• Each record (instance) is assumed to belong to a
  predefined class, as determined by one of the
  attributes, called the class label
• The set of all records used for construction of
  the model is called training set
• The model is usually represented in the form of
  classification rules, (IF-THEN statements) or
  decision trees
• 2. Model Evaluation (Accuracy)
• Estimate accuracy rate of the model based on a
  test set
• The known label of test sample is compared with
  the classified result from model
• Accuracy rate percentage of test set samples
  correctly classified by the model
• Test set is independent of training set otherwise
  over-fitting will occur
• 3. Model Use (Classification)
• The model is used to classify unseen instances
  (assigning class labels)
• Predict the value of an actual attribute

5
Model Construction
6
Model Evaluation
7
Model Use Classification
8
Classification Methods

• Decision Tree Induction
• Neural Networks
• Bayesian Classification
• Association-Based Classification
• K-Nearest Neighbor
• Case-Based Reasoning
• Genetic Algorithms
• Fuzzy Sets
• Many More

9
Decision Trees

• A decision tree is a flow-chart-like tree
  structure
• Internal node denotes a test on an attribute
  (feature)
• Branch represents an outcome of the test
• All records in a branch have the same value for
  the tested attribute
• Leaf node represents class label or class label
  distribution

10
Decision Trees

• Example is it a good day to play golf?
• a set of attributes and their possible values
• outlook sunny, overcast, rain
• temperature cool, mild, hot
• humidity high, normal
• windy true, false

A particular instance in the training set might
be ltovercast, hot, normal, falsegt play
In this case, the target class is a binary
attribute, so each instance represents a
positive or a negative example.
11
Using Decision Trees for Classification

• Examples can be classified as follows
• 1. look at the example's value for the feature
  specified
• 2. move along the edge labeled with this value
• 3. if you reach a leaf, return the label of the
  leaf
• 4. otherwise, repeat from step 1
• Example (a decision tree to decide whether to go
  on a picnic)

So a new instance ltrainy, hot, normal,
truegt ? will be classified as noplay
12
Decision Trees and Decision Rules
If attributes are continuous, internal nodes may
test against a threshold.
Each path in the tree represents a decision rule
Rule1 If (outlooksunny) AND
(humiditylt0.75) Then (playyes) Rule2 If
(outlookrainy) AND (windgt20) Then (playno)
Rule3 If (outlookovercast) Then
(playyes) . . .
13
Top-Down Decision Tree Generation

• The basic approach usually consists of two
  phases
• Tree construction
• At the start, all the training examples are at
  the root
• Partition examples are recursively based on
  selected attributes
• Tree pruning
• remove tree branches that may reflect noise in
  the training data and lead to errors when
  classifying test data
• improve classification accuracy
• Basic Steps in Decision Tree Construction
• Tree starts a single node representing all data
• If sample are all same class then node becomes a
  leaf labeled with class label
• Otherwise, select feature that best separates
  sample into individual classes.
• Recursion stops when
• Samples in node belong to the same class
  (majority)
• There are no remaining attributes on which to
  split

14
Trees Construction Algorithm (ID3)

• Decision Tree Learning Method (ID3)
• Input a set of training examples S, a set of
  features F
• 1. If every element of S has a class value yes,
  return yes if every element of S has class
  value no, return no
• 2. Otherwise, choose the best feature f from F
  (if there are no features remaining, then return
  failure)
• 3. Extend tree from f by adding a new branch
  for each attribute value of f
• 3.1. Set F F f,
• 4. Distribute training examples to leaf nodes (so
  each leaf node n represents the subset of
  examples Sn of S with the corresponding attribute
  value
• 5. Repeat steps 1-5 for each leaf node n with Sn
  as the new set of training examples and F as the
  set of attributes
• Main Question
• how do we choose the best feature at each step?

Note ID3 algorithm only deals with categorical
attributes, but can be extended (as in C4.5) to
handle continuous attributes
15
Choosing the Best Feature

• Use Information Gain to find the best (most
  discriminating) feature
• Assume there are two classes, P and N (e.g, P
  yes and N no)
• Let the set of instances S (training data)
  contains p elements of class P and n elements
  of class N
• The amount of information, needed to decide if an
  arbitrary example in S belongs to P or N is
  defined in terms of entropy, I(p,n)
• Note that Pr(P) p / (pn) and Pr(N) n / (pn)

16
Choosing the Best Feature

• More generally, if we have m classes, and s1, s2,
  , sm are the number of instances of S in each
  class, then the entropy is
• where pi is the probability that an arbitrary
  instance belongs to the class i.

17
Choosing the Best Feature

• Now, assume that using attribute A a set S of
  instances will be partitioned into sets S1, S2 ,
  , Sv each corresponding to distinct values of
  attribute A.
• If Si contains pi cases of P and ni cases of N,
  the entropy, or the expected information needed
  to classify objects in all subtrees Si is
• The encoding information that would be gained by
  branching on A
• At any point we want to branch using an attribute
  that provides the highest information gain.

The probability that an arbitrary instance in S
belongs to the partition Si
where,
18
Attribute Selection - Example

• The Golf example what attribute should we
  choose as the root?

S 9,5-
Outlook?
overcast
rainy
sunny
2,3-
3,2-
4,0-
I(9,5) -(9/14).log(9/14) - (5/14).log(5/14)
0.94
I(4,0) -(4/4).log(4/4) - (0/4).log(0/4)
0
I(2,3) -(2/5).log(2/5) - (3/5).log(3/5)
0.97
Gain(outlook) .94 - (4/14)0
- (5/14).97
- (5/14).97
.24
I(3,2) -(3/5).log(3/5) - (2/5).log(2/5)
0.97
19
Attribute Selection - Example (Cont.)
S 9,5- (I 0.940)
humidity?
high
normal
6,1- (I 0.592)
3,4- (I 0.985)
Gain(humidity) .940 - (7/14).985 -
(7/14).592 .151
S 9,5- (I 0.940)
wind?
strong
weak
So, classifying examples by humidity
provides more information gain than by wind.
Similarly, we must find the information gain for
temp. In this case, however, you can verify
that outlook has largest information gain, so
itll be selected as root
3,3- (I 1.00)
6,2- (I 0.811)
Gain(wind) .940 - (8/14).811 - (8/14)1.0
.048
20
Attribute Selection - Example (Cont.)

• Partially learned decision tree
• which attribute should be tested here?

S 9,5-
D1, D2, , D14
Outlook
sunny
overcast
rainy
?
?
yes
4,0-
2,3-
3,2-
D1, D2, D8, D9, D11
D3, D7, D12, D13
D4, D5, D6, D10, D14
Ssunny D1, D2, D8, D9, D11
Gain(Ssunny, humidity) .970 - (3/5)0.0 -
(2/5)0.0 .970
Gain(Ssunny, temp) .970 - (2/5)0.0 - (2/5)1.0
- (1/5)0.0 .570
Gain(Ssunny, wind) .970 - (2/5)1.0 -
(3/5).918 .019
21
Dealing With Continuous Variables

• Partition continuous attribute into a discrete
  set of intervals
• sort the examples according to the continuous
  attribute A
• identify adjacent examples that differ in their
  target classification
• generate a set of candidate thresholds midway
• problem may generate too many intervals
• Another Solution
• take a minimum threshold M of the examples of the
  majority class in each adjacent partition then
  merge adjacent partitions with the same majority
  class

70.5
77.5
Example M 3
Same majority, so they are merged
Final mapping temperature 77.5 gt yes
temperature gt 77.5 gt no
22
Over-fitting in Classification

• A tree generated may over-fit the training
  examples due to noise or too small a set of
  training data
• Two approaches to avoid over-fitting
• (Stop earlier) Stop growing the tree earlier
• (Post-prune) Allow over-fit and then post-prune
  the tree
• Approaches to determine the correct final tree
  size
• Separate training and testing sets or use
  cross-validation
• Use all the data for training, but apply a
  statistical test (e.g., chi-square) to estimate
  whether expanding or pruning a node may improve
  over entire distribution
• Use Minimum Description Length (MDL) principle
  halting growth of the tree when the encoding is
  minimized.
• Rule post-pruning (C4.5) converting to rules
  before pruning

23
Pruning the Decision Tree

• A decision tree constructed using the training
  data may need to be pruned
• over-fitting may result in branches or leaves
  based on too few examples
• pruning is the process of removing branches and
  subtrees that are generated due to noise this
  improves classification accuracy
• Subtree Replacement merge a subtree into a leaf
  node
• Using a set of data different from the training
  data
• At a tree node, if the accuracy without splitting
  is higher than the accuracy with splitting,
  replace the subtree with a leaf node label it
  using the majority class

Suppose with test set we find 3 red no
examples, and 2 blue yes example. We can
replace the tree with a single no node. After
replacement there will be only 2 errors instead
of 5.
24
Bayesian Methods

• Bayess theorem plays a critical role in
  probabilistic learning and classification
• Uses prior probability of each category given no
  information about an item
• Categorization produces a posterior probability
  distribution over the possible categories given a
  description of an item
• The models are incremental in the sense that each
  training example can incrementally increase or
  decrease the probability that a hypothesis is
  correct. Prior knowledge can be combined with
  observed data
• Given a data sample X with an unknown class
  label, H is the hypothesis that X belongs to a
  specific class C
• The conditional probability of hypothesis H
  given observation X, Pr(HX), follows the Bayess
  theorem
• Practical difficulty requires initial knowledge
  of many probabilities, significant computational
  cost

25
Axioms of Probability Theory

• All probabilities between 0 and 1
• True proposition has probability 1, false has
  probability 0.
• P(true) 1 P(false) 0
• The probability of disjunction is

26
Conditional Probability

• P(A B) is the probability of A given B
• Assumes that B is all and only information known.
• Defined by

27
Independence

• A and B are independent iff
• Therefore, if A and B are independent
• Bayess Rule

These two constraints are logically equivalent
28
Bayesian Categorization

• Let set of categories be c1, c2,cn
• Let E be description of an instance.
• Determine category of E by determining for each
  ci
• P(E) can be determined since categories are
  complete and disjoint.

29
Bayesian Categorization (cont.)

• Need to know
• Priors P(ci) and Conditionals P(E ci)
• P(ci) are easily estimated from data.
• If ni of the examples in D are in ci,then P(ci)
  ni / D
• Assume instance is a conjunction of binary
  features/attributes

30
Naïve Bayesian Categorization

• Problem Too many possible instances (exponential
  in m) to estimate all P(E ci)
• If we assume features/attributes of an instance
  are independent given the category (ci)
  (conditionally independent)
• Therefore, we then only need to know P(ej ci)
  for each feature and category

31
Estimating Probabilities

• Normally, probabilities are estimated based on
  observed frequencies in the training data.
• If D contains ni examples in category ci, and nij
  of these ni examples contains feature/attribute
  ej, then
• However, estimating such probabilities from small
  training sets is error-prone.
• If due only to chance, a rare feature, ek, is
  always false in the training data, ?ci P(ek
  ci) 0.
• If ek then occurs in a test example, E, the
  result is that ?ci P(E ci) 0 and ?ci P(ci
  E) 0

32
Smoothing

• To account for estimation from small samples,
  probability estimates are adjusted or smoothed.
• Laplace smoothing using an m-estimate assumes
  that each feature is given a prior probability,
  p, that is assumed to have been previously
  observed in a virtual sample of size m.
• For binary features, p is simply assumed to be
  0.5.

33
Naïve Bayesian Classifier - Example

• Here, we have two classes C1yes (Positive) and
  C2no (Negative)
• Pr(yes) instances with yes / all instances
  9/14
• If a new instance X had outlooksunny, then
  Pr(outlooksunny yes) 2/9
• (since there are 9 instances with yes (or P)
  of which 2 have outlooksunny)
• Similarly, for humidityhigh,
  Pr(humidityhigh no) 4/5
• And so on.

34
Naïve Bayes (Example Continued)

• Now, given the training set, we can compute all
  the probabilities
• Suppose we have new instance X ltsunny, mild,
  high, truegt. How should it be classified?
• Similarly

X lt sunny , mild , high , true gt
Pr(X no) 3/5 . 2/5 . 4/5 . 3/5
Pr(X yes) (2/9 . 4/9 . 3/9 . 3/9)
35
Naïve Bayes (Example Continued)

• To find out to which class X belongs we need to
  maximize Pr(X Ci).Pr(Ci), for each class Ci
  (here yes and no)
• To convert these to probabilities, we can
  normalize by dividing each by the sum of the two
• Pr(no X) 0.04 / (0.04 0.007) 0.85
• Pr(yes X) 0.007 / (0.04 0.007) 0.15
• Therefore the new instance X will be classified
  as no.

X ltsunny, mild, high, truegt
Pr(X no).Pr(no) (3/5 . 2/5 . 4/5 . 3/5) .
5/14 0.04
Pr(X yes).Pr(yes) (2/9 . 4/9 . 3/9 . 3/9)
. 9/14 0.007
36
Association-Based Classification

• Recall quantitative association rules
• If the right-hand-side of the rules are
  restricted to the class attribute to be
  predicted, the rules can be used directly for
  classification
• It mines high support and high confidence rules
  in the form of
• cond_set gt Y
• where Y is a class label.
• Has been shown to work better than decision tree
  models in some cases.

37
Measuring Effectiveness of Classification Models

• When the output field is ordinal or nominal
  (e.g., in two-class prediction), we use the
  classification table, the so-called confusion
  matrix to evaluate the resulting model
• Example
• Overall correct classification rate (18 15) /
  38 87
• Given T, correct classification rate 18 / 20
  90
• Given F, correct classification rate 15 / 18
  83

Predicted Class
Actual Class
38
Measuring Effectiveness Lift

• usually used for classification, but can be
  adopted to other methods
• measure change in conditional probability of a
  target class when going from the general
  population (full test set) to a biased sample
• Example
• suppose expected response rate to a direct
  mailing campaign is 5 in the training set
• use classifier to assign yes or no value to a
  target class predicted to respond
• the yes group will contain a higher proportion
  of actual responders than the test set
• suppose the yes group (our biased sample)
  contains 50 actual responders
• this gives lift of 10 0.5 / 0.05
• What if the lift sample is too small
• need to increase the sample size
• trade-off between lift and sample size

39
What Is Prediction?

• Prediction is similar to classification
• First, construct a model
• Second, use model to predict unknown value
• Prediction is different from classification
• Classification refers to predicting categorical
  class label (e.g., yes, no)
• Prediction models are used to predict values of a
  numeric target attribute
• They can be thought of as continuous-valued
  functions
• Major method for prediction is regression
• Linear and multiple regression
• Non-linear regression
• K-Nearest-Neighbor
• Most common application domains
• recommender systems, credit scoring, customer
  lifetime values

40
Prediction Regression Analysis

• Most common approaches to prediction linear or
  multiple regression.
• Linear regression Y ? ? X
• The model is a line which best reflects the data
  distribution the line allows for prediction of
  the Y attribute value based on the single
  attribute X.
• Two parameters , ? and ? specify the line and
  are to be estimated by using the data at hand
• Common approach apply the least squares
  criterion to the known values of Y1, Y2, , X1,
  X2, .
• Regression applet
• http//www.math.csusb.edu/faculty/stanton/pro
  bstat/regression.html
• Multiple regression Y b0 b1 X1 b2 X2
• Necessary when prediction must be made based on
  multiple attributes
• E.g., predict Customer LTV based on Age, Income,
  Spending, Items purchased, etc.
• Many nonlinear functions can be transformed into
  the above.

41
Measuring Effectiveness of Prediction

• Predictive models are evaluated based on the
  accuracy of their predictions on unseen data
• accuracy measured in terms of error rate (usually
  of records classified incorrectly)
• error rate on a pre-classified evaluation set
  estimates the real error rate
• Prediction Effectiveness
• Difference between predicted scores and the
  actual results (from evaluation set)
• Typically the accuracy of the model is measured
  in terms of variance (i.e., average of the
  squared differences)
• E.g, Root Mean Squared Error compute the
  standard deviation (i.e., square root of the
  co-variance between predicted and actual ratings)

42
Example Recommender Systems

• Basic formulation as a prediction problem
• Typically, the profile Pu contains interest
  scores by u on some other items, i1, , ik
  different from it
• Interest scores on i1, , ik may have been
  obtained explicitly (e.g., movie ratings) or
  implicitly (e.g., time spent on a product page or
  news article)

Given a profile Pu for a user u, and a target
item it, predict the interest score of user u on
item it
43
Example Recommender Systems

• Content-based recommenders
• Predictions for unseen (target) items are
  computed based on their similarity (in terms of
  content) to items in the user profile.
• E.g., user profile Pu contains
• recommend highly and recommend
  mildly

44
Content-Based Recommender Systems
45
Example Recommender Systems

• Collaborative filtering recommenders
• Predictions for unseen (target) items are
  computed based the other users with similar
  interest scores on items in user us profile
• i.e. users with similar tastes (aka nearest
  neighbors)
• requires computing correlations between user u
  and other users according to interest scores or
  ratings

Can we predict Karens rating on the unseen item
Independence Day?
46
Example Recommender Systems

• Collaborative filtering recommenders
• Predictions for unseen (target) items are
  computed based the other users with similar
  interest scores on items in user us profile
• i.e. users with similar tastes (aka nearest
  neighbors)
• requires computing correlations between user u
  and other users according to interest scores or
  ratings

prediction
Correlation to Karen
Predictions for Karen on Indep. Day based on the
K nearest neighbors
47
Possible Interesting Project Ideas

• Build a content-based recommender for
• Movies (e.g., previous example)
• News stories (requires basic text processing and
  indexing of documents)
• Music (based on features such as genre, artist,
  etc.
• Build a collaborative recommender for
• Movies (using movie ratings), e.g., movielens.org
• Music, e.g., pandora.com
• Recommend songs or albums based on collaborative
  ratings
• Or, recommend whole playlists based on playlists
  from other users (this might be a good candidate
  application for association rule mining (why?)

48
Other Forms of Collaborative and Social Filtering

• Social Tagging (Folksonomy)
• people add free-text tags to their content
• where people happen to use the same terms then
  their content is linked
• frequently used terms floating to the top to
  create a kind of positive feedback loop for
  popular tags.
• Examples
• Del.icio.us
• Flickr

49
Social Tagging

• Deviating from standard mental models
• No browsing of topical, categorized navigation or
  searching for an explicit term or phrase
• Instead is use language I use to define my world
  (tagging)
• Sharing my language and contexts will create
  community
• Tagging creates community through the overlap of
  perspectives
• This leads to the creation of social networks
  which may further develop and evolve
• But, does this lead to dynamic evolution of
  complex concepts or knowledge? Collective
  intelligence?

50
Clustering and Collaborative Filtering
clustering based on ratings movielens
51
Clustering and Collaborative Filtering tag
clustering example
52
Classification Example - Bank Data

• Want to determine likely responders to a direct
  mail campaign
• a new product, a "Personal Equity Plan" (PEP)
• training data include records kept about how
  previous customers responded and bought the
  product
• in this case the target class is pep with
  binary value
• want to build a model and apply it to new data (a
  customer list) in which the value of the class
  attribute is not available

53
Data Preparation

• Several steps for prepare data for Weka and for
  See5
• open training data in Excel, remove the id
  column, save results (as a comma delimited file
  (e.g., bank.csv)
• do the same with new customer data, but also add
  a new column called pep as the last column the
  value of this column for each record should be
  ?
• Weka
• must convert the the data to ARFF format
• attribute specification and data are in the same
  file
• the data portion is just the comma delimited data
  file without the label row
• See5/C5
• create a name file and a data file
• name file contains attribute specification
  data file is same as above
• first line of name file must be the name(s) of
  the target class(es) - in this case pep

54
Data File Format for Weka
_at_relation train-bank-data' _at_attribute 'age'
real _at_attribute 'sex' 'MALE','FEMALE' _at_attribute
'region' 'INNER_CITY','RURAL','TOWN','SUBURBAN'
_at_attribute 'income' real _at_attribute 'married'
'YES','NO' _at_attribute 'children'
real _at_attribute 'car' 'YES','NO' _at_attribute
'save_act' 'YES','NO' _at_attribute 'current_act'
'YES','NO' _at_attribute 'mortgage'
'YES','NO' _at_attribute 'pep' 'YES','NO' _at_data 4
8,FEMALE,INNER_CITY,17546,NO,1,NO,NO,NO,NO,YES 40,
MALE,TOWN,30085.1,YES,3,YES,NO,YES,YES,NO . . .
Training Data
_at_relation 'new-bank-data' _at_attribute 'age'
real _at_attribute 'region' 'INNER_CITY','RURAL','TO
WN','SUBURBAN' . . . _at_attribute 'pep'
'YES','NO' _at_data 23,MALE,INNER_CITY,18766.9,YES,
0,YES,YES,NO,YES,? 30,MALE,RURAL,9915.67,NO,1,NO,Y
ES,NO,YES,?
New Cases
55
C4.5 Implementation in Weka
children lt 2 children lt 0 married
YES mortgage YES
save_act YES NO (16.0/2.0)
save_act NO YES (9.0/1.0) mortgage
NO NO (59.0/6.0) married NO
mortgage YES save_act
YES NO (12.0) save_act NO YES
(3.0) mortgage NO YES (29.0/2.0)
children gt 0 income lt 29622
children lt 1 income lt 12640.3
NO (5.0) income gt 12640.3
current_act YES YES (28.0/1.0)
current_act NO
income lt 17390.1 NO (3.0)
income gt 17390.1 YES (6.0)
children gt 1 NO (47.0/3.0) income gt
29622 YES (48.0/2.0) children gt 2 income lt
43228.2 NO (30.0/2.0) income gt 43228.2 YES
(5.0)

• To build a model (decision tree) using the
  classifiers.trees.j48..J48 class

Decision Tree Output (pruned)
56
C4.5 Implementation in Weka
Error on training data Correctly
Classified Instances 281 93.6667
Incorrectly Classified Instances 19
6.3333 Mean absolute error
0.1163 Root mean squared error
0.2412 Relative absolute error 23.496
Root relative squared error 48.4742
Total Number of Instances 300
Confusion Matrix a b lt--
classified as 122 13 a YES 6 159 b
NO Stratified cross-validation
Correctly Classified Instances 274
91.3333 Incorrectly Classified Instances 26
8.6667 Mean absolute error
0.1434 Root mean squared error
0.291 Relative absolute error
28.9615 Root relative squared error
58.4922 Total Number of Instances 300
Confusion Matrix a b lt--
classified as 118 17 a YES 9 156 b
NO
The rest of the output contains statistical
information about the model, including confusion
matrix, error rates, etc.
The model can be saved to be later applied to the
test data (or to new unclassified instances).
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
