Title: Overview of Finite Element Methods


1
Overview of Finite Element Methods
Group Members Daniel Braley Heriberto
Cortes Adam Hollrith
2
Outline
  • Fundamental Concept of FEM
  • Reasons for Using FEM
  • Various Steps in FEM Analysis
  • Examples
  • Brief Outline of Algor
  • Explanation of Homework Problem

3
The Fundamental Concept of FEM
  • A continuous field ? of a domain ? and an
    infinite number of degrees of freedom is broken
    up and approximated by a set of piecewise
    continuous functions of a finite number of
    degrees of freedom.
  • The piecewise functions are then defined over a
    set of subdomains called elements. The unknown
    ?s are defined at nodes and are evaluated using
    the equation, K? F

4
Concept of FEM
Discrete Element
Node
Continuous function
Finite Degrees of Freedom
Infinite Degrees of Freedom
5
Reasons For Using FEM
  • Serves as a tool for
  • - Stress and vibration analysis
  • - Fluid flow analysis
  • - Electrostatic analysis
  • - Displacement analysis
  • Allows for an approximation of otherwise
    impossible calculations

6
Various Steps in FEM Analysis
  • 1) Discretize the Structure
  • a) identify and label nodes
  • i) must be at points where loads
    act
  • ii) must be at points where
    geometry
  • changes
  • b) identify and label elements
  • c) identify symmetry conditions

7
Steps in FEM Analysis Cont.
  • 2) Select a displacement function that is
    defined within the element, using the nodal
    values of the element.

1
1
2
6
2
3
6
3
5
4
4
5
8
Steps in FEM Analysis Cont.
  • 3) Define the strain and stress displacement
    relationships

In the case of one-dimensional deformation,
strain in the x-direction
Now apply Hookes Law for the stress analysis
?x
is the stress in the x direction
E is the modulus of elasticity
9
Steps in FEM Analysis Cont.
  • 4) Derive the element stiffness matrix by the
    work or energy methods, or by methods of weighted
    residuals
  • fkd
  • Utilizes the method of weighted residuals
  • f is the vector of the element nodal forces
  • k is the element stiffness matrix
  • d is the vector of unknown element nodal
    degrees of freedom or generalized displacements

10
Steps in FEM Analysis Cont.
  • 5) Assemble the element equations to obtain the
    global or total equations, and also introduce
    boundary conditions
  • FKd
  • F is the vector global nodal forces
  • K is the structure global or total stiffness
    matrix
  • d is now the vector of known and unknown
    structure nodal degrees of freedom or generalized
    displacements

11
Steps in FEM Analysis Cont.
  • 6) Solve for unknown degrees of freedom or
    generalized displacements by such methods as the
    Gauss-Elimination Method
  • 7) Solve for the element strains and stresses
  • 8) Interpret the results and analyze them for use
    in the design/analysis process.
  • Lets Look at an Example!!

12
Example
  • Find the nodal displacements at points 1,2, and
    3, and find the stress in each element

3
1
1
2
2
Where P is a load applied at node 2 to the center
of the bar, the bar has a constant area A, and an
elastic modulus of E
13
Example Continued
1) Discretize the function
1
3
2
1
2
1
2
2
3
1
2
u1
u2
u2
u3
14
Example Continued
2) Select a displacement function for bar
1
2
2
3
1
2
u1
u2
u2
u3
Note that this a one-dimensional problem and the
displacement is only in the x-direction
15
Example Continued
  • 3) Define the stress and strain relationships

Now apply Hookes Law for the stress analysis
?x is the stress in the x direction
E is the modulus of elasticity
16
Example Continued
4) Derive the element stiffness matrix for each
element
  • Model Using a 1-D bar of the following
    dimensions
  • Given
  • sx Eex.

  • sx P/A

  • ex du/dx
  • du/dx (d2x
    d1x)
  • By substitution Eex P/A , P
    EA ex , P f
  • -f1 EA (d2x d1x)
  • f1 EA (d1x d2x)
  • L
  • f2 EA (d2x d1x)
  • L

L
A
f2
f1
d1x
d2x
L
L
The stiffness matrix k can now be found by
  • -1
  • -1 1

k EA
L
17
Example Continued
  • f kd
  • For element 1
  • For element 2

1
3
2
1
2
u1
u2
1 -1 -1 1
EA
f1 f21
u1 u2
u1 u2

L
1
2
2
3
1
2
u1
u2
u2
u3
u2
u3
1 -1 -1 1
EA
f22 f3
u2 u3

L
18
Example Continued
  • 5) Construct the global matrix and introduce the
    boundary conditions and known values
  • -1 0
  • -1 2 -1
  • 0 -1 1

f1 f21f22 f3
EA
u1 u2 u3

L
u10 , u30 , f2 f21f22 P
  • -1 0
  • -1 2 -1
  • 0 -1 1

f1 P f3
EA
0 u2 0

L
19
Example Continued
  • 6) Solve for the Unknowns
  • -1 0
  • -1 2 -1
  • 0 -1 1

f1 P f3
EA
0 u2 0

L
Reaction 1 f1 (-EAu2)/L
P (2EAu2)/L, so u2 (PL)/(2EA)
Reaction 3 f3 (-EAu2)/L
20
Example Continued
  • 7) Solve for the element strains and stresses

u1 u2
1/L -1 1
0 u2
0 u2
?x1 1/L -1 1
?x1 E/L -1 1
u2 0
u2 0
?x2 E/L -1 1
?x2 1/L -1 1
21
End of Example
  • 8) Analyze the results found
  • - Do they make sense?
  • - In being a static problem, do all of
    the
  • forces add up to 0?

22
Algor
  • A method for computer aided analysis (i.e. can
    import Pro/E files into Algor)
  • Saves time and money for companies by not having
    to calculate everything by hand

23
References
  • Chandrakath, Shet. FEM Class Notes.
    http//www.eng.fsu.edu/chandra/courses/eml4536
    2003.
  • Logan, Daryl L. A First Course in the Finite
    Element Method Third Edition. Brooks/Cole.
    2002.
  • Fancher, Darren, et.al., IAS2 Spring Report
    Integrated Advanced Surveillance System Final
    Report. 2003.
