Web Services and the VO: Using SDSS DR1

1
Web Services and the VOUsing SDSS DR1

• Alex Szalay, and Jim Gray
• with
• Tamas Budavari, Sam Carlisle, Vivek Haridas,
  Nolan Li, Tanu Malik, Maria Nieto-Santisteban,
  Wil OMullane, Ani Thakar

2
Changing Roles

• Exponential growth
• Projects last at least 3-5 years
• Data sent upwards only at the end of the project
• Data will be never centralized
• More responsibility on projects
• Becoming Publishers and Curators
• Larger fraction of budget spent on software
• Lot of development duplicated, wasted
• More standards are needed
• Easier data interchange, fewer tools
• More templates are needed
• Develop less software on your own

3
Standards and Interoperability

• Standards driven by e-business requirements
• Exchange of rich and structured data (XML)
• DB connectivity, Web Services, Grid computing
• Application to astronomy domain
• Data dictionaries (UCDs)
• Data models
• Protocols
• Registries and resource/service discovery
• Provenance, data quality
• Dealing with the astronomy legacy
• FITS data format
• Software systems

Boundary conditions
4
Virtual Observatory

• Many new surveys are coming
• SDSS is a dry run for the next ones
• LSST will be 5TB/night
• All the data will be on the Internet
• But how? ftp, webservice
• Data and apps will be associated withthe
  instruments
• Distributed world wide
• Cross-indexed
• Federation is a must, but how?
• Will be the best telescope in the world
• World Wide Telescope

5
SkyServerSkyServer.SDSS.orgor
Skyserver.Pha.Jhu.edu/DR1/

• Sloan Digital Sky Survey Data Pixels Data
  Mining
• About 400 attributes per object
• Spectrograms for 1 of objects
• Demo pixel space record space set
  space teaching

6
Show Cutout Web Service
7
SkyQuery (http//skyquery.net/)

• Distributed Query tool using a set of web
  services
• Four astronomy archives from Pasadena, Chicago,
  Baltimore, Cambridge (England).
• Feasibility study, built in 6 weeks
• Tanu Malik (JHU CS grad student)
• Tamas Budavari (JHU astro postdoc)
• With help from Szalay, Thakar, Gray
• Implemented in C and .NET
• Allows queries like

SELECT o.objId, o.r, o.type, t.objId FROM
SDSSPhotoPrimary o, TWOMASSPhotoPrimary t
WHERE XMATCH(o,t)lt3.5 AND AREA(181.3,-0.76,6.5)
AND o.type3 and (o.I - t.m_j)gt2
8
SkyQuery Structure

• Each SkyNode publishes
• Schema Web Service
• Database Web Service

• Portal is
• Plans Query (2 phase)
• Integrates answers
• Is itself a web service

9
National Virtual Observatory

• NSF ITR project, Building the Framework for the
  National Virtual Observatory is a collaboration
  of 17 funded and 3 unfunded organizations
• Astronomy data centers
• National observatories
• Supercomputer centers
• University departments
• Computer science/information technology
  specialists
• Trying to build standards, interfaces and
  prototypes
• Goal federate datasets, enable new
  discoveries,make it easier to publish new data

10
International Collaboration

• Similar efforts now in more than 12 countries
• USA, Canada, UK, France, Germany, Italy, Japan,
  Australia, India, China, Korea, Russia, South
  Africa, Hungary,.
• Active collaboration among projects
• Standards, common demos
• International VO roadmap being developed
• Regular telecons over 10 timezones
• Formal collaboration
• International Virtual Observatory Alliance (IVOA)


11
NVO How Will It Work?

• Huge pressure to build something useful today
• We do not build everything for everybody
• Use the 90-10 rule
• Define the standards and interfaces
• Build the framework
• Build the 10 of services that are used by 90
• Let the users build the rest from the components
• Define commonly used core services
• Build higher level toolboxes/portals on top

12
Core Services

• Metadata information about resources
• Waveband
• Sky coverage
• Translation of names to universal dictionary
  (UCD)
• Simple search patterns on the resources
• Cone Search
• Image mosaic
• Unit conversions
• Simple filtering, counting, histogramming
• On-the-fly recalibrations

13
Higher Level Services

• Built on Core Services
• Perform more complex tasks
• Examples
• Automated resource discovery
• Cross-identifications
• Photometric redshifts
• Outlier detections
• Visualization facilities (connect pixels to
  objects)
• Expectation
• Build custom portals in matter of days from
  existing building blocks (like today in IRAF or
  IDL)

14
Using SDSS DR1 as a Prototype

• SDSS DR1 (Data Release1) is now publicly
  available
• http//skyserver.pha.jhu.edu/dr1/
• About 1TB of catalog data
• Using MS SQL Server 2000
• Complex schema (72 Tables)
• About 80 million photometric objects
• Two versions (TARGET/BEST)
• Automated documentation
• Raw data at FNAL file server with URL access

15
DR1 SkyServer

• Classic 2-node web server (20k total)
• 1TB database
• 1M hpm (180k peak day)
• DSS load killing us12 m rows per hour downloads
• Answer set size follows power law

Jim Gray Quick Performance Measure of SkyServer
Dr1 4 June 2003 1500 PST
16
Loading DR1

• Automated table driven workflow system for
  loading
• Included lots of verification code
• Over 16K lines of SQL code
• Loading process was extremely painful
• Lack of systems engineering for the pipelines
• Poor testing (lots of foreign key mismatch)
• Detected data bugs even a month ago
• Most of the time spent on scrubbing data
• Fixing corrupted files (RAID5 disk errors)
• Once data was clean, everything loaded in 3 days
• Neighbors calculation took about 10 hours
• Reorganization of data took about 1 week of
  experiments in partitioning/layouts

17
Public Data Release Versions

• June 2000 EDR
• Early Data Release
• July 2003 DR1
• Contains 30 of final data
• 200 million photo objects
• 4 versions of the data
• Target, best, runs, spectro
• Total catalog volume 1.7TB
• See Terascale sneakernet paper
• Published releases served forever
• EDR, DR1, DR2, .
• Soon to include email archives, annotations
• O(N2) only possible because of Moores Law!

EDR
18
Organization and Reorganization

• Introduced partitions and filegroups
• Photo, Tag, Neighbors, Spectro, Frame, Other,
  Profiles
• Keep partitions under 100GB
• Vertical partitioning tried and abandoned
• Both partitioning and index build now table
  driven
• Stored procedures to create/drop indices at
  various granularities
• Tremendous improvement in performance when doing
  this on a large memory machine (24GB)
• Also much better performance afterwards
• But this was nice but not hard

19
Spatial Features

• Precomputed Neighbors
• All objects within 30
• Boundaries, Masks and Outlines
• Stored as spatial polygons
• Time Domain
• Precomputed Match
• All objects with 1, observed at different times
• Found duplicates due to telescope tracking errors
• Manual fix, recorded in the database
• MatchHead
• The first observation of the linked list used as
  unique id to chain of observations of the same
  object

20
Spatial Data Access SQL extension

• Szalay, Gray, Kunszt, Fekete, OMullane, Brunner
  http//www.sdss.jhu.edu/htm
• Added Hierarchical Triangular Mesh (HTM)
  table-valued functions for spatial joins
• Every object has a 20-deep Mesh ID
• Given a spatial definition,routine returns up to
  10 covering triangles
• Spatial query is then up to 10 range queries
• Fast 10,000 triangles / second / cpu

21
Web Services in Progress

• Registry
• Harvesting and querying, discovery of new
  services
• Data Delivery
• Query driven Queue management
• MyDB, VOSpace, VOProfile minimize data movement
• Graphics and visualization
• Query driven vs interactive
• Show spatial objects (Chart/Navi/List)
• Footprint/intersect
• It is a fractal
• Cross-matching
• SkyQuery and SkyNode
• Ferris-wheel
• Distributed vs parallel

22
Graphics/Visualization Tools

• Density plot
• Show densities of attributes as a function of sky
  position
• Chart/Navi/List
• Tie together catalogs and pixels
• Spectrum viewer
• Display spectra of galaxies and stars drawn from
  the database
• Filter profiles
• Catalog of astronomical filters (optical
  bandpasses)
• Mirage with VO connections
• Linked multi-pane visualization tool (Bell Labs)
• VO extensions built at JHU

23
Other Tools

• Spatial
• Cone Search
• SkyNode
• CrossMatch (SkyQuery)
• Footprint

• Information Management
• Registry services
• Name resolver
• Cosmological calculator
• CASService
• MyDB
• VOSpace
• User Authentication

24
Registry Easy Clients

• Just use SOAP toolkit (T. McGlynn J. Lee have
  done Perl client).
• Easy in Java
• java org.apache.axis.wsdl.WSDL2Java
  "http//skyservice.pha.jhu.edu/devel/registry/regi
  stry.asmx?wsdl"
• Gives set of Classes for accessing the service
• Gives Classes for the XML which is returned (i.e.
  SimpleResource)
• Still need to write client like
• RegistryLocator loc new RegistryLocator()
• RegistrySoap reg loc.getRegistrySoap()
• ArrayOfSimpleResource reses null
• reses reg.queryRegistry(args0)
• http//skyservice.pha.jhu.edu/devel/registry/index
  .aspx

Demo
25
Archive Footprint

• Footprint is a fractal
• Result depends on context
• all sky, degree scale, pixel scale
• Translate to web services
• Footprint()returns single region that contains
  the archive
• Intersection(region, tolerance) feed a region
  and returns the intersection with archive
  footprint
• Contains(point) returns yes/no (maybe fuzzy) if
  point is inside archive footprint

26
Cross-Matching

• SkyQuery SkyNode
• Currently lots of proprietary features
• Data transmitted via .NET DataSet gt VOTable
• Query plan written in MS T-SQL gt ADQL
• Spatial operator restricted to a cone
  gtVORegion
• Made up metadata delivery gt VORegistry
• Data delivery in XML/HTML gt VOTable
• Catalogs in the near future
• SDSS DR1, FIRST, 2MASS, INT
• POSS-1, GSC-2, HST, ROSAT, 2dF
• GALEX, IRAS, PSCZ

27
Spatial Cross-Match

• For small area HTM is close to optimal, but needs
  more speed
• For all-sky surveys the zone algorithm is best
• Current heuristic is a linear chain of all nodes
• Easy to generalize to include precomputed
  neighbors
• But, for all sky queries very large numberof
  random reads instead of sequential

28
Ferris-Wheel

• Sky split into buckets/zones
• All archives scan in sync
• Queries enter at bottom
• Results come back afterfull circle
• Only sequential accessgt buckets get into
  cache,then queries processed

29
Data Access is hitting a wall

• FTP and GREP are not adequate
• You can GREP 1 MB in a second
• You can GREP 1 GB in a minute
• You can GREP 1 TB in 2 days
• You can GREP 1 PB in 3 years.
• Oh!, and 1PB 5,000 disks
• At some point you need indices to limit
  search parallel data search and analysis
• This is where databases can help

• You can FTP 1 MB in 1 sec
• You can FTP 1 GB / min ( 1 /GB)
• 2 days and 1K
• 3 years and 1M

30
Smart Data (active databases)

• If there is too much data to move around,
• take the analysis to the data!
• Do all data manipulations at database
• Build custom procedures and functions in the
  database
• Automatic parallelism guaranteed
• Easy to build-in custom functionality
• Databases Procedures being unified
• Example temporal and spatial indexing
• Pixel processing
• Easy to reorganize the data
• Multiple views, each optimal for certain types of
  analyses
• Building hierarchical summaries are trivial
• Scalable to Petabyte datasets

31
Generic Catalog Access

• After 2 years of SDSS EDR and 6 months of DR1
  usage, access patterns start to emerge
• Lots of small users, instant response
• 1/f distribution of request sizes (tail of the
  lognormal)
• How to make everybody happy?
• No clear business model
• We need a separate interactive and batch server
• We also need access to full SQL with extensions
• Users want to access services via browsers
• Other services will need SOAP access

32
Data Formats

• Different data formats requested
• HTML, CSV, FITS binary, VOTABLE, XML, graphics
• Quick browsing and exploration
• Small requests, need to be nicely rendered
• Needs good random access performance
• Also simple 2D scatter plots or density plots
  required
• Heavy duty statistical use
• Aggregate functions on complex joins, lots of
  scans but small output, mostly want CSV
• Successive Data Filter
• Multi-step non-indexed filtering of the whole
  database,mostly want FITS binary

33
Data Delivery

• Small requests (lt100MB)
• Putting data on the stream
• Medium requests (lt1GB)
• Use DIME attachments to SOAP messages
• Large requests (gt1GB)
• Save data in scratch area and use asynch delivery
• Only practical for large/long queries
• Iterative requests
• Save data in temp tables in user space
• Let user manipulate via web browser
• Paradox if we use web browser to submit, users
  want immediate response from batch-size queries

34
How To Provide a UserDB

• Goal through several search/filter operations
  reduce data transfer to manageable sizes
  (1-100MB)
• Today people download tens of millions of rows,
  and then do their next filtering on client side,
  using F77
• Could be much better done in the database
• But users need to create/manage temporary tables
• DOS attacks, fragmentation, who pays for it
• Security, who can see my data (group access)?
• Follow progress of long jobs
• Who does the cleanup?

35
Query Management Service

• Enable fast, anonymous access to small requests
• Enable large queries, with ability to manage
• Enable creation of temporary tables in user space
• Create multiple ways to get query output
• Needs to support multiple mirrors/load balancing
• Do all this without logging in to Windows
• Need also support of machine clients
• Web Service http//skyservice.pha.jhu.edu/devel/C
  asJobs/
• Two request categories
• Quick
• Batch

36
Queue Management

• Need to register batch power users
• Query output goes to MyDB
• Can be joined with source database
• Results are materialized from MyDB upon request
• Users can do
• Insert, Drop, Create, Select Into, Functions,
  Procedures
• Publish their tables to a group area
• Data delivery via the CASService (C WS)

• http//skyservice.pha.jhu.edu/devel/CasService/Cas
  Service.asmx

37
Summary

• Exponential data growth distributed data
• Web Services hierarchical architecture
• Distributed computing Grid services
• Primary access to data is through databases
• The key to interoperability metadata, standards
• Build upon industry standards, commercial tools,
  and collaborate with the rest of the world
• Give interesting new tools into the hands of
  smart young people
• they will quickly turn them into cutting edge
  science

38
http//skyservice.pha.jhu.edu/develop/
