CS542 Topics in Distributed Systems

1
CS542 Topics inDistributed Systems
Diganta Goswami
2
Algorithms to Find Global States

• Why?
• (Distributed) garbage collection think multiple
  processes sharing and referencing objects
• (Distributed) deadlock detection, termination
  think database transactions
• Global states most useful for detecting stable
  predicates once true always stays true (unless
  you do something about it)
• e.g., once a deadlock, always stays a deadlock
• What?
• Global statestates of all processes states of
  all communication channels
• Capture the instantaneous state of each process
• And the instantaneous state of each communication
  channel, i.e., messages in transit on the
  channels
• How?
• Well see this lecture!

3
Obvious First Solution

• Synchronize clocks of all processes
• Ask all processes to record their states at known
  time t
• Problems?
• Time synchronization possible only approximately
  (but distributed banking applications cannot take
  approximations)
• Does not record the state of messages in the
  channels
• Again synchronization not required causality
  is enough!

4
Two Processes and Their Initial States
5
Execution of the Processes
6
Cuts

• Cut time frontier, one at each process
• f ? cut C iff f is to the left of the frontier C

7
Consistent Cuts

• f ? cut C iff f is to the left of the frontier C
• A cut C is consistent if and only if
• ?e ? C (if f ? e then f ? C)
• A global state S is consistent if and only if it
  corresponds to a consistent cut
• A consistent cut a global snapshot

Lamports happens-before
8
The Snapshot Algorithm

• Problem Record a set of process and channel
  states such that the combination is a global
  snapshot/consistent cut.
• System Model
• There is a uni-directional communication channel
  between each ordered process pair (Pj ? Pi and Pi
  ? Pj)
• Communication channels are FIFO-ordered
• No failure, all messages arrive intact, exactly
  once
• Any process may initiate the snapshot (by sending
  a special message called Marker)
• Snapshot does not require application to stop
  sending messages, does not interfere with normal
  execution
• Each process is able to record its state and the
  state of its incoming channels (no central
  collection)

9
The Snapshot Algorithm (2)

• 1. Marker sending rule for initiator process P0
• After P0 has recorded its own state
• for each outgoing channel C, send a marker
  message on C
• 2. Marker receiving rule for a process Pk
• on receipt of a marker over channel C
• if Pk has not yet received a marker
• record Pks own state
• record the state of C as empty
• for each outgoing channel C, send a marker on C
• turn on recording of messages over other incoming
  channels
• else
• record the state of C as all the messages
  received over C since Pk saved its own state
  stop recording state of C

10
Chandy and Lamports Snapshot Algorithm
Marker receiving rule for process pi On pis
receipt of a marker message over channel c if
(pi has not yet recorded its state) it records
its process state now records the state of c as
the empty set turns on recording of messages
arriving over other incoming channels else
pi records the state of c as the set of messages
it has received over c since it saved its
state. end if Marker sending rule for process
pi After pi has recorded its state, for each
outgoing channel c pi sends one marker message
over c (before it sends any other message over
c).
11
Snapshot Example

e10
e13
P1
a
e23
P2
e20
b
P3
e30
12
Provable Assertion Chandy-Lamport algo.
determines a consistent cut

• Let ei and ej be events occurring at pi and pj,
  respectively such that ei ? ej
• The snapshot algorithm ensures that
• if ej is in the cut then ei is also in the cut.
• if ej ? ltpj records its stategt, then it must be
  true that ei ? ltpi records its stategt.
• By contradiction, suppose ltpi records its stategt
  ? ei
• Consider the path of app messages (through other
  processes) that go from ei ? ej
• Due to FIFO ordering, markers on each link in
  above path precede regular app messages
• Thus, since ltpi records its stategt ? ei , it must
  be true that pj received a marker before ej
• Thus ej is not in the cut gt contradiction

13
Formally Speaking. Process Histories

• For a process Pi , where events ei0, ei1,
  occur
• history(Pi) hi ltei0, ei1, gt
• prefix history(Pik) hik ltei0, ei1, ,eik gt
• Sik Pi s state immediately after kth event
• For a set of processes P1 , ,Pi , .
• global history H ?i (hi)
• global state S ?i (Siki) ?channels
• a cut C ? H h1c1 ? h2c2 ? ? hncn
• the frontier of C eici, i 1,2, n

14
Global States useful for detecting Global
Predicates

• A cut is consistent if and only if it does not
  violate causality
• A Run is a total ordering of events in H that is
  consistent with each his ordering
• A Linearization is a run consistent with
  happens-before (?) relation in H (history of all
  events).
• Linearizations pass through consistent global
  states.
• A global state Sk is reachable from global state
  Si, if there is a linearization, L, that passes
  through Si and then through Sk.
• The distributed system evolves as a series of
  transitions between global states S0 , S1 , .

15
Reachability between states in the snapshot
algorithm
'
16
Distributed debugging

• Examine the problem of recording a systems
  global state so that we may make useful
  statements about whether a transitory state as
  opposed to a stable state occurred in an actual
  execution
• This is what we require, in general, when
  debugging a distributed system
• Is xi xj lt ? where xi is a variable in
  process Pi

17
Distributed debugging

• Chandy and Lamports algorithm collects state in
  a distributed fashion
• The processes in the system can send the state
  they gather to a monitor process for collection
• Algorithm Marzullo and Neiger, 91 The
  observed processes send their states to a process
  called a monitor, which assembles globally
  consistent states from what it receives
• The monitor lie outside the system, observing its
  execution

18
Distributed debugging

• Goal is to determine cases when a given global
  state predicate ? was definitely True at some
  point in the execution we observed, and cases
  when it was possibly True
• Possibly because we may extract a consistent
  global state S from an executing system and find
  that ?(S) is True.
• No single observation of a consistent global
  state allows us to conclude whether a non-stable
  predicate ever evaluated to True in the actual
  execution

19
Distributed debugging

• Possibly ? There is a consistent global state S
  through which a linearization of H passes such
  that ?(S) is True
• Definitely ? For all linearization L of H,
  there is a consistent global state S through
  which L passes such that ?(S) is True

20
Distributed debugging

• We now describe
• How the process states are collected
• How the monitor extracts consistent global states
• How the monitor evaluates possibly ? and
  definitely ? in both asynchronous and synchronous
  systems

21
Distributed debugging

• The observed processes pi (I 1, 2, N) send
  their initial state to monitor process initially,
  and thereafter from time to time, in state
  messages
• No need to send state except initially and when
  it changes
• Global state predicate may depend only on certain
  parts of the process states hence need only
  send relevant state
• Need only send state at times when the predicate
  may become True or cease to be True
• The monitor process records the state messages
  from process pi in a separate queue Qi, for each
  i 1, 2, N

22
Distributed debugging

• In order that the monitor can distinguish
  consistent global states from inconsistent global
  states, the observed processes enclose their
  vector clock values with their state messages
• Each queue Qi is kept ordered in sending order
  (can be established by examining the i-th
  component of the vector clock)

23
Distributed debugging

• Let S (s1, s2, , SN) be a global statedrawn
  from the state messages that the monitor has
  received. Let V(si) be the vector clock of the
  state si received from pi
• S is a consistent global state iff
• V(si)i gt V(sj)i for i, j 1, 2, , N
• That is, the no. of pis events known at pj when
  it sent sj is no more than the no. of events that
  have occurred at pi when it sent si.
• Hence, if one processs state depends upon
  another, then the global state also encompasses
  the state upon which it depends

24
Distributed debugging

• The monitor process may establish whether a
  given global state is consistent, using the
  vector timestamps sent by the observed processes
• It can construct a lattice of consistent global
  states corresponding to the execution of the
  processes captures the relation of reachability
  between consistent global states
• The nodes denote global states, and the edges
  denote possible transitions between these states

25
Vector timestamps and variable values
26
The lattice of global states for the execution
of previous Fig
27
Distributed debugging

• A linearization traverses the lattice from any
  global state to any global state reachable from
  it on the next level that is, in each step some
  process experiences one event. For ex. S22 is
  reachable from S20, but S22 is not reachable from
  S30.
• The lattice shows all linearizations
  corresponding to a history
• A monitor process can now evaluate possibly ? and
  definitely ?

28
Distributed debugging

• To evaluate possibly ?, the monitor process
  starts at the initial state and steps through all
  consistent states reachable from that point,
  evaluating ? at each stage. It stops when ?
  evaluates to True
• To evaluate definitely ?, the monitor process
  must attempt to find a set of states through
  which all linearizations must pass, and at each
  of which ? evaluates to True
• Note that, the state S is reachable from S iff
• V(sj)j gt V(si)j for j 1, 2, , N, j ? i

29
Algorithms to evaluate possibly ? and
definitely ?
30
Global State Predicates

• A global-state-predicate is a function from the
  set of global states to true, false , e.g.,
  deadlock, termination
• A global state S0 satisfies liveness property P
  iff
• liveness(P(S0)) ? ? L? linearizations from S0 L
  passes through an SL P(SL) true
• Ex P(S) the computation will terminate
• A global state S0 satisfies this safety property
  P if
• safety(P(S0)) ? ?S reachable from S0, P(S)
  false
• Ex P(S) S has a deadlock
• Global states often useful for detecting stable
  global-state-predicate it is one that once it
  becomes true, it remains true in subsequent
  global states, e.g., an object O is orphaned, or
  deadlock
• A stable predicate may be a safety or liveness
  predicate

31
Liveness versus Safety

• Can be confusing, but terms are very important
• Livenessguarantee that something good will
  happen, eventually
• Guarantee of termination is a liveness property
• Guarantee that at least one of the atheletes in
  the 100m final will win gold is liveness
• A criminal will eventually be jailed
• Completeness in failure detectors
• Safetyguarantee that something bad will never
  happen
• Deadlock avoidance algorithms provide safety
• A peace treaty between two nations provides
  safety
• An innocent person will never be jailed
• Accuracy in failure detectors
• Can be difficult to satisfy both liveness and
  safety!
