Solar Thermal Group

1
Concentrated Solar Power to
and beyond!
Solar Thermal Group Department Of Engineering
2
Overview

• Jeff
• Solar-thermal basics
• The new Big Dish! Now Even Bigger!
• Some research
• Rebecca
• Solar-thermal power in Las Vegas
• Ammonia storage
• Some more research

3
Concentrated Solar Power The Basics

• Parabolic-shaped mirror
• Receiver at focal point
• Solar Radiation heats fluid medium or drives
  chemical reaction

4
Why Solar Thermal?

• Solar Thermal arrays as baseload power stations
• Transition to renewables via add-on to existing
  plants
• Large-scale energy storage!

5
Types of Concentrated Solar Power Plants

• Linear Fresnel Arrays
• (CR 20)

We expect to see much higher concentration ratios
with the new Big Dish
Power Towers (CR 1500)
Parabolic Troughs (CR 80)
6
The old dish looks like this
7
The new dish looks like
Sorry, commercial in confidence ?
8
Some clues

• Its bigger (from 400m2 to 500m2)

9
The site
10
The site last week
11
1st big Dish demonstration power system planned
for Whyalla, South Australia
12
Some Research Directions

• Videographic Flux Mapping
• Raytracing
• Receiver modelling
• Transient Simulations

13
Concentrated Solar Power in Vegas!

• Nevada Solar One 64 MW
• Typical coal power station 2000 MW
• Home photovoltaic array 2 kW

Solar Thermal Group Department Of Engineering
14
Solar Thermal Group Department Of Engineering
15
Solar Thermal Group Department Of Engineering
16
Solar Thermal Group Department Of Engineering
17
Solar Thermal Group Department Of Engineering
18
Solar Thermal Group Department Of Engineering
19
Solar Thermal Group Department Of Engineering
20
Back to storage
24 hour electricity
concentrator
storage

• Molten salt
• Hot oil
• Superheated steam

Solar Thermal Group Department Of Engineering
21
Ammonia storage
500oC
700oC
heat
ammonia (liquid)
nitrogen (gas)
hydrogen (gas)
Solar Thermal Group Department Of Engineering
22
Little Dish
Ammonia thermochemistry

• 20m2
• (Big Dish 400m2)

Solar Thermal Group Department Of Engineering
23
Rim angle 70o
Solar Thermal Group Department Of Engineering
24
Solar Thermal Group Department Of Engineering
25
Solar Thermal Group Department Of Engineering
26
Solar Thermal Group Department Of Engineering
27
Questions?
Solar Thermal Group Department Of Engineering
28
Solar Power station to provide all of Australias
energy needs ?
Australian and New Zealand Solar Energy Society
29
Land Area for a Solar Future

• Assume
• 5000Wh/m2/day average insolation
• 5000PJ 5x1018J required per year
• Conversion of solar energy at 20 efficiency
• 5000Wh/m2/day x 365days x 0.2 1314MJ/m2/year
• (5 x 1018J/year)/(1.314 x 109J/m2 /year) 3.81 x
  109m2
• 3805km2 61.7km x 61.7km
• Allowing for spacing between collectors
• _at_ 10 coverage 38052km2 195km x 195km
• _at_ 20 coverage 19026km2 138km x 138km
